Page 1 TX-LR42DT60 TX-LR47DT60 TX-LR50DT60 TX-LR55DT60 TX-LR60DT60 e HELP English...
Page 2: Table Of Contents
Watching my Home Screen • Information • How to use • Settings Basic • Satellite connection • Basic connection • Selecting channel • Information banner • Option Menu • Subtitle • Off Timer • Last view External equipment • External connection • Watching external input • Operating with TV’s remote control • HDMI features • Terminal information • Valid input signals For best picture • Viewing Mode...
Page 3 TV Guide • Using TV Guide • Timer Programming Teletext • Viewing Teletext • Teletext mode • Note • 3D Eyewear - Maintenance • Viewing 3D • 3D Mode Selection • 3D Settings • Source image format Tuning and editing channels • Setting menu • Favourites Edit • Channel List • Auto Setup • Manual Tuning • Update Channel List • New Channel Message • Signal Condition...
Page 4 • Editing timer programming • Note Technical information • USB HDD Internet service Internet content • Information • Selecting internet content • Note Network connections • Internet connection • Note Network settings • Network Connection • Custom - Wireless • Custom - Wired • Network Status • VIERA remote Settings • Network Link Settings • Software Update • New Software Message Home network...
Page 5 • Custom - Wired • Custom - Wireless Access Point • Network Status • VIERA remote Settings • Network Link Settings • Software Update • New Software Message Photos • Selecting file • Viewing photo • Using slideshow Videos • Selecting file • Watching video • Video Setup • Audio output settings Music • Selecting file • Playing music • Music Setup DIGA Recorder...
Page 6 • Viewing photo • Sorting photos • Multi Shot 3D • Using slideshow Video mode • Selecting file • Watching video • Video Setup • Audio output settings Recorded TV mode • Selecting content • Watching recorded TV • Grouping contents • Deleting content • Changing device • Chapter List • Audio output settings Music mode • Selecting file • Playing music • Music Setup...
Page 7 • Settings Multi Window • Information • How to use • Note VIERA Link “HDAVI Control™” • Summary of VIERA Link • Preparations • Easy playback • Power on Link • Power off Link • Standby Power Save • Intelligent Auto Standby • VIERA Link Control • Speaker Selection • Note Child Lock • Using Child Lock • PIN number Data Service Application • Using Data Service Application...
Page 8 Setting characters • Using numeric buttons Voice Control • Preparations • How to use Bluetooth devices • Bluetooth Setup Keyboard / Gamepad • Keyboard • Gamepad Settings Setting menu • How to use Picture • Viewing Mode • Basic settings • Ambient Sensor • Noise reduction settings • Resolution Remaster • Caption Smoother • Brilliance Enhancer • Intelligent Frame Creation • 24p Smooth Film...
Page 9 • Basic settings • Volume settings • Voice Guidance Settings • Advanced settings • Reset to Defaults Network • Network Connection • Network Status • VIERA remote Settings • Network Link Settings • Other settings Timer • Off Timer • Timer Programming • Time Zone • Auto Standby • No signal Power off Setup • Eco Navigation • Voice Control Settings • USB Device Setup • Recording Setup...
Page 10 Support FAQs • Picture • Digital TV • Analogue TV • Sound • 3D • HDMI • Network • Other Maintenance • Care and Cleaning Information • Using Help menu Optional accessories • 3D Eyewear • Communication Camera • Wall-hanging bracket Licence • Licence Letters enclosed in a box indicate remote control buttons. Menu Letters in cyan indicate on-screen display items.
Page 11: My Home Screen
Watching my Home Screen Information “my Home Screen” is a gateway to the TV, applications, and more. It provides easy access to special features such as the Media Player, videos, games, communication tools, etc. as shown below (example). HOME HOME Home Screen Selected content screen (TV, application, etc.) Home Screen Selection...
Page 12: How To Use
How to use Home Screen provides access to special features such as the Media Player, TV, internet content, data services, communication tools, etc. 1. Display Home Screen with HOME (Example) The last viewed Home Screen is displayed when the TV is turned on. ●...
Page 13: Settings
Settings Select the setup menu from the tool guide on the top of the screen, or use coloured button to display the setup menu. (Example) ■ Home Screen Selection 1. Display Home Screen Selection with HOME (Example) 2. Select the screen with and press to set Full Screen...
Page 14 ■ Settings You can customise any Home Screen. (For example, changing the wallpaper, renaming freely, editing applications, setting the screen launched when the TV is turned on, etc.) 1. Select Settings from the tool guide 2. Follow the on-screen instructions ■...
Page 15: Basic
Basic Satellite connection Please ensure that the unit is disconnected from the mains socket before attaching or disconnecting any cables. For DVB-S ● ■ Dual tuner (DiSEqC) Connect the both of satellite IN 1 / IN 2 terminals to the satellite dish with Multi Switcher, and you can watch or record 2 DVB-S programmes simultaneously, etc.
Page 16 ■ Single tuner Connect the satellite IN 1 terminal to the satellite dish. Watching or recording 2 DVB-S programmes simultaneously, etc. are not ● available. Satellite IN 1 terminal Satellite cable Satellite dish = Note = To ensure your satellite dish is correctly installed, please consult your local ●...
Page 17: Basic Connection
Basic connection Please ensure that the unit is disconnected from the mains socket before attaching or disconnecting any cables. ■ Aerial Terrestrial / cable terminal RF cable Terrestrial aerial or cable For DVB-C, DVB-T, Analogue ● ■ DVD Recorder / VCR Terrestrial / cable terminal RF cable DVD Recorder / VCR...
Page 18 ■ DVD Recorder / VCR and Set top box HDMI terminal HDMI cable Set top box Cable AV1 (SCART) terminal SCART cable – AV1 (SCART) adaptor (supplied) is necessary when connecting to the Terrestrial / cable terminal RF cable DVD Recorder / VCR Terrestrial aerial For VIERA Link connections ●...
Page 19: Selecting Channel
Selecting channel 1. Display the TV Selection screen with 2. Select the mode with and press to set DVB-S DVB-C DVB-T Analogue The selectable modes vary depending on the channels stored. ● You can also select the mode pressing repeatedly on the remote ●...
Page 20: Information Banner
■ To select a channel using TV Guide 1. Display TV Guide with GUIDE 2. Select the current programme or channel with and press to access 3. Select View with and press to access (DVB) – The current programme is displayed on the top left of the screen. 4.
Page 21 Current time Features available / message meanings Sound mute is on signal: Poor quality TV signal Dolby Dolby D, HE-AAC: Dolby Digital Plus, Dolby Digital or HE-AAC audio track Subtitle service available Teletext service available Multiple audio available Multiple video available Multiple audio and video available Stereo, Mono: Audio mode...
Page 22: Option Menu
To hide the banner ● EXIT Extra information (DVB) ● – Press again to hide the banner. To adjust banner timeout, set Banner Display Timeout. ● Settings Setup Display Settings Option Menu Confirm or change the current status. 1. Display Option Menu with OPTION...
Page 23 Sub Channel Selects the multifeed programme - sub channel (if available). For DVB mode ● Subtitle Language Selects the language for subtitles (if available). For DVB mode ● Not valid on the sub screen in multi window mode ● Teletext Character Set Sets the teletext language font.
Page 24: Subtitle
Subtitle Display / hide subtitles (if available) with STTL. To select the preferred language for DVB subtitles (if available), set ● Preferred Subtitles. Settings Setup Language = Note = Subtitles may not be displayed properly in 3D images. ● If you press STTL in Analogue mode, the TV switches to teletext service ●...
Page 25: External Equipment
External equipment External connection These diagrams show our recommendations for connection of your TV to various pieces of equipment. For other connections, consult the instructions for each piece of equipment. For basic connection ● Watching Basic Basic connection To use the specific devices supporting Bluetooth wireless technology ●...
