- Page 1 Janus HD Janus Media Hub User’s Guide (North America Edition) P/N: 95-86xxxx-06 V1.5...
- Page 2 THE COPYRIGHT OWNER OF THE MATERIALS TO AVOID VIOLATING THE LAW WHICH COULD RESULT IN DAMAGES OR OTHER REMEDIES. TRADEMARKS Entone and the tagline “Connecting the Home” are trademarks of Entone, Inc. All other trademarks or registered trademarks belong to their respective owners. CHANGES The material in this document is for information only and is subject to change without notice.
-
Page 3: Table Of Contents
Janus HD - User’s Guide Table of Contents Declaration of Conformity ............................. 2 Preface ....................................5 TYPOGRAPHICAL CONVENTIONS ........................5 OVERVIEW OF THIS USER’S GUIDE ........................5 Safety Precautions ..............................6 IMPORTANT SAFETY INSTRUCTIONS ........................ 6 Index to Parts and Controls ............................8 CONTENTS IN THE BOX ............................ -
Page 4: Declaration Of Conformity
Janus HD - User’s Guide Declaration of Conformity To ensure proper use of this product, please read this manual carefully and retain it for future reference. Should the unit require maintenance, contact an authorized service location. WARNING: This symbol indicates the presence of uninsulated dangerous voltage within the product's enclosure that constitutes a risk of electric shock. - Page 5 Low voltage Directive 73/23/EEC Entone products are designed and tested to meet IEC60065, the standard for the Safety of Information Technology Equipment. This is the international standard for these types of products to reduce the risk of product damage and of personal injury.
- Page 6 Janus HD - User’s Guide Energy — Circuit with high energy or potential as burn hazards Heat — Accessible part of the product at high temperatures Radiation Noise Canada Certification Notice The Industry Canada label identifies certified equipment.
-
Page 7: Preface
Janus HD - User’s Guide Preface TYPOGRAPHICAL CONVENTIONS The following typographic conventions are used in this manual to provide visual clues as to the purpose or specific features of the Set-Top-Box (STB) application. Bold text describes menu options and selections displayed on the screen. -
Page 8: Safety Precautions
Janus HD - User’s Guide Chapter Safety Precautions Before installing Janus, be sure to unplug Janus, your TV and any other audio-video equipment you are using. This precautions list will help you to prevent danger of electrical shock and damage to Janus and your equipment. - Page 9 Janus HD - User’s Guide have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. To reduce the risk of electric shock, DO NOT remove cover or back panel. No user serviceable parts inside.
-
Page 10: Index To Parts And Controls
Janus HD - User’s Guide Chapter Index to Parts and Controls CONTENTS IN THE BOX Item Picture Quantity Janus Media Hub (Janus) RF Cable (with IEC connectors) (1.8 m) RJ45 Ethernet Cable (3m) RCA A/V Cable (2m) Component Video Cable (2m) Power Supply with 1.8m power cord (100-... -
Page 11: Front Panel And Rear Panel
Janus HD - User’s Guide FRONT PANEL AND REAR PANEL Figure 2-1 Janus Front Panel Part Name Description POWER If held for less than 5 sec, turns the Janus Media Hub ON/OFF. Lights blue when the receiver is turned on. If held for longer than 5 sec, the Janus Media Hub will be reset. -
Page 12: Remote Control
Janus HD - User’s Guide REMOTE CONTROL Part Name Description Selects to control TV Puts remote control in STB mode. Switches the power on/off for the currently selected POWER device. Switches STB to power on / standby mode. Selects to control AUX device. -
Page 13: Janus Introduction
Janus Introduction ABOUT THE JANUS MEDIA HUB Janus Media Hub is the latest member of Entone’s cost-effective high-definition Customer Premise Equipment (CPE) solutions. Janus is a multi-functional IPTV receiver with MPEG-4 (AVC/H.264) HD capabilities that integrates easily with popular home networking and broadband services. Integrated digital video recorder (DVR) service can be offered flexibly either through pre-installed hard drive or external SATA hard drive. -
Page 14: Connecting The Tv
Janus HD - User’s Guide Chapter Connecting the TV Janus offers comprehensive options for connecting audio and video to popular TV and audio equipment. You can connect Janus to the primary TV using RCA, Component or HDMI connection. You may also connect the Janus to TVs located in other rooms using coaxial cable connection. -
