Summary of Contents for Opel Tigra TwinTop

  • Page 1 OPEL Tigra TwinTop Owner’s Manual Back to overview...
  • Page 2 Back to overview...
  • Page 3 OPEL Tigra TwinTop Operation, Safety, Maintenance Back to overview...
  • Page 4 Data specific to your vehicle Please enter your vehicle’s data here to keep it easily accessible. You can find it in the "Service and Maintenance" and "Technical data" sections and also on the identification plate. Fuel Designation Engine oil Grade Viscosity Tyre pressure Tyre size...
  • Page 5 When this Manual refers to a workshop "Technical data". visit, we recommend you use an Opel z Directional data, e.g. left or right, Service Partner. Caution or front or back, in the descriptions All Opel Service Partners provide first-class always relate to the direction of travel.
  • Page 6 Back to overview...

  • Page 7: Table Of Contents

    In Brief ............2 Contents Keys, doors, windows, TwinTop .... 22 Seats, Interior .......... 46 Instruments, Controls ......68 Lighting ........... 88 Infotainment system ......92 Climate control ........94 Driving and Operation ......102 Self-help, care for your car ....128 Service and maintenance ....

  • Page 8: In Brief

    In Brief In Brief Picture no: 15335t.tif Picture no: 16414s.tif To unlock the driver’s door: To unlock and open luggage Press button compartment: Press button remote control twice, press Door locks 3 24, Key 3 22, Electronic button beneath the boot lid immobiliser 3 23, Remote control 3 3 24, Central locking 3 3 25, Anti-theft alarm To unlock with button on driver’s door:...
  • Page 9 In Brief Picture no: 15855s.tif Picture no: 15856s.tif Picture no: 15857s.tif To adjust seat leg room: To adjust seat backrests: Seat cushion height: Pull lever Pull handle, slide seat, Turn handwheel Lift lever and relieve some weight from seat release handle to raise it or press down on seat with body Do not lean on seat backrest whilst weight to lower it.
  • Page 10 In Brief Picture no: 15859s.tif Picture no: 15862s.tif Picture no: 15861s.tif Head restraint height: To release, Pull out the seat belt and click Adjust exterior mirrors tilt head restraint forward, hold into belt buckle Select corresponding exterior mirror and and adjust height, engage adjust with the four-way switch.

  • Page 11: Steering Wheel Adjustment 3 3

    In Brief Picture no: 16406s.tif Picture no: 15863s.tif To adjust interior mirror by Steering wheel adjustment swivelling Swivel lever down, adjust height, swivel lever up, engage Swivel lever on underside of mirror housing to reduce dazzle. Adjust steering wheel only when vehicle is stationary and steering column lock is Interior mirror 3 34 released.
  • Page 12 In Brief Back to overview...
  • Page 13 In Brief Parking lamps, dipped 10 Hazard warning lamps ..3 12, 3 90 20 Brake pedal ..3 72, 3 108, 3 121 beam ........3 11, 3 88 LED for 21 Ignition switch anti-theft alarm system 3 .....3 32 Side with steering wheel lock ....
  • Page 14 In Brief Back to overview...

  • Page 15: With Steering Wheel Lock 3

    In Brief Side air vents ....... 3 94 Turn signal indicators ..3 11, 3 89 15 Ignition switch Headlamp flash ....3 11, 3 89 with steering wheel lock ....3 15 Front passenger airbag ....3 56 Dipped beam, 16 Steering wheel adjustment 3 ..
  • Page 16 In Brief Control indicators Engine oil pressure, Alternator, 3 70. 3 71. Seat belt 3 3 68, 3 51. Turn signal lamps, Brake system, clutch system, 3 11, 3 71, 3 89. 3 72, 3 168. > Fog lamps 3, 3 68, 3 89.

  • Page 17: Parking Lamps, Dipped Beam

    In Brief Picture no: 13715s.tif Picture no: 18475s.tif Picture no: 14054h.tif Exterior lights Headlamp flash, main beam and Switch on turn signal lamps dipped beam Turn right Stalk up Headlamp flash = Pull stalk towards left Stalk down steering wheel Parking lamps Turn signals 3 89.

  • Page 18: Horn:

    In Brief Picture no: 15865s.tif Picture no: 11548s.tif Picture no: 15866s.tif Hazard warning lamps Horn: press right or left Windscreen wipers Operated with the ¨ button. Airbag system 3 56, Remote control on & Fast steering wheel 3 3 92. Slow Hazard warning flashers 3 90.

  • Page 19: Wheel 3

    In Brief Picture no: 15867s.tif Picture no: 15868s.tif Picture no: 15935s.tif Operating windscreen washer Heated rear window, heated To clear fogged or icy windows system: Pull stalk toward steering exterior mirrors Rotary knob for temperature and air wheel mixture clockwise, air distribution on V, Operated with the Ü...
  • Page 20 In Brief Before starting off, check z Tyre pressure and tyre condition 3 123, 3 180 z Engine oil level and fluid levels 3 164 to 3 170 z All windows, mirrors, exterior lighting and number plates are free from dirt, snow and ice and operational.
  • Page 21 In Brief Picture no: 15678t.tif Picture no: 15582a.tif Picture no: 11554s.tif Steering wheel lock and ignition Starting the engine Releasing the hand brake: Raise lever slightly, Press release Turn key to position 1. Move the steering Depress the clutch and brake pedals, button, Lower lever fully wheel slightly to release the steering wheel manual transmission automated 3 in N, do...
  • Page 22 In Brief Parking the vehicle Advice when parking z If the vehicle is on a level surface or uphill slope, engage first gear before switching z Always apply handbrake without z Do not park the vehicle on flammable off the ignition. On an uphill slope, turn pressing release button.
  • Page 23 In Brief Interesting functions Picture no: 15894s.tif Picture no: 15896s.tif Airbag System Side airbag system The side airbag is triggered in the event of The airbag system consists of several a side-on collision to form a safety cushion separate systems. for the driver or front passenger in the Front airbag system respective door area.

  • Page 24: Infotainment System 3

    In Brief Picture no: 15593t.tif Picture no: 15559t.tif Picture no: 14034s.tif Operating menus in the Selection using multifunction button 3 : To select with steering wheel buttons 3 rotate and press multifunction button. Select menu options via the menus and the information display buttons.

  • Page 25: Trip Computer 3 83

    In Brief Ü Board Computer 19,5° 19:36 BC 1 All values BC 2 257.0 Timer Ø km/h 31.0 Ltr. Ø Ltr./100km Picture no: 16719t.tif Picture no: 16421s.tif Picture no: 16055s.tif Trip computer Opening TwinTop z Release the locking levers on upper right and left of the window frames, Functions: Only with vehicle stationary.
  • Page 26 In Brief Closing TwinTop Only with stationary vehicle and closed boot lid. The luggage compartment partition must be engaged in its rear position. Do not place any objects in front of the luggage compartment partition. z Engage hand brake z Switch on ignition. Picture no: 15903s.tif Picture no: 15904s.tif z Press S until the roof and boot lid are...
  • Page 27 In Brief Picture no: 16056s.tif Picture no: 18322s.tif Ultrasonic parking sensors z Move the locking levers on right and left of the window frames all the way up. When reverse gear is selected, the park Each retaining hook must engage and pilot switches itself on automatically.