Page 26 ■ AV devices AV2 (COMPONENT) terminals Component cables – AV2 (COMPONENT / VIDEO) adaptor (supplied) is necessary. DVD player AV2 (VIDEO) terminals Composite cables – AV2 (COMPONENT / VIDEO) adaptor (supplied) is necessary. Camcorder / Game equipment ■ USB devices USB port USB cable USB HDD / Communication Camera...
Page 27 You cannot connect any devices by using USB card reader. ● Additional information for the devices may be on the following website. ● (English only) http://panasonic.net/viera/support ■ To listen with speakers DIGITAL AUDIO Optical digital audio cable Amplifier with speaker system To enjoy the sound from the external equipment in multi-channel sound ●...
Page 28: Watching External Input
Watching external input Connect the external equipment (VCRs, DVD equipment, etc.) and you can watch through the input. 1. Display the input selection menu with 2. Select the input mode connected to the equipment with and press to watch (The selected mode is displayed on the top left of the screen) TV receives input signals automatically connecting with SCART when ●...
Page 29: Operating With Tv's Remote Control
Operating with TV’s remote control You can operate the contents in Media Player / media server, recording functions or the connected equipment with the below buttons of this TV’s remote control. Playback videocassette / DVD / video content Stop the operations Rewind, view the picture rapidly in reverse (VCR) Skip to the previous track, title or chapter (DVD / video content) Rewind, view the picture rapidly in reverse (VCR)
Page 30: Hdmi Features
■ How to change the code Each Panasonic product has its own remote control code. Change the code according to the product for operation. 1. Press and hold Standby On / Off switch during the following operations 2. Enter the appropriate code as follows with numeric buttons Codes for each product and features ●...
Page 31 ■ Applicable HDMI features Input audio signal: ● 2ch Linear PCM (sampling frequencies - 48 kHz, 44.1 kHz, 32 kHz) Input video signal: ● Matches the output setting of the digital equipment. Watching External equipment Valid input signals VIERA Link (HDAVI Control 5) ●...
Page 32: Terminal Information
Terminal information ■ AV1 SCART terminal (RGB, VIDEO) 1 : Audio out (R) 12: -- 2 : Audio in (R) 13: Red earth 3 : Audio out (L) 14: Earth 4 : Audio earth 15: Red in 5 : Blue earth 16: Status RGB 6 : Audio in (L) 17: CVBS earth...
Page 33: Valid Input Signals
■ HDMI terminal 1 : TMDS Data2+ 11 : TMDS Clock Shield 2 : TMDS Data2 Shield 12: TMDS Clock− 3 : TMDS Data2− 13: CEC 4 : TMDS Data1+ 14: Utility 5 : TMDS Data1 Shield 15: SCL 6 : TMDS Data1− 16: SDA 7 : TMDS Data0+ 17: DDC/CEC Ground...
Page 34: For Best Picture
For best picture Viewing Mode 1. Display the menu with MENU 2. Select Picture Viewing Mode with and press to access 3. Select the mode with and press to set Viewing Mode (Dynamic Normal Cinema True Cinema Custom Professional1 Professional2) Selects your favourite picture mode for each input.
Page 35: Ambient Sensor
In each Viewing Mode, Backlight, Contrast, Brightness, Colour, Tint, Sharpness, Colour Temperature, Vivid Colour, Adaptive Backlight Control, Ambient Sensor, Noise Reduction, MPEG Remaster, Resolution Remaster, Caption Smoother, Brilliance Enhancer, Intelligent Frame Creation Smooth Film can be adjusted and stored. When in True Cinema, Custom...
Page 36: Aspect
Aspect Change the aspect ratio (image size) with ASPECT. ■ To change the aspect ratio manually 1. Display Aspect Selection list with ASPECT 2. Select the mode with and press to set You can also change the mode pressing ASPECT. ●...
Page 37: Aspect Control Signal
= Note = Display the image (TV, external input, etc.) full-screen to use this function ● completely. Aspect mode can be memorised separately for SD (Standard definition) ● and HD (High definition) signals. Aspect cannot be changed in teletext service and 3D mode. ●...
Page 38 ● AV1 (SCART) / AV2 (VIDEO) terminals Valid input signal format: SECAM PAL 525/60 M.NTSC NTSC : Control signal through SCART (pin 8) / HDMI terminal only ● AV2 (COMPONENT) terminals (WSS only) Valid input signal format: 625 (576) / 50i, 50p Invalid input signal format: 525 (480) / 60i, 60p 750 (720) / 60p, 50p...
Page 39: Advanced Settings
Advanced Settings You can adjust and set up the detailed picture settings for each input when Viewing Mode is set to True Cinema, Custom Professional1 / 2 mode. Watching For best picture Viewing Mode 1. Select the input mode with 2.
Page 40 ■ White Balance R-Gain G-Gain B-Gain Adjusts the white balance of bright red / green / blue areas. R-Cutoff G-Cutoff B-Cutoff Adjusts the white balance of dark red / green / blue areas. More Detailed Adjustment Adjusts more detailed White Balance items. Input Signal Level: Adjusts the input signal level.
Page 41: Reset To Defaults
Y-Saturation C-Saturation / M-Saturation: Adjusts the saturation of yellow / cyan / magenta areas. Y-Luminance C-Luminance / M-Luminance: Adjusts the luminance of yellow / cyan / magenta areas. Reset to Defaults: Resets to the default detailed Colour Management. Reset to Defaults Resets to the default Colour Management.
Page 42: Lock Settings
Lock Settings Locks the settings of Professional1 / 2 mode for each input. 1. Display the menu with MENU 2. Select Picture Lock Settings with and press to access 3. Enter the PIN number (4 digits) with numeric buttons Enter the PIN number twice at first setting. ●...
Page 43: For Best Audio
For best audio Sound mode 1. Display the menu with MENU 2. Select Sound Mode with and press to access 3. Select the mode with and press to set Mode (Standard Music Ambience / User) Selects your favourite sound mode for each input. Standard: Provides the suitable sound quality for all types of scenes.
Page 44: Tv Guide
TV Guide Using TV Guide TV Guide - Electronic Programme Guide (EPG) provides an on-screen listing of the programmes currently broadcast and the forthcoming broadcasts over the next seven days (depending on the broadcasters). 1. Display the TV Selection screen with 2.
Page 45 To watch the programme ● 1) Select the current programme with and press access 2) Select View with and press to access (DVB) – To use timer programming, select Timer Programming. (Depending on the country you select, you can also set Signal Supported Recording.)
Page 46: Timer Programming
Timer Programming The Timer Programming menu allows you to choose programmes that you want to remind watching or record to the USB HDD. At the correct time, the TV will tune to the correct channel even if the TV is in Standby mode. 1.
Page 47: Teletext
Teletext Viewing Teletext 1. Switch to teletext with TEXT Displays the index page (content varies depending on the ● broadcasters). Current / sub page numbers are displayed on the top left of the screen. ● Time / date is displayed on the top right of the screen. ●...
Page 48 ■ Watch TV and teletext in two windows at once 1. Press MENU twice 2. Set Picture and text with Operations can be made only in teletext screen. ● ■ Store frequently viewed pages in the colour bar (List mode) 1.
Page 49: Teletext Mode
Teletext mode Teletext services are the text information provided by the broadcasters. The features may vary depending on the broadcasters. ● 1. Display the menu with MENU 2. Select Setup Display Settings Teletext with and press access 3. Select TOP (FLOF) List with and press...
Page 50: Note
Note Display the image (TV, external input, etc.) full-screen for viewing 3D. ● Do not exert pressure on or scratch the lens of the 3D Eyewear. ● 3D content will not be correctly visible if the 3D Eyewear is worn upside ●...
Page 51: Viewing 3D
■ 3D-supported broadcast Please consult the suppliers of contents or programmes for availability of ● this service. ■ 3D photos and 3D videos taken by 3D-compatible Panasonic products Available in Media Player and Network services ● Media Player Home network ■...
Page 52: 3D Mode Selection
3D Mode Selection You can easily change the viewing mode between 2D and 3D with 3D. 1. Display the 3D Mode Selection screen with 2. Select the mode with and press to set Items of 3D Mode Selection vary depending on the condition. ●...
