- Page 1 CHP-03AR/L/U Water Filtration Device • This product can not be used if the voltage is different from that mentioned in the rating plate. • For your safety and proper use of the product, please read this User’s Manual before use. • Warranty card is included in this User’s Manual.
- Page 2 FEATURES Sleep Sleep 1. Power saving function using the light sensor If you press the "Sleep" button, as it decreases the driving times of the motor and the heater at night automatically, the amount of the power consumption is decreased. Sleep 2. Booster pump for boosting the main water (CHP-03AR) It equipped the booster pump to show the uniform filtering Booster abilities in the region with the low main water pressure. Pump 3. Low water level detecting function Water Level It decreases the power consumption by stopping the working of the motor and the heater when the water level in the dtorage tank Water Level is lowered due to the water failure.
-
Page 3: Table Of Contents
DEAR CUSTOMERS Coway Water Filtration Device. Thank you for using our Please read this Users’ Manual to use and maintain the product correctly. If you encounter a problem while using the product, you may solve the problem referring to the User’s Manual. As this manual contains the product warranty card, please keep it in a safe place. This system (CHP-03AR/L/U) conforms to NSF/ANSI 42 for aesthetic chlorine reduction and NSF/ANSI 53 for VOC reduction as verified and substantiated by test data. This system (CHP-03AR/L) conforms to NSF/ANSI 58 for the reduction of pentavalent arsenic, barium, cadmium, selenium, radium 226/228, trivalent chromium, hexavalent chromium, lead, nitrate/nitrite as verified and substantiated by test data. This system (CHP-03AR/L) registered in California. See performance data sheet for individual contaminants and reduction performance. This system (CHP-03AR/L) is acceptable for treatment for influent concentrations of no more than 27 mg/L nitrate and 3 mg/L nitrite in combination measured as N and is certified for nitrate/nitrite reduction only for water supplies with a pressure of 280 kPa(40 psi) or greater. CONTENTS FOR INFORMATION HOW TO USE SAFETY INFOrMATION . . . . . . . . . . . . . . . . . . . 3 INSTALLATION prECAuTIONS . -
Page 4: Safety Information
SAFETy INFORMATION Be careful to keep this safety information. Please read this information to prevent property loss and ensure your safety. If not observed, If not observed, If not observed, slight serious injury or serious injury or injury or property even death could property damage damage could occur. Danger Warning Caution occur. could occur. Electricity safety Do not use a damaged Do not pull the power power cord or plug, and cord . -
Page 5: Installation Safety
Otherwise, electric shock or fire may occur as a result. Otherwise, electric shock or fire may occur as a result. In the case the power cord is damaged, do not replace the cord yourself . Call Coway Service Center to have it replaced . Otherwise, electric shock or fire may occur as a result. Installation safety Avoid installing the Do not install near a system in places where heating device . -
Page 6: Operation Safety
SAFETy INFORMATION If not observed, If not observed, If not observed, slight serious injury or serious injury or injury or property even death could property damage damage could occur. Danger Warning Caution occur. could occur. Operation safety When the water is coming If our product produces a inside of the product or strange noise or odd smell, there is a puddle on the immediately unplug from product, call Service Center the electrical outlet and... -
Page 7: Others
Danger Warning Caution Others Clean after unplugging . Do not clean by spraying the water directly or don’t Otherwise, electric shock or wipe the product using the fire may occur as a result. benzene and thinner . Otherwise, electric shock or fire may occur as a result. Do not repair, Do not use filtered water disassemble, for the water exchange of or modify . -
Page 8: Parts Name
PARTS NAME Front Front cover Hot water safety button Jog shuttle Indication part Operation part Cold/Room water Changeover faucet Cup-touch lever Front draining door Hot water safety faucet Gutter Rear Top cover Rear cover Power cord Radiator Outlet(Blue, CHP-03AR/L) Inlet(Orange) -
Page 9: Water Filtration Process
WATER FILTRATION PROCESS The filter is the core technology of the filtration system. If you don’t use qualifying filter or if you use an old filter that has expired, the system performance may degrade. The 5-step water filtering system (CHP-03AR/L) STEp 1, 2 : NEO-SENSE FILTEr This neo-sense filter has the function to reduce aesthetic chlorine, odor, volatile organic compounds(VOC's). STEp 3 : rO MEMbrANE FILTEr RO membrane filter has the function to reduce water contaminants such as pentavalent arsenic, barium, cadmium, selenium, radium 226/228, trivalent chromium, hexavalent chromium, lead, nitrate/nitrite. STEp 4 : INNO-SENSE FILTEr This inno-sense filter has the functions to reduce smell induction material and to improve taste of water. It also has the function to reduce aesthetic chlorine, volatile organic compounds(VOC's). STEp 5 : ANTIbACTErIAL FILTEr... - Page 10 WATER FILTRATION PROCESS The 6-step water filtering system (CHP-03AR/L) STEp 1, 2 : NEO-SENSE FILTEr This neo-sense filter has the function to reduce aesthetic chlorine, odor, volatile organic compounds(VOC's). STEp 3 : rO MEMbrANE FILTEr RO membrane filter has the function to reduce water contaminants such as pentavalent arsenic, barium, cadmium, selenium, radium 226/228, trivalent chromium, hexavalent chromium, lead, nitrate/nitrite. STEp 4 : pOST-CArbON FILTEr This post-carbon filter has the functions to reduce smell induction material and to improve taste of water. It also has the function to reduce aesthetic chlorine, volatile organic compounds(VOC's). STEp 5 : FINE FILTEr This fine filter has the function to reduce fine particles in the water. STEp 6 : ANTIbACTErIAL FILTEr...