  • Page 28: Keys, Doors, Windows, Twintop

    Keys, doors, windows, TwinTop Keys, doors, windows, Replacement keys The key number is specified in the TwinTop Car Pass 3. The key is part of the electronic immobiliser. Locks 3 153. Replacement keys ....... Key with retractable key blade 3 ..Car Pass..........
  • Page 29 Keys, doors, windows, TwinTop If control indicator A illuminates after the engine has started, there is a fault in the engine electronics or transmission electronics 3 3 69, 3 106, 3 114 or there is water in the diesel fuel filter 3 3 167. Note The immobiliser does not lock the doors.
  • Page 30 Keys, doors, windows, TwinTop Fault If the central locking system cannot be operated with the radio remote control, it may be due to the following: z Range exceeded z Battery voltage in remote control too low, change battery, z Frequent successive activations of the remote control outside the range of the vehicle (this means that the remote control is no longer recognized).
  • Page 31 Keys, doors, windows, TwinTop Key with fixed key bit, see Fig. 15331 T on previous page. Have the workshop change the battery. Radio remote control synchronisation After changing the battery, unlock the door using the key. Insert the key in the ignition lock to synchronise the remote control.
  • Page 32 Keys, doors, windows, TwinTop Picture no: 15333t.tif Picture no: 15985s.tif Picture no: 15334t.tif Press button m in the door. To lock Mechanical anti-theft locking system 3 Close doors, luggage compartment and The vehicle can be locked even if the Warning tank flap.
  • Page 33 Keys, doors, windows, TwinTop Within 10 seconds of locking, press the p Fault button on the remote control again. If the central locking cannot be operated, this can be for one of the following reasons: Unlocking the vehicle switches off the mechanical anti-theft locking system.
  • Page 34 Keys, doors, windows, TwinTop Picture no: 15918s.tif Picture no: 16414s.tif Picture no: 16415s.tif Luggage compartment To open with the button beneath the boot To close: Press the button below the boot lid until the To open with the button in the door 1.
  • Page 35 Keys, doors, windows, TwinTop Picture no: 16417s.tif Picture no: Picture no: 16416s.tif 3. Turn the tool 90 to the right to remove. 5. Pull the tool forward out of the flooring. Fault The luggage compartment lid can only be 4. Pull the front of the tool upward and out operated if the roof has been fully and of the flooring.
  • Page 36 Keys, doors, windows, TwinTop Picture no: 15919s.tif Picture no: 15920s.tif Picture no: 16418s.tif 6. Open and fold down the cover of the 8. Have a second person hold the rear of To close the boot lid, have a second person emergency release cable.

  • Page 37: Anti-Theft Alarm System 3

    Keys, doors, windows, TwinTop Anti-theft alarm system monitors z doors, luggage compartment, bonnet, z the passenger compartment, z vehicle tilt e.g. if it is raised, z the ignition. Warning Do not use the system if there are people in the vehicle! The doors cannot be unlocked from the inside.
  • Page 38 Keys, doors, windows, TwinTop After the first 10 seconds of anti-theft alarm system activation: z LED flashes = System switched on, slowly z LED comes = Switch-off function. on for approx. 1 second On faults, contact a workshop. Picture no: 15987s.tif Picture no: 15335t.tif Light emitting diode (LED) To deactivate...
  • Page 39 Keys, doors, windows, TwinTop Note z Changes to the vehicle interior, such as the use of seat covers, could impair the function of passenger compartment monitoring. z Switch off passenger compartment monitoring if the interior of the parked vehicle is heated. Alarm When triggered, the alarm gives off an acoustic signal (horn) and a visual signal...
  • Page 40 Keys, doors, windows, TwinTop Electric windows Warning Exercise care when operating electric windows. Risk of injury, especially for children. Vehicle passengers should be informed accordingly. Keep a close watch on the windows when closing them. Ensure that nothing becomes trapped in them as they move. Ready for operation Ready for operation when the ignition is on Picture no: 15868s.tif...
  • Page 41 Keys, doors, windows, TwinTop When a door is opened, the window of that door opens a slit. It closes automatically after the door is closed. When the TwinTop is opened or closed, the windows open a slit. They close automatically once the TwinTop is completely opened or closed.

  • Page 42: Climate Control

    Keys, doors, windows, TwinTop TwinTop Overload If the windows are repeatedly operated at The TwinTop, a foldable steel top, enables short intervals, the power supply is briefly the Tigra to combine the attributes of a cut off. coupe and a convertible. Fault Warning If the windows cannot be opened and...
  • Page 43 Keys, doors, windows, TwinTop Picture no: 12481s.tif Picture no: 16421s.tif Picture no: 16055s.tif Opening the roof Engage the luggage compartment Release the locking levers on upper right Only with vehicle stationary. partition in the rear position. and left of the window frames, pulling both levers all the way down.
  • Page 44 Keys, doors, windows, TwinTop Press S until the roof and boot lid are completely closed. An acoustic signal sounds at the beginning and end of the procedure. If button S is actuated when the hand brake is not engaged, a warning buzzer sounds and the roof remains open.
  • Page 45 Keys, doors, windows, TwinTop Fault If there is a fault in the automatic drive or Automatic roof operation is only loss of battery power, the fully opened roof functional if the roof has been properly can be manually closed as follows: closed or opened beforehand.
  • Page 46 Keys, doors, windows, TwinTop Picture no: 16417s.tif Picture no: Picture no: 16416s.tif 6. Turn the tool 90 to the right to remove. 8. Pull the tool forward out of the flooring. 5. Fold down the left seat backrest. The tool is fastened underneath the seat. 7.
  • Page 47 Keys, doors, windows, TwinTop Picture no: 16427s.tif Picture no: 16428s.tif Picture no: 15909s.tif 9. Use the tool to forcefully pull the lock bar 10. With the lock bar pulled, have a helper 11. Press the button below the luggage to unlock the cover in front of the rear pivot the cover upward by hand.
  • Page 48 Keys, doors, windows, TwinTop Picture no: 16429s.tif Picture no: 16430s.tif Picture no: 15912s.tif 12. Release the front catches of the boot lid 13. With two people working 14. Release the roof retainer at the rear left using the tool by inserting the tool in the simultaneously on the right and left, of the luggage compartment partition guide and pressing the upper end...
  • Page 49 Keys, doors, windows, TwinTop Picture no: 15913s.tif Picture no: 15914s.tif Picture no: 16056s.tif 15. With the aid of a second person, 16. Pull the roof up to the windscreen 17. Push the locking levers on the right and carefully and slowly pull the roof frame.
  • Page 50 Keys, doors, windows, TwinTop Picture no: 15915s.tif Picture no: 15916s.tif Picture no: 15917s.tif 18. Have a second person help to force the 19. Next, if possible open and close the 20. Press down the cover in front of the rear boot lid closed simultaneously on the boot lid once using the button below window.
  • Page 51 Keys, doors, windows, TwinTop Wind deflector Install the wind deflector to reduce wind turbulence, draught and noise in the passenger compartment when the TwinTop is open. Picture no: 16057s.tif Insert the wind deflector in the opening in the centre of the rollover protection and fasten it with the crank.

  • Page 52: Seats, Interior

    Seats, Interior Seats, Interior Front seats ........... Head restraints ........Luggage compartment partition ..Three-stage safety system....Three-point seat belts ......Picture no: 15855s.tif Picture no: 15856s.tif Belt tensioners........Front seats Adjusting the backrest Using the belts ........Turn side handwheel on the seat while Child restraint systems 3 ....
  • Page 53 Seats, Interior Picture no: 15857s.tif Picture no: 15858s.tif Picture no: 15883s.tif Adjusting the seat height Fold backrest forward Seat position Lift lever and relieve some weight from seat To fold the backrest forwards, – e.g. to to raise it or press down on seat with body reach the storage compartment behind the Warning weight to lower it.

