XTS DVR72XX-S User Manual

Slimline series standalone dvr
Hide thumbs
Table of Contents

Advertisement

Quick Links

XTS-DVR72 XX- S Slimline Series
Standalone DVR User's Manual
1

Advertisement

Table of Contents
loading

Related Manuals for XTS DVR72XX-S

Summary of Contents for XTS DVR72XX-S

  • Page 1 XTS-DVR72 XX- S Slimline Series Standalone DVR User's Manual...

  • Page 2: Table Of Contents

    Table of Contents FEATURES AND SPECIFICATIONS..............10 Overview ............................... 10 Features ..............................10 Specification ............................11 OVERVIEW AND CONTROLS ................. 15 Front Panel ............................15 Rear Panel............................16 Connection Sample ..........................17 Remote Control............................ 18 Mouse Control............................19 Virtual Keyboard & Front Panel ......................21 2.6.1 Virtual Keyboard..........................
  • Page 3 HDD Installation ........................... 22 Connecting Power Supply ........................23 Connecting Video Input and Output Devices .................. 23 3.5.1 Connecting Video Input........................23 3.5.2 Connecting Video Output....................... 24 Connecting Audio Input & Output, Bidirectional Audio ..............24 3.6.1 Audio Input............................24 3.6.2 Audio Output............................
  • Page 4 4.3.1 Search Menu ........................... 34 4.3.2 Basic Operation..........................35 4.3.3 Calendar............................36 Schedule ............................... 36 4.4.1 Schedule Menu ............................ 36 4.4.2 Snapshot ............................37 4.4.3 Image FTP ............................39 Detect ..............................39 4.5.1 Go to Detect Menu..........................39 4.5.2 Motion Detect............................39 4.5.3 Video Loss.............................
  • Page 5 UNDERSTANDING OF MENU OPERATIONS AND CONTROLS ....52 Menu Tree ............................52 Main Menu ............................52 Setting ..............................53 5.3.1 General............................. 53 5.3.2 Encode ............................. 54 5.3.3 Schedule ............................56 5.3.4 RS232............................... 56 5.3.5 Network ............................56 5.3.6 Alarm..............................63 5.3.7 Detect ...............................
  • Page 6 Go to Pan/Tilt/Zoom Menu ......................... 74 6.1.1 3D Intelligent Positioning Key ....................... 74 Preset /Patrol / Pattern /Border Function..................75 6.2.1 Preset Setup ............................ 76 6.2.2 Activate Preset ..........................76 6.2.3 Patrol Setup ............................. 76 6.2.4 Activate Patrol ..........................76 6.2.5 Pattern Setup...........................
  • Page 7 Un-install Web Control........................119 PROFESSIONAL SURVEILLANCE SYSTEM ..........120 FAQ......................... 121 APPENDIX A HDD CAPACITY CALCULATION ..........126 APPENDIX B COMPATIBLE USB DRIVE LIST ..........127 APPENDIX C COMPATIBLE CD/DVD BURNER LIST........128 APPENDIX D COMPATIBLE SATA HDD LIST ........... 129 APPENDIX E COMPATIBLE DISPLAYER LIST ..........
  • Page 8 Welcome Thank you for purchasing our DVR! This operating manual is designed to be a reference tool for the installation and operation of your system. Here you can find information about this series DVR features and functions, as well as a detailed menu tree.

  • Page 9: Important Safeguards And Warnings

    Important Safeguards and Warnings 1．Electrical safety All installation and operation here should conform to your local electrical safety codes. We assume no liability or responsibility for all the fires or electrical shock caused by improper handling or installation. 2．Transportation security Heavy stress, violent vibration or water splash are not allowed during transportation, storage and installation.

  • Page 10: Features And Specifications

    1 FEATURES AND SPECIFICATIONS 1.1 Overview This series product is an excellent digital monitor product. It adopts embedded Linux OS to maintain reliable operation. Popular H.264 compression algorithm and G.711 audio compression technology realize high quality, low bit stream. Unique frame by frame play function is suitable for detail analysis.

  • Page 11: Specification

    Support various decode protocols to allow the PTZ to control the speed dome. Intelligent operation Mouse operation function In the menu, support copy and paste setup function Slight function differences may be found due to different series. 1.3 Specification XTS-DVR7204S XTS-DVR7208S XTS-DVR7216S Parameter High-performance industrial embedded micro controller Main...
  • Page 12 Video PAL (625 line, 50f/s), NTSC (525 line, 60f/s) Standard Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s Record per channel Speed Video 1/4 windows(Optional) 1/4/9 windows 1/4/9 /16 windows Partition Monitor Support monitor tour functions such as alarm, motion detection, and Touring schedule auto control.
  • Page 13 Playback Repeat When hard disk is full, system can overwrite previous video file. Record Various search engines such as time, type and channel. Search Playback Various fast play, slow play speeds, manual frame by frame playback Mode and reverse play mode. Various File Can switch to previous or next file or any file in current play list.
  • Page 14 Network RJ45 10M/100M self-adaptable Ethernet port connection PTZ control port RS485 Support various PTZ control protocols. Ordinary COM (Debug),keyboard connection and transparent serial RS232 port(COM input and output via network ) System Hard Disk Display HDD current status Information Information Data Data stream statistics for each channel (in wave mode) Stream...

