Citizen QUARTZ Eco-Drive CTZ-B6775 Instruction Manual

CITIZEN QUARTZ
Eco-Drive
Model No. EP0XXX
Cal. No. 851
• INSTRUCTION MANUAL
CTZ-B6775
1. BEFORE USING THE WATCH
This is a solar cell analog quartz watch with a solar
cell incorporated in its dial. We recommend that you
first read these instructions. Please expose the
watch to light and recharge before use.
2. ABOUT THE SOLAR CELL WATCH
This watch is powered not by an ordinary battery, but
by converting photo energy to electrical energy.
A secondary battery is used in this watch to store the
converted electrical energy. After being fully recharged
once, the watch can continue to run accurately for
about 60 days without any further recharging.
I How to use the solar cell watch well
To use this watch comfortably, make sure that the
watch is always recharged before it finally stops.
There is no concern for overcharging this watch,
(Overcharging Prevention Feature) we recomend
that you recharge the watch every day.
I Replacing the secondary battery
However often the secondary battery is repeatedly
recharged their is no need to replace it like a battery.
But if the secondary battery deteriorates, its
rechargeability might decrease and recharging might
take time. If this happens, please replace the
secondary battery.
2. SPECIAL ADDITIONAL FEATURES OF THE
SOLAR CELL WATCH
These additional featurtes are only found in the solar
cell watch.
I Quick Start Feature
The watch will stop if it is completely discharged.
It will begin to operate soon after it is exposed to light.
(However the time it takes to start may vary according to
the brightness of the light.)
Please note that if the light is blocked the watch might stop
again as a result of being insufficiently recharged.
I Overcharge Prevention Function
You can recharge without worry.
Once the secondary battery is fully recharged, the
overcharging prevention feature comes into operation
and prevents over-recharging
I Insufficient Charge Warning
Feature
The second hand changes to a two
second interval movement to
indicate insufficient recharging.
Even, in such a case, the watch
keeps correct time, but if about 24
hours pass after two second interval
movement begins, the watch stops
operating. After exposing the watch
to light, recharging takes place and the watch returns
to one second interval movement.
I Time Setting Indication Feature
If the watch stops, subsequent
exposure to light allows the Quick
Start Function to start again, and the
second hand moves with a hitch
movement to indicate that the
displayed time is now incorrect.
In this case, quickly recharge the
watch and reset the time.
Otherwise, the hitch movement will continue.
4. SETTING THE TIME AND CALENDAR
I Setting the time
1. Stop the second hand at the 0 second position by
pulling the crown out to the 2nd click.
2. Turn the crown to set the time.
3. After setting the time, firmly push the crown back in
to its normal position.
I Setting the calendar
Adjusting the date
1. Pull the crown out to the 1st click.
2. Set the desired date by turning the crown.
• If you adjust the date when the watch display is
reading between 9:00 pm and 1:00 am, the date
might not change on the following day.
After you have set the calendar, be sure to firmly
return the crown to its normal position.
5. WHEN THE SECOND HAND MOVEMENT IS
ABNORMAL
I Two-second interval movement
Insufficient recharging warning feature is working.
Recharge the watch by quickly exposing it to light
until it has returned to one-second interval
movement.
During two-second interval movement, the watch
continues to keep the correct time.
If two-second interval movement continues for about
24 hours, the watch stops.
