Topfield TF 5010 PVR User Manual

Digital satellite receiver personal video recorder
Hide thumbs Also See for TF 5010 PVR:
Table of Contents

Advertisement

Quick Links

TOPFIELD
TF 5010 PVR
TF 5510 PVR

User Guide

Digital Satellite Receiver
Personal Video Recorder
CONAX

Advertisement

Table of Contents
loading

Summary of Contents for Topfield TF 5010 PVR

  • Page 1: User Guide

    TOPFIELD TF 5010 PVR TF 5510 PVR User Guide Digital Satellite Receiver Personal Video Recorder CONAX...
  • Page 3: Table Of Contents

    Contents iii Contents 1 Introduction Features ....... Controlling the digital receiver .
  • Page 4 iv Contents 3.2.2 Colour model ......19 3.2.3 Video cassette recorder ....20 3.2.4 Television aspect ratio .
  • Page 5 Contents v 6 Listing Services Editing the services list ..... . . 47 Editing the favourite list ..... . 49 How to use on-screen keyboard .
  • Page 6 vi Contents 7.3.5 To play back a recording repeatedly ... 73 7.3.6 To play back recordings in sequence ... 73 7.3.7 To play back a scrambled recording .
  • Page 7: Introduction

    Chapter 1 Introduction The TF 5010 PVR/TF 5510 PVR digital receiver is fully compli- ant with the international Digital Video Broadcasting (DVB) standard, and can receive digital broadcasts. For its operation, you need an antenna, which must be installed appropriately.
  • Page 8: Controlling The Digital Receiver

    • Time shift is a special technical feature available on the TF 5010 PVR/TF 5510 PVR. You can pause the pro- gramme you are watching and resume it again at a later time. Then you can quickly go to whatever part of the current programme by fast foward and rewind search.
  • Page 9: The Front Panel

    1.2 Controlling the digital receiver 3 on, it is in operation mode. Even when you are not using the digital receiver, you should keep it plugged into a wall outlet to be in standby mode so that it can run timer events at any time.
  • Page 10: The Remote Control

    4 Introduction VOLUME buttons increase and decrease the volume. They are also used to change options for a menu item. OK button displays the services list. It is also used to select menu items. Pull the right edge of the front panel to open the flap. You have to insert your subscription card into the slot to watch pay services.
  • Page 11 1.2 Controlling the digital receiver 5 button displays the electronic programme guide. GUIDE button switches between television services and ra- dio services. button displays the main menu. It is also used to MENU return to the previous menu from a submenu. button is used to select an audio track and sound mode, or a video track of multifeed programme.
  • Page 12 6 Introduction button is used to stop playback, to stop recording, or to jump back to live television from time-shifted televi- sion. button starts recording. button pauses live television or playback of a recorded programme. button changes the position of sub-screen counter- clockwise.
  • Page 13: What Is Common Interface

    1.3 What is common interface? 7 1.3 What is common interface? Some broadcasts are scrambled so that only paid subscribers can enjoy them. Scrambled ser- vices can only be viewed with a Conditional Ac- cess Module (CAM) and a subscription card be- longing with the scrambling system.
  • Page 14: Setup

    8 Setup Chapter 2 Setup 2.1 Unpacking Before going any further, check that you have received the fol- lowing items with your digital receiver. • Remote control unit • Two batteries for the remote control (AAA 1.5 V) • One SCART-to-component cable •...
  • Page 15 2.2 Safety precautions 9 • The wall outlet should be near the equipment. Do not run an extension lead to the unit. • Do not expose the digital receiver to any moisture. The digital receiver is designed for use indoors only. Use dry cloth when cleaning the digital receiver.
  • Page 16: Rear Panel Connections

    10 Setup 2.3 Rear panel connections The TF 5010 PVR/TF 5510 PVR has a wide range of connec- tions on the back panel. VIDEO RF OUT LNB 1 IN LNB 2 IN RF IN IF 1 OUT IF 2 OUT...
  • Page 17: Connecting Up Your Digital Receiver