  • Page 15: Overview And Controls

    2 Overview and Controls This section provides information about front panel and rear panel. When you install this series DVR for the first time, please refer to this part first. 2.1 Front Panel The front panel is shown as in Figure 2-1. Figure 2-1 Please refer to the following sheet for front panel button information.

  • Page 16: Rear Panel

    Backspace function: in numeral control or text control, press it for 1.5seconds to delete the previous character before the cursor. In motion detection setup, working with Fn and direction keys to realize setup. In text mode, click it to switch between numeral, English character(small/capitalized) and etc.

  • Page 17: Connection Sample

    Figure 2-2 The 8-ch rear panel is shown as below. See Figure 2-3. Figure 2-3 The 16-ch real panel is shown as below. See Figure 2-4. Figure 2-4 Please refer to the following sheet for detail information. Video input Audio input Video CVBS output Audio output Network port...

  • Page 18: Remote Control

    Figure 2-5 2.4 Remote Control The remote control interface is shown as in F igure 2-6 X 2 8 2 H 2 8 2 H 2 8 2 H 2 8 6 H Please note remote control is not our standard accessory and it is not included in the accessory bag.

  • Page 19: Mouse Control

    Figure 2-6 Serial Number Name Function Address Click it to input device serial number, so that you can control Multiple-window switch Please refer to the multiple- window switch button in the front panel (MULT) 0-9 number key Input password, channel or switch channel.
  • Page 20 In input box, you can select input methods. Left click the corresponding button on the panel you can input numeral/English character (small/capitalized). Here ← stands for backspace button. ＿ stands for space button. In English input mode: _stands for input a backspace icon and ← stands for deleting the previous character.

  • Page 21: Virtual Keyboard & Front Panel

    2.6 Virtual Keyboard & Front Panel 2.6.1 Virtual Keyboard The system supports two input methods: numeral input and English character (small and capitalized) input. Move the cursor to the text column, the text is shown as blue, input button pops up on the right. Click that button to switch between numeral input and English input (capitalized and small), Use >...

  • Page 22: Installation And Connections

    3 Installation and Connections Note: All the installation and operations here should conform to your local electric safety rules. 3.1 Check Unpacked DVR When you receive the DVR from the forwarding agent, please check whether there is any visible damage. The protective materials used for the package of the DVR can protect most accidental clashes during transportation.

  • Page 23: Connecting Power Supply

    7. Connect the HDD cable and 8. Place the upper cover back power cable. and screw firmly. After completing HDD installation, please check connection of data ribbon and power cord. 3.4 Connecting Power Supply Please check input voltage and device power button match or not. We recommend you use UPS to guarantee steady operation, DVR life span, and other peripheral equipments operation such as cameras.

  • Page 24: Connecting Video Output

    Figure 3-1 3.5.2 Connecting Video Output Video output includes a B NC(PAL/NTSC BNC（1.0VP- P， 75Ω）output and a VGA output. System supports BNC, VGA and HDMI output at the same time. See F igure 3-2 X 2 8 4 H 2 8 4 H 2 8 4 H 2 8 8 H When you are using pc-type monitor to replace the monitor, please pay attention to the following points: To defer aging, do not allow the pc monitor to run for a long time.

  • Page 25: Audio Output

    Figure 3-3 3.6.2 Audio Output The audio output signal parameter is usually over 200mv 1KΩ (BNC). It can directly connect to low impedance earphone, active sound box or amplifier-drive audio output device. If the sound box and the pick-up cannot be separated spatially, it is easy to arouse squeaking. In this case you can adopt the following measures: Use better sound pick-up with better directing property.

  • Page 26: Alarm Input And Output Details

    Figure 3-5 There are two alarm input types for you to select: normal open (NO) and normal close (NC). 1. Alarm input a. Please make sure alarm input mode is grounding alarm input. b. Grounding signal is needed for alarm input. c.

  • Page 27: Alarm Input Port

    Figure 3-6 Parameter Grounding Alarm Ground line Alarm Input 1, 2, …, 8. It becomes valid in low voltage. Three NO activation outputs. 1-NO C， 2-NO C， 3-NO C Relay Output 1,2,3,4: NO and C(Normally Open and Com) 5: NO,C and NC(Normally Open, Com, Normally Closed) 6: Ctrl 12V(This is used for reset the senor) 485 A/B 485 communication port.
  • Page 28 Maximum switch currency Insulation Between touches with same 1000VAC 1minute polarity 1000VAC 1minute Between touches with different polarity Between touch and winding 1000VAC 1minute Between touches with same Surge voltage 1500V (10×160us) polarity 3ms max Length of open time 3ms max Length of close time Longevity...

  • Page 29: Other Interfaces

    Figure 3-8 3.10 Other Interfaces There are still other interfaces on the DVR, such as USB ports. You can refer to the F igure 3-9 X 2 9 0 H 2 9 0 H 2 9 0 H 2 9 4 H more information.

  • Page 30: Overview Of Navigation And Controls

    4 Overview of Navigation and Controls Before operation, please make sure: You have properly installed HDD and all the cable connections. The provided input power and the device power are matched. The external power shall be DC +12V 3.3A. Always use the stable current, if necessary UPS is a best alternative measure. 4.1 Login, Logout &...