- Page 11 The 5-step water filtering system (CHP-03AU) STEp 1, 2 : NEO-SENSE FILTEr This neo-sense filter has the function to reduce aesthetic chlorine, odor, volatile organic compounds(VOC's). STEp 3 : INNO-SENSE FILTEr This inno-sense filter has the functions to reduce smell induction material and to improve taste of water. It also has the function to reduce aesthetic chlorine, volatile organic compounds(VOC's). STEp 4 : uF MEMbrANE FILTEr STEp 5 : ANTIbACTErIAL FILTEr NEO-SENSE INNO-SENSE UF MEMBRANE ANTIBACTERIAL FILTER FILTER FILTER FILTER * ANTIBACTERIAL FILTER...
- Page 12 WATER FILTRATION PROCESS The 5-step water filtering system (CHP-03AU) STEp 1, 2 : NEO-SENSE FILTEr This neo-sense filter has the function to reduce aesthetic chlorine, odor, volatile organic compounds(VOC's). STEp 3 : pOST-CArbON FILTEr This post-carbon filter has the functions to reduce smell induction material and to improve taste of water. It also has the function to reduce aesthetic chlorine, volatile organic compounds(VOC's). STEp 4 : uF MEMbrANE FILTEr STEp 5 : ANTIbACTErIAL FILTEr NEO-SENSE POST-CARBON UF MEMBRANE ANTIBACTERIAL FILTER FILTER FILTER...
-
Page 13: Installation Precautions
INSTALLATION PRECAUTIONS The summary for the proper installation of the water filtration device 1 . Close main water supply valve to separate the faucet . 2 . Wind the teflon tape on the adaptor and fit it to the pipe . Do not turn the water pipe . - Page 14 INSTALLATION PRECAUTIONS Please check before use! Only connect the power cord to the voltage rating that matches it on the rating plate . • Open the main water supply valve. The main water must be supplied to operate the water filtration device normally. • After installing the product Get rid of the saved water above the full water in the inner water tank 2 times or more to use. • When the indicator in the indication part is turned off When the indicator in the indication part is turned off, check if the power supply was stopped due to the power failure or other cause. • Regularly filter replacement It is important to replace the filter regularly to maintain water quality as it is designed. If the filter is overused beyond its service life, the performance of the water filtration device deteriorate, Do not miss the filter replacement cycle. • When you didn’t use for a long time If you saved the water for a long time or you didn’t use, drain the water inside of the water filtration device completely and remove the newly filtered water one time to use.
-
Page 15: Operation / Indication Part
OPERATION / INDICATION PART Indication part/Operation part Indication part Operation part Hot water Hot water function Water level indicator Water indicator Power temperature indicator level Cold water function indicator Sleep mode indicator Cold water temperature indicator Hot water function indicator Hot water temperature When you select hot water indicator mode, the indicator is turned The indicator is turned on according to the hot water temperature. As many indicators are turned on, the Water level indicator hot water becomes hot more and more. The indicator is lightened according to the water level Sleep mode indicator of the storage tank. - Page 16 OPERATION / INDICATION PART Operation part Water level Cold water function selection button Hot water function selection button Sleep mode selection button Light sensor Cold water function Hot water function selection button selection button When you want to select/ When you want to deselect cold water select/deselect Hot function, use it. water function, use it. Sleep mode Light sensor It is the sensor sensing selection button the light around the When you wish to select/ product.