Page 53: 3D Settings
3D Settings 1. Display the menu with MENU 2. Select Picture 3D Settings with and press to access 3. Select one of the following items with and press to access 3D Detection 3D Signal Message 2D 3D Depth 3D Adjustment L/R Picture Swap Edge Smoother Safety Precautions...
Page 54 3D Adjustment / Off) Adjustment of the 3D effect (except in 2D 3D mode). Set to to enable Effect setting. When setting to On, a safety precaution message will appear. Read it ● carefully and press BACK/RETURN to go to Effect setting.
Page 55: Source Image Format
Source image format If the picture appears to be abnormal, refer to the table of images that can be seen for each 3D Mode Selection (Manual) and the source image format, and select the correct 3D mode. 3D images are displayed correctly with appropriate 3D format as following ●...
Page 56: Tuning And Editing Channels
Tuning and editing channels Setting menu You can retune channels, create your favourite channel lists, skip unwanted channels, etc. 1. Display the TV Selection screen with 2. Select the mode with and press to set DVB-S DVB-C DVB-T Analogue 3. Display the menu with MENU 4.
Page 57: Favourites Edit
Favourites Edit ■ List favourite DVB channels Create your favourite channel lists from various broadcasters (up to 4: Favourites 1 to 4). The DVB Favourites lists are available from Category in the information banner and the TV Guide screen. Watching Basic Information banner Watching...
Page 58 ■ Edit DVB Favourites list You can edit the favourites list while the cursor is on the channel in the favourites list. To move the channel ● 1) Select the channel with 2) Press (green) 3) Select the new position with or numeric buttons 4) Press (green) to store...
Page 59: Channel List
Channel List ■ Skip unwanted DVB / Analogue channels You can hide (skip) unwanted channels. The hidden channels cannot be displayed except in this function. 1. Select Channel List with and press to access 2. Select a channel with 3. Press to set Reveal Hide...
Page 60: Auto Setup
To rename the channel name (Analogue) ● 1) Press (blue) to edit 2) Enter characters (maximum 5 characters) with numeric buttons, and press to set 3) Press BACK/RETURN to store = Note = If a VCR is connected only with the RF cable in Analogue mode, edit VCR. ●...
Page 61 3. Select LNB Configuration with and press to access Select Dual Tuner Mode with , set to with to use dual ● tuner function. 4. Select Satellite with and set with Select IN 1 IN 2 Signal Input with to set for each tuner. ●...
Page 62 ■ DVB-C, DVB-T, Analogue channels 1. Select Auto Setup with and press to access 2. Set DVB-C Auto Setup Settings with and press to store (DVB-C) Scan Mode ● Full: Scans the whole frequency range. Quick: Scans the suitable frequency in your country. Normally set Frequency, Symbol Rate Network ID...
Page 63: Manual Tuning
Manual Tuning Normally use Auto Setup Update Channel List to retune DVB channels. ● If tuning has not been done completely or for adjusting the direction of the ● aerial or dish, use this function. (DVB) All DVB channels found will be added to Channel List.
Page 64: Update Channel List
■ Analogue Set Analogue channel manually after Auto Setup. 1. Select the channel position with numeric buttons 2. Select the channel with Channel Up / Down button 3. Search with 4. Select Store with and press to set Fine Tuning to make small adjustments to the tuning of an individual ●...
Page 65: Signal Condition
Signal Condition Selects a channel and checks the signal condition. A good Signal Strength is not an indication of suitable signal for DVB reception. Use the Signal Quality indicator as follows. ● – Green bar: Good – Yellow bar: Poor –...
Page 66: Selectable Satellites
Selectable satellites ■ Selectable satellites and dish alignment to tune DVB-S channels To ensure your satellite dish is correctly installed, please consult your local dealer. Also please consult the received satellite broadcasting companies for details. Intelsat at 85.2° East Hot Bird at 13° East ●...
Page 67: Recording
Recording USB HDD setup Preparations You can record the digital TV programmes to the connected USB HDD and enjoy playing back in various ways. Prepare the USB HDD for the exclusive use of recording with this TV. ● Connect the USB HDD to the USB 3 port with the USB cable. ●...
Page 68: Setting For Usb Hdd
The data recorded on the USB HDD with this TV can only be played back ● on this TV. You cannot play back its contents with another TV (including the TV of the same model number) or any equipment. Do not turn the TV off, pull out the mains plug or remove the USB HDD ●...
Page 69 5. When the confirmation screen of USB HDD name is displayed, select with and press to set The name for the USB HDD is created automatically. If you want to edit ● the name, select Yes. 1) Enter characters with or numeric buttons, and press to set 2) Press...
Page 70: One Touch Recording
Recording current programme One Touch Recording Records the current programme to the USB HDD immediately. Confirm the remote control code is “73”. ● Watching External equipment Operating with TV’s remote control 1. Display the menu with MENU 2. Select Setup Recording Setup One Touch Recording with...
Page 71: Rew Live Tv
REW LIVE TV Records the current programme to the USB HDD constantly within the maximum recordable time. Confirm the remote control code is “73”. ● Watching External equipment Operating with TV’s remote control 1. Display the menu with MENU 2. Select Setup Recording Setup REW LIVE TV...
Page 72 ■ To stop REW LIVE TV 1. Display the menu with MENU 2. Select Setup Recording Setup REW LIVE TV with and press to access 3. Select with to stop REW LIVE TV If you stop REW LIVE TV, the recorded content for REW LIVE TV will be ●...
Page 73: Timer Programming
Timer Programming Setting timer programming The Timer Programming menu allows you to select programmes that you want to be reminded to watch or record to the USB HDD. Not valid in Analogue mode ● 1. Display the TV Selection screen with 2.
Page 74 (Example) !: Overlapped timer programming events Function (USB HDD Rec. / Reminder) TV mode S: DVB-S C: DVB-C D: DVB-T – You cannot change the mode within the menu. Channel position and name <TIMER>: Timer Programming STTL: Displays subtitles (if available) –...
Page 75: Editing Timer Programming
Editing timer programming 1. Display the menu with MENU 2. Select Timer Timer Programming with and press to access 3. Select the event with To change a timer programming event ● – Correct as necessary. Recording Timer Programming Setting timer programming To delete a timer programming event ●...
Page 76: Note
Note TV Guide may also be used to set timer programming event. ● Watching TV Guide Timer Programming Timer Programming can store up to 15 events. ● Timer Programming only works reliably if correct time information is ● received via the signal from the broadcaster or service provider. For recording using Timer Programming, the TV must be either on or in...
Page 77: Usb Hdd
Regarding performance, not all USB HDDs are guaranteed. Check the ● USB HDDs that have been tested for compatibility with this TV at the following website. (English only) http://panasonic.net/viera/support = Note = Data modified with a PC may not be displayed. ●...
Page 78: Internet Service
Internet service Internet content Information You can access some specific websites supported by Panasonic, and enjoy internet contents such as videos, games, communication tools, etc. from APPS List. (Example) To enable this function, you need a broadband network environment. ●...
Page 79: Note
The services through APPS List are operated by their respective service ● providers and such service may be discontinued either temporarily or permanently without notice. Therefore, Panasonic will make no warranty for the contents or the continuity of the services. Some contents may be inappropriate for some viewers.
Page 80: Network Connections
Network connections Internet connection To use internet service, you need a broadband network environment. If you do not have any broadband network services, please consult your ● retailer for assistance. Dial-up internet connections cannot be used. ● Required speed (effective): at least 1.5 Mbps for SD (Standard Definition) ●...
Page 81: Note
Note Ensure to use a LAN straight cable. ● Set up and connect equipment required for the network environment. You ● cannot make such settings on this TV. Read the manual of the equipment. If your modem has no broadband router functions, use a broadband router. ●...
Page 82 For WPS(Push button) ● 1) Select Easy setup with Push button with and press access 2) Press the WPS button on the access point until the light flashes 3) Connect the TV with the access point with – WPS: Wi-Fi Protected Setup™ –...