  • Page 31: Logout

    Figure 4-2 4.1.3 Logout There are two ways for you to log out. One is from menu option: In the main menu, click shutdown button, you can see an interface is shown as below. See F igure 4-3 X 2 9 3 H 2 9 3 H 2 9 3 H 2 9 7 H Figure 4-3 There are several options for you.

  • Page 32: Manual Record

    Before replacement, please save the system setup, otherwise, you may lose the data completely! 4.2 Manual Record 4.2.1 Live Viewing After you logged in, the system is in live viewing mode. You can see system date, time and channel name. If you want to change system date and time, you can refer to general settings (Main Menu->Setting->General).
  • Page 33 You can use mouse or direction key to highlight channel number. See F igure 4-6 X 2 9 6 H 2 9 6 H 2 9 6 H 3 0 0 H Figure 4-6 4.2.2.4 Enable all channel recording Highlight ○ below All, you can enable all channel recording. All channel schedule record Please highlight “ALL”...

  • Page 34: Search & Playback

    Figure 4-9 4.3 Search & Playback 4.3.1 Search Menu Click search button in the main menu, search interface is shown as below. See Figure 4-10. Usually there are three file types: R: Regular recording file. A: External alarm recording file. M: Motion detection recording file Select playback mode Playback control bar...

  • Page 35: Basic Operation

    Fast play Previous frame Next frame Volume Previous file Next channel Next file Previous channel Search Backup 4.3.2 Basic Operation 4.3.2.1 Playback There are various search modes: video type, channel number or time. The system can max display 128 files in one screen. You can use page up/down button to view if there are more than one page.

  • Page 36: Calendar

    Backward play: In normal playback mode, left click backward When system is in in playback backward play or play button , system begins backward interface. frame by frame playback. playback mode, you Double click backward play button again, can click play system goes to pause mode.

  • Page 37: Snapshot

    Please highlight icon to select the corresponding function. After completing all the setups please click save button, system goes back to the previous menu. At the bottom of the menu, there are color bars for your reference. Green color stands for regular recording, yellow color stands for motion detection and red color stands for alarm recording.
  • Page 38 Figure 4-13 4.4.2.2 Activation Snapshot Please follow the steps listed below to enable the activation snapshot function. After you enabled this function, system can snapshot when the corresponding alarm occurred. In Encode interface, click snapshot button to input snapshot mode, size, quality and frequency.

  • Page 39: Image Ftp

    4.4.3 Image FTP In Network interface, you can set FTP server information. Please enable FTP function and then click save button. See Figure 4-15. Please boot up corresponding FTP server. Please enable schedule snapshot (Chapter 4.4.2.1) or activation snapshot (Chapter 4.4.2.2) first, now system can upload the image file to the FTP server.
  • Page 40 Send email: System can send out email to alert you when alarm occurs. PTZ activation: Here you can set PTZ movement when alarm occurs. Such as go to preset, tour &pattern when there is an alarm. Click “select” button, you can see an interface is shown as in F igure 4-18 X 3 0 5 H 3 0 5 H 3 0 5 H 3 0 9 H...

  • Page 41: Video Loss

    Figure 4-17 Figure 4-18 Figure 4-19 Figure 4-20 4.5.3 Video Loss F igure 4-16 , select video loss from the type list. You can see the interface is shown as in X 3 1 0 H 3 1 0 H 3 1 0 H 3 1 4 H F igure 4-21 .

  • Page 42: Camera Masking

    Figure 4-21 4.5.4 Camera Masking When someone viciously masks lens, the system can alert you to guarantee video continuity. Camera masking interface is shown as in F igure 4-22 X 3 1 2 H 3 1 2 H 3 1 2 H 3 1 6 H Tips: You can enable preset/tour/pattern activation operation when video loss occurs.

  • Page 43: Go To Alarm Setup Interface

    4.6.1 Go to alarm setup interface In the main menu, from Setting to Alarm, you can see alarm setup interface. See F igure 4-23 X 3 1 3 H 3 1 3 H 3 1 3 H 3 1 7 H 4.6.2 Alarm setup Alarm interface is shown as below.
  • Page 44 Figure 4-23 Figure 4-24 Figure 4-25...

  • Page 45: Backup

    Figure 4-26 4.7 Backup DVR support USB device backup and network download. Here we introduce USB backup first. You can refer to Chapter 7 Web Client Operation for network download backup operation. 4.7.1 Detect Device Click backup button, you can see an interface is shown as in F igure 4-27 .

  • Page 46: Ptz Control And Color Setup

    Figure 4-28 Click backup button, system begins burning. At the same time, the backup button becomes stop button. You can view the remaining time and process bar at the left bottom. See F igure X 3 2 1 H 3 2 1 H 3 2 1 H 3 2 5 H 4-29 Figure 4-29 The file name format usually is: SN_CH+channel number+time Y+M+D+H+M+S.

  • Page 47: Ptz Setup

    Connect the dome RS485 port to DVR 485 port. Connect dome video output cable to DVR video input port. Connect power adapter to the dome. 4.8.2 PTZ Setup Note: The camera video should be in the current screen. Before setup, please check the following connections are right: PTZ and decoder connection is right.

  • Page 48: Intelligent Positioning Key

    Figure 4-31 Click Pan/Tilt/Zoom, the interface is shown as below. See F igure 4-32 X 3 2 4 H 3 2 4 H 3 2 4 H 3 2 8 H Here you can set the following items: Step: value ranges fro 1 to 8. Zoom Focus Iris...

