Hawking HA12W Specifications

HA12W HA12W
Extend the Distance of your Wireless Devices up to 2 miles
The Hawking 12 dBi Hi-Gain Wi-Fi Directional Window Antenna boosts your wireless signal from a standard 2dBi to 12dBi. It is
an easy to install solution that plugs directly into an antenna port of your wireless device (router or adapter).* The HA12W is
built with high grade material ensuring maximum quality and performance.The power rating of WiFi antennas is measured in
terms of decibels (dBi). The HA12W boosts the antenna power of standard antennas from a minimal 2dBi to a staggering
12dBi. This results in extended wireless distances of up to 2 miles.*
corporate building to another, or simply from the front house to the back house, the Directional Window Antenna provides
wireless users with a high powered solution to extend their wireless network.
Installation of the HA12W is simple and straight forward. It is compatible with most wireless devices (Access Points, Routers,
Bridges and Network Adapters) on the market with removable external antennas. The Hawking Antenna comes equipped with
RP-SMA, RP-TNC connectors to support a wide range of wireless devices. For those devices that use adapters not included in
the packaging, please visit the Hawking Technologies website for a selection of specific connectors for your device.
Features
2.4 GHz Frequency - Works with popular Wireless Standards
Reverse SMA Plug - Compatible with most Access Points/Adapters
TNC Adapter is included for Cisco & Linksys Routers
A 12dBi Directional Antenna - Ensures optimal coverage
Supports all network operation systems
Setup is quick and simple
System Requirements:
One Wireless 2.4GHz 802.11b/g Device with a Removable External Antenna
Connector Type: Reverse SMA or Reverse TNC
Hi-Gain TM 12dBi
Window Antenna
HA12W
2.4GHz Hi-Gain 12dBi Directional
Window Antenna
PACKAGE CONTENTS:
One 12dBi Directional Window Antenna
50cm Extension Cable (N-Plug to Rev. SMA Plug)
TNC Adapter
Window/Wall Mounting Kit
One User's Manual
Whether extending the wireless network from one
*Results may vary due to different operating environments.
Directional