    2.4 Connecting up your digital receiver 11 Audio and video input/output socket for the video cassette recorder or suchlike. USB port for firmware update and data transfer. RF OUT Analogue television output socket. RF IN Analogue television input socket. S/PDIF Dolby digital output socket for the audio system.
  • Page 18: Connecting The Antenna

    12 Setup 2.4.1 Connecting the antenna Whatever sort of connection you have between the digital re- ceiver and the television, you need to connect the digital re- ceiver to your television antenna so that it can receive digital television services. Connect the antenna cable to the LNB 1 IN socket on the back panel of the digital re- ceiver.
  • Page 19: Connecting To Your Television

    2.4 Connecting up your digital receiver 13 2.4.2 Connecting to your television Between all the following connectors of your digital receiver, we recommend you use the first connector to get best picture quality. If your television does not have the matching connec- tor then use the next connector in the following order for best picture quality.
  • Page 20 14 Setup To use the S-Video connector You will need to obtain a S-Video cable to use the S-Video connector. Plug one end of the cable into the S-VIDEO socket on the digital receiver, and the other end into the matching socket on your television.
  • Page 21: Connecting To Your Video Cassette Recorder

    2.4 Connecting up your digital receiver 15 To use the RF connector If your television does not have any video and audio input, you will need to use the radio frequency output from the dig- ital receiver. In this case, you will need to connect a ca- ble from the RF OUT socket to the antenna connector on your television.
  • Page 22 16 Setup used batteries. The manufacturer accepts no liability for dam- age resulting from leaking batteries. NOTE Batteries, including those which contain no heavy metals, may not be disposed of with household waste. Please dispose of used batteries in an environmentally sound manner. Find out about the legal regulations which apply in your area.
  • Page 23: Preference Settings

    Chapter 3 Preference Settings 3.1 Language settings You can select the language in which the menu would be dis- played. In addition to that, you can select which language of au- dio track as well as of subtitle track to be output. Select the System Setting Language Setting menu.
  • Page 24: Video And Audio Settings

    18 Preference Settings Subtitle language Set the 1st Subtitle Language and the 2nd Subtitle Language options to your desired languages. When you watch a pro- gramme, if the programme has a subtitle track of the language that is designated for the 1st Subtitle Language, it will be dis- played.
  • Page 25: Television Standard

    3.2 Video and audio settings 19 3.2.1 Television standard The digital receiver supports two types of television standard. One is the PAL standard, and the other is the NTSC stan- dard. PAL was adopted in European countries while NTSC is adopted in USA, Canada, Mexico and so forth. Refer to Table for television standard of your local area.
  • Page 26: Video Cassette Recorder

    20 Preference Settings model but the CVBS colour model does the least. So RGB would be most desirable for this option. 3.2.3 Video cassette recorder You can have the digital receiver linked to your video cassette recorder or such an appliance via the VCR SCART connec- tor.
  • Page 27: Sound Mode

    3.2 Video and audio settings 21 figure, set the 16:9 Display Format option to Letter Box. Wide- screen pictures then will be reduced to fit to the width of the normal screen. Otherwise, to watch them in the shape like the right figure, set it to Center extract.
  • Page 28: Local Time Setting

    22 Preference Settings Set the RF Channel option to a channel number as you desire. You then have to retune your television set to the new channel number. 3.3 Local time setting You should set your local time for timer events. If you do not set the local time right, the programme time table provided by the programme guide may be distrustful.
  • Page 29 3.3 Local time setting 23 Table 3.2: Time offset table Time offset City 12:00 Eniwetok, Kwajalein 11:00 Midway Island, Samoa 10:00 Hawaii 09:00 Alaska 08:00 Pacific Time US, Canada 07:00 Mountain Time US, Canada 06:00 Central Time US, Canada, Mexico City 05:00 Eastern Time US, Canada, Bogota, Lima 04:00...
  • Page 30: Parental Control

