- Page 1 NP320W OWNER’S GUIDE www.sharkclean.com NP320W_40_IB_ENG_120409_4.indd 1 12-04-09 2:10 PM...
-
Page 2: Important Safety Instructions
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOULD ALWAYS BE OBSERVED, SHOCK OR INJURY: INCLUDING THE FOLLOWING: GENERAL ELECTRICAL SAFETY: READ ALL INSTRUCTIONS BEFORE USING 1. Unplug from electrical outlet when not in use YOUR SHARK LIFT-AROUND PORTABLE ® ™ and before servicing. VAC. - Page 3 GENERAL USE: GENERAL CLEANING: 1. Use only as described in this manual. 1. DO NOT pick up large-sized objects. 2. DO NOT put any objects into openings. DO 2. DO NOT pick up hard or sharp objects such as NOT use with any opening blocked; keep free of glass, nails, screws or coins that could damage dust, lint, hair, and anything that may reduce air the vacuum cleaner.
- Page 4 This manual covers model number: NP320W 40 TECHNICAL SPECIFICATIONS Voltage: 120V., 60Hz Watts: 550 W Amps: 4.6 A TOLL FREE: 1-800-798-7398 NP320W_40_IB_ENG_120409_4.indd 4 12-04-09 2:10 PM...
-
Page 5: Table Of Contents
Contents Thank you for Getting Started ................6 purchasing the How to Use ...................8 Shark ® Maintenance ................9 Lift-Around Checking for Blockages ...............11 ™ Portable Vac. Storing ..................12 Resetting the Motor Thermostat ..........12 Ordering Replacement Parts ............12 Troubleshooting Guide ..............13 Warranty & Registration .............15 www.sharkclean.com... -
Page 6: Getting Started
Getting Started Use the Shark Lift-Around Portable ® ™ FIRST THING’S FIRST, YOU NEED TO KNOW WHAT’S IN THE BOX YOU JUST OPENED: Vac as a stand alone vacuum for spot- Lift-Around Portable Vac cleaning small areas and large piles of debris, ™... - Page 7 STRAIGHT SUCTION NOZZLE (G) NOTE: Always turn the power off before attaching or detaching accessories. Powerful cleaning on low-pile carpets and hardwood floors. REMOVABLE TOOL CADDY (B) FLEXIBLE HOSE (H) Specially designed to hold the crevice tool, dusting brush and upholstery brush for quick access to With the right cleaning tool in place and the Flexible tools when vacuuming and cleaning around the Hose, you can extend your reach into hard-to-clean...
-
Page 8: How To Use
How to Use Pull out to remove tool caddy Align arrows to attach tool caddy Fig. 1 Fig. 2 Fig. 3 Fig. 4 Power Button Fig. 6 Fig. 5 ASSEMBLING THE LIFT-AROUND PORTABLE VAC FOR ADDED COMFORT OR FOR AN EXTENDED ™... -
Page 9: Maintenance
Maintenance To reduce the risk of electric shock, unplug the unit before performing any cleaning, maintenance, or troubleshooting checks. Reassemble all parts securely before operating vacuum. CAUTION: For best results empty the Dust Cup Unplug the vacuum; after each use; empty several times failure to do so might during prolonged usage or when it result in electric shock. - Page 10 Maintenance - cont. COMPONENT MAINTENANCE SCHEDULE Dust Cup Empty each time you vacuum. Pre-Motor Foam Filter Rinse and air dry every month under normal use. Pre-Motor Felt Filter Rinse and air dry every month under normal use. Post-Motor HEPA Filter Clean once every 24 months under normal use.
-
Page 11: Checking For Blockages
Checking for Blockages Locking Latch Turbine Wheel Rotating Fig. 15 Fig. 16 Bristle Brush Blockages may cause your vacuum to overheat and shut down. To prevent this from happening, check potential blockage areas after heavy use or if you detect a loss of suction or poor cleaning performance. CLEANING THE POWER BRUSH DUST CUP •... -
Page 12: Storing
Storing Resetting the Motor Thermostat Your Shark Lift-Around™ Portable Vac is ® equipped with a protective Motor Thermostat. If the motor should overheat, the thermostat shuts off the power. To reset the Motor Thermostat: Press the Power Button to turn the vacuum off. -
Page 13: Troubleshooting Guide
Troubleshooting Guide PROBLEM POSSIBLE REASONS & SOLUTIONS Check Filters to see if they need cleaning. Follow instructions for rinsing and drying the Filters before re-inserting back into the Vacuum. (See “Maintenance” sections for instructions.) Vacuum is not Dust Cup may be full; empty Dust Cup. picking up dirt. - Page 14 Notes TOLL FREE: 1-800-798-7398 NP320W_40_IB_ENG_120409_4.indd 14 12-04-09 2:10 PM...
-
Page 15: Warranty & Registration
Product Registration Please visit www.sharkclean.com or call 1-800-798-7398 to register your new Shark product within ten ® (10) days of purchase. You will be asked to provide the store name, date of purchase and model number along with your name and address. - Page 16 Euro-Pro Operating LLC USA: Newton, MA 02459 CAN: 4400 Bois Franc, St-Laurent, QC H4S 1A7 English: 1-800-798-7398 www.sharkclean.com COPYRIGHT© EURO-PRO OPERATING LLC 2012 PRINTED IN CHINA Illustrations may differ from actual product. NP320W.E.120409.4 NP320W_40_IB_ENG_120409_4.indd 16 12-04-09 2:10 PM...