  • Page 49: Preset/ Patrol/Pattern/Scan

    4.9 Preset/ Patrol/Pattern/Scan F igure 4-32 , please click the “set” button. The interface is shown as below. See F igure 4-35 X 3 2 8 H 3 2 8 H 3 2 8 H 3 3 2 H X 3 2 9 H 3 2 9 H 3 2 9 H 3 3 3 H Here you can set the following items: Preset Tour...

  • Page 50: Activate Preset

    F igure 4-32 , use eight direction arrows to adjust camera to the proper position. X 3 3 5 H 3 3 5 H 3 3 5 H 3 3 9 H F igure 4-35 , click preset button and input preset number. The interface is shown as in F igure X 3 3 6 H 3 3 6 H 3 3 6 H 3 4 0 H X 3 3 7 H 3 3 7 H 3 3 7 H 3 4 1 H...

  • Page 51: Activate Pattern Function

    Figure 4-39 4.9.6 Activate Pattern Function F igure 4-36 , input mode value in the No. blank, and click pattern button. X 3 4 6 H 3 4 6 H 3 4 6 H 3 5 0 H 4.9.7 Auto Scan Setup F igure 4-35 , click border button.

  • Page 52: Understanding Of Menu Operations And Controls

    5 Understanding of Menu Operations and Controls 5.1 Menu Tree This series DVR menu tree is shown as below. Backup Information HDD Info Version Online Users Setting General Encode Schedule RS232 Menu Network Alarm Detect Pan/ Tilt/Zoom Display Default Search Advanced HDD Management Alarm Output...

  • Page 53: Setting

    Figure 5-1 5.3 Setting In main menu, highlight setting icon and double click mouse. System setting interface is shown as below. See F igure 5-2. X 3 5 6 H 3 5 6 H 3 5 6 H 3 6 0 H Figure 5-2 5.3.1 General General setting includes the following items.

  • Page 54: Encode

    while the next HDD is no empty, then system stops recording, If the current HDD is full and then next HDD is not empty, then system overwrites the previous files. Pack duration: Here is for you to specify record duration. The value ranges from 60 to 120 minutes.
  • Page 55 Encode setting includes the following items. See F igure 5-6. X 3 6 1 H 3 6 1 H 3 6 1 H 3 6 5 H Please note some series do not support extra stream. Channel: Select the channel you want. Compression: System supports H.264.

  • Page 56: Schedule

    Figure 5-7 5.3.3 Schedule Please refer to chapter 4.4 schedule. 5.3.4 RS232 RS232 interface is shown as below. There are five items. See Figure 5-8 X 3 6 3 H 3 6 3 H 3 6 3 H 3 6 7 H Function: There are various devices for you to select.
  • Page 57 function, IP/Subnet mask/Gateway display as zero. You need to disable DHCP function to view current IP information. Besides, when PPPoE is operating, you can not modify IP/Subnet mask /Gateway. TCP port: Default value is 37777. UDP port: Default value is 37778. HTTP port: Default value is 80.
  • Page 58 Figure 5-11 5.3.5.3 Multiple Cast Setup Multiple-cast setup interface is shown as in F igure 5-12 X 3 6 7 H 3 6 7 H 3 6 7 H 3 7 1 H Figure 5-12 Here you can set a multiple cast group. Please refer to the following sheet for detailed information.
  • Page 59 -Private address space Like the single broadcast address of RFC1918 Can not be used in Internet transmission Used for multiple cast broadcast in limited space. Except the above mentioned addresses of special meaning, you can use other addresses. For example: Multiple cast IP: 235.8.8.36 Multiple cast PORT: 3666.
  • Page 60 Alaska GMT-9 Pacific Time(P.T) GMT-8 American Mountain Time(M.T) GMT-7 American Central Time(C.T) GMT-6 American Eastern Time(E.T) GMT-5 Atlantic Time GMT-4 Brazil GMT-3 Middle Atlantic Time GMT-2 Figure 5-14 5.3.5.6 DDNS Setup DDNS setup interface is shown as in F igure 5-15 X 3 7 0 H 3 7 0 H 3 7 0 H 3 7 4 H You need a PC of fixed IP in the internet and there is the DDNS software running in this PC.
  • Page 61 Private DDNS function shall work with Dahua DDNS server and Dahua Professional Surveillance Software (PSS). 5.3.5.7 DNS There are two modes: Manual setup and auto setup Manual Setup You can double click DNS to set DNS address manually. See F igure 5-16. 3 7 5 H Please input preferred DNS server IP and alternative DNS server IP.
  • Page 62 Figure 5-18 You can use a PC or FTP login tool to test setup is right or not. For example, you can login user ZHY to F TP://10.10.7.7 and then test it can modify or delete H 1 4 0 H 1 4 0 H 1 4 0 H 1 4 2 H T U U T H folder or not.

  • Page 63: Alarm

    Figure 5-20 Please highlight the icon in front of Enable to activate FTP function. Here you can input FTP server address, port and remote directory. When remote directory is null, system automatically create folders according to the IP, time and channel. User name and password is the account information for you to login the FTP.
  • Page 64 Transparency: Here is for you to adjust transparency. The value ranges from 128 to 255. Channel name: Here is for you to modify channel name. System max support 25-digit (The value may vary due to different series). Please note all your modification here only applies to DVR local end.