    24 Preference Settings the numeric buttons. The time format is day/month/year 24- hour:minute. If daylight saving time is observed in your state at the mo- ment, set the Daylight Saving Time option to On. NOTE Daylight saving adds one hour to the time when the option is set to On, and it removes one hour when the option is set to Off.
  • Page 31: Adjusting The On-Screen Display

    3.5 Adjusting the on-screen display 25 NOTE If a programme does not have any programme classification information, your censorship setting will not take effect. If anyone is trying to watch a programme that is of or above the censorship setting, the person has to enter the personal identification number to override.
  • Page 32: To Turn On The Time Shift Feature

    26 Preference Settings 3 line. The more high the value is set, the more low the information box will be positioned. 3.6 To turn on the time shift feature Time shift means that the most recent hour of the television service you are watching gets saved temporarily on the hard disk of the digital receiver.
  • Page 33: Service Search

    Chapter 4 Service Search After connecting up the digital receiver, you will need to per- form a service search. 4.1 Searching broadcasting services This digital receiver can be operated with both fixed and mo- torized antenna system. You have to configure antenna set- tings according to your antenna system in the following order: 1.
  • Page 34 28 Service Search The other is K band which ranges approximately from 12 to 18 GHz. The LNB (Low Noise Block converter) is used to take a wide band of rel- atively high frequencies, amplify and convert them to similar signals carried at a much lower frequency, which is called IF (Intermediate Frequency).
  • Page 35 4.1 Searching broadcasting services 29 NOTE Both the LNB 1 IN and LNB 2 IN sockets should be connected to your antennas either directly or via the loop-through cable. If you have connected only one socket, some features such as dual recording will not function.
  • Page 36: Configuring Diseqc 1.2 Settings

    30 Service Search For example, to select the antenna con- nected to the A5 input in the left fig- ure, set the DiSEqC 1.1 option to 2 of 4 and the DiSEqC 1.0 option to 1 of 4. If you have a mini DiSEqC 1.0 switch which has only two inputs, you should set the DiSEqC 1.0 option to Mini A in- stead of 1 of 4.
  • Page 37: Configuring Usals Settings

    4.1 Searching broadcasting services 31 1. Choose your desired satellite at the Satellite Name op- tion. 2. Select the tuner that is connected to the motorized an- tenna at the Tuner Select option. 3. Set the DiSEqC Command Mode to User. 4.
  • Page 38 32 Service Search To use the USALS, select the Installation USALS Setting menu. You should see a screen like the left figure. At first you have to set the Mo- torized DiSEqC 1.3 option to Enable. To calculate every satellite position, perform the following steps: 1.
  • Page 39: Searching Services

    4.1 Searching broadcasting services 33 4.1.4 Searching services To perform service search, se- lect the Installation Service Search menu. You should see a screen like the left figure. There are four service search methods: • Searching every service of a satellite. •...
  • Page 40 34 Service Search 4. Input the symbol rate of your desired transponder to the Symbol Rate option with the numeric buttons. 5. Set the Polarization option to the polarization of your de- sired transponder. NOTE You can get transponder information from a satellite magazine or web site such as To search one service of a transponder, perform the following steps:...
  • Page 41: Copying Services

    4.2 Copying services 35 4. Input the symbol rate of your desired transponder to the Symbol Rate option with the numeric buttons. 5. Set the Polarization option to the polarization of your de- sired transponder. You can search pay services as well as free services. To search only free services, set the FTA/Scrambled option to FTA only.
  • Page 42 36 Service Search • Favourite list • Timer list • Preference settings You can reset all data of the digital receiver. If you want to re- set all the data, select the Installation Factory Setting menu, then you will be asked for confirmation. If you select Yes, service entries, favourite entries and timer events will all be deleted, and preference options will be reset to the manufac- turer’s factory settings.
  • Page 43: Daily Usage

