Dear Customer,
May we take this opportunity to thank you for purchasing this
Panasonic Video Cassette Recorder. Please use this Quick
Start Guide to help you set up your VCR. We would also
advise you to carefully study the operating instructions and
note the listed precautions before use.
Check List
Check that you have the accessories and items shown
RF cable
K2KF2BA00001, VJA0728-A
or K1TWACC00001
AC Mains lead
RJA0044-3C
Batteries for the
Remote Control
R6 size
Operating Instructions
RQTD0043-B
www.panasonic.co.uk
• Order accessory and consumable items for your product with ease and confidence by phoning our Customer Care Centre
Mon–Friday 9:00am–5:30pm. (Excluding public holidays.)
• Or go on line through our Internet Accessory ordering application.
• Most major credit and debit cards accepted
• All enquiries transactions and distribution facilities are provided directly by Panasonic UK Ltd.
• It couldn't be simpler!
Customer Care Centre
For UK customers: 08705 357357
For Republic of Ireland customers: 01 289 8333
How to use this Guide
(1) Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pages 2–4
(2) Auto Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pages 5–6
RQCAD0005
F04C03-0
Quick Start Guide
(for UK and Republic of Ireland customers only)
Condensation Precaution
This VCR is not fitted with a condensation sensor. If you bring
in the VCR from a cold place, e.g. a car, into a warm house,
dew may form inside the VCR.
Do not switch it on for at least 1 hour.
Remote Control
N2QAKB000044
Quick Start Guide
RQCAD0005 (This leaflet)
Guarantee Card
- 1 -
Video Cassette Recorder
Model No.
NV-SV120EB
Fit the Batteries into
the Remote Control
