Chicago Electric 92966 Assembly, Setup, And Adjusting Instructions

Sewing machine - single needle
Hide thumbs
Table of Contents

Advertisement

Quick Links

SEWING MACHINE - SINGLE NEEDLE
Model
92966
Assembly, SEtup, AND ADjuStiNg iNStRuCtiONS
Shown mounted to table (Sku 3929; not included)
®
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web site at http://www.harborfreight.com
tO pREVENt SERiOuS iNjuRY, READ
AND uNDERStAND ALL WARNiNgS
AND iNStRuCtiONS BEfORE uSE.
Copyright
2005 by Harbor Freight Tools
. All rights reserved. No portion of this
©
®
manual or any artwork contained herein may be reproduced in any shape or
form without the express written consent of Harbor Freight Tools.
for technical questions and replacement parts, please call 1-800-444-3353

Advertisement

Table of Contents
loading

Related Manuals for Chicago Electric 92966

Summary of Contents for Chicago Electric 92966

  • Page 1 . All rights reserved. No portion of this © ® manual or any artwork contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools. for technical questions and replacement parts, please call 1-800-444-3353...

  • Page 2: Specifications

    Machine Type Heavy duty, industrial sewing machine; high speed, single needle-lock stitch Drive V-belt driven Foot pedal operation, along with a knee and manual lifting arm for presser foot. Action Presser tension adjustment Feed Type Link style needle feed reduces slippage...
  • Page 3 Use of any other parts will void the warranty. Only use accessories intended for use with this tool. Approved accessories are available from Harbor Freight Tools. Do not operate tool if under the influence of alcohol or drugs. Read warning labels if taking prescription medicine to determine if your judgment or reflexes are impaired while taking drugs.
  • Page 4 Note that the machine table shown is not included, and must be ordered separately. If any parts are missing or broken, please call Harbor Freight Tools at the number on the cover of this manual as soon as possible.
  • Page 5 Power Switch The assembly instructions describe mounting the Single-Needle Sewing Machine (Model 92966) to the Table Stand (Model 03929), not included. In order to complete this procedure, you must first purchase and assemble the Table Stand Kit (Model 03929). Locate four corner rests in the rectangular hole of the Table Stand where the machine will sit.
  • Page 6 Tilt the machine back to expose the Oil Pan (D). See figure 5. Fill the Oil Pan with sewing machine lubrication oil (#7 white oil) to the “high” mark “A”. Add more oil when the level is to the “low” mark “B”. After lubrication, and during opera- tion, oil splashing can be seen through the Oil Sight Window (H).
  • Page 7 (10-26). Insert a Screw (10-27) and Nut (10-43) through the Hanger as explained in the note in step 14, above. Tighten the Screw and place the Column Cap (10-25) over the end of the Upper Column (10-26). SKU 92966 for technical questions, please call 1-800-444-3353. Page 7...

  • Page 8: Table Of Contents

    (10-23). Leave the Screws just loose enough to allow the Base to slide. 23. Swing the Sewing Machine back into it’s operating position. Put the Bobbin Winder in the ‘OFF’ position-see OFF Position, below. Slide the Bobbin Winder Assembly close to the belt until it just barely doesn’t touch it (...

  • Page 9: Bobbin Winder Operation

    Setup and Adjustment Caution: to properly break-in your new sewing machine, and avoid possible damage to the machine, sew at moderate to slow speeds for the first 15 minutes of use. Bobbin Winder Operation The Bobbin Winder assists in winding thread onto the Bobbin.

  • Page 10: Threading The Machine

    Presser Bar (5-18). Insert the needle and push it up until it will go no farther. While holding in place, securely tighten Screw (2). SKU 92966 for technical questions, please call 1-800-444-3353. threading the Machine Head Set the thread spool on its holder...

  • Page 11: Stitch Length

    Turn the Tension Knob Screw (3) clockwise (A) to increase pressure; or turn counterclockwise (B) to decrease pressure. Replace Tension Knob Screw (3), tighten Set Screw (4), and replace the assembly. SKU 92966 for technical questions, please call 1-800-444-3353. Page 11...

  • Page 12: Thread Take-Up Stroke

    To advance the feed timing in order to prevent uneven material feed, move the Feed Eccentric Cam up (clockwise). To delay feed timing and increase stitch tightness, move Feed Eccentric Cam down (counterclockwise). SKU 92966 for technical questions, please call 1-800-444-3353. Page 12...

  • Page 13: Needle-To-Hook Timing

    Machine adjustments should only be performed by a qualified technician. Check the oil level weekly when the machine is used daily. Add sewing machine oil as required to the high level marking. Clean the machine with a clean, damp cloth. Do not use solvents or thinners.

  • Page 14: Parts List

    OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. SKU 92966 for technical questions, please call 1-800-444-3353. NOtE: When ordering parts from the following lists, always include the list title, item number and description, and page number.
  • Page 15 ASSEMBLY DiAgRAM 2 - NEEDLE fEED MAiN SHAft pARtS LiSt 2 Hand wheel REV 01/06 SKU 92966 for technical questions, please call 1-800-444-3353. Page 15...
  • Page 16 ASSEMBLY DiAgRAM 3 - fEED MECHANiSM COMpONENtS pARtS LiSt 3 SKU 92966 for technical questions, please call 1-800-444-3353. Page 16...
  • Page 17 ASSEMBLY DiAgRAM 4 - fEED MECHANiSM COMpONENtS pARtS LiSt 4 SKU 92966 for technical questions, please call 1-800-444-3353. Page 17...
  • Page 18 ASSEMBLY DiAgRAM 5 - pRESSER ARM pARtS LiSt 5 SKU 92966 for technical questions, please call 1-800-444-3353. Page 18...
  • Page 19 ASSEMBLY DiAgRAM 6 - fEED MECHANiSM COMpONENtS pARtS LiSt 6 SKU 92966 for technical questions, please call 1-800-444-3353. Page 19...
  • Page 20 ASSEMBLY DiAgRAM 7 - LuBRiCAtiON COMpONENtS pARtS LiSt 7 SKU 92966 for technical questions, please call 1-800-444-3353. Page 20...
  • Page 21 ASSEMBLY DiAgRAM 8 - OiL RESERVOiR pARtS LiSt 8 SKU 92966 for technical questions, please call 1-800-444-3353. Page 21...
  • Page 22 ASSEMBLY DiAgRAM 9 - ACCESSORiES pARtS LiSt 9 SKU 92966 for technical questions, please call 1-800-444-3353. Page 22...
  • Page 23 10-16 Screw 10-17 Tension Disc 10-18 Screw 10-19 Tension Spring 10-20 Thread Tension Stud Nut 10-21 Screw 10-22 Wood Screw 10-23 Washer SKU 92966 for technical questions, please call 1-800-444-3353. pARtS LiSt 10 tHREAD StAND Q’ty part Description 10-24 Thread Hanger...
  • Page 24 Limited 90 day warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of ninety days from the date of purchase.