  • Page 54: Heated Seat 3

    Seats, Interior z Sit with your shoulders as far back against the backrest as possible. Set the backrest rake so that you can easily reach the steering wheel with your arms slightly bent. Maintain contact between your shoulders and the backrest when turning the steering wheel.
  • Page 55 Seats, Interior Picture no: 15884s.tif Picture no: 11581s.tif Picture no: 16453s.tif Luggage compartment partition Head restraint position Removing Press and release the two catches. Pull and When the TwinTop is closed, the partition Warning remove the head restraint. can be folded forward to enlarge the luggage compartment: pull both catches Only drive with the head restraint set to Note...
  • Page 56 Seats, Interior Three-stage safety system Warning Comprising: z three-point seat belts, The airbag systems serve to supplement the three-point seat belts and belt z belt tensioners at the seats, tensioners. The seat belts must therefore z airbag systems for driver and front always be worn.
  • Page 57 They are not suitable for anyone under 12 years of age or 150 cm. For children up to 12 years of age, we recommend the Opel child restraint Picture no: 15862s.tif Three-point seat belts system 3 55.
  • Page 58 Seats, Interior Belt tensioners The seat belts are pulled down at the buckles on a front or rear impact above a certain severity. This tightens the belts. Picture no: 11594s.tif Picture no: 15898s.tif Actuation of belt tensioners Control indicator v for belt tensioners is indicated by illumination of control The function of the belt tensioners and indicator v.
  • Page 59 Seats, Interior Important z The belt tensioner and airbag system Warning control electronics can be found in the z Do not affix or place accessories or other centre console area. In order to avoid objects within the deployment zone of Have the cause of the fault eliminated malfunctions, do not store magnetic the belt tensioners.
  • Page 60 Seats, Interior Picture no: 15891s.tif Picture no: 16422s.tif Picture no: 16423s.tif Using the belts Removing the belt Warning To release seat belt, press red button on Fitting seat belts belt buckle. The seat belt must not be twisted and must On pregnant women in particular, the lie snugly against the body.
  • Page 61 6 to 12 years z The covers of Opel child restraint systems can be wiped clean. z Do not stick anything on the child restraint systems and do not cover them with any other materials.
  • Page 62 Opel child restraint system with transponders 3 has been fitted to the front passenger seat. Seat occupancy recognition – 3 60. Opel child restraint system with transponders 3 3 61.
  • Page 63 Seats, Interior Picture no: 15894s.tif Picture no: 15883s.tif Picture no: 15862s.tif When triggered, the front airbags inflate in The front airbag system will not be Warning milliseconds and form a safety cushion for triggered in the event of driver and front passenger. Forward z the ignition is switched off, Optimum protection is only provided movement is checked and the risk of...
  • Page 64 The ignition must be on. z the side impact sensors, z control light for airbag systems v in instrument panel, z seat occupancy recognition 3, z the control indicator for Opel child restraint systems with transponders 3 in the courtesy lamp. Back to overview...
  • Page 65 The side airbags will not be triggered in the or an Opel child restraint system with event of transponders 3 has been fitted to the front passenger seat. Seat occupancy z the ignition is switched off, recognition –...
  • Page 66 3 60, Fig. 12097 S. Picture no: 15898s.tif If an Opel child restraint system with Control indicator v for airbag systems transponders 3 is fitted, the control The function of the airbag systems is...
  • Page 67 3 can be identified by a sticker or badge. Control indicator for Opel child restraint systems with transponders 3 The presence of an Opel child restraint Picture no: 12106a.tif Picture no: 16409s.tif system with transponders 3 is indicated Vehicles with seat occupancy recognition...
  • Page 68 If no Opel child restraint system with z Only protective covers which are z Do not place any objects between the transponders 3 is fitted, the control...
  • Page 69 Seats, Interior z Do not perform any alterations on the z In vehicles with seat occupancy z When using an Opel child restraint components of the airbag system, as this recognition 3 persons weighing less than system with transponders 3 on the front would render the vehicle unroadworthy.
  • Page 70 – see page Fig. 12106 A. The seat occupancy recognition system detects Opel child restraint systems with transponders 3 and deactivates the front and side airbags for the front passenger Picture no: 11704a.tif...
  • Page 71 Seats, Interior Do not exceed the maximum power consumption of 120 watts. Electrical accessories connected to the socket must comply with the electromagnetic compatibility requirements laid down in DIN VDE 40 839, otherwise vehicle malfunctions may occur. Do not connect any current-delivering accessories, e.g.

  • Page 72: Ashtray 3

    Seats, Interior Picture no: 11589s.tif Picture no: 15889s.tif Picture no: 15885s.tif Ashtray Stowage compartments To empty, open the ashtray cover fully beyond its resistance point, causing the Stowage compartment behind the seats Caution insert to lift. Grip both sides of the ashtray The compartment is only suitable for insert and pull upwards.

  • Page 73: Glove Compartment 3

    Seats, Interior Sun visors Use the sun visor to protect from glare by pulling it down and swivelling it to the side. Picture no: 15890s.tif Picture no: 16059s.tif Coin holder Glove compartment To open, pull handle upwards. In the centre console. Can be locked with the vehicle key.

  • Page 74: Instruments, Controls

    Instruments, Controls Instruments, Controls Picture no: 17915s.tif Picture no: Control indicators Seat belt 3 The control indicators described here are Control indicator lights red. Control indicators ........ not present in all vehicles. The description Instrument display ....... applies to all instrument versions. This comes on after turning on the ignition Information display ......
  • Page 75 Instruments, Controls Exhaust emission Control indicator lights or flashes yellow. It illuminates when the ignition is switched on and goes out shortly after the engine starts. Illuminates when the engine is running Fault in emission control system. The permitted emissions may be exceeded. Contact a workshop immediately.
  • Page 76 Instruments, Controls 1. Depress clutch. 2. Move gearshift lever to neutral, or with manual transmission automated 3 place selector lever in N. 3. Move out of the flow of traffic as quickly as possible without impeding other vehicles. 4. Switch off ignition. Warning When the engine is off, considerably more force is needed to brake and steer.

