Your Digital Box

Front view

Back view

AERIAL INPUT
Aerial Input.
Connect the aerial
to this socket
4
Serial port
TV Scart
(Service use only)
Connection to TV
SERVICE ONLY
AERIAL OUTPUT RS232
Aerial Output.
Connect the supplied
RF cable to the TV.
TV VCR
AUX Scart
for connection to a VCR
or a DVD Recorder
Standby button
Coaxial Digital
Right Audio Out
SPDIF R
VIDEO L
Left Audio
Out
Composite Video
