Escort PASSPORT 8500ci Quick Install Manual

R A D A R • L A S E R • S A F E T Y • D E T E C T O R
S i m p l e . E a s y . I n s t a l l e d .
Q U I C K - I N S T A L L E D
PASSPORT 8500ci Comes Complete
Front Radar/Laser Receiver Miniature Display Controller
• Miniature weather-proof Radar/Laser • Display Controller mounts easily to
Receiver instrument pod,dashboard or
console
• Universal mounting bracket with
stainless steel hardware • Optional hidden display included
• Built-in 16 foot shielded cable with
Interface
water proof connector
• 12 nylon wire ties to secure cable • Central module connects to
switched 12-volt power and ground
• All components plug directly in
using modular connections
• 3M connector taps into existing
vehicle wiring
P R O T E C T I O N
Documentation
• Comprehensive Owner's Manual
• Installation Manual
Built-in Diagnostics
• Confirms all components are
operational
• Fully compatible with Laser Shifters
Important Notes

Read This First
Please read both sides of these
instructions before starting your
installation.
For the easiest trouble-free
installation,install the Interface
first,and wire it to a 12-volt
switched circuit.
1
Installation of this system
12-volt installation
requires some experience and
experience is
expertise in automotive
suggested
electronics.Car Audio specialists
and many new car dealers can
install this for you.
2
If you choose to install it
yourself without expertise in
automotive electronics,please
note that it can cause personal
injury or damage to your vehicle.
To get the best possible
Performance
performance,installation of the
Warning
Radar/Laser receiver is critical.
Although radar signals will pass
through some materials,
including plastic,laser signals
will not.For this reason the
receiver must have a clear view
of the road in order to work
properly.
Then before installing the other
components,plug all of them
into the Interface and power up
the unit to confirm proper
operation.
3
If your vehicle is damaged
during installation,its safety
systems may be compromised
and could cause personal injury
or property damage.
4
Improper installation may
also void PASSPORT's warranty.
NOTE:INSTALLTHE RECEIVER
HORIZONTALLY AND LEVEL,
WITH A CLEAR VIEW OFTHE
ROAD.