  • Page 65: Default

    Figure 5-23 In tour mode, you can see the following interface. On the right corner, right click mouse or click shift button, you can control the tour. There are two icons: stands for enabling window switch stands for enabling window function. See F igure 5-24 X 3 8 0 H 3 8 0 H 3 8 0 H 3 8 4 H Figure 5-24...

  • Page 66: Search

    Please highlight icon to select the corresponding function. After all the setups please click save button, system goes back to the previous menu. Warning! System menu color, language, time display mode, video format, IP address, user account will not maintain previous setup after default operation! Figure 5-25 5.4 Search Please refer to chapter 4.3 Search.

  • Page 67: Abnormity

    You can see current HDD type, status, capacity and record time. When HDD is working properly, system is shown as O. When HDD error occurred, system is shown as X. You can select HDD mode from the dropdown list such as read-only or you can erase all data in the HDD.

  • Page 68: Alarm Output

    Show message: system can pop up the message in the local screen to alert you when alarm occurs. Alarm upload: System can upload the alarm signal to the network (including alarm centre) if you enabled current function. Send email: System can send out email to alert you when alarm occurs. Figure 5-29 5.5.3 Alarm Output Here is for you to set proper alarm output.

  • Page 69: Auto Maintain

    Add new user Modify user Add group Modify group Modify password. For account management please note: System account adopts two-level management: group and user. No limit to group or user amount. For group or user management, there are two levels: admin and user. The user name and group name can consist of eight bytes.

  • Page 70: Tv Adjust

    Figure 5-32 5.5.7 TV Adjust Here is for you to adjust TV output setup. See F igure 5-33 X 3 8 9 H 3 8 9 H 3 8 9 H 3 9 3 H Please drag slide bar to adjust each item. After all the setups please click OK button, system goes back to the previous menu.

  • Page 71: Hdd Information

    5.6.1 HDD Information Here is to list hard disk type, total space, free space, video start time and status. See F igure 5-35 X 3 9 1 H 3 9 1 H 3 9 1 H 3 9 5 H ○...

  • Page 72: Log

    Figure 5-36 5.6.3 Log Here is for you to view system log file. System lists the following information. See F igure 5-37 X 3 9 3 H 3 9 3 H 3 9 3 H 3 9 7 H Log types include system operation, configuration operation, data management, alarm event, record operation, log clear and etc.

  • Page 73: Shutdown

    Here is for you manage online users. See F igure 5-39 X 3 9 5 H 3 9 5 H 3 9 5 H 3 9 9 H You can disconnect one user or block one user if you have proper system right. Max disconnection setup is 65535 seconds.

  • Page 74: About Auxiliary Menu

    6 About Auxiliary Menu Go to Pan/Tilt/Zoom Menu In the one-window surveillance mode, right click mouse (click “fn” Button in the front panel or click AUX key in the remote control). The interface is shown as below: See F igure 6-1 X 3 9 7 H 3 9 7 H 3 9 7 H 4 0 1 H Figure 6-1 Click Pan/Tilt/Zoom, the interface is shown as in...

  • Page 75: Preset /Patrol / Pattern /Border Function

    In the middle of the eight direction arrows, there is a 3D intelligent positioning key. See F igure X 4 0 1 H 4 0 1 H 4 0 1 H 4 0 5 H . Please make sure your protocol supports this function and you need to use mouse to control.

  • Page 76: Preset Setup

    Figure 6-6 6.2.1 Preset Setup Note: The following setups are usually operated in the F igure 6-2 F igure 6-5 F igure 6-6 X 4 0 5 H 4 0 5 H 4 0 5 H 4 0 9 H X 4 0 6 H 4 0 6 H 4 0 6 H 4 1 0 H X 4 0 7 H 4 0 7 H 4 0 7 H 4 1 1 H F igure 6-2...

  • Page 77: Activate Pattern Function

    You can memorize all these setups as pattern 1. Figure 6-9 6.2.6 Activate Pattern Function F igure 6-6 input mode value in the No. blank, and click pattern button. X 4 1 9 H 4 1 9 H 4 1 9 H 4 2 3 H 6.2.7 Border Setup F igure 6-5 , click border button.
  • Page 78 Figure 6-11...

  • Page 79: Web Client Operation

    7 WEB CLIENT OPERATION Please note all the operations here are based on our 4-ch DVR. There might be slightly difference in the interface due to different series. 7.1 Network Connection Before web client operation, please check the following items: Network connection is right DVR and PC network setup is right.
  • Page 80 Figure 7-2 After installation, the interface is shown as below. See F igure 7-3 X 4 3 0 H 4 3 0 H 4 3 0 H 4 3 4 H Please input your user name and password. Default factory name is admin and password is admin. Note: For security reasons, please modify your password after you first login.

  • Page 81: Real-Time Monitor

    Section 1: there are five function buttons: configuration (chapter 7.3), search (chapter 7.4), alarm (chapter 7.5), about (chapter 7.6), log out (chapter 7.7). Section 2: there are channel number and three function buttons: start dialog and local play, refresh. Section3: there are PTZ (chapter 7.2.2), color (chapter 7.2.3) button and you can also select picture path and record path.
  • Page 82 In section 2, left click the channel name you want to view, you can see the corresponding video in current window. On the top left corner, you can view device IP, channel number, network monitor bit stream. Figure 7-7 On the top right corer, there are six unction buttons. See F igure 7-8 X 4 3 4 H 4 3 4 H 4 3 4 H 4 3 8 H 3 4 5...