Page 83: Custom - Wireless
Custom - Wireless Ensure the connections are completed before starting network setup. Internet service Network connections 1. Display the menu with MENU 2. Select Network Network Connection Custom Wireless with and press to access Confirm the encryption key, settings and position of your access point ●...
Page 84 4. Enter the encryption key of the access point with and press to set You can set characters using numeric buttons. ● Press BACK/RETURN to store ● 5. The VIERA Name/IP/DNS Settings screen is displayed VIERA Name You can set your favourite name for this TV. ●...
Page 85: Custom - Wired
Proxy Port: This number is also specified by the provider with the Proxy address. 1) Select Proxy Port with 2) Enter the number with numeric buttons 3) Press BACK/RETURN to store 6. Select Network Status with and press to access Internet service Network settings Network Status...
Page 86 Proxy Settings It is not required for normal household use. ● Some internet services may not be available depending on the proxy ● settings. Proxy: This is the address of the relay server connected between the browser and the target server and sends data to the browser. 1) Select Proxy with...
Page 87: Network Status
Network Status Displays and checks the network status (MAC Address, current network settings, etc.). 1. Display the menu with MENU 2. Select Network Network Status with and press to access 3. Automatically testing is done and the Network Status screen is displayed Again: Performs automatic testing of the network connection for the TV and displays the current status again.
Page 88: Home Network
Home network DLNA Information This TV is a DLNA Certified™ product. DLNA (Digital Living Network Alliance) is a standard that makes DLNA ® Certified digital electronics easier and more convenient to use on a home network. To learn more, visit www.dlna.org. To enable this function, connect this TV to your home network.
Page 89 ● To use a PC as a media server Prepare the PC with Windows 7 / Windows 8 or ensure the server software is installed on the PC. “Windows 7 / Windows 8” and “Twonky 7 (installed on the PC with Windows XP or Mac)” are the server software that has been tested for compatibility with this TV (as of November, 2012).
Page 90 And you need to install the application for controlling VIERA on your smartphone. For information of the application (English only): http://panasonic.net/viera/support For the operations, refer to the support information of the application. “Windows 7 / Windows 8” are the OS that have been tested for ●...
Page 91 Sharing the current programme may not be available when selecting radio ● channels, encrypted (copy-protected) programmes or when the broadcast prohibits the output of video and audio. = Note = To use this function, turn this TV on. ● This function is available only with 1 piece of other equipment. ●...
Page 92: Using Dlna
Using DLNA To use DLNA features, ensure the preparations of the media server, network ® connections and network settings are completed. Home network DLNA Information Home network Network connections Home network Network settings 1. Display APPS List with APPS 2. Select Media Server with and press...
Page 93: Network Connections
Network connections DLNA connection To use DLNA features, you need a home network environment and you can operate the features without a broadband network environment. To use internet service, you need a broadband network environment. ● Internet service Network connections Internet connection ■...
Page 94 ■ Wired connection (For DLNA and internet service) ETHERNET terminal LAN cable (Shielded) Use the Shielded Twist Pair (STP) LAN cable. ● Hub or Router Internet environment DLNA Certified media server ■ Wireless connection (For DLNA) To use the TV as a wireless access point ●...
Page 95: Note
Note Ensure to use a LAN straight cable. ● Set up and connect equipment required for the network environment. You ● cannot make such settings on this TV. Read the manual of the equipment. If you use the equipment compatible only with 100BASE-TX, category 5 or ●...
Page 96 5. Enter the encryption key of the access point with and press to set You can set characters using numeric buttons. ● Press BACK/RETURN to store ● 6. Automatically setup is done and the Network Status screen is displayed Home network Network settings Network Status 7.
Page 97: Custom - Wireless
Custom - Wireless Ensure the connections are completed before starting network setup. Home network Network connections 1. Display the menu with MENU 2. Select Network Network Connection Custom Wireless with and press to access Confirm the encryption key, settings and position of your access point ●...
Page 98 4. Enter the encryption key of the access point with and press to set You can set characters using numeric buttons. ● Press BACK/RETURN to store ● 5. The VIERA Name/IP/DNS Settings screen is displayed VIERA Name You can set your favourite name for this TV. ●...
Page 99: Custom - Wired
Proxy Port: This number is also specified by the provider with the Proxy address. 1) Select Proxy Port with 2) Enter the number with numeric buttons 3) Press BACK/RETURN to store 6. Select Network Status with and press to access Home network Network settings Network Status...
Page 100 Proxy Settings It is not required for normal household use. ● Some internet services may not be available depending on the proxy ● settings. Proxy: This is the address of the relay server connected between the browser and the target server and sends data to the browser. 1) Select Proxy with...
Page 101: Custom - Wireless Access Point
Custom - Wireless Access Point You can use the TV as a wireless access point and connect the network equipment without an access point. Confirm the PIN code, network settings of the equipment before starting ● setup. For details, read the manual of the equipment. 1.
Page 102: Network Status
For the operations, refer to the support information of the application. Device to upload contents Selects device to upload contents from the network equipment (smartphone, etc.). = Note = Depending on the area, this function may not be available. For details, ● consult your local Panasonic dealer. - 102 -...
Page 103: Network Link Settings
To use this function with your smartphone, you need to install the ● application for controlling VIERA on your smartphone. For information of the application (English only): http://panasonic.net/viera/support For the operations, refer to the support information of the application. Registration Type (Auto...
Page 104: Software Update
= Note = Depending on the area, this function may not be available. For details, ● consult your local Panasonic dealer. Software Update Accesses the specific website to update the TV’s software if any updates are available. 1. Display the menu with MENU 2.
Page 105: Photos
Photos Selecting file Ensure the preparations of the media server, network connections and network settings are completed. Home network DLNA Information Home network Network connections Home network Network settings 1. Display APPS List with APPS 2. Select Media Server with and press to access 3.
Page 106: Viewing Photo
Viewing photo ■ Playback Photos are displayed one at a time. To operate Single view ● : To the previous photo : To the next photo : Stop (return to list) : Slideshow To display / hide the operation guide ●...
Page 107 Transition Effect (Off Fade Dissolve Motion / Random) Selects the transition effect for switching the photo during the slideshow. Fade: The next photo fades in gradually. Dissolve: Each photo is dissolved when switching to the next photo. Motion: Each photo is displayed with an effect of enlarging, reducing, moving up or moving down.
Page 108: Videos
Videos Selecting file Ensure the preparations of the media server, network connections and network settings are completed. Home network DLNA Information Home network Network connections Home network Network settings 1. Display APPS List with APPS 2. Select Media Server with and press to access 3.
Page 109: Watching Video
Watching video ■ Playback If you have stopped the last playback halfway, the confirmation screen is displayed to select whether to start from where you stopped last time or from the beginning. To operate playback ● Manual skip – Press to skip forward approx. 30 seconds. : Rewind : Fast forward : Stop...
Page 110: Video Setup
Video Setup Set up the settings for video file operations on this TV. 1. Display the option menu with OPTION 2. Select Video Setup with and press to access 3. Select one of the following items with and press to access Video Preview Multi Audio Dual Audio...
Page 111: Audio Output Settings
Audio output settings You can enjoy the multi-channel sound via an amplifier connected to DIGITAL AUDIO or HDMI2 (ARC function) terminal. To confirm or change the current sound status ● Home network Videos Video Setup 1. Display the menu with MENU 2.
Page 112: Music
Music Selecting file Ensure the preparations of the media server, network connections and network settings are completed. Home network DLNA Information Home network Network connections Home network Network settings 1. Display APPS List with APPS 2. Select Media Server with and press to access 3.
Page 113: Playing Music
Playing music ■ Playback To operate playback ● : Rewind : Fast forward : Stop : Pause / Playback To display / hide the operation guide ● To the previous track ● (red) To the next track ● (green) To return to list ●...