  • Page 77: Fog Tail Lamp

    Instruments, Controls Preheating system 3 Control indicator lights yellow. Preheating activated. Only activates when outside temperatures are low. Winter program on manual transmission automated 3 Control indicator lights yellow. Control indicator is illuminated when winter program is enabled 3 105. Picture no: 18323s.tif Picture no: Fog tail lamp...
  • Page 78 Instruments, Controls Engine oil level 3 Control indicator lights yellow. The engine oil level is checked automatically. Illuminates when the engine is running Engine oil level too low. Check engine oil level and top up engine oil if necessary 3 165. Electric power steering Control indicator lights yellow.
  • Page 79 Instruments, Controls Plus Electronic Stability Program (ESP® Fuel level Control indicator flashes or lights yellow. Control indicator lights or flashes yellow. Flashing during driving Lamps System engages 3 116. Level in fuel tank too low. Illuminates while driving Flashing Fault in system 3 116. Fuel supply exhausted, refuel immediately.
  • Page 80 Instruments, Controls Picture no: 15872s.tif Picture no: Picture no: 11688s.tif Instrument display Kilometre display Coolant temperature display If the ignition is off the mileage is displayed Coolant temperature display. Tachometer for approx. 15 seconds by briefly pressing Displays the engine rpm. Pointer in = Engine operating the reset knob.
  • Page 81 Instruments, Controls Picture no: 11689s.tif Picture no: 12478s.tif Picture no: 14419s.tif Fuel gauge Transmission display 3 Service Display 3 Display of fuel level in tank Display of current gear or mode with When the indicator InSp in the display of manual transmission automated 3 : the odometer lights up, make a service When level is low, the control indicator Y...
  • Page 82 Instruments, Controls Some information appears in the display in an abbreviated form. Ü Board Computer 19,5° 19:36 BC 1 All values 12:01 °C BC 2 257.0 Timer 90,6 Ø FM 3 km/h 31.0 Ltr. Ø Ltr./100km Picture no: 17913s.tif Picture no: 16719t.tif Information display Graphical Information Display 3 Display of time, outside temperature and...
  • Page 83 Instruments, Controls Warning Caution: The road surface may already be icy even though the display indicates a few degrees above 0 8:56 °C Slippery road -2,5°C 07.04.2004 Picture no: 17913s.tif Picture no: 16707t.tif Outside temperature In vehicles with graphical information display 3, the warning message Slippery A fall in temperature is indicated road is shown in the display as a warning...
  • Page 84 Instruments, Controls Automatic time synchronisation 3 The RDS signal of most VHF transmitters automatically sets the time. This can be identified by } in the display. Some transmitters do not send a correct [TP] CDin time signal. In such cases, we recommend 8:56 °C that you switch off automatic time...
  • Page 85 Instruments, Controls Picture no: 15593t.tif Picture no: 15559t.tif Picture no: 14034s.tif To select with four-way button Selection with the multifunction knob 3 Selection using buttons 3 on steering Select menu items via menus and with the Turn the multifunction button to highlight wheel buttons/four-way button of the menu items or commands and to select...
  • Page 86 Instruments, Controls Settings 19,5° 19:36 Time, Date 19,5° 19:36 [TP] CDin Time, Date 19:36 Time 19:36 Language 90.6 Units 10 . 07 . 2004 Date 10 . 07 . 2004 Contrast Day / Night Synchron. clock automatical. Ign. logic 19,5° 19:36 Picture no: 16711t.tif Picture no: 16712t.tif...
  • Page 87 Instruments, Controls Automatic time synchronisation 3 The RDS signal of most VHF transmitters automatically sets the time. 13 Languages 19,5° 19:36 Settings 19,5° 19:36 Some transmitters do not send a correct time signal. In such cases, we recommend Time, Date Deutsch that you switch off automatic time Language...
  • Page 88 Instruments, Controls Setting display mode 3 Display brightness is independent of vehicle lighting. Settings are made as follows: Contrast 19,5° 19:36 Settings 19,5° 19:36 Select menu item Day / Night from the Time, Date Settings menu. Language Europe-SI The options are displayed. "...

  • Page 89: Trip Computer 3 3

    Instruments, Controls Ü Board Computer 19,5° 19:36 BC 1 All values Range BC 2 257.0 Range Timer Aver. Consump. Ltr./100km Ø 33km km/h Inst. Consumpt. Ltr./100km 31.0 Ltr. Ø Ltr./100km 19,5° 19:36 Picture no: 16719t.tif Picture no: 16710t.tif Picture no: 16718t.tif Graphical information display Range If the fuel in the tank will allow less...
  • Page 90 Instruments, Controls Instantaneous consumption Distance travelled Effective consumption Display of current consumption. At low Display of distance travelled. The Display of fuel consumed. The speeds, consumption per hour is displayed. measurement can be reset at any time. measurement can be reset at any time. Average speed Average consumption Display of average speed.
  • Page 91 Instruments, Controls Ü Board Computer 19,5° 19:36 Ü Reset BC 1 19,5° 19:36 Ü Reset BC 1 19,5° 19:36 BC 1 All values All values All values BC 2 257.0 257.0 257.0 Timer Ø Ø Ø km/h km/h km/h 31.0 31.0 31.0 Ltr.
  • Page 92 Instruments, Controls Warning buzzers The stop watch information to be displayed can be selected via menu Options 3: When starting the engine or whilst driving: Driving Time excl. Stops Ü Board Computer 19,5° 19:36 z if seat belt 3 is not fastened; Measurement of the time the vehicle is in motion.
  • Page 93 Instruments, Controls Adjustable wipe interval 3 Setting wiper interval to a value between 2 and 15 seconds: Stalk to timed interval wipe $ , stalk to §, wait for desired interval, stalk back to timed interval wipe $. The interval time selected remains stored until it is next changed or until the ignition is turned off.

  • Page 94: Lighting

    Lighting Lighting Versions with daytime running lights 3 With ignition on and light switch to 7, the dipped beam is switched on without instrument panel lighting. The daytime running lights switch off when the ignition is switched off. Follow the regulations of the country in which you are driving when using daytime running lights and fog lamps 3.
  • Page 95 Lighting Picture no: 18475s.tif Picture no: 14054h.tif Picture no: 13720s.tif Main beam, headlamp flash Turn signal lamps Fog lamps >3 To switch from dipped to main beam, press The fog lamps can only be switched on Stalk up Turn signal stalk forwards when both the ignition and lights are on.

  • Page 96: Headlamp Range Adjustment 3

    Lighting Picture no: 15865s.tif Picture no: 13719s.tif Picture no: 14302s.tif Hazard warning lamps Headlamp range adjustment Environment lighting Operated with the ¨ button. Adjust headlamp range to the vehicle load Dipped beam lights for around 30 seconds with dipped beam switched on: turn after switching on and closing the driver’s To aid location of the pushbutton, the red adjuster wheel to desired position.

  • Page 97: Instrument Illumination 3

    Lighting Battery discharge protection Some consumers such as the interior lighting switch themselves off after approx. 30 minutes if the ignition is off in order to protect the battery charge. Misted light covers The inside of the lamp covers may briefly mist up under unfavourable wet/cold weather conditions, during heavy rain or after the vehicle has been washed.

  • Page 98: Infotainment System

    Infotainment system Infotainment system Radio reception Radio reception may be disrupted by static, noise, distortion or loss of reception due to z changes in distance from the transmitter, z multi-path reception due to reflection z shadowin.g Picture no: 14034s.tif Remote control on steering Radio reception 3........
  • Page 99 3.5 mm jack plug via the AUX input. exceeding 10 watts. malfunctions of the vehicle electronics Always keep the AUX input clean and dry. We recommend using your Opel Service when operated inside the vehicle Partner. He keeps consoles and various without an external antenna unless the...

  • Page 100: Climate Control

    Climate control Climate control Heating and ventilation system, air conditioning system 3....Air vents ..........Heating and ventilation system ..Air conditioning system 3....Picture no: 15922s.tif Picture no: 15928s.tif Air intake ..........101 Heating and ventilation system, Air vents Pollen filter ...........

