American Standard MOMENTS 2506.821 Specification Sheet

2506.801
6-1/16"
(153mm)
5-5/16"
(134.5mm)
MOUNTING
SURFACE
140mm
(5-1/2")
2-1/8" D.
(54mm)
32mm OD
(1-1/4" OD)

GENERAL DESCRIPTION:

Cast brass valve bodies with flexible hose connections for 6"
to 12" (152mm to 305mm) installations. 1/4 turn washerless
ceramic disc valve cartridges. Brass spout. One-half inch
male inlet shanks with brass coupling nuts. 20 inch (500mm)
long flexible stainless steel drain cable is pre-assembled to
spout. Metal Speed Connect
(32mm) tail piece. 1.5 gpm/5.7L/min. maximum flow rate.
Choice of "Euro" style (2506.801) version or individual base
escutcheons (2506.821).
SUGGESTED SPECIFICATION:
Two handle widespread lavatory faucet shall feature cast brass valve bodies with flexible hose connections for 6" to 12"
installations. Shall also feature 1/4 turn washerless ceramic disc valve cartridges. Shall also feature a metal drain body with
stainless steel cable actuation. Fitting shall be American Standard Model #2506.___.___.
© 2008 AS America Inc.
2506.821
6-5/16"
(160.7mm)
1-3/8"
(35mm)
1-3/16" MAX.
(30mm) MAX.
(H)
1/2-14 MALE
N.P.S.M INLETS
® drain body with 1-1/4 inch
TWO-HANDLE WIDESPREAD LAVATORY FAUCET
MODEL NUMBER:
2506.801 Widespread Lavatory
Metal Speed Connect
Metal Lever handles. "Euro" brass deck plate.
2506.821 Widespread Lavatory
Metal Speed Connect Pop-up drain.
Metal Lever handles. Individual base escutcheon.
8"
(203.2mm)
2506.801
1-1/8" D.
(29mm)
(76mm)
(C)
1-3/8"
(35mm)
2506.821
1-3/16" MAX.
(30mm) MAX.
(H)
1/2-14 MALE
N.P.S.M INLETS

PRODUCT FEATURES:

Brass Construction:
with water. Provides the finest surface for application of colors
and finishes.
Ceramic Disc Valve Cartridges:
drip-free performance.
Low Lead:
Meets NSF Standard 61/Section 9 & Prop 65 lead
requirements.
Exclusive Speed Connect Metal Drain:
• Fewer parts. Installs in less time.
• No adjustments required - seals the first time, every time.
• Flexible stainless steel cable - installs effortlessly in tight spaces.
Choice of Finishes:
Stainless Steel (PVD).
C43
MOMENTS
WITH BRASS SPOUT
® Pop-up drain.
3"
6-1/2" to 12"
(165mm to 305mm)
2-5/16" D.
(59mm)
1-1/8" D.
(29mm)
(C)
Durable. Ideal for prolonged contact
Assures a lifetime of
Available in Polished Chrome or
3"
(76mm)