Page 114: Diga Recorder
DIGA Recorder Controlling DIGA Recorder Ensure the preparations of the media server, network connections and network settings are completed. Home network DLNA Information Home network Network connections Home network Network settings 1. Display APPS List with APPS 2. Select Media Server with and press to access...
Page 115: Technical Information
Technical information Photo format ■ Supported Photo formats ● JPEG (.jpg, .jpeg, .mpo) Image resolution (pixel): 8 × 8 to 30,719 × 17,279 Sub-sampling: 4:4:4, 4:2:2, 4:2:0 DCF and EXIF standards ● Progressive JPEG is not supported. ● = Note = Some files may not be played back even if they fulfil these conditions.
Page 116 ● SD-Video (.mod) Video codec: MPEG1, MPEG2 Audio codec: Dolby Digital, MPEG Audio SD-Video Standard Ver. 1.31 (Entertainment Video Profile) ● The data may not be available if a folder structure on the device is ● modified. ● AVI (.avi) Video codec: H.264 BP/MP/HP, MPEG1, MPEG2, MPEG4 SP/ASP, VC-1, Windows Media Video Ver.
Page 117 Video codec: H.264 BP/MP/HP, MPEG1, MPEG2, MPEG4 SP/ASP Audio codec: AAC, Dolby Digital, Dolby Digital Plus, HE-AAC, MPEG Audio, MP3 This TV supports this container recorded with Panasonic products. For ● details, read the manual of the products. ● FLV (.flv) Video codec: H.264 BP/MP/HP...
Page 118: Music Format
■ Supported Subtitles formats ● MicroDVD, SubRip, TMPlayer (.srt, .sub, .txt) The video file and subtitles text file are inside the same folder, and the file ● names are the same except for the file extensions. If there are more than one subtitles text files inside the same folder, they ●...
Page 119: Media Player
Media Player Using Media Player Information Media Player allows you to enjoy photo, video or music recorded on an SD Card and a USB Flash Memory with this TV, and contents recorded with this TV to the formatted USB HDD. (Example) Photo mode: Still pictures recorded with digital cameras will be displayed.
Page 120 Picture setting may not work depending on the conditions. ● Folder and file names may be different from those on the digital camera or ● digital video camera used. ■ To insert or remove the SD Card Gently insert the SD Card with the label surface facing front. Push the centre of the card until a click is heard.
Page 121: Selecting Device / Mode
Selecting device / mode 1. Insert the SD Card or USB Flash Memory to the TV When you insert the SD Card, Media Player will start automatically. ● Media Player Using Media Player Information To play back contents in the USB HDD, ensure the connection and ●...
Page 122 = Note = You may also access each mode directly from APPS List. ● Functions APPS List How to use Recorded TV is available for contents recorded on the USB HDD with this ● Select the appropriate device and content for playing back each file. ●...
Page 123: Photo Mode
Photo mode Selecting file Select the file in the thumbnail view with and press to start playback. : Error display To change the size of photos in the thumbnail view ● 1) Display the option menu with OPTION 2) Select Change Size with and press...
Page 124: Sorting Photos
Viewing photo ■ Playback To operate Single view ● : To the previous photo : To the next photo : Stop (return to thumbnail) : Slideshow To display / hide the operation guide ● To rotate 90° ● (blue) To return to thumbnail ●...
Page 125: Multi Shot 3D
Multi Shot 3D This TV can create a 3D photo using a pair of photos in the SD Card and save it into the same SD Card. This TV can also create a 3D photo from photos in the USB Flash Memory, ●...
Page 126: Using Slideshow
Using slideshow Slideshow ends when all photos within the current thumbnail are viewed. 1. Select the file from the thumbnail of photos for the first view with 2. Start Slideshow with (red) and To display / hide the operation guide ●...
Page 127 Gallery (+ calendar) / Gallery: Various sizes of photos in the frames are displayed. You can select whether to display the calendar or not. The month of ● calendar is changed with Cinema: Photos are displayed as old films (sepia tone). Colour Effect (Off Sepia...
Page 128 Screen Mode (Normal / Zoom) Selects enlarged or normal viewing in Single view and Slideshow. Not valid when Frame is set to Collage, Drift, Gallery, Cinema or when ● Transition Effect is set to Motion Depending on the photo size, the photo may not be fully enlarged to fill the ●...
Page 129 User: Music files in the device registered by yourself will be played back. If no music files have been registered or the device which had ● registered music files is removed, no sound will be played back. ● To register music 1) Select the music file with and press to access...
Page 130: Selecting File
Video mode Selecting file 1. Select the title in the thumbnail view with : Error display : The file does not support thumbnail view. The preview will start when the title / scene is highlighted in the ● thumbnail view if it supports a preview. To turn off the preview, set Video Preview to Off.
Page 131: Watching Video
Watching video ■ Playback from the selected scene in the title (SD-Video or AVCHD) Playback of the selected scene will start and continue until the end of the title. 1. Select the title with and press to access 2. Select the scene with 3.
Page 132 To change aspect ● 1) Display Aspect Selection list with ASPECT 2) Select the mode with and press to set Aspect1: Displays the content enlarged without distortion. Aspect2: Displays the content full-screen. Original: Displays the content original size. – You can also change the mode pressing ASPECT. (Press repeatedly until you reach the desired mode.) –...
Page 133: Video Setup
Video Setup Set up the settings for Video mode. 1. Display the option menu with OPTION 2. Select Video Setup with 3. Select one of the following items with and press to access Video Preview Multi Audio Dual Mono Audio Subtitle Subtitle Text Repeat...
Page 134: Audio Output Settings
Audio output settings You can enjoy the multi-channel sound via an amplifier connected to DIGITAL AUDIO or HDMI2 (ARC function) terminal. To confirm or change the current sound status ● Media Player Video mode Video Setup 1. Display the menu with MENU 2.
Page 135: Selecting Content
Recorded TV mode Selecting content For exclusive USB HDD ● To play back contents in the USB HDD, ensure the connection and ● settings are completed. Recording USB HDD setup 1. Contents list of the selected device is displayed in Recorded TV mode Remaining capacity of the selected device is displayed on the top right.
Page 136: Watching Recorded Tv
Watching recorded TV ■ Playback To operate playback ● Manual skip – Press to skip forward approx. 30 seconds. – Press and hold to skip backward approx. 15 seconds. : Rewind : Fast forward : Stop : Pause (displays the time seek bar) / Playback To jump to the specified time point ●...
Page 137: Grouping Contents
To confirm or change the current status (if available) ● Watching Basic Option Menu To return to list ● BACK/RETURN The recorded content may not be played back properly while 2 recordings ● are in progress. Grouping contents 1. Select the content to edit with and press (blue) to tick in the contents list...
Page 138: Deleting Content
Deleting content 1. Select the content to edit with and press (blue) to tick in the contents list 2. Delete the content with (red) 3. When the confirmation screen is displayed, select with press to set Changing device You can change the current device to another device directly in the same mode when two or more available devices are connected.
Page 139: Audio Output Settings
Audio output settings You can enjoy the multi-channel sound via an amplifier connected to DIGITAL AUDIO or HDMI2 (ARC function) terminal. To confirm or change the current sound status ● Media Player Video mode Video Setup 1. Display the menu with MENU 2.
Page 140: Selecting File
Music mode Selecting file 1. Select the folder in the thumbnail view with 2. Start playback with (red) For supported file formats ● Media Player Technical information Music format ■ Thumbnail view To display / hide information of the highlighted content ●...
Page 141: Music Setup
To the next track ● (green) To return to thumbnail ● BACK/RETURN Music Setup Set up the setting for Music mode. This function is available in the thumbnail view. ● 1. Display the option menu with OPTION 2. Select Music Setup Repeat with 3.
Page 142: Device Handling Caution
Back up the recorded data at regular intervals to prevent data ● deterioration, data damage or erratic operation of the TV. Panasonic is not liable for any deterioration or damage of recorded data. SD Card ■...
