Summary of Contents for Hoover HECH 616 X
- Page 1 Cooker hood Instruction Manual HECH 616 X HECH 916 X...
-
Page 2: Table Of Contents
CONTENT 1……………………………………….………. Notice 2………….……………………………………. Feature 3……………….………………………………. Installation 4…………………….…………………………. Notice of installation 5………………………….……………………. Safety Warning 6……………………………….………………. Use 7…………………………………….…….…… Maintenance 8…………………………………..…………... Troubleshooting 9…………………………………..……..Service Centre... -
Page 3: Notice
(1) NOTICE 1. Thank you for choosing our cooker hood. Please read the instruction manual carefully before use. 2. The installation work must be undertaken by a qualified and competent fitter. 3. The manufacturer disclaims all liability for any damage or injury caused as a result of not following instructions for installation contained in the following text. -
Page 4: Installation
(3) INSTALLATION 3.1 The cooker hoods should be placed at a distance of 65-75cm from the cooking surface for best effect. See pic1. 3.2 To install onto the wall every 100mm drill 3 holes of Ø8mm on a suitable place in line with the hook on the hood. 3.3 Insert expended screws into the holes. -
Page 5: Notice Of Installation
NOTICE OF INSTALLATION 1. Before installation, please ensure the area is clean to avoid suction of the remaining bits of broken wood and dust. 2. It cannot share the same air ventilation tube with other appliance such as gas tube, warmer tube, and hot wind tube. 3. -
Page 6: Use
(6) USE – (Speed adjustment. See pictures) Push button 1. Push stop button, and the motor will stop. 2. Push the Low button, the buzzer will buzz once, and the motor runs at low speed. 3. Push the Mid button, the buzzer will buzz once, and the motor runs at mid speed. -
Page 7: Maintenance
(7) MAINTENANCE 7.1 The cleaning of the carbon grease filter mesh The filter mesh is made of high-density stainless steel. Please do not use the corrosive detergent on it. Keeping this filter clean will keep the appliance running correctly. Please strictly follow the guidelines below. Method 1: Put the mesh into 40-50 c clean water, pour on detergent, and soak for 2-3 mins. -
Page 8: Troubleshooting
(8) TROUBLESHOOTING Fault Cause Solution The leaf blocked Get rid of the blocking Light on, but motor The capacitor damaged Replace capacitor does not work The motor jammed bearing Replace motor damaged The internal with of motor off Replace motor or a bad smell from the motor Beside the above mentioned, check the following: Light does not... -
Page 9: Electrical Diagram
Electrical Diagram Main Parameters Rated Input 220V-240V, 50Hz Rated Power 220W Lighting Power 40W X 2 Motor Power 140W Drive Mode Single Motor Speed Speed I Speed II Speed III Air tube diameter 150MM Air output ≥6.6m3/min Air pressure ≥250Pa Noise ≤64Db(A) -
Page 10: Service Centre
(9) SERVICE CENTRE Before calling the Service Centre If the hood is not working, we recommend that: - you check the troubleshooting on chapter 8. - you check that the cooker hood is properly plugged into the power supply If the cause of the fault cannot be detected: disconnect the hood from the mains, do not touch the hood and call the after sales service.