    Chapter 5 Daily Usage 5.1 Volume control Use the buttons to alter the volume to a com- fortable level. You may need to adjust the volume on your television set too. To temporarily switch off the sound, press button. Press it again to restore the sound to previous level.
  • Page 44 38 Daily Usage On the services list, you can see the service information: • Service number and name • Transmitting satellite • Receiving tuner: T1 stands for the first tuner; T2 stands for the second tuner. • Transponder information A dollar sign ($) may be marked on some entries, indicating pay service.
  • Page 45 5.2 Watching television 39 • Select your desired tuner at the Tuner option, then only services provided through the selected tuner will be listed. • By setting the Show Provider option to On, you can view the provider of the services, which is usually the name of the television company responsible for broadcasting them.
  • Page 46: The Favourite Services List

    40 Daily Usage Fav–NoFav from favourite services to unfavourite services. Pressing the button displays the satellite list. Once you select a desired satellite in the satellite list, only services pro- vided by the selected satellite are listed. You can switch between the television services list and the ra- dio services list by pressing the button.
  • Page 47: Viewing Programme Information

    5.2 Watching television 41 Besides that, you can add or delete a favourite group or ser- vice. To add the service you are currently watching into a favourite group, put the highlight bar of the group list on a desired group and press the button.
  • Page 48: Selecting Audio Tracks

    42 Daily Usage Pressing the button once more displays detailed informa- tion about the current programme. To hide the information box, press the button. EXIT 5.2.4 Selecting audio tracks Some programmes are provided with audio tacks in one or more languages. Pressing the button displays available au- dio tracks.
  • Page 49: Viewing Electronic Programme Guide

    5.3 Viewing electronic programme guide 43 5.3 Viewing electronic programme guide The Electronic programme Guide shows the current and scheduled programmes that are or will be available on each service with a short summary for each programme. Pressing the button dis- GUIDE plays the electronic programme guide, on which you can see the...
  • Page 50: Using Time Shift

    44 Daily Usage If a multifeed programme is provided on the current service, the multifeed symbol ( ) will be marked on the information box. Press the button, then available video tracks will be listed. Once you select one, it will be presented. At this time, you have to press the button once more to select audio tracks.
  • Page 51: Using Picture In Picture

    5.6 Using picture in picture 45 • You can jump forward 30 seconds at a time by pressing button. • You can jump backward 10 seconds at a time by pressing button. • You can change playback speed. For slow motion see §...
  • Page 52 46 Daily Usage 1. Press the button to display a sub-screen, on which another service will be presented. 2. Pressing the button once more minifies the sub- screen, and pressing it once again hides the sub-screen. 3. Pressing the button swaps the main picture with the sub-picture.
  • Page 53: Listing Services

    Chapter 6 Listing Services 6.1 Editing the services list You would have got the services list after service search. You can rename, move, lock or delete service entries on the ser- vices list. Select the Organizing Services menu. You should see a screen like the left figure.
  • Page 54 48 Listing Services To edit the radio services list, press button; then radio ser- vice entries will be listed on the right column. To switch back to the television services list, press it again. To change the name of a service, select the Rename and select a desired service;...
  • Page 55: Editing The Favourite List

    6.2 Editing the favourite list 49 CAS–FTA from pay services to free services Fav–NoFav from favourite services to unfavourite services. Transponder by transponder 6.2 Editing the favourite list You can make your own favourite services list. In fact, you can define multiple favourite services lists, each being a ‘group’...
  • Page 56 50 Listing Services You can add a favourite service to a group by performing the following steps: 1. Put the highlight bar on a desired group entry in the group list and press the button to select it. The high- light bar then moves to the services list.
  • Page 57: How To Use On-Screen Keyboard