Page 143: Usb Devices
You cannot connect any devices using a USB card reader. ● Additional information for the devices may be found on the following ● website. (English only) http://panasonic.net/viera/support ■ USB Flash Memory (for playing back in Media Player) USB Flash Memory format: FAT16, FAT32 or exFAT USB HDDs formatted on a PC are not guaranteed to work in Media Player.
Page 144: Photo Format
Photo format ■ Supported Photo formats ● JPEG (.jpg, .jpeg, .mpo) Image resolution (pixel): 8 × 8 to 30,719 × 17,279 Sub-sampling: 4:4:4, 4:2:2, 4:2:0 DCF and EXIF standards ● Progressive JPEG is not supported. ● = Note = Some files may not be played back even if they fulfil these conditions. ●...
Page 145: Video Format
Video format ■ Supported Video formats ● AVCHD (.mts) Video codec: H.264 BP/MP/HP Audio codec: Dolby Digital AVCHD Standard Ver. 2.0 (AVCHD 3D, AVCHD Progressive) ● The data may not be available if a folder structure on the device is ●...
Page 146 Video codec: H.264 BP/MP/HP, MPEG1, MPEG2, MPEG4 SP/ASP Audio codec: AAC, Dolby Digital, Dolby Digital Plus, HE-AAC, MPEG Audio, MP3 This TV supports this container recorded with Panasonic products. For ● details, read the manual of the products. ● FLV (.flv) Video codec: H.264 BP/MP/HP...
Page 147 ● PS (.mod, .mpg, .mpeg, .vob, .vro) Video codec: H.264 BP/MP/HP, MPEG1, MPEG2, VC-1 Audio codec: AAC, Dolby Digital, Dolby Digital Plus, HE-AAC, LPCM, MPEG Audio, ● TS (.mts, .m2ts, .tp, .trp, .ts, .tts) Video codec: H.264 BP/MP/HP, MPEG1, MPEG2, VC-1 Audio codec: AAC, Dolby Digital, Dolby Digital Plus, DTS core, HE-AAC, MPEG Audio, MP3...
Page 148: Music Format
Music format ■ Supported Music formats ● MP3 (.mp3) ● AAC, Apple Lossless (.m4a) Copy-protected files cannot be played back. ● ● WMA / WMA Pro (.wma) Copy-protected files cannot be played back. ● ● LPCM (.wav) ● FLAC (.flac) = Note = Some files may not be played back even if they fulfil these conditions.
Page 149: Information
Functions APPS List Information Various applications (internet contents, network contents, Media Player, etc.) can be accessed easily from APPS List. ■ APPS List (Example) = Note = APPS List is subject to change without notice. ● - 149 -...
Page 150 How to use You can access special features such as internet contents, network contents, Media Player, etc. from APPS List. 1. Display APPS List with APPS (Example) To exit APPS List ● EXIT 2. Select an icon of the features with and press to access Internet contents...
Page 151: Settings
Settings You can customise APPS List (screen settings, etc.). 1. Display APPS List with APPS 2. Select the icon for settings on APPS List with and press to access 3. Follow the on-screen instructions = Note = Setup menu items may be changed without notice. ●...
Page 152 How to use You can select a channel while watching another programme or external input. 1. Display the menu with MENU 2. Select Picture Screen Settings Multi Window with and press to access You can also access the multi window mode by selecting Multi Window ●...
Page 153 ■ Watching View (Example) Main screen TV mode / input mode / channel position and name Sub screen Press to select the screen to operate. ● – displays on the screen. To select the sound ● 1) Display Option Menu with OPTION 2) Select...
Page 154: Note
Note Ensure that Dual Tuner Mode is set to Auto Setup to display DVB-S ● mode both in two windows. Watching Tuning and editing channels Auto Setup Analogue channel cannot be displayed both in two windows. ● Data services are not available in the multi window mode. ●...
Page 155: Summary Of Viera Link
VIERA Link “HDAVI Control™” Summary of VIERA Link Enjoy additional HDMI Inter-Operability with Panasonic products which have “HDAVI Control™” function. VIERA Link (HDAVI Control) connects the TV and the equipment with VIERA Link function, and enables easy control, playback, energy saving, creating home theatre, etc., without complicated settings.
Page 156 ● Connect the equipment supporting VIERA Link to the TV’s HDMI terminal ● via an HDMI cable. About HDMI cable for connecting Panasonic HD Video Camera or LUMIX Camera, read the manual of the equipment. HDMI terminal HDMI cable Equipment with VIERA Link function (DIGA Recorder / DVD Player / Blu- ray Disc Player / HD Video Camera / LUMIX Camera) ■...
Page 157 ■ VIERA Link (HDMI and Audio out connections) Use a fully wired HDMI compliant cable. ● Connect the equipment supporting VIERA Link to the TV’s HDMI terminal ● via an HDMI cable. Use a fully wired SCART cable. ● Use the optical digital audio cable or SCART cable for audio output from ●...
Page 158 : If the connected equipment has “HDAVI Control 5” function, you do not have to use this audio cable (Optical digital audio cable or SCART cable). In this case, connect the equipment to the TV’s HDMI2 terminal via an HDMI cable. ■...
Page 159: Preparations
■ VIERA Link Control of compatible equipment The following is the maximum number of compatible equipment that can be controlled by VIERA Link Control. This includes connections to equipment already connected to the TV. For example, DIGA Recorder connected to Amplifier which is connected to the TV via an HDMI cable.
Page 160: Easy Playback
Easy playback Automatic input switching - When the connected equipment is operating, the input mode is switched automatically. Power on Link Power on Link in the Setup Menu to use this function. Settings Setup VIERA Link Settings When the connected equipment starts playback or direct navigator / function menu for the equipment is activated, the TV is automatically turned on.
Page 161: Intelligent Auto Standby
Intelligent Auto Standby Intelligent Auto Standby in the Setup Menu to use this function. Settings Setup VIERA Link Settings When the TV is on, non-used connected equipment goes into Standby mode automatically to reduce the power consumption. For example, when the input mode is switched from HDMI or when Speaker Selection is changed to...
Page 162: Speaker Selection
■ If multiple recorders or players are connected Each recorder / player is numbered. The number is given from the TV’s lower number of HDMI terminal connected to the same type of equipment. For example, when two recorders are connected to HDMI2 and HDMI3, the recorder connected to HDMI2 is displayed as Recorder1, and the recorder connected to HDMI3 is displayed as Recorder2.
Page 163: Note
■ Multi-channel sound If you want to enjoy the multi-channel sound (e.g. Dolby Digital 5.1ch) via an Amplifier, connect it with an HDMI cable and Optical digital audio cable, and then select Home Cinema. If your Amplifier has the “HDAVI Control 5” function, you only need to connect it with an HDMI cable to the TV’s HDMI2 terminal.
Page 164: Using Child Lock
Child Lock Using Child Lock You can lock specific channels / AV input terminals to restrict access to them. When the locked channel / input is selected, a message appears. Enter the PIN number to watch. 1. Display the menu with MENU 2.
Page 165: Pin Number
PIN number You can change the PIN number. 1. Select Change PIN with and press to access 2. Enter a new PIN number twice with the numeric buttons = Note = Setting Shipping Condition erases the PIN number and all settings. ●...
Page 166: Using Data Service Application
Data Service Application Using Data Service Application You can enjoy Hybrid Broadcast Broadband TV application that is one of the interactive data services for digital broadcasting. 1. Display the TV Selection screen with 2. Select the mode with and press to set DVB-S DVB-C...
Page 167: Note
Note To use Hybrid Broadcast Broadband TV application fully, you need a ● broadband network environment. Ensure the network connections and network settings are completed. Internet service Network connections Internet service Network settings Not all the data services are available depending on the country, area and ●...
Page 168: Caution
Common Interface Caution Turn the TV off with Mains power On / Off switch whenever inserting or ● removing the Common Interface (CI) Module. If a view card and a card reader come as a set, first insert the card reader, ●...
Page 169: Using Common Interface
Using Common Interface The Common Interface Module menu provides access to software contained in Common Interface (CI) Modules. This function may not be available in some countries or regions. ● Video and audio signals may not be output depending on broadcasts or ●...