  • Page 101: Centre Air Vents 3

    Climate control Centre and side (1) air vents Additional vents Direct the flow of air by tilting and can be found beneath the windscreen and swivelling the slats. the side windows, and also in the footwell. Temperature switch in central area: that air that comes out of the centre air vents is cooler than the air coming out of the side air vents.
  • Page 102 Climate control Picture no: 15923s.tif Picture no: 15924s.tif Picture no: 15925s.tif Heating and ventilation system Air flow Air distribution Adjustment with centre rotary switch. Adjustment with right rotary switch. Temperature Adjustment with left rotary switch. Towards windscreen and door Selected fan speed windows Red area Warm...
  • Page 103 Climate control Heating For rapid warming of the passenger compartment: z turn the temperature switch clockwise as far as it will go (warm), z set the fan to speed 3, z set air distribution switch to desired position, preferably position J 3 96. The comfort and general well-being of the vehicle occupants are to a large extent dependent on a suitable ventilation and...

  • Page 104: Air Conditioning System 3 3

    Climate control Air conditioning system z Set fan to 3 or 4, As a supplement to the heating and z Set air distribution switch to V. ventilation system, the air conditioning z Activate heated rear window Ü, system cools and dehumidifies (dries) z Open side air vents as required and inflowing air.
  • Page 105 Climate control Warning The air recirculation system minimises the entry of outside air. The humidity increases, and the windows can mist up. The quality of the passenger compartment air deteriorates which may cause the vehicle occupants to feel drowsy. Air distribution to V: the air recirculation system is automatically switched off to speed up window demisting and prevent fogging.
  • Page 106 Climate control Picture no: 15933s.tif Picture no: 15934s.tif Picture no: 16432s.tif Comfort setting Maximum cooling Demisting and defrosting windows Briefly open windows to allow heated air to z Set cooling n as desired. Warning escape quickly. z Air recirculation system 4 off. z Cooling n on.
  • Page 107 Climate control Regular operation z Cooling n on, the air conditioning compressor automatically switches For consistently good operation the off in low outdoor temperatures cooling 3 must be switched on for several (ice formation), minutes once per month regardless of the weather and the time of year.

  • Page 108: Driving And Operation

    Driving and Operation Driving and Operation Manual transmission automated The Easytronic manual transmission automated 3 permits manual (Manual mode) or automatic gear shifting (Automatic mode), both with automatic clutch control. Picture no: 12478s.tif Transmission display Manual transmission automated 3 ... 102 Shows the mode or current gear.
  • Page 109 Driving and Operation Selector lever in o (centre position) Once the selector lever has been moved from N to position o (centre position) with the foot brake operated, the Easytronic is in automatic mode and first gear has been selected (second gear with winter programme enabled).

  • Page 110: Manual Transmission Automated 3

    Driving and Operation Selector lever in + or - Stopping the vehicle In Automatic and Manual mode, when the Shift to a higher gear. vehicle has stopped first gear (second gear Shift to a lower gear. with Winter mode engaged) is engaged If a higher gear is selected when the automatically and the clutch is released.
  • Page 111 Driving and Operation Engine braking Automatic mode: When driving downhill, the manual transmission automated does not shift into higher gears until a fairly high engine speed has been reached. When braking, it shifts down in good time. Manual mode: To utilise the engine braking effect, select a lower gear in good time when driving downhill.
  • Page 112 Driving and Operation Vehicle storage Apply hand brake and remove ignition key. The most recently engaged gear (indicator in transmission display) remains engaged. With N, no gear is engaged. When the ignition is switched off, the manual transmission automated no longer responds to movement of the selector lever.

  • Page 113: Manual Transmission

    Driving and Operation 3. Clean gearbox around the cap (see fig.) so that no dirt can get into the opening when the cap is removed. 4. Rotate cap to slacken and remove by lifting upwards – see figure. 5. Turn the adjusting screw clockwise using a flat-head screwdriver (vehicle tools 3 135) until clear resistance can be felt.

  • Page 114: Driving Hints

    Driving and Operation Driving hints Brake servo unit Switching off the engine When the engine is not running, the brake When you switch off, fans in the engine The first 1000 km servo unit is no longer effective once the compartment may continue running for Drive your vehicle at various speeds.
  • Page 115 Driving and Operation Overrun cut-off Warming up Cooling fan The fuel supply is automatically cut off Allow the engine to warm up while driving. The cooling fan is controlled via a during overrun, e.g. when the vehicle is Do not warm it up by letting it run at idling thermoswitch and therefore only runs driven with a gear engaged but no throttle speed.

  • Page 116: Saving Fuel, Protecting The Environment

    Full throttle and warming up at idle centres and the recycling of end-of-life speed increase wear, fuel consumption, Trend-setting technology vehicles is available at www.opel.com. exhaust emission, the amount of In the development and manufacture of pollutant in the exhaust and the amount...
  • Page 117 Do not race your engine. Avoid driving at z We recommend that repair and great deal of time. high engine speeds. maintenance be entrusted to your Opel Tyre pressure Making use of the tachometer helps to Partner. z Inadequate tyre pressure, leading to save fuel.

  • Page 118: Fuel, Refuelling

    Driving and Operation Fuel, refuelling Fuel for petrol engines Fuel for diesel engines Only use unleaded fuel that complies Only use diesel fuel that complies with Fuel consumption with DIN EN 228. DIN EN 590. The fuel must have low Fuel consumption is determined under sulphur content (maximum 50 ppm).
  • Page 119 Driving and Operation Fuel filler cap Open the tank flap. Only a Opel Genuine fuel filler cap provides Unscrew fuel filler cap to open and full functionality. Diesel-engined vehicles suspend from tank flap. have special fuel filler caps. The fuel tank has a limiting system which Refuelling prevents overfilling of the tank.

  • Page 120: Catalytic Converter, Engine Emissions

    Driving and Operation Caution Damage to the catalytic converter or the vehicle may result if the following points are not observed. z In the event of misfiring, uneven engine running, a clear reduction in engine performance or other unusual problems, have the cause of the fault rectified by a workshop as soon as possible.
  • Page 121 Driving and Operation If it illuminates briefly, but does not recur, it is of no significance. Illumination of A can indicate water in the diesel fuel filter. Check fuel filter for possible water residue3 167. If it flashes after the ignition is switched on, there is a fault in the immobiliser system.

  • Page 122: Drive Control Systems

    We recommend Plus ESP® improves driving stability when that you entrust this work to your Opel necessary in any driving situation Engine exhaust gases contain poisonous Partner, who has proper equipment and regardless of the type of road surface or carbon monoxide, which is colourless trained personnel available.
  • Page 123 Driving and Operation As soon as the vehicle starts to swerve Illuminates while driving: (understeer/oversteer), engine output is Fault in the system. Driving can be reduced and the wheels are braked continued. Poor road surface conditions individually. This considerably improves may however still cause vehicle stability the driving stability of the vehicle on to be impaired.

  • Page 124: Cruise Control 3 3

    Driving and Operation Cruise control 3 With manual transmission automated 3, Cruise control can store and maintain only use cruise control when in automatic speeds of approx. 30 to 200 km/h. mode. Deviation from the stored speed is possible Warning on uphill or downhill inclines.
  • Page 125 Driving and Operation Increase To deactivate Stored speed With cruise control active, hold down Briefly press the O button: cruise control is The speed is saved until the ignition is button I or briefly press it repeatedly: deactivated. switched off. speed is increased continuously or in Automatic deactivation: To resume the saved speed, briefly press...
  • Page 126 Driving and Operation Ultrasonic parking sensors 3 Fault Park pilot makes reverse parking easier by On system faults, a permanent tone measuring the distance between the rear sounds at a distance of 1 metre from the of the vehicle and obstacles behind it. It is obstacle.