    6.3 How to use on-screen keyboard 51 6.3 How to use on-screen keyboard You can move the highlight key horizontally with the buttons and vertically with buttons. Press- ing the button on a key en- ters its letter in the input line. To type a space, select the Space key.
  • Page 58: Editing Channel Data On Your Computer

    52 Listing Services 1. Plug one end of a RS-232 cable (9 pin D- sub cable) into the RS-232 port on the digital receiver, and the other end into the matching port on the other digital re- ceiver. 2. turn on the source digital receiver. 3.
  • Page 59 6.5 Editing channel data on your computer 53 If you have a RS-232 cable (9 pin D-sub cable), plug one end of the cable into the RS-232 port on the digital receiver, and the other end into the matching port on your computer.
  • Page 60: Editing Satellite And Transponder List

    54 Listing Services 2. A box appears asking for your confirmation. Press the Download button on it. 3. Turn on the digital receiver. Data transfer will start as soon as it is turned on. 6.5.1 Editing satellite and transponder list To edit the satellite list, first select the View Satellite Informa- tion menu item.
  • Page 61: Editing Television And Radio Services List

    6.5 Editing channel data on your computer 55 to perform the Motorized DiSEqC 1.2 menu of the digital re- ceiver. Refer that menu to § 4.1.2. After making a new satellite entry by pressing the OK button on the box, you should con- figure LNB settings for it.
  • Page 62: Editing Favourite List

    56 Listing Services To delete a service entry, choose your desired service entry at the TV Service list, and press the Delete key on your key- board. When a confirmation dialog box appears, the selected service entry will be deleted by pressing the Yes button on it. Checking the CAS check box designates a selected service en- try as a pay service.
  • Page 63 6.5 Editing channel data on your computer 57 To delete a favourite group, choose your desired favourite group at the Favorite Group Name drop-down list box, and then select the Function Fav Group Delete Current Fav Group menu item. When a confirmation dialog box appears, the selected favourite group will be deleted by pressing the Yes button on it.
  • Page 64 58 Listing Services To add a favourite group, select the Function Group Add New Fav Group menu item. Then you will see a dialog box like the left figure. Enter your desired name into the Favorite Group Name text box to name a new group. If you make a radio favourite group, select the Radio op- tion button.
  • Page 65: Recording And Playing

    Chapter 7 Recording and Playing With one tuner of the digital receiver, you can record a ser- vice and at the same time watch another service—if the two services are provided through the same transponder. The TF 5010 PVR/TF 5510 PVR digital receiver has two tuners so that you can enjoy the following: •...
  • Page 66: Recording A Programme

    60 Recording and Playing 7.1 Recording a programme Once recording has started, a symbol like the left fig- ure will be displayed at the top right of the screen for a few seconds. When you are watching a service dif- ferent from the service being recorded, you can view a number on the center of the symbol, which indicates the order that the recording is started.
  • Page 67 7.1 Recording a programme 61 Pressing the button will pause the live show and begin time shifting within the current recording even with the Time Shifting option disabled. How- ever, it is still possible to pause a recording. After a recording is started, pressing the but- ton displays a menu like the left...
  • Page 68: Current Programme Recording

    62 Recording and Playing To stop recording, press the button; then a box like the left figure appears, which shows programmes currently being recorded. If you select one, its recording will stop. While a recording is going on, you can watch or record another service.
  • Page 69: Timer Recording

    7.1 Recording a programme 63 Set the Satellite option to the satellite which transmits the ser- vice you want. Pressing the button on this option displays a satellite list, from which you can select your desired satel- lite. Set the Service option to the service which provides the pro- gramme you want.
  • Page 70 64 Recording and Playing To input a timer recording, se- lect the System Setting Timer Setting menu; then the timer list will be displayed. To add a new timer event, press button, and a box like the left figure appears. Take the fol- lowing steps: 1.
  • Page 71 7.1 Recording a programme 65 Weekly means ‘one day every week.’ Every Weekday means ‘from Monday to Friday ev- ery week.’ If your favourite programme is broadcasted at week- ends and you wish to record every episode of the pro- gramme, set the Mode option to Every Weekend.
  • Page 72: Scheduling A Recording Using The Programme Guide

