Specifications
Approvals
Technical Data
Supply voltage
Maximum switching current
GFCI
Ambient setpoint range
(A/AF mode)
Floor setpoint range (F mode) 40°F to 104°F (5°C to 40°C)
Floor limit setpoint range
(AF mode)
Operating temperature range 32°F to 120°F (0°C to 50°C)
Storage temperature range
Kit Contents
A
1
QuickStat-TC thermostat
B
2
Mounting screws
C
1
Floor temperature sensor 15 ft (4.6m)
D
5
Wire nuts
E
1
Screwdriver
400-115-052
F
A
2
120 V, 208 V, 240 V, 60 Hz
15 A
Class A, 5 mA trip level
40°F to 86°F (5°C to 30°C)
40°F to 104°F (5°C to 40°C)
–4°F to 120°F (–20°C to 50°C)
QuickStat-TC
Installation & Operation Manual
General Information
Use of this Manual
This manual covers the installation and operation of the Raychem
QuickStat-TC thermostat and must be used with the following document:
• QuickNet System Installation Manual (H57704)
Important: For the Tyco Thermal Controls warranty and agency
approvals to apply, the instructions included in this manual and product
packages must be followed.
Features
The QuickStat-TC is an electronic thermostat that must be used with the
Raychem QuickNet floor heating mats.
QuickStat-TC provides the following features:
• Integrated Class A, Ground-Fault Circuit Interrupter (GFCI).
• Operates at 120 V, 208 V, 240 V, 60 Hz.
• Switches on your heating system at predetermined times on different
days of the week.
• Offers 4 periods each day that you can set at different temperatures.
• Comes with a preprogrammed schedule that is suitable for most
installations. However, you can customize this program any time you
wish.
• Allows you to reset the thermostat to factory settings.
• Changes the start time of a heating period automatically so that the
desired temperature is reached at the time that you set.
• Multiple temperature control options so users can control the system
based on floor temperature (F), ambient air temperature (A), or both
(AF).
• On/Off switch to turn off thermostat during summer months.
A
B
C
D
E
Advertisement
Related Manuals for Raychem QuickStat-TC
Summary of Contents for Raychem QuickStat-TC
-
Page 1: General Information
Features The QuickStat-TC is an electronic thermostat that must be used with the Raychem QuickNet floor heating mats. QuickStat-TC provides the following features: • Integrated Class A, Ground-Fault Circuit Interrupter (GFCI). -
Page 2: Installation
QuickStat-TC Installation & Operation Manual Installation 6. Push the excess length of the wires back inside the electrical junction Important: This thermostat must be installed according to all national and local electrical codes. The installation must be performed by 7. Secure the power base to the electrical junction box using the qualified personnel. provided mounting screws 8. Verify the settings of the configuration switches on the back of the Locating the floor temperature sensor control module. Default settings for the configuration switches are The floor temperature sensor is installed under the floor surface. -
Page 3: Controls And Display
Daylight Savings Time reset, it was nuisance tripping and the system is functioning properly. The QuickStat-TC can automatically adjust for Daylight Savings Time. If the GFCI trips again after the reset, there is a ground-fault. The user When this function is enabled, the thermostat switches to Daylight should contact a qualified electrician to troubleshoot the issue. -
Page 4: Programming
In this mode, the programmed schedule is not used and the setpoint 2. Press and hold the corresponding preset button ( , or temperature must be set manually. To place the QuickStat-TC in this until the corresponding icon is displayed. mode: Floor Temperature Limit (AF Mode Only) 1. Press the Mode/Ret button until the icon appears on the display. -
Page 5: Error Messages
QuickStat-TC Installation & Operation Manual Vacation Mode In this mode, the QuickStat-TC is set to the Vacation setpoint temperature and will override all programming until Vacation mode is disabled. To place the QuickStat-TC in this mode: 1. Press the button, and the icon appears on the display. 2. To disable Vacation mode, press the Mode/Ret button to change the mode to Automatic or Manual To reset the QuickStat-TC to factory default settings: 3. Turn the thermostat to Off. - Page 6 QuickStat-TC Installation & Operation Manual Tyco, QuickNet and QuickStat are registered and/or unregistered trademarks of Tyco Thermal Controls LLC or its affiliates. Worldwide Headquarters Canada Important: All information, including illustrations, is believed to be reliable. Users, however, should independently evaluate the suitability of each product for their particular application. Tyco Thermal Controls Tyco Thermal Controls...