- Page 17 To use the cold water function Press the cold water function selection button and check if cold water mode indicator in the indication part is turned on. If you want to turn off the cold water mode, press the selection button for several seconds. You can drink the cold water when you turn on the cold water function and about 1 hour is passed. To use the hot water function Press the hot water function selection button, check if the hot water function indicator in the indication part is turned on. If you want to turn off the hot water mode, please press the selection button for several seconds. You can drink the hot water when you turn on hot water function and 30 minutes is passed. To use the sleep mode When you press the sleep mode selection button, as the sleep mode indicator is turned on and the number of the motor driving is decreased at night, the power consumption is decreased. When the sleep mode is operated, the cold water become less cool.
-
Page 18: How To Use
HOW TO USE To drink the cold water press the cold water selection button and check the lightening status in the cold water function indicator . Turn the jog shuttle to the left in the cold water/room water changeover faucet and push the cup-touch lever. ▶ If the cold water doesn’t come from the water filtration device, check if the cold water mode indicator in the indication part is turned on (See P.16). Tips To drink the hot water press the hot water selection button and check the lightening status in the hot water function indicator . -
Page 19: To Drink The Room Water
To drink the room water Turn the jog shuttle to the right in the cold water/room water changeover faucet and push the cup-touch lever. ▶... -
Page 20: Installation
INSTALLATION Follow the instruction for installation Main water 2 cooling stopper supply valve voltage rating that matches it on the rating plate. Connect the orange color inlet tubing to the tap water supplying pipe. Connecting the outlet tubing Inlet tubing(Orange) Outlet tubing (Blue, CHP-03AR/L) - Page 21 Water filtration device installation place 2 Please install at the place where it is 10 cm or more off from the wall and the bottom is flat and firm. After installing the water filtration system Get rid of the filtered water above the fulled water 2 times or more necessarily after installing. Cold water plumbing Please connect to the cold water pipe necessarily. (If you connect to the warm water pipe, the filter can be damaged.) Movement and installation When the position is moved, connect the power cord when 30 minutes passes after installing. To maintain optimal product performance, consult a Coway engineer for the detailed installation methods. Tips There may be some water remaining inside of the filter which was used to test the product during inspection process at the factory. Please feel at easy and use as it isn’t the used product. Don’t reuse the main water supply valve and hose that was previously used when you install the product.
-
Page 22: Cleaning Method
CLEANING METHOD Storage tank 1 . Turn off by pressing cold water/hot water mode selection button in the front of the product for 2~3 seconds or more and unplug the power cord . Close the main water supply valve . 2 . - Page 23 4 . Shake and clean an antibacterial filter * in the taken water by rotating and separating it from the cold water/room water separation membrane 5 . please wipe the surface of the storage tank with soft clothes . 6 . use the storage tank after cleaning it with the taken water, draining completely using the draining hose, and emptying the newly filtered water one time or more .
-
Page 24: Gutter
CLEANING METHOD 8 . Open the main water supply valve after closing the upper cover and plugging the power cord . please operate the water filtration device again by pressing cold water/hot water mode selection button in the front of the product after checking if the water is coming from the cold water/room water extraction faucet and the hot water extraction faucet . -
Page 25: Filter Replacement
FILTER REPLACEMENT Filter The life of the water filtration system is the filter. It isn’t the legitimated filter or you use too long even if it is the legitimated filter, the filter performance can be lowered. Please change to the legitimated filter according to the replacement cycle. Filter replacement cycle If the filter is not regularly replaced, it may degrade the water quality from the product. The filter replacement cycle depending on the main water quality can be shortened rater than the expected replacement cycle. CHp-03Ar Part No. Names of Filter Usable Period WJNF11-S Neo-sense filter 6 months WJMF11-50 RO Membrane filter (CHP-03AR) 24 months WJMF11-30-S RO Membrane filter (CHP-03AL) 24 months WJIF11 Inno-sense filter 18 months / WJCF11-POST / Post-carbon filter WJFF 7 Fine filter 18 months... -
Page 26: Filter Replacement Method
FILTER REPLACEMENT METHOD 1 . Close the main water supply valve after unplugging the power cord, and drain the water inside of the water filtration device (See p .21) . 2 . remove the gutter, and separate the front cover by pressing down, and unplug and separate all the cables connected completely . - Page 27 3 . After separating the fitting connected to the filter trying to replace, please replace the filter . (Separate the fitting using the proper tool .) By changing the filter and connecting the fitting and the hose precisely, check that there is no leakage and drain the first filtered water necessarily. Tips 4 . After connecting all the separated cables, fit a groove in the front cover and close with pressing it down .