    66 Recording and Playing 7.1.4 Scheduling a recording using the programme guide If the electronic programme guide is properly provided, you can make timer events on it by taking the following steps: The instructions on how to make timer recordings using the electronic programme guide are as follows: 1.
  • Page 73: Recording A Time-Shifted Programme

    7.1 Recording a programme 67 7.1.5 Recording a time-shifted programme See § for detailed description about the time shift feature. While watching a programme with time shift, you can record it by performing the following steps: 1. Press the button to display the progress bar. 2.
  • Page 74: File Archive

    68 Recording and Playing NOTE If you switch to other service or use time shift in the middle of recording a pay programme, it will be recorded without de- scrambling from that moment. Even if the recording is only partially descrambled, you need the subscription card to play it back.
  • Page 75: To Sort Recordings

    7.2 File archive 69 7.2.2 To sort recordings To sort the recordings, perform the following steps: 1. Press the button to display the additional options. 2. Set the Sorting option to Alphabetic, Time or Size as you want. 3. Press the button.
  • Page 76: To Make A New Folder

    70 Recording and Playing 7.2.5 To make a new folder To make a new folder, press the button; then a new folder named GROUP # is created. You can change its name in the same manner as renaming a recording. See above. 7.2.6 To move a recording to another folder To move a recording to another folder, put the highlight bar on a desired recording and press the...
  • Page 77: To Navigate Using The Progress Bar

    7.3 Playing back a recording 71 • To go forward, hold down the button; to go back- ward, hold down the button. • To display the progress bar, press the button; to hide it, press the button again. • when the progress bar is hidden, you can move to a de- sired scene by entering the percentage with the numeric buttons 7.3.1 To navigate using the progress bar...
  • Page 78: To Play In Fast Motion

    72 Recording and Playing 7.3.3 To play in fast motion To watch in fast motion duration a playback, press the button. If you press it repeatedly, the playback speed changes in 3 steps: 2, 4 and 6 times. To resume normal speed, press the button.
  • Page 79: To Play Back A Recording Repeatedly

    7.3 Playing back a recording 73 7.3.5 To play back a recording repeatedly You can play a recording repeatedly both in whole and in part. To play a recording repeatedly in whole, press the button when the progress bar is hidden; then the repetition symbol ) is displayed on the information box.
  • Page 80: To Play Back A Scrambled Recording

    74 Recording and Playing 5. To jump to start of next selected recording, press the button to display the progress bar, then press the but- ton. 7.3.7 To play back a scrambled recording If you have recorded a programme of a pay service with the subscription card, you can play it as freely like one of a free service.
  • Page 81: Copying A Recording

    7.5 Copying a recording 75 7.5 Copying a recording You can copy a recording file in whole or in part during a play- back by performing the following steps: 1. Start playback of a recording you want. 2. Move to a scene from which you want to start copy by holding down the button.
  • Page 82: Transferring Recording Files

    76 Recording and Playing 7.7 Transferring recording files You can transfer files between the digital receiver and your computer via USB connection with Altair, which is a program used to transfer files. You can download it from the Topfield web site, To transfer files, take the following steps: 1.
  • Page 83: Formatting The Hard Disk

    7.8 Formatting the hard disk 77 panel shows files and folders that are on your computer. 2. To transfer files from the digital receiver to your com- puter, press the right arrow button ( 3. To transfer files from your computer to the digital re- ceiver, press the left arrow button ( At the top of the panel, you will see a message that says Turbo Off.
  • Page 84 78 Recording and Playing NOTE If a new hard disk drive is installed, it must be formatted be- cause the file system of the digital receiver is different from any of the personal computer. You can neither record nor use time shift with an unformatted hard disk.
  • Page 85: Topfield Application Program

