Definitive Technology
Thank You
Thank you for choosing the Definitive Technology Mythos Solo Surround Array
Loudspeaker System featuring Spatial Array™ technology. The Mythos SSA-42 is a
unique speaker that provides a stunning 5-channel surround experience from just one
speaker. This extraordinary speaker makes enjoying a high performance surround audio
system more convenient than ever before. You chose wisely.
Our engineers spent many years developing this product. In order to ensure that you
experience the finest performance possible, we encourage you to take a moment to fully
read this owner's manual and familiarize yourself with the proper installation and set-up
procedures for your Mythos SSA-42 speaker.
Specifications
SSA-42
Dimensions:
40
/
" W (102.5 cm) x 4
3
8
(speaker only, not including bracket)
Driver Complement:
Three 3
1
/
" (8.3 cm) BDSS High-output drivers with coincident
4
array
/
" (20 mm) ferro-magnetic fluid damped pure aluminum
3
4
dome tweeter.
Two 3
1
/
" (8.3 cm) BDSS High-output full-range drivers.
4
Four 3" (7.6 cm) full-range high-output surround drivers
with butyl rubber surrounds.
Frequency Response:
60 Hz – 30 kHz
Nominal Impedance:
8 Ohms
Rec. Assoc. Amplification:
20 – 175 Watts/channel
Sensitivity:
89 dB
Weight:
20 lbs. (4.52 kG)
Specifications subject to change without notice.
SSA-42
/
" D (10.48 cm) x 4
/
" H (11.4 cm)
1
1
8
2
OWNER'S MANUAL
Mythos Solo Surround Array Loudspeakers
Unpacking Your SSA Speakers
Please Inspect For Shipping Damage
Each loudspeaker leaves our plant in perfect condition. Any visible or concealed
damage most likely occurred in handling after it left our plant and should be reported
at once to your Definitive dealer or the delivery company that delivered your loud-
speaker. Please unpack your system carefully. Save all cartons and packing materials in
case you move or need to ship your system. Record the serial number found on the
back of the Mythos SSA in the appropriate place on the product registration card,
answer all questions and send it in.
VERY IMPORTANT: Accessories
Various parts and accessories that you will need to use your Mythos SSA are in the
carton but are easy to overlook. Open both ends of the shipping carton. Carefully
examine the contents of the shipping carton and packing material to find the plastic
bags with accessories.
Advertisement
Related Manuals for Definitive Technology Mythos SSA-42
Summary of Contents for Definitive Technology Mythos SSA-42
-
Page 1: Specifications
Thank You Thank you for choosing the Definitive Technology Mythos Solo Surround Array Loudspeaker System featuring Spatial Array™ technology. The Mythos SSA-42 is a unique speaker that provides a stunning 5-channel surround experience from just one speaker. This extraordinary speaker makes enjoying a high performance surround audio system more convenient than ever before. - Page 2 Feet on page 3]. Revised Artwork: SSA-42 Manual Wall Bracket Template Even if you intend to place the SSA speaker on a TV or shelf you must attach the wall-mount bracket to the speaker. See Using the Leveling Feet on page 3.
- Page 3 SSA-42 OWNER’S MANUAL 13. When the wall mounting bracket is securely screwed to the wall, line wire has some indicator (such as color-coding, ribbing or writing) up the speaker’s protruding Mounting Screws with the keyhole slots on one of the two conductors to help you maintain consistency. It is on the wall mounting bracket.
-
Page 4: Limited Warranty
3-Years for Electronic Components 2. Select “Yes” when asked if you are using a subwoofer. DEI Sales Co., dba Definitive Technology (herein “Definitive”) warrants to the original retail purchaser only that this Definitive loudspeaker product (the “Product”) will be free from defects in 3.