  • Page 127: Hydraulic Brake System

    Driving and Operation When the engine is not running, the support of the brake servo unit disappears once the brake pedal has been depressed once or twice. Braking effect is not reduced, but braking requires significantly greater force. This is especially important to bear in mind when towing.

  • Page 128: Anti-Lock Braking System (Abs U)

    Driving and Operation Anti-lock Braking System (ABS Self-check When the engine is started and the vehicle ABS prevents the wheels from locking. starts off, the system performs a self-check, ABS starts to regulate brake pressure as which may be audible. soon as a wheel shows a tendency to lock.

  • Page 129: Hand Brake

    Driving and Operation Brake assist Wheels, tyres If the brake pedal is operated with a fast, Suitable tyres and restrictions 3 180. powerful push, the vehicle is automatically Tyres fitted in the factory are adapted to braked at full braking power in order to the chassis and provide optimum driving achieve the shortest possible braking comfort and safety.
  • Page 130 Driving and Operation Fitting new tyres Do not reduce tyre pressure when the tyres Fit tyres in pairs or in sets, which is even are warm. Otherwise the pressure may better. Ensure that tyres on one axle are drop below the permissible minimum when z the same size, the tyres cool down.
  • Page 131 Driving and Operation Picture no: 9358t.tif Picture no: 15941s.tif Picture no: 6457u.tif Tyre condition, wheel condition Tread depth Warning Drive over edges slowly and at right angles Check tread depth regularly. if possible. Driving over sharp edges can For reasons of safety, tyres should be If the pressure is too low, this can result cause tyre and wheel damage.
  • Page 132 Driving and Operation General information Winter tyres 3 Notes on fitting new tyres 3 124. z The risk of aquaplaning is greater if the tyres are worn. Restrictions 3 180. z Tyres age, even if they are used little or Winter tyres improve driving safety at not at all.
  • Page 133 Remove the wheel trims if using tyre chains Use wheel trims and tyres that are 3 127. approved by Opel for the vehicle in Tyre chains may only be used at speeds question and therefore meet all the up to 50 km/h. They must only be used for...

  • Page 134: Self-Help, Care For Your Car

    Self-help, care for your car Self-help, Diesel fuel system, bleeding Never let the tank run dry! If control care for your car indicator Y illuminates, refuel as soon as possible. Refuel immediately if it flashes. If the tank is allowed to run dry, the diesel fuel system must be bled.

  • Page 135: Bonnet

    Self-help, care for your car Starting the engine with jump leads Do not start with a fast charger or by pushing or towing. A vehicle with a discharged battery can be started using jump leads and the battery of another vehicle. Warning Be extremely careful when starting with jump leads.
  • Page 136 Self-help, care for your car z Use a booster battery with the same voltage (12 volts). Its capacity (Ah) must not be much less than that of the discharged battery. z Use jump leads with insulated terminals and a cross section of at least 16 mm (25 mm for diesel engines).

  • Page 137: Towing Your Own Vehicle

    Self-help, care for your car Route the leads so that they cannot catch on rotating parts in the engine compartment. To start the engine: 1. Start the engine of the vehicle providing the jump start. 2. After 5 minutes, start the other engine. Start attempts should be made at intervals of 1 minute not last longer than 15 seconds.

  • Page 138: Warning Triangle

    Self-help, care for your car Select neutral gear. Caution Drive slowly. Do not drive jerkily. Excessive tractive force can damage the vehicle. When the engine is not running, considerably more force is needed to brake and steer. To prevent the entry of exhaust fumes from the towing vehicle, switch on the air recirculation 3 and close the windows.

  • Page 139: Spare Wheel 3

    Self-help, care for your car Picture no: 16441s.tif Picture no: 15947s.tif Picture no: 16442s.tif Spare wheel Fasten the velcro straps to the warning Pull the spare wheel forward and then triangle and the first-aid kit (cushion) as upward out of the wheel well. Some vehicles are equipped with a tyre illustrated.
  • Page 140 Self-help, care for your car General information Notes on temporary spare wheel 3 Notes on directional tyres 3 Depending on version, the spare wheel z The use of the temporary spare wheel Fit directional tyres such that they roll in the may be in the form of a temporary spare may affect the handling of the vehicle, direction of travel.

  • Page 141: Changing Wheels

    Self-help, care for your car Changing wheels z Use the jack 3 only to change wheels. Some versions have tyre repair aerosol z If the ground on which the vehicle is instead of a spare wheel 3 139. standing is soft, a solid board (max. 1 cm thick) should be placed under the jack 3.
  • Page 142 Self-help, care for your car Picture no: 15949s.tif Picture no: 15950s.tif Picture no: 11643s.tif 1. Pull off the wheel trim with the hook 3. Alloy wheels 3: Prise off the hub cap 3 2. Push the wheel bolt wrench 3 on as far Vehicle tools 3 135.
  • Page 143 Self-help, care for your car Picture no: 15951s.tif Picture no: 11645s.tif Picture no: 11646s.tif 3. The jacking points are marked. 4. Set the jack 3 to the necessary height. The edge of the jack base must be on the Position the jack arm at the front or rear ground directly below the jacking point so that the jack claw (arrow in Fig.) spans in a manner that prevents it from...
  • Page 144 Self-help, care for your car 5. Unscrew the wheel bolts. 10. Before refitting the wheel trim, clean the wheel around the retaining clips. Valve If the wheel bolts have retaining symbol 3 on back of wheel trim must washers 3, they must not be removed. point towards valve on wheel.
  • Page 145 Self-help, care for your car The tyre repair aerosol is located in the 5. Remove the seal. Hold the aerosol luggage compartment in the spare wheel upright and depress the button until the well. aerosol has completely discharged. The tyre has then been filled. 1.

  • Page 146: Electrical System

    Self-help, care for your car The tyre repair aerosol allows for temporary use of the tyre; it merely allows for continued travel until the tyre can be changed. Fold the used tyre repair aerosol in a cloth and stow in the luggage compartment. The tyre repair spray can only be used once for repair and must then be replaced.
  • Page 147 Self-help, care for your car Picture no: 15952s.tif Picture no: 15954s.tif Picture no: 15955s.tif Fuse box Place spare fuses at the point provided in Slot fuse-gripping tool onto fuse and The fuse box is located in the engine the fuse box; next to this on the right is the withdraw it.

  • Page 148: Fuses And The Most Important Circuits They Protect

    Self-help, care for your car Circuit Electric window (left) – – Ignition switch, starter Injection system, fuel pump Horn Central control unit Information display, Infotainment system: engine Z 13 DT Picture no: 15543s.tif Picture no: Fuses and the most important Circuit circuits they protect Instruments, information display,...
  • Page 149 Self-help, care for your car Circuit Anti-theft alarm system Heated exterior mirrors Windscreen washer system Courtesy lamp Central control unit Heated rear window Picture no: 15544s.tif Picture no: 15544s.tif Circuit Circuit Electric window (right) Infotainment system, Information display, Light switch, –...
  • Page 150 Self-help, care for your car Circuit Right dipped beam, headlamp range adjustment Tail lamp (left), parking lamp (left) Tail lamp (right), parking lamp (right) Brake lamps, cruise control Fog lamps Picture no: 11743s.tif Picture no: Circuit Circuit Engine control TwinTop Diesel filter heater Engine control unit Electric window,...
  • Page 151 Self-help, care for your car Circuit Fog tail lamp Main beam (left) Main beam (right) Ventilation fan Engine control unit TwinTop Starter Picture no: 11744s.tif Picture no: Circuit Circuit Plus ESP® Radiator fan Plus ABS, ESP® Radiator fan Petrol engine: Easytronic –...