  • Page 83: Ptz

    Refresh You can use button to refresh camera list. Start Dialogue You can click this button to enable audio talk. Click 【▼】 to select bidirectional talk mode. There are two options: DEFAULT/G711a. Please note, the audio input port from the device to the client-end is using the first channel audio input port.
  • Page 84 3D Intelligent Positioning You can click this icon to display or hide the PTZ control platform. Figure 7-11 7.2.2.1 Direction key and 3D positioning key In Figure 7-10, there are eight direction keys. In the middle of the eight direction keys, there is a 3D intelligent positioning key. Click 3D intelligent positioning key, system goes back to the single screen mode.
  • Page 85 Figure 7-12 7.2.2.4 Auto Scan F igure 7-12 , move the camera to you desired location and then click left limit button. X 4 3 9 H 4 3 9 H 4 3 9 H 4 4 3 H Then move the camera again and then click right limit button to set a right limit. 7.2.2.5 Pattern F igure 7-12 , you can input pattern value and then click start record button to begin PTZ...

  • Page 86: Color

    Figure 7-13 7.2.3 Color Click color button in section 3, the interface is shown as F igure 7-14 X 4 4 4 H 4 4 4 H 4 4 4 H 4 4 8 H Here you can select one channel and then adjust its brightness, contrast, hue and saturation. (Current channel border becomes green).

  • Page 87: Configure

    Figure 7-16 Click record path button, you can see an interface is shown as in F igure 7-17 X 4 4 8 H 4 4 8 H 4 4 8 H 4 5 2 H Please click choose button to modify path. Figure 7-17 Click reboot button, system pops up the following dialogue box.
  • Page 88 Figure 7-19 7.3.1.2 HDD information Here you can view local storage status and network status including, free capacity and total capacity. See F igure 7-20 X 4 5 0 H 4 5 0 H 4 5 0 H 4 5 4 H Figure 7-20 7.3.1.3 Log Here you can view system log.

  • Page 89: System Configuration

    Figure 7-21 Click backup button, the interface is shown as in F igure 7-22 X 4 5 2 H 4 5 2 H 4 5 2 H 4 5 6 H Figure 7-22 Please refer to the following sheet for log parameter information. Parameter Function Log types include: system operation, configuration operation, data...
  • Page 90 7.3.2.1 General Setup Here you can set system time, record length, video format and etc. See F igure 7-23 X 4 5 3 H 4 5 3 H 4 5 3 H 4 5 7 H Figure 7-23 Figure 7-24 Figure 7-25 Please refer to the following sheet for detailed information.
  • Page 91 Parameter Function Here is for you to modify system time. Please click Save button after System your completed modification Time Sync PC You can click this button to save the system time as your PC current time. Here you can select data format from the dropdown list. Data Format Please select separator such as –...
  • Page 92 Figure 7-26 Figure 7-27 Please refer to the following sheet for detailed information. Parameter Function Here is for you to select a monitor channel. Channel Here is to display current channel name. You can modify it. Channel Name Compression H.264 Main Stream It includes main stream, motion stream and alarm stream.
  • Page 93 Parameter Function Audio/Video For the main stream, recorded file only contains video by default. You need to draw a circle here to enable audio function. For extra stream, you need to draw a circle to select the video first and then select the audio if necessary.
  • Page 94 Parameter Function Copy It is a shortcut menu button. You can copy current channel setup to one or more channels. The interface is shown as in F igure 7-28 X 4 5 5 H 4 5 5 H 4 5 5 H 4 5 9 H Save You can click save button after you complete setup for one channel, or you can complete the whole setups and then click save button.
  • Page 95 Figure 7-30 Please refer to the following sheet for detailed information. Parameter Function Please select a channel first. Channel Pre-record Please input pre-record value here. System can record the three to five seconds video before activating the record operation into the file. (Depends on data size). Setup F igure 7-29 , click set button, you can go to the corresponding...
  • Page 96 Figure 7-31 Please refer to the following sheet for detailed information. Parameter Function RS232 There are two options: COM 01 and keyboard. Console is to upgrade the program or debug via COM or Function mini terminal software. Keyboard: COM control protocol. You can use keyboard to control DVR via COM.
  • Page 97 Figure 7-32 Please refer to the following sheet for detailed information. Parameter Function Ethernet Please select the network card first. DHCP Dynamically get IP address. You can get the device IP from the DHCP server if you enabled this function. TCP Port Default value is 37777.
  • Page 98 Figure 7-33 Please refer to the following sheet for detailed information. Parameter Function Input server address and then enable this function. SMTP Server Port Default value is 25. You can modify it if necessary. The sender email account user name. User Name The sender email account password.
  • Page 99 Figure 7-34 Please refer to the following sheet for detailed information. Parameter Function Server Type You can select DDNS protocol from the dropdown list and then enable DDNS function. The private DDNS protocol means you use your self-defined private protocol to realize DDNS function. Server IP DDNS server IP address Server Port...
  • Page 100 Figure 7-35 Please refer to the following sheet for detailed information. Parameter Function Please select network storage protocol and then enable NAS enable NAS function. Server IP Input remote storage server IP address. Input Remote storage server port number. Port Log in user account.
  • Page 101 transmission only and its port shall be 123.The update interval ranges from 1 to 65535. Default value is 10 minutes. Figure 7-36 You can refer to the following sheet for time zone information. City /Region Name Time Zone London GMT+0 Berlin GMT+1 Cairo...
  • Page 102 Figure 7-37 7.3.2.6 Alarm Alarm setup interface is shown as in F igure 7-38 X 4 6 7 H 4 6 7 H 4 6 7 H 4 7 1 H Please make sure you have connected the corresponding alarm output device such as the light, buzzer and etc.
  • Page 103 Figure 7-39 Please refer to the following sheet for detailed information. Parameter Function Event It includes local alarm/network alarm. Type Local alarm: Device detects alarm from input port. Network: Device detects alarm from network. Alarm in Select corresponding alarm channel. Enable You need to draw a circle here so that system can detect the alarm signal.
  • Page 104 Parameter Function Capture You need to input capture channel number so that system can backup snapshot file when alarm occurs. Copy It is a shortcut menu button. You can copy current channel setup to one or more (all) channels. Save You can click save button after you complete setup for one channel, or you can complete the whole setups and then click save button.
  • Page 105 Figure 7-41 Please refer to the following sheet for detailed information. Parameter Function Event There are three types: Motion detection/video loss/Camera Masking. Type Channel Select channel name from the dropdown list. Enable You need to draw a circle to enable motion detection function. There are six levels.
  • Page 106 Parameter Function Here you can set PTZ movement when alarm occurs. Such as go to Activation preset x when there is an alarm. Capture You need to input capture channel number so that system can backup motion detection snapshot file. Copy It is a shortcut menu button.
  • Page 107 Parameter Function Data Bit Default setup is 8. Please set according to the speed dome dial switch setup. Default setup is 1. Please set according to the speed dome dial switch Stop bit setup. Parity Default setup is none. Please set according to the speed dome dial switch setup.