    Chapter 8 Topfield Application Program If you are good at programming with C++ language, you can make a program executable to run on the digital receiver. We call this a Topfield Application program (TAP). In mak- ing a TAP, it is recommended to use Diab compiler of Wind River, whose web site address is Some variants of GCC compiler also might be available as a compiler for TAPs.
  • Page 86 80 Topfield Application Program To run a TAP in the digital receiver, perform the following steps: 1. Press the button and then the button to display the program file list. 2. Place the highlight bar on a file entry you want to run. 3.
  • Page 87: Firmware Update

    Chapter 9 Firmware Update The digital receiver has a stable and convenient firmware to use. However, a new firmware may be released to improve the digital receiver. You can get the latest firmware and an update utility from the web site, You have to check the firmware information of your digital re- ceiver before downloading a...
  • Page 88: From Your Computer Via Usb Port

    82 Firmware Update 9.1 From your computer via USB port You can transfer a new firmware to the digital receiver from your computer by connecting them with a USB cable. You need TFDN USB, a firmware transfer utility for this, which is available from the web site, To update the firmware with this method, perform the follow- ing steps:...
  • Page 89: From Your Computer Via Rs-232 Port

    9.2 From your computer via RS-232 port 83 9.2 From your computer via RS-232 port It is possible to transfer a new firmware to the digital receiver from your computer by connecting them with a RS-232 cable. You need TFD-Down, a firmware transfer utility for this, which is available from the web site, To update the firmware with this method, perform the follow- ing steps:...
  • Page 90: From Another Digital Receiver Via Rs-232 Port

    84 Firmware Update 9.3 From another digital receiver via RS-232 port It is possible to transfer a new firmware to the digital receiver from another same digital receiver by connecting them with a RS-232 cable. To update the firmware with this method, perform the follow- ing steps: 1.
  • Page 91 9.4 Over the air 85 Select Installation Firmware Upgrade menu. You should see a screen like the left figure. Selecting the Start option starts firmware update. On the left table is presented Satellite Astra the transponder information Frequency 12603 MHz appointed by the manufac- Symbol Rate 22000 KS/s...
  • Page 92: Index

    86 INDEX Index 16:9, C band, 16:9 Display Format, CAM, 1st Audio Language, CAS, 1st Subtitle Language, CAS, 22 kHz, CAS only, 2nd Audio Language, CAS TP, 2nd Subtitle Language, CAS–FTA, 39, 4:3, Censorship, Center extract, A/V Output Setting, Change PIN Code, Access Control, Add New Fav Group, Common Interface,...
  • Page 93 Edit Current Fav Group, LNB 1 IN, Edit Satellite, LNB 2 IN, 12, 28, Edit Transponder, LNB 2 IN, Electronic programme Guide, LNB Frequency, Every Day, LNB Power, Every Weekday, LNB Setting, Every Weekend, Local Time, Lock, 39, 48, 56, Factory Setting, Locked, Fav–NoFav, 40,...
  • Page 94 88 INDEX Position Index, services list, program file list, Show Provider, Program Files, Size, progress bar, SMATV, Provider, SMATV, Sort, Quick, Sorting, 39, Sound Mode, Radio, 58, Space, Radio Service, specifications, 9, radio services list, Start, Record, Start Search, Start Time, 63, Record continue, Record No, std, 52,...
  • Page 95 Tuner 2, Tuner 2 to Tuner 1, Tuner Select, 28, 31, 32, Turbo Off, TV, 13, TV Aspect Ratio, TV Service, 55, TV Type, Type, Upload, Upload from STB, USALS, USALS Setting, USB, 53, 76, USB, User, User Select, VCR, VCR, VCR Scart Type, Vega,...
  • Page 98 Correct disposal of this product This marking shown on the product or its literature indicates that it should not be disposed with other household wastes at the end of its working life. To prevent possible harm to the environment or human health from uncon- trolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.