Page 15: Connecting The Tv Using Coaxial Cable
Janus HD - User’s Guide CONNECTING THE TV USING COAXIAL CABLE Use the coaxial cable that comes with Janus to connect your TV’s antenna input to the Janus’s “TV OUT” connector. Tune your TV to channel 3 or channel 4 to view the output (depending on selection of the on-screen user menu). -
Page 16: Connecting Tv Using Component
Janus HD - User’s Guide CONNECTING TV USING COMPONENT 1. Acquire the required cable. Component cable comes packaged with the Janus. 2. Connect the Component and audio cables to the Janus. 3. Connect the opposite end of the video and audio cables to the matching input in the TV. -
Page 17: Connecting Tv Using Rca Composite Or S-Video
Janus HD - User’s Guide CONNECTING TV USING RCA COMPOSITE OR S-VIDEO 1. Acquire the required cable. RCA cable comes packaged with the Janus. 2. Connect the video and audio cables to the Janus. 3. Connect the opposite end of the video and audio cables to the matching input in the TV. -
Page 18: Connecting The Tv Using Hdmi
Janus HD - User’s Guide CONNECTING THE TV USING HDMI 1. Acquire the required cable. Component cable comes packaged with the Janus. 2. Connect the HDMI cable to the Janus. (HDMI does not require separate audio cable connection.) 3. Connect the opposite end of the video and audio cables to the matching input in the TV. -
Page 19: Connecting Audio System
Janus HD - User’s Guide Chapter Connecting Audio System Your Janus supports AC-3 (Dolby Digital 5.1 channel). To enjoy multi-channel surround-sound, the content source must carry multi-channel AC-3 signal. Please refer to your service provider for availability of AC-3 5.1 programs. -
Page 20: Powering-Up Janus
Janus HD - User’s Guide Chapter Powering-Up Janus Follow these steps to power up the Janus: 1. Follow your TV/Network service provider’s instruction to connect the Janus to your network modem or network access unit using the Ethernet cable. Figure 6-1 Connecting Janus (Ethernet connection) 2. - Page 21 Janus HD - User’s Guide 5. Within 60 seconds splash screen will appear on the TV. Figure 6-3 Janus Boot-up Splash Screen 6. The total boot-up time may vary depending on the middleware application and the service provider environment. ...
-
Page 22: Remote Controls
Janus HD - User’s Guide Chapter Remote Controls LOADING BATTERIES The remote control comes with AA-size batteries, which needs to be installed when you first receive your system. When you replace old batteries, you should replace all of the batteries. Use batteries of the same kind, for example alkaline or carbon zinc, and do not mix batteries of different kinds. -
Page 23: Controlling The Janus Using Ir
Janus HD - User’s Guide CONTROLLING THE JANUS USING IR Janus uses InfraRed (IR) to receive remote control signals. IR signals travel only short distances (40 feet or less), and cannot go through walls or other solid objects. You must point the remote control to the Janus, with no objects blocking the line of sight. -
Page 24: User Menu
Janus HD - User’s Guide Chapter User Menu The Janus User Menu is an on-screen setup menu to set up your Janus features. You need to connect the TV properly before using the User Menu. Table 8-1 User Menu Features Available Options ... -
Page 25: Specifications
Janus HD - User’s Guide Chapter Specifications Main components Decoder Single decoder Main CPU MIPS 4380 class with FPU Memory 512MB, 1GB NAND Flash Software Real-time, multi-threaded embedded OS, Java Virtual Machine with MHP APIs, HTML 4.01 compliant browser with JavaScript 1.5... - Page 26 Janus HD - User’s Guide Connectors 1 x Optional CABLE / ANT IN IEC connector (DVB-S) or F-connector (ATSC / QAM / DVBS-2) 1 x TV OUT F-connector 1 x Optional RF PASS-THROUGH IEC connector (DVB-S) or F- connector (DVBS-2)
-
Page 27: Troubleshooting
Janus HD - User’s Guide Chapter Troubleshooting This section describes some of the most common problems that might be encountered when installing Janus, and the solutions to those problems. Symptom Remedy Reference Check batteries are correctly loaded. Section 7 – Remote Remote controls ... - Page 28 Janus HD - User’s Guide AC-3. If HDMI is used, check the resolution and try to use the composite audio output. Check with service provider that programs Section 5 – Connecting Multi-channel sound not Audio System contain multi-channel AC-3 signal.