-
Page 28: Troubleshooting
TROUBLESHOOTING The water filtration device may operate abnormally due to minor causes not because of the product malfunction but because of the fact that the user is not familiar with the product use. In such a case, problems can be solved easily even without the help from the Service Center by checking the following items. If you can’t solve the problem after checking the following items, please call the Service Center. Symptom Check Measures to take • Did you clean the storage tank? Clean the storage tank. The water tastes • You didn’t use the water filtration device Get rid of the saved water and clean the weird. for a long time. storage tank. • Isn’t it about time to change the filter? Request the filter replacement. • Is the water supply cut or isn’t the water Open the main water supply valve. The water doesn’t supply valve closed? come. • Did you miss the filter replacement times? Request the filter replacement. • Isn’t it about time to change the filter? Request the filter replacement. • Does the main power connect to the Connect the power cord to the voltage voltage rating that matches it on the rating that matches it on the rating plate. -
Page 29: Specification
SPECIFICATION Product Water Filtration Device Model CHP-03AR CHP-03AL CHP-03AU Filtration Method RO(Reverse Osmosis) USA : 120 V 60 Hz Power Supply EUROPE : 220 V – 240 V 50/60 Hz Room Water 7.2 L Cold Water 3.61 L Tank Capacity Hot Water 1.2 L Total 12.01 L Dimension 344 mm(W) × 540 mm(D) × 525 mm(H) Working Temperature 5 °C - 35 °C Production Rate 190 L/d (25 °C, 414 kPa) 113 L/d (25 °C, 138 kPa) 1 500 L/d (25 °C, 108 kPa) Working Pressure 69 kPa – 827 kPa 138 kPa – 827 kPa 69 kPa – 827 kPa Net Weight 22.3 kg 19.8 kg... -
Page 30: Water Flow Diagram
WATER FLOW DIAGRAM CHp-03Ar CHp-03AL CHp-03Au The Antibacterial filter contains silver, which is known to inhibit the propagation of microorganisms and to maintain the integrity of the filter. • A fine post carbon filter may be installed instead of an inno-sense filter. For the precise specifications of your product, refer to the data plate on the product. - Page 31 MEMO...
- Page 32 MEMO...
- Page 33 MEMO...
-
Page 34: Warranty Card
WArrANTY CArD Or WArrANTY LETTEr ONE YEAr LIMITED WArrANTY WATEr FIrTrATION DEVICE CHp-03Ar/L/u (“prODuCT”) Model: Serial Number: Customer Name: (“OWNER”) Date of Purchase: What This Warranty Covers: Limitations and Exclusions: Commencing with the date of purchase of the TO THE EXTENT PERMITTED BY APPLICABLE LAW, Product and continuing for a period of one year, COWAY DISCLAIMS ANY OTHER WARRANTY if manufacturing defects in the Product cause the EXPRESS OR IMPLIED, THAN THAT PROVIDED Product to not operate properly for its intended FOR HEREIN. THIS WARRANTY IS IN LIEU OF AND EXCLUDES ALL OTHER WARRANTIES, GUARANTEES, use, then subject to the exclusions, conditions, and... - Page 35 If the Product fails to operate for its intended purpose, then notify Coway or its a) The defect or damage is not caused Representative Agency within 48 hours or by or is the result of : abnormal use or within the next business day after discovery conditions; improper storage, unauthorized of any defect in the Product. The OWNER must modifications or repair; misuse, neglect, give written notice to COWAY no later than accident, alteration, improper installation or thirty (30) days after a defect is discovered or other acts that are not the fault of Coway or should by reasonable diligence have been the manufacturer of the product or that are discovered. Claims under this Warranty will not covered by the manufacturer’s warranty; require proof of purchase by the OWNER. b) The Product has not been altered, modified or repaired without prior written approval of COWAY; c) The OWNER has notified COWAY in writing of any failure of the Product covered by this Warranty within thirty (30) days following such failure; d) There has been no misuse, abuse or negligence with respect to the Product on the part of the OWNER. COWAy Add : Coway co., Ltd. 658, Yugu-Ri, Yugu Eub, Gongju-si, Choongchungnam-Do, Korea Tel. : 82-42-850-7879 Fax. : 82-41-841-7876...
- Page 36 MADE IN KOREA 1004149...
