Dear Panasonic Customer, Welcome to the Panasonic family of customers. We hope that you have many years of enjoyment from your new colour television. The best way to understand the features of this television is to read this book thoroughly, before operating the set. -
Page 3: Warnings And Precautions
If the fitted plug has a removable fuse cover you must ensure that it is refitted when the fuse is replaced. If you lose the fuse cover the plug must not be used until a replacement cover is obtained. Replacement fuse covers can be purchased through your local Panasonic dealer. The plug fitted to this appliance incorporates a mains filter circuit. If this is removed or replaced with a non ---filtered mains plug this television will no longer meet the European standards for Electromagnetic Compatibility (EMC). -
Page 4: D Accessories
ACCESSORIES Check that you have the accessories and items shown Remote Control Transmitter EUR511300 Batteries for the Remote Control Transmitter. (2 x R6 (UM3) size) Operating Instruction book AV cover (TX---21JT1L only) TKK8E043 TV Guarantee Telescopic Aerial (TX---14JT1L only) TSA---120026 FITTING REMOTE CONTROL BATTERIES Slide off the battery cover Replace the cover... - Page 5 INSTALLATION AND SET---UP TV only Mains Socket Connect Aerial co---axial cable direct to TV RF IN socket. USING A VCR Mains Socket Connect aerial co---axial cable to RF Input socket of VCR and a RF co---axial cable from VCR RF Out socket to TV RF IN socket.
-
Page 6: Installation And Set
INSTALLATION AND SET---UP If the TV has not been programmed for you Switch ON your VCR. * then Auto setup will begin. TV stations will Switch ON your Satellite Receiver.* be located and stored ready for use. * Plug the TV into a mains socket and switch ON. Programmes will appear immediately if your Switch the VCR Test Signal ‘off’. -
Page 7: Location Of Controls
LOCATION OF CONTROLS On Screen Displays Menu Title Main Menu Contrast Brightness Cursor Bar Colour Sharpness Sub Menu C---A---T---S Tuning Menu Commands : : Select ---/+ : Adjust A guide to the various options available : Exit when in On Screen Menu operations. Front Panel Controls Headphone socket Mains Power On/Off switch... -
Page 8: Menu Operation
MENU OPERATION ATP start Manual Tuning store Programme Swap Store in Tuning menu Display Menu / Previous Menu Adjust / Access Select Exit Menu Main Menu Main Menu Contrast Contrast Brightness Colour Sharpness Brightness C ---A ---T ---S Tuning Menu Colour : Select ---/+ : Adjust... -
Page 9: Tuning Menu
MENU OPERATION Tuning Menu The Tuning menu provides access to both manual and automatic Main Menu tuning menus. Contrast Brightness Colour Sharpness Auto Setup C ---A ---T ---S Tuning Menu The Auto Setup menu allows you to automatically retune the TV, particularly useful if you move to an area that is served by a different transmitter. -
Page 10: Teletext Operation
TELETEXT OPERATION Teletext features may vary depending on the Broadcasting Companies and are only available if the selected channel is transmitting Teletext. If the F button is pressed in Teletext mode the cyan contrast scale will appear; press buttons “+” and “---” to change the settings. -
Page 11: Audio / Video Connections
AUDIO / VIDEO CONNECTIONS (FRONT OR REAR) AV (Audio / Video) is a dedicated input for VCR’s, Satellite Receivers and other Audio / Video equipment. This TV is capable of switching to AV operation automatically if the equipment connected provides a switching signal to the SCART socket. -
Page 12: Vcr Installation
VCR INSTALLATION Your new TV is supplied with programme position ‘0’ designed specifically to receive an RF signal from a VCR. However, depending on the VCR’s setting you may not receive any picture or sound from the VCR on programme position ‘0’ of the TV. It will be necessary to either adjust the RF channel of the VCR or to adjust the tuning of the TV’s programme position ‘0’... -
Page 13: Vcr Operation
VCR OPERATION The Remote Control is capable of operating some functions of selected Panasonic VCR’s, please consult your dealer for details. Some VCR’s have different functions, so to ensure compatibility please refer to the VCR’s instruction book. VCR Standby Record... -
Page 14: Trouble
Do not operate the television set for a continuous period of time while using TV games or home computers. This type of picture tube damage is not an operating defect and as such is not covered by the Panasonic warranty. -
Page 15: Specifications
SPECIFICATIONS Model Number: TX ---21JT1L TX ---14JT1L Power Source: 220---240V 50Hz A.C. Power Consumption: Standby Power Consumption: 1,1W Picture Tube: 51cm visible diagonal 34cm visible diagonal Audio Output (music) 6W, 8Ω impedance, mono Dimensions: 476 (H) x 512 (W) x 470 (D) mm 352 (H) x 371 (W) x 371,5 (D) mm Weight: 20,6 kg... - Page 16 Most major credit and debit cards accepted. All enquiries, transactions and distribution facilities are provided directly by Panasonic UK Ltd. It couldn’t be simpler! Also available through our Internet is direct shopping for a wide range of finished products, take a browse on our website for further details.