  • Page 152: Bulb Replacement

    Self-help, care for your car Bulb replacement Switch off the ignition and switch off the relevant switch or close the doors. Only hold a new bulb at the base! Do not touch the bulb glass with your bare hands. Replace the bulb, checking that the data on the base matches that of the defective bulb.
  • Page 153 Self-help, care for your car Main beam Have bulbs changed by a workshop. Parking lamps Have bulbs changed by a workshop. Picture no: 15958s.tif Picture no: 15959s.tif 3. Detach plug connector from bulb. 6. When fitting the new bulb, insert lugs in the reflector recesses.

  • Page 154: Turn Signal Lamps

    Self-help, care for your car Side turn signal lamp Have bulbs changed by a workshop. Fog lamps Have bulbs changed by a workshop. Picture no: 15960s.tif Picture no: 15961s.tif Turn signal lamps 3. Remove bulb mounting from reflector. Front indicator lamps 4.

  • Page 155: Tail Lamps

    Self-help, care for your car Picture no: 15962s.tif Picture no: 15963s.tif Picture no: 15964s.tif Tail lamps 5. Disengage and remove socket by 6. Push bulb into holder a little, rotate left turning anticlockwise: and remove. 1. Open the luggage compartment. Reversing lamp 7.

  • Page 156: Number Plate Lamp

    Self-help, care for your car Picture no: 15965s.tif Picture no: 15966s.tif Picture no: 15967s.tif Number plate lamp 2. Rotate bulb holder to left and 3. Remove bulb from socket. disengage. 1. Insert screwdriver vertically on right- 4. Insert new bulb. hand side of bulb housing, exert pressure 5.
  • Page 157 Self-help, care for your car Picture no: 16445s.tif Picture no: 12927j.tif Picture no: 12928j.tif Courtesy light Luggage compartment lamp 2. Press bulb slightly towards spring 1. Prise the lamp out with a screwdriver. clip and remove. Front courtesy lamp 1. Unclip the scatter disc on the housing at 3.

  • Page 158: Vehicle Care

    Self-help, care for your car Vehicle care Clean edges and folds on opened doors Wheels and tyres and flaps as well as the areas they cover. Do not use high-pressure jet cleaners. When caring for your vehicle, observe all national environmental regulations, Thoroughly rinse off and leather-off the Clean wheels with a pH-neutral wheel particularly when washing it.
  • Page 159 Self-help, care for your car Interior and upholstery Locks Underbody Only clean the vehicle interior, including The locks are lubricated at the factory Some areas of the vehicle underbody have the instrument panel fascia and panelling, using a high quality lock cylinder grease. a PVC undercoating while other critical with a dry cloth or interior cleaner.

  • Page 160: Service And Maintenance

    Recommended Fluids and Lubricants 161 Booklet. The date and kilometre reading Inspection system ........ 163 are given with the stamp and signature of Genuine Opel Parts and Accessories . 164 the servicing garage. Performing work ........164 Ensure that the Service and Warranty Engine oil ..........
  • Page 161 Replace pollen filter or active charcoal filter ⊕o If air is very dirty, has a high dust or sand content or high pollen level, By agreement with customer / Opel Partner if the air conditioning system has an odour Replace air filter insert every 4 years / 60,000 km ⊕...
  • Page 162 Service and maintenance Service work after years km (x1000) Replace toothed belts and tensioning roller Z 18 XE every 6 years / 90,000 km ⊕ Change engine oil and filter ⊕o Drain water from fuel filter, diesel (for high residual humidity and/or lower quality fuel) Replace fuel filter and drain out water, diesel (quality EN 590) Z 13 DT Check parking brake and adjust (wheel unloaded);...
  • Page 163 ⊕o Clean and lubricate folding roof in dusty countries (by agreement with customer/Opel Partner) Test drive, final check (steering and ignition lock, instruments and control indicators, entire braking system, steering, air conditioning, engine, bodywork and chassis), reset service interval display with TECH 2 ⊕...
  • Page 164 Replace pollen filter or active charcoal filter ⊕o If air is very dirty, has a high dust or sand content or high pollen level, By agreement with customer / Opel Partner if the air conditioning system has an odour Replace air filter insert every 4 years / 60,000 km ⊕...
  • Page 165 Service and maintenance Service work after years km (x1000) Replace toothed belts and tensioning roller Z 18 XE every 6 years / 90,000 km ⊕ Change engine oil and filter ⊕o Drain water from fuel filter, diesel (for high residual humidity and/or lower quality fuel) Replace fuel filter and drain out water, diesel (quality EN 590) Z 13 DT Check parking brake and adjust (wheel unloaded);...
  • Page 166 ⊕o Clean and lubricate folding roof in dusty countries (by agreement with customer/Opel Partner) Test drive, final check (steering and ignition lock, instruments and control indicators, entire braking system, steering, air conditioning, engine, bodywork and chassis), reset service interval display with TECH 2 Whichever occurs first.

  • Page 167: Additional Service Work

    Service and maintenance Additional Service Work Recommended Fluids and Under extreme operating conditions, it may be necessary to perform certain Lubricants Additional Work ⊕ service work more frequently than at the Additional work is work which is not Only use products which have been tested scheduled intervals.
  • Page 168 Validity index twice between two oil changes). The temperature. viscosity must comply with requirements. Opel engine oil complies with The use of engine oil category ACEA A1/B1 classifications GM-LL-A-025 and and A5/B5 is expressly prohibited as it can GM-LL-B-025 and is therefore suitable cause long-term damage to the engine for both petrol and diesel engines.

  • Page 169: Inspection System

    Opel Partner, who has excellent gathered and is used to calculate the knowledge of Opel vehicles and is in remaining distance until the next service. possession of the necessary tools and current service instructions from Opel.

  • Page 170: Genuine Opel Parts And Accessories

    "Genuine Opel Parts and Accessories" and Picture no: 17922s.tif Picture no: 15969s.tif conversion parts approved by Opel can be Performing work obtained from your Opel Partner, who can Warning provide expert advice on permitted...

  • Page 171: Engine Oil

    Service and maintenance Engine oil For vehicles with engine oil level check 3, the engine oil level is checked automatically 3 72. We recommend checking the engine oil level before starting a long journey. Picture no: 16475s.tif Picture no: 16476s.tif Check with the vehicle on a level surface.
  • Page 172 Service and maintenance Top up to between the MIN and MAX marks 3 182. Fit the cap on straight and tighten it. Picture no: 15972s.tif Picture no: 15973s.tif We recommend that you use the same The engine oil level must not exceed engine oil as was used the last time it was the MAX mark on the dipstick.

  • Page 173: Diesel Fuel Filter

    Service and maintenance Diesel fuel filter Coolant On each engine oil change, have the fuel The coolant provides anti-freeze filter checked for any water residue by a protection down to approx. -28 workshop. Caution Illumination of A indicates water in the fuel filter 3.

  • Page 174: Brake Fluid

    Service and maintenance Top up with anti-freeze. If no anti-freeze is available, fill with clean tap water or distilled water. Have the anti-freeze concentration checked. Have the cause of coolant loss rectified by a workshop. Caution Too low a coolant level can cause engine damage.