Page 170: Shipping Condition
Shipping Condition Shipping Condition Resets the TV to its original condition (i.e. no channels tuned in). All settings other than USB Device Setup are reset (channels, picture, sound settings, etc.). 1. Display the menu with MENU 2. Select Setup System Menu Shipping Condition with and press...
Page 171: Auto Update
Updating the TV Software Information A new version of software may be released for download to enhance the performance or operations of the TV. If there is an update available and the channel has the update information, a notification message is displayed. To install new software, select Standby with...
Page 172: Manual Update
= Note = Download may take a few hours. ● During software download and update, DO NOT switch off the TV. ● A notification message may be a reminder. In this case, schedule ● information (the date when the new version can be used) will appear. You can set the reservation for update.
Page 173: Using Numeric Buttons
Setting characters Using numeric buttons You can enter characters for free input items using numeric buttons. Press the numeric button repeatedly until you reach the desired character. : . @ / 1 ! : # + - * _ ( ) “ ‘ % & ? , ; = $ [ ] ~ < > { } | ` ^ \ : a b c 2 A B C : d e f 3 D E F : g h i 4 G H I...
Page 174: Preparations
Voice Control Preparations Voice Control function allows you to operate the TV (e.g. selecting a channel), search the content from various features, etc. with your speech. To use this function fully, you need a broadband network environment. ● Ensure the network connections and network settings are completed. Internet service Network connections Internet service...
Page 175 = Note = To use Voice Control function fully, you need a broadband network ● environment, because this function accesses the speech recognition server with the internet connection. Even if you have the internet environment, this function may not be available depending on the proxy settings.
Page 176: Bluetooth Setup
Bluetooth devices Bluetooth Setup You can use Bluetooth keyboards and Bluetooth audio devices (headphones, etc.) with this TV by setting Bluetooth Setup in the Setup Menu. Settings Setup Bluetooth Setup : HID (Human Interface Device Profile) compliant keyboards can be used. : A2DP (Advanced Audio Distribution Profile) compliant audio devices can be used.
Page 177 Settings in the Sound Menu may not be effective for the Bluetooth audio ● devices. This setup has not been designed for the VIERA Touch Pad Controller ● supporting Bluetooth wireless technology. Additional information for the devices may be found on the following ● website. (English only) http://panasonic.net/viera/support - 177 -...
Page 178: Keyboard
Keyboard / Gamepad Keyboard Keyboards requiring the drivers are not supported. ● To change the language type, set Keyboard Layout. ● Settings Setup System Menu Characters may not be displayed correctly on the TV screen depending on ● the connected keyboard or the keyboard layout setting. Some of the keys of keyboards may correspond to the operation of the ●...
Page 179: Gamepad
Gamepad Check the gamepads that have been tested for compatibility with this TV ● at the following website. (English only) http://panasonic.net/viera/support Some of the keys of gamepads correspond to the operation of the remote ● control. Volume Up / Down...
Page 180 Settings Setting menu How to use Various menus allow you to make settings for the picture, sound, and other functions. 1. Display the menu with MENU Displayed items vary depending on the input signal. ● 2. Select the menu with and press to access 3.
Page 181 To reset the settings ● – To initialise picture or sound settings only, select Reset to Defaults the Picture Menu or Sound Menu. Settings Picture Reset to Defaults Settings Sound Reset to Defaults – To initialise all settings, select Shipping Condition.
Page 182: Viewing Mode
Picture Viewing Mode Selects your favourite picture mode for each input. (Dynamic Normal Cinema True Cinema Custom Professional1 Professional2) Dynamic: Improves contrast and sharpness for viewing in a bright room. Normal: Normal use for viewing in a normal lighting condition. Cinema: Improves the performance of contrast, black and colour reproduction for watching movies in a darkened room.
Page 183: Basic Settings
Basic settings Backlight, Contrast, Brightness, Colour, Tint, Sharpness Adjusts the levels of these options according to your personal preference. Colour Temperature (Cool2 Cool1 Normal Warm1 / Warm2) Sets the overall colour tone of the picture (bluer - redder). Vivid Colour / Off) Automatically adjusts colours to vivid ones.
Page 184: Caption Smoother
Caption Smoother Makes caption contours smooth. Specially effective for low resolution contents. (Auto / Off) Not valid in 3D mode ● Brilliance Enhancer Enhances picture contrast locally to increase picture brilliance. (Max / Off) Not valid in 3D mode ● Intelligent Frame Creation Automatically compensates the picture frame rate and removes juddering movements to make the images smooth.
Page 185: Option Settings
Option Settings Game Mode / Off) Provides suitable images for fast response signals when playing games. Not valid on TV or multi window mode ● To display a continuous record of time spent using Game mode, set ● Playing Time Display.
Page 186: Screen Settings
AV Colour System (Auto SECAM M.NTSC / NTSC) Selects optional colour system based on video signals. For AV input ● 3D-COMB / Off) Makes still or slow moving pictures more vivid. Occasionally, while viewing still or slow moving pictures, colour patterning ●...
Page 187: D Settings
Zoom Adjustments Adjusts the vertical position and size when aspect is set to Just, Sidecut Just, Zoom Sidecut Zoom. Multi Window Displays two windows at once. Functions Multi Window Information Screen Display / Off) Turns the screen off when you select Off. This function is effective in reducing power consumption when listening to the sound without watching the TV screen.
Page 188 2D 3D Depth (Max / Min) Selects a level of 3D-image depth for viewing converted 2D images. 3D Adjustment / Off) Adjustment of the 3D effect (except in 2D 3D mode). Set to to enable Effect setting. When setting to On, a safety precaution message will appear. Read it ●...
Page 189: Copy Adjustment
Lock Settings Locks the settings of Professional1 / 2 mode for each input. Watching For best picture Lock Settings Copy Adjustment Copies the selected True Cinema, Custom, Professional1 Professional2 settings to those of the other input. Watching For best picture Copy Adjustment Reset to Defaults Resets the current Picture Viewing Mode to the default settings.
Page 190: Mode
Sound Mode Selects your favourite sound mode for each input. (Standard Music Ambience / User) Standard: Provides the suitable sound quality for all types of scenes. Music: Improves sound quality for watching music videos, etc. Ambience: Improves spatial effects and provides clear sounds. User: Adjusts the sounds manually using the equaliser to suit your favourite sound quality.
Page 191: Basic Settings
Basic settings Bass Adjusts level to enhance or minimise lower, deeper sound output. Treble Adjusts level to enhance or minimise sharper, higher sound output. Equaliser Adjusts the frequency level to suit your favourite sound quality. This function is available when Mode is set to User.
Page 192: Volume Settings
Digital Remaster / Off) Compensates a compressed audio signal to reproduce the original sound quality. This function is effective only for the sound from TV speakers. ● Volume settings Headphone Volume Adjusts the volume of headphones. Auto Gain Control / Off) Automatically regulates large sound level differences between channels and inputs.
Page 193: Voice Guidance Settings
Voice Guidance Settings Voice Guidance / Off) Set to to enable voice guidance of the basic features (menu item, on- screen messages, etc.) for visually impaired users. Speed (Fast Normal / Slow) Selects the readout speed for the voice guidance. Volume (Max / Min)
Page 194: Advanced Settings
Advanced settings Selects multiplex sound mode (if available). Stereo: Use this normally. Mono: When stereo signal cannot be received / M2: Available while mono signal is transmitted. For Analogue mode ● Audio Preference (Auto / MPEG) Selects the initial setting for audio tracks. Auto: Automatically selects the audio tracks if a programme has more than two tracks.
Page 195 SPDIF Selection (Auto / PCM) Selects the initial setting for digital audio output signal from DIGITAL AUDIO and HDMI2 (ARC function) terminals. SPDIF is a standard audio transfer file format. ● Auto: Dolby Digital Plus, Dolby Digital and HE-AAC multi-channel are output as Dolby Digital Bitstream.