  • Page 108: Advanced

    7.3.3 Advanced 7.3.3.1 HDD Management HDD management includes net storage management and local storage management. Please note, if you want to use local storage function, your storage device need to support current function. Please select the storage device first and then you can see the items on your right become valid. You can check the corresponding item here.
  • Page 109 Figure 7-45 Important The alarm output port should not be connected to high power load directly (It shall be less than 1A) to avoid high current which may result in relay damage. Please use the co contactor to realize the connection between the alarm output port and the load. Please refer to the following sheet for detailed information.
  • Page 110 Figure 7-46 Please refer to the following sheet for detailed information. Parameter Function System enables auto record function as you set in record schedule Auto setup. Enable corresponding channel to record no matter what period Manual applied in the record setup. Stop current channel record no matter what period applied in the Stop record setup.
  • Page 111 Figure 7-47 7.3.3.5 Auto Maintenance Here you can select auto reboot and auto delete old files interval from the dropdown list. See F igure 7-48 X 4 7 6 H 4 7 6 H 4 7 6 H 4 8 0 H Figure 7-48...
  • Page 112 7.3.3.6 Snapshot Snapshot interface is shown as in F igure 7-49 X 4 7 7 H 4 7 7 H 4 7 7 H 4 8 1 H Figure 7-49 Please refer to the following sheet for detailed information. Parameter Function Channel It is the monitor channel.

  • Page 113: Additional Function

    Figure 7-50 Please refer to the following sheet for detailed information. Parameter Function Event The abnormal events include: no disk, no space, disk error, net error. Type You need to draw a circle to enable this function. Normal The corresponding alarm activation output channel when alarm occurs, There are three channels.

  • Page 114: Search

    Figure 7-51 7.4 Search Click search button, you can see an interface is shown as in F igure 7-52 X 4 7 9 H 4 7 9 H 4 7 9 H 4 8 3 H Please select record playback mode, and then select start time, end time and channel. Then please click search button, you can see the corresponding files in the list.
  • Page 115 Figure 7-52 Select the file(s) you want to download and then click download button, system pops up a dialogue box shown as in F igure 7-53 , then you can specify file name and path to download the X 4 8 0 H 4 8 0 H 4 8 0 H 4 8 4 H file(s) to your local pc.
  • Page 116 Figure 7-55 Please refer to the following sheet for detailed information. Type Parameter Function Type Record Search general record, alarm record and motion detection record. Alarm Search alarm record. Motion Search motion detection record. Detection Local Search local record. Snapshot Search snapshot file.

  • Page 117: Alarm

    2: Pause 3: Stop 4: Slow play 5: Fast play Playback device IP address and channel number. Playback control bar Figure 7-56 7.5 Alarm Click alarm function, you can see an interface is shown as in F igure 7-57 X 4 8 3 H 4 8 3 H 4 8 3 H 4 8 7 H Here you can set device alarm type and alarm sound setup.

  • Page 118: About

    Figure 7-57 Please refer to the following sheet for detailed information. Please make sure current device can upload the alarm. Type Parameter Function Alarm Video loss System alarms when video loss occurs. Type Motion detection System alarms when motion detection alarm occurs, Disk full System alarms when disk is full.

  • Page 119: Log Out

    Figure 7-58 7.7 Log out Click log out button, system goes back to log in interface. See F igure 7-59 X 4 8 5 H 4 8 5 H 4 8 5 H 4 8 9 H You need to input user name and password to login again. Figure 7-59 7.8 Un-install Web Control You can use web un-install tool “uninstall web.bat”...

