P-660HN-Fx Series ENGLISH Introduction The P-660HN-Fx series are high performance routers which combine high- speed ADSL Internet access, a built-in switch, a firewall and high-speed wireless networking capability. How It Works A computer can connect to the P-660HN-Fx using an Ethernet cable (a) or using wireless connection (b).
ENGLISH Before You Begin Make sure you have the following things before you set up your P-660HN-Fx. • Internet access - account information provided by your ISP, such as user name and password. • Internet Explorer 6.0 or later or Netscape Navigator 7.0 or later, with JavaScript enabled.
P-660HN-Fx Series ENGLISH Hardware Connections 1. DSL: Use a telephone wire to connect this port to a telephone jack. 2. ETHERNET 1-4: Use an Ethernet cable to connect a computer to this port for initial configuration and/or Internet access. 3. POWER: Use the power adaptor provided with your P-660HN-Fx to connect an appropriate power source to this socket.
Page 6
ENGLISH 4. Push the power switch to the on position. Make sure to remove the plastic sheet on the top panel. Look at the LEDs (lights) on the top panel of the P-660HN-Fx. • The POWER light blinks during start-up and is green once the P-660HN- Fx is ready.
Page 7
P-660HN-Fx Series ENGLISH If you have a PPPoE or PPPoA connection, a screen displays prompting you to enter your Internet account information. Enter the username, password and/or system password (1234 by default) exactly as provided. Click Apply. If the INTERNET light is off but the DSL light is on, go to Internet/Wireless Setup on page...
Page 8
ENGLISH Internet/Wireless Setup 1. Open your browser and enter http://192.168.1.1 (the P-660HN-Fx's default IP address) as the address. 2. Enter the admin password 1234 and click Login. If the login screen does not display, make sure you allow web browser pop-up windows, JavaScripts and Java permissions. Your computer should be also set to get an IP address automatically from a DHCP server.
Page 9
P-660HN-Fx Series ENGLISH 3. It is strongly recommended that you change the admin password in the following screen. If you change it, you will not see this screen the next time you log in. 4. Click Apply to replace the P-660HN-Fx’s default digital certificate. The certificate is used for authentication when using a secure HTTPS connection over the Internet.
Page 10
ENGLISH 5. Select Go to Wizard setup and click Apply. The connection wizard helps you set up your Internet connection as well as your wireless settings. Enter the Internet access information exactly as given to you by your ISP in each wizard screen and then click Next to continue or click Back to return to the previous screen.
Page 11
P-660HN-Fx Series ENGLISH 6. Click INTERNET/WIRELESS SETUP. Wait while the P-660HN-Fx tries to detect your Internet connection. If the P-660HN-Fx cannot detect your Internet connection, follow the directions in the screen. Enter the information provided by your ISP. Keep the default settings if your ISP did not provide some information.
Page 12
ENGLISH If you cannot access the Internet and the INTERNET light is off, make sure you enter the correct information in the INTERNET/ WIRELESS SETUP wizard screens. If you are using a new Internet account, contact your ISP to make sure it is active. If you are trying to access the Internet wirelessly, make sure the wireless and security settings in your wireless client are the same as the settings in the P-660HN-Fx.