  • Page 175: Windscreen Wiper Replacement

    Service and maintenance Brake fluid change Brake fluid is hygroscopic, i.e. it absorbs water. If the brakes become hot, such as when driving on long downhill stretches, vapour bubbles can occur in the water, which can have an extremely adverse effect on braking power (depending on the proportion of water).

  • Page 176: Windscreen Washer System

    Service and maintenance Protecting electronic components In order to prevent faults in electronic components in the electrical system, never connect or disconnect battery with engine running or ignition switched on. Never start engine with battery disconnected, e.g. when starting using jump leads. To avoid damaging the vehicle, do not make any modifications to the electrical system, e.

  • Page 177: Laying The Vehicle Up For A Long Period Of Time

    Service and maintenance Laying the vehicle up for a long Putting the vehicle back into z Park vehicle in dry and well ventilated period of time place. With manual transmission select service first gear or reverse gear, and with If the vehicle is to be laid up for several Perform the following work before Easytronic 3 move selector lever to months, the following work should be...

  • Page 178: Technical Data

    Technical Data Technical Data Vehicle data......... 172 Picture no: 15980s.tif Picture no: 15979s.tif Engine data.......... 174 Vehicle data In another version, the identification plate Performance......... 175 is attached to the right hand front door The technical data is determined in Fuel consumption, CO -emissions ..
  • Page 179 Technical Data Picture no: 13329j.tif Picture no: 15981s.tif Picture no: 15982s.tif Information on identification plate: The vehicle identification number is Engine identifier and engine number: stamped on the identification plate and on marked on left-hand side of engine in Manufacturer the right side of the floor of the vehicle engine block.

  • Page 180: Engine Data

    Technical Data Engine data Sales designation 1.4 TWINPORT 1.3 CDTI Engine identifier code Z 14 XEP Z 18 XE Z 13 DT Number of cylinders Piston displacement [cm 1364 1796 1248 Brake horse power [kW/bhp] at rpm 5600 6000 4000 Torque [Nm] at rpm 4000...

  • Page 181: Performance

    Technical Data Performance Z 14 XEP Z 18 XE Z 13 DT Maximum speed [km/h] Sports transmission Manual transmission automated – – The maximum speed is achievable with a maximum of half payload. Optional equipment may reduce the specified maximum speed of the vehicle. Back to overview...

  • Page 182: Fuel Consumption, Co

    Technical Data Fuel consumption, CO -emissions The directive is oriented to actual driving The figures given must not be taken as a practices: Urban driving is rated at guarantee for the actual fuel consumption Directive 80/1268/EEC (last amended of a particular vehicle. approx.
  • Page 183 Technical Data Fuel consumption, CO emissions Z 14 XEP Z 18 XE Z 13 DT Sports transmission/manual transmission automated Fuel consumption urban [l/100 km] 8.1/ 8.0 10.4/– 5.8/– rural [l/100 km] 5.0/ 4.9 5.8/– 3.9/– total [l/100 km] 6.1/ 6.0 7.5/–...

  • Page 184: Weights, Payload And Roof Load

    Technical Data Weights, payload and roof load Optional equipment and accessories Roof loads are not permitted. increase the kerb weight, which means that The payload is the difference between the Driving hints 3 108 the payload will also change slightly. permitted gross vehicle weight (see identification plate 3 172) and the EC kerb Note weight ranges in the vehicle...
  • Page 185 Technical Data Kerb weight Tigra TwinTop Engine Sport transmission Easytronic without air Z 14 XEP 1235 1235 conditioning [kg] Z 18 XE 1265 – Z 13 DT 1278 – with air conditioning [kg] Z 14 XEP 1260 1260 Z 18 XE 1290 –...

  • Page 186: Tyres

    205/45 R 17 must not be used as Spare wheel currently meet the structural requirements. winter tyres. We recommend that you consult an Opel Depending on design, the spare wheel is If you use winter tyres 3, the spare wheel Partner concerning suitable tyre makes.
  • Page 187 Technical Data Tyre pressure (overpressure) Tyre pressure for load with one person Tyre pressure for full load and light luggage Tyres front [kPa/bar] rear [kPa/bar] front [kPa/bar] rear [kPa/bar] Z 14 XEP, 185/55 R 15 250/2.5 250/2.5 250/2.5 250/2.5 Z 18 XE, 185/60 R 15, 230/2.3 210/2.1...

  • Page 188: Capacities

    Technical Data Capacities Engine oil Z 14 XEP Z 18 XE Z 13 DT Engine Inc. Filter [l] 4.25 Between MIN and MAX [l] Fuel tank Petrol/diesel, nominal capacity [l] Back to overview...

  • Page 189: Dimensions

    Technical Data Dimensions Tigra Length [mm] 3921 Width without exterior mirrors [mm] 1684 Width with two exterior mirrors [mm] 1905 Height [mm] 1376 Wheelbase [mm] 2491 Turning circle diameter [m] 11.00 Back to overview...

  • Page 190: Index

    Index Index ABS (Anti-lock Braking System) ... 122 Battery ........... 109, 170 Accessories......... 55, 64, 132 Interruption of power supply 27, 36, 107 Accessory socket ........65 Battery discharge protection ....91 Air conditioning system ......98 Before starting off ........14 Air intake..........
  • Page 191 Index Coolant........... 167 Coolant level .......... 168 Capacities ..........182 Easytronic ........14, 102 Coolant temperature display ....74 Car Pass............ 22 Driving programmes ......104 Coolant thermometer......74 Care ............152 fault ............ 106 Correcting time ........81 Catalytic converter ......114, 116 Interruption of power supply ....

  • Page 192: Front Passenger Airbag 3

    Exhaust gases ........116 High-pressure cleaners ......153 Generator, see Alternator....... 71 Exhaust system ........108 Horn............12 Genuine Opel Parts and Accessories ... 164 Exterior mirrors......33, 34, 36 Glove compartment ........ 67 Graphical information display ....76 Identification plate......172, 173 Gross vehicle weight......
  • Page 193 Brakes ..........168 Oil consumption ........174 Catalytic converter ......116 Oil pressure ..........70 Engine oil..........165 Opel Service ........... 154 Language selection ......... 81 Fuel consumption ......111 Operating temperature ......109 Light switch ..........11 Tyre pressure......124, 180 Outside temperature gauge ....
  • Page 194 Index Seats ............. 3, 46 heated ..........48 Radio ............92 Tachometer ..........74 Selector lever.......... 103 Radio equipment (CB)......93 Tail lamps ..........88 Self-diagnosis ......53, 60, 122 Radio remote control ......24 Bulb replacement ......149 Self-help ..........128 Rear lamp cluster........
  • Page 195 Index Turn signals Bulb replacement....... 148 Warning buzzers ........86 TwinTop........19, 20, 36 Warning triangle ........132 Tyre chains ........127, 180 Washer fluid reservoir, windscreen Tyre condition ........125 washer system ........170 Tyre pressure........124, 180 Weights ..........178 Tyre repair aerosol ........
  • Page 196 Index Back to overview...
  • Page 197 Back to overview...
  • Page 198 Copyright by ADAM OPEL GmbH, Rüsselsheim, Germany. The information contained in this publication is effective as of the date indicated below. Adam Opel GmbH reserves the right to make changes to the technical specifications, features and design of the vehicles relative to the information contained in this publication, as well as changes to the publication itself.

Table of Contents