  • Page 120: Professional Surveillance System

    8 Professional Surveillance System Besides Web, you can use our Professional Surveillance Software (PSS) to login the device. For detailed information, please refer to PSS user’s manual.

  • Page 121: Faq

    9 FAQ 1. DVR can not boot up properly. There are following possibilities: Input power is not correct. Power connection is not correct. Power switch button is damaged. Program upgrade is wrong. HDD malfunction or something wrong with HDD ribbon. Seagate DB35.1，DB35.2，SV35 or Maxtor 17-g has compatibility problem.
  • Page 122 DVR color or brightness setup is not correct. 6. Can not search local records. There are following possibilities: HDD ribbon is damaged. HDD is broken. Upgraded program is not compatible. The recorded file has been overwritten. Record function has been disabled. 7.
  • Page 123 PTZ decoder and DVR address is not compatible. When there are several decoders, please add 120 Ohm between the PTZ decoder A/B cables furthest end to delete the reverberation or impedance matching. Otherwise the PTZ control is not stable. The distance is too far. 12.
  • Page 124 System uses too much CPU resources. Please stop record first and then begin backup. Data amount exceeds backup device capacity. It may result in burner error. Backup device is not compatible. Backup device is damaged. 17. Keyboard can not control DVR. There are following possibilities: DVR serial port setup is not correct Address is not correct...
  • Page 125 There is no DivX503Bundle.exe control when you play the file transformed to AVI via media player. No DivX503Bundle.exe or ffdshow-2004 1012 .exe in Windows XP OS. 23. Forget local menu operation password or network password Please contact your local service engineer or our sales person for help. We can guide you to solve this problem.

  • Page 126: Appendix A Hdd Capacity Calculation

    Appendix A HDD Capacity Calculation Calculate total capacity needed by each DVR according to video recording (video recording type and video file storage time). Step 1: According to Formula (1) to calculate storage capacity that is the capacity of each channel needed for each hour, unit Mbyte.

  • Page 127: Appendix B Compatible Usb Drive List

    Appendix B Compatible USB Drive List NOTE: Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below. If you use the USB drive, please confirm the format FAT or FAT32. Manufacturer Model Capacity Sandisk Cruzer Micro 512M Sandisk...

  • Page 128: Appendix C Compatible Cd/Dvd Burner List

    Appendix C Compatible CD/DVD Burner List NOTE: Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below. And you can use the USB cable with the model recommended to set USB burner. Manufacturer Model Port Type Type Sony...

  • Page 129: Appendix D Compatible Sata Hdd List

    Appendix D Compatible SATA HDD List NOTE: Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below. And SATA HDD should be used for the DVR with SATA port. Port Manufacturer Series Model Capacity Mode Seagate Barracuda.10...
  • Page 130 Western Digital Cariar SE16 WD5000KS2 500G SATA Western Digital Cariar SE16 WD4000KD2 400G SATA Western Digital Cariar SE16 WD3200KS2 320G SATA Western Digital Cariar SE16 WD2500KS2 250G SATA Western Digital RE series WD5000ABYS 500G SATA Western Digital Caviar Green series WD20EADS SATA Samsung...

  • Page 131: Appendix E Compatible Displayer List

    Appendix E Compatible Displayer List Please refer to the following sheet form compatible displayer list. Brand Model Dimension (Unit: inch) BENQ（LCD） ET-0007-TA 19-inch (wide screen) DELL（LCD） E178FPc 17-inch BENQ（LCD） Q7T4 17-inch BENQ（LCD） Q7T3 17-inch LENOVO（LCD） LXB-L17C 17-inch SANGSUNG（LCD） 225BW 22-inch (wide screen) LENOVO(CRT) LXB-FD17069HB 17-inch...

  • Page 132: Appendix Fearthing

    Appendix F Earthing 1. What is the surge? Surge is a short current or voltage change during a very short time. In the circuit, it lasts for microsecond. In a 220V circuit, the 5KV or 10KV voltage change during a very short time (about microseconds) can be called a surge.
  • Page 133 work. The signal lightning arrester has many specifications, and widely used in many devices such as telephone, network, analog communication, digital communication, cable TV and satellite antenna. For all the input port, especially those from the outdoor, you need to install the signal lightning arrester. Antenna feed cable lightning arrester: It is suitable for antenna system of the transmitter or the device system to receive the wireless signal.
  • Page 134 Mixed ground: The mix ground consists of the feature of the one-point ground and multiple-point ground. For example, the power in the system needs to use the one-point ground mode while the radio frequency signal requires the multiple-point ground. So, you can use the following figure to earth.
  • Page 135 The monitor system usually can adopt the one-point ground. Please connect the ground end of 3-pin socket in the monitor system to the ground port of the system (protection ground cable) 4. The shortcut way to check the electric system using the digital multimeter For 220V AC socket, from the top to the bottom, E (ground cable), N (neutral cable), L(live cable).
  • Page 136 For L (live cable) Turn the digital multimeter to 750V AC, use your one hand to hold the metal end, and then the other hand insert the pen to the L port of the socket. See the following figure. If the multimeter shows 120, then you can see current live cable connection is standard.

This manual is also suitable for:

Xts-dvr7204sXts-dvr7208sXts-dvr7216s

Table of Contents
