American Standard 2149.012 Elongated Front Parts List

ORIGINAL EQUIPMENT
WATER CONTROL
C L
REPLACEMENT
SMART VALVE
3198.000-B
FOR COMPONENT PART ORDERING SEE CURRENT PRODUCT SELECTOR
AND PRICING GUIDE.
P r o d u c t n a m e s l i s t e d h e r e i n a r e t r a d e m a r k s o f A m e r i c a n S t a n d a r d I n c .
A m e r i c a n S t a n d a r d I n c . 1 9 9 9
C
ORIGINAL
EQUIPMENT
TRIP
LEVER
REPLACEMENT BRASS ARM TRIP LEVER
LEFT HAND ONLY 8098.002 CHROME
AVAILABLE IN THE 8098.020 WHITE
FOLLOWING COLORS: 8098.099 POLISHED BRASS
DESCRIPTION
Elongated Bowl only w/(2) Bolt Caps
Tank w/Fittings & Cover (12" R.I.)
Tank Cover only
ORIGINAL EQUIPMENT REPAIR PARTS
Water Control Assembly (with Float Ball)
Flush Valve
Trip Lever
Bolt Cap Kit
Coupling Kit, Bowl-to-Tank
Flapper Assembly
COMPACT EL SPACE SAVER
1.6 G.P.F. TOILET
MODEL NUMBER
2149.012 ELONGATED FRONT
TANK
COVER
BOLT
CAPS
Replace XXX with
Fixture Color Code,
YYY with Trim Finish
COMPONENT
3027.012.XXX
4010.010.XXX
735018-410-XXX
PART NUMBER
738145-0070A
738138-0070A
047242-XXX0A
034783-XXX0A
047188-0070A
738159-0070A
ORIGINAL EQUIPMENT
FLUSH VALVE
ORIGINAL
EQUIPMENT
FLAPPER
ASSEMBLY
PKG QTY
1
1
1
PKG QTY
1
1
1
2
1
1
I-79
REV. B