Page 196: Reset To Defaults
Sets to control the TV with devices connected to the network. Home network Network settings Network Link Settings Other settings Software Update Checks for available software updates from the Panasonic website. Internet service Network settings Software Update Home network Network settings...
Page 197: Off Timer
Timer Off Timer Sets the duration of time until the TV automatically goes into Standby mode. (minutes)) Watching Basic Off Timer Timer Programming Sets a timer to record or remind forthcoming programmes. Recording Timer Programming For DVB mode ● Time Zone Adjusts the time data.
Page 198: Eco Navigation
Setup Eco Navigation Automatically sets the TV to the most suitable energy-saving mode. The concerned items and their current settings are displayed. Select Set to to set them to the energy-saving settings at once. Voice Control Settings Settings for Voice Control function. Functions Voice Control Preparations...
Page 199: Tuning Menu
Tuning Menu Favourites Edit Creates a list of favourite channels. Watching Tuning and editing channels Favourites Edit Not valid in Analogue mode ● Channel List Skips unwanted channels or edits channels. Watching Tuning and editing channels Channel List Auto Setup Automatically searches for receivable channels.
Page 200 Antenna System (One LNB MiniDiSEqC DiSEqC 1.0 Single Cable) Sets the antenna system to use plural LNBs for receiving several satellites. Watching Tuning and editing channels Auto Setup This TV supports DiSEqC Version 1.0. ● For DVB-S mode ● LNB Configuration Selects the satellite for each LNB.
Page 201: Language
Language OSD Language Changes language for on-screen displays. Preferred Audio 1 / 2 Selects the first and second preferred language for DVB multi audio (depending on the broadcaster). Preferred Subtitles 1 / 2 Selects the first and second preferred language for DVB subtitles (depending on the broadcaster).
Page 202 Teletext Character Set (West East1 / East2) Selects teletext language font. West: English, French, German, Greek, Italian, Spanish, Swedish, Turkish, etc. East1: Czech, English, Estonian, Lettish, Rumanian, Russian, Ukrainian, etc. East2: Czech, Hungarian, Lettish, Polish, Rumanian, etc. Default Guide (Channel List Guide) Selects the default TV Guide type when pressing GUIDE.
Page 203 VIERA Connect Banner / Off) Sets the VIERA Connect introduction banner display. For Full Screen TV ● Playing Time Display / Off) Set to to display a time period of continuous use in Game mode on the top right of the screen every 30 minutes. This function is available when Game Mode is set to On.
Page 204: Common Interface
Common Interface Sets to watch encrypted channels, etc. Functions Common Interface VIERA Link Settings VIERA Link / Off) Sets to use VIERA Link functions. Functions VIERA Link “HDAVI Control™” Power on Link / Off) Sets to use Power on Link functions. Functions VIERA Link “HDAVI Control™”...
Page 205: Professional Mode (Isfccc)
Professional Mode (isfccc) Enables the professional picture settings. Set to to display the modes of Professional1 Professional2 Viewing Mode. isfccc is the picture setting for the certified professional dealer. For details, ● consult your local dealer. Data Service Application Service (Auto Start On Auto Start Off / Off)
Page 206: System Menu
System Menu Keyboard Layout Selects the language that your USB or Bluetooth Keyboard supports. For information of using Keyboard ● Functions Keyboard / Gamepad Keyboard Shipping Condition Resets all settings to the original condition. Functions Shipping Condition System Update Downloads new software to this TV. Functions Updating the TV Software Licence Menu...
Page 207: Picture
Picture Before requesting service or assistance, please follow these simple guides to solve the problem. If the problem still persists, please contact your local Panasonic dealer for assistance. Auto aspect Auto aspect is designed to provide you with the best ratio to fill the screen.
Page 208 No image can be displayed Check all required cables and connections are firmly in place. ● Check the correct input mode is selected. ● Check the setting of AV2 (COMPONENT / VIDEO) in Input Selection ● match the output of the external equipment. Watching External equipment Is Contrast,...
Page 209: Digital Tv
Digital TV Before requesting service or assistance, please follow these simple guides to solve the problem. If the problem still persists, please contact your local Panasonic dealer for assistance. Block noise, frozen or disappearing image occurs / Some channels cannot be tuned Check the position, direction and connection of the aerial or dish.
Page 210: Analogue Tv
Analogue TV Before requesting service or assistance, please follow these simple guides to solve the problem. If the problem still persists, please contact your local Panasonic dealer for assistance. White spots or shadow image (ghosting) occurs / Some channels cannot be tuned Check the position, direction and connection of the aerial.
Page 211: Sound
Sound Before requesting service or assistance, please follow these simple guides to solve the problem. If the problem still persists, please contact your local Panasonic dealer for assistance. No sound is produced Is “Sound mute” active? Press MUTE to switch sound mute on or off.
Page 212 Before requesting service or assistance, please follow these simple guides to solve the problem. If the problem still persists, please contact your local Panasonic dealer for assistance. Cannot view 3D images Ensure that 3D Mode Selection is set to 3D.
Page 213: Hdmi
HDMI Before requesting service or assistance, please follow these simple guides to solve the problem. If the problem still persists, please contact your local Panasonic dealer for assistance. Sound is unusual Set the sound setting of the connected equipment to “2ch L.PCM”.
Page 214: Network
Network Before requesting service or assistance, please follow these simple guides to solve the problem. If the problem still persists, please contact your local Panasonic dealer for assistance. Cannot connect to the network Check the LAN cable or wireless LAN is connected properly.
Page 215: Other
● Other Before requesting service or assistance, please follow these simple guides to solve the problem. If the problem still persists, please contact your local Panasonic dealer for assistance. VIERA Link function does not work and an error message appears Check the connections.
Page 216 An error message appears Follow the message’s instructions. ● If the problem persists, contact your local Panasonic dealer or the ● authorised service centre. The touch pad controller does not work or cannot be registered Are the batteries installed correctly? ●...
Page 217: Care And Cleaning
Maintenance Care and Cleaning First, remove the mains plug from the socket outlet. ■ Display panel, Cabinet, Pedestal Regular care: Gently wipe the surfaces of the display panel, cabinet, or pedestal using a soft cloth to clean the dirt or fingerprints. For stubborn dirt: First clean the dust on the surface.
Page 218: Using Help Menu
Information Using Help menu 1. Display the menu with MENU 2. Select Help with and press to access 3. Select TV Self Test System Information Device Information with and press to access TV Self Test Makes a diagnosis of picture or sound problems. Follow the on-screen instructions.
Page 219: D Eyewear
3D Eyewear TY-EP3D20E ● (1 pack includes 2 eyewears) – If you need 3D Eyewear additionally, please purchase this optional accessory. – Use Panasonic 3D Eyewear for passive 3D. – For more information (English only): http://panasonic.net/viera/eu/ Communication Camera ■ Communication Camera TY-CC20W ●...
Page 220: Wall-Hanging Bracket
Wall-hanging bracket ■ Wall-hanging bracket Please contact your local Panasonic dealer to purchase the recommended ● wall-hanging bracket. = Warning = Using other wall-hanging brackets, or installing a wall-hanging bracket ● by yourself have the risk of personal injury and product damage. In order to maintain the unit’s performance and safety, be absolutely sure to ask...
Page 221: Licence
The Bluetooth word mark and logos are registered trademarks owned by ® Bluetooth SIG, Inc. and any use of such marks by Panasonic Corporation is under license. Other trademarks and trade names are those of their respective owners. SDXC Logo is a trademark of SD-3C, LLC.
Page 222 Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,487,535 & other U.S. and worldwide patents issued & pending. DTS, the Symbol, & DTS and the Symbol together are registered trademarks & DTS 2.0+Digital Out is a trademark of DTS, Inc.
Page 223 Please refer to the detailed terms and conditions thereof shown in the “Software Licence” menu on this product. At least three (3) years from delivery of this product, Panasonic will give to any third party who contacts us at the contact information provided below,...
Page 224 Ver.1.01...
