- Page 1 Owner’s Manual & Warranty...
-
Page 2: Table Of Contents
Contents Introduction Guild’s Commitment to Craftsmanship Moisture Content and Humidity Protection From Temperature and Humidity Cracks in the Wood Finish Checking General Maintenance Tuning Machines Tuning 6-String Guitars Tuning 2-String Guitars Changing Strings Re-Stringing Guitars Truss Rod Adjustment Adjustment of Action Traveling With Your Guitar Guild Warranty Servicing Your Guitar... -
Page 3: Introduction
Introduction Thank you for choosing a Guild. We believe this new instrument will give you many years of pleasure. Please take a few moments to read through this booklet. In it you will find answers to many of your questions and other invaluable information about care and maintenance for your guitar. For detailed specifications of Guild instruments, please visit our Guild website at: www.guildguitars.com... -
Page 4: Guild's Commitment To Craftsmanship
Guild’s Commitment to Craftsmanship Guild was established in 952 by Alfred Dronge. The first guitars from his small workshop were handmade with expensive rare woods, costly lacquers, hand-wound pickups for the electrics, and the attention to detail that only an experienced musician could give. The workshop was located in New York City, where most of the top jazz, studio and touring guitarists were frequently seen. Their suggestions were always listened to carefully. The Guild name is derived from the master craft guilds of the Middle Ages. During that period, only the craftsmen who had achieved the highest skills were permitted to join these guilds. Our policy today is much like that of yesteryear. The name “Guild” expresses the highest standards in the art of wood craftsmanship and guitar making. Even today, the woods used in Guild guitars are selected by hand. Our buyers travel the world extensively, directly to the sources of the many different woods we use. There, they carefully select from opened logs and purchase only the highest grade woods for creating Guild guitars. Guild guitars are handmade in Tacoma, Wash., in an environment where quality, innovation and service are the ultimate goals of the entire Guild staff. Our highly skilled artisans take extreme pride in every guitar we produce. A pride that restores meaning to the words “American made”. We are confident you will share this pride in the ownership... -
Page 5: Moisture Content And Humidity
Moisture Content and Humidity Wood is a porous, organic material, and is affected dimensionally by changes in the amounts of moisture it contains. Fine guitars made from solid woods are without a doubt more susceptible to the effects of changes in humidity than laminated instruments, and therefore require ongoing attention to their condition. The moisture content of wood is determined by the relative humidity and temperature of the surrounding atmosphere. Relative humidity is expressed as a percentage of air’s capability to hold moisture. For example, 30% relative humidity means that the air is holding 30% of the moisture it could possibly hold at a given temperature. The moisture content for wood and the relative humidity for air are measured quite differently. In wood, a 6% moisture content is present at 30% relative humidity and 72 degrees F temperature, (about 22.2 degrees C). Protection From Temperature and Humidity The greatest threats to a fine wood guitar are extremes of and rapid changes in temperature and humidity. High humidity can cause softening of the glues used in the construction of the instrument. Also, as the woods absorb moisture from the air, high humidity can cause the top and back, especially on flat-top and... - Page 6 When the instrument is not in use, we recommend that you keep it in its case and use one of the small guitar humidifiers such as “Dampit,” available from many instrument dealers. Do not leave the guitar out for long periods near a heating vent, radiator or in direct sunlight near a window. Do not leave your guitar in the trunk of a car for long periods and keep it away from excessive heat and cold. Please note: Damage caused to the guitar as the result of exposure to temperature or humidity changes will not be covered under the Guild warranty.
-
Page 7: Cracks In The Wood
Cracks in the wood, which occur as the result of exposure to temperature or humidity changes, will not be covered under the Guild warranty. Finish Checking Finish checking (very small splits in the finish), usually occurs in winter and is typically the result of suddenly exposing a cold instrument to the shock of warmer temperatures. -
Page 8: General Maintenance
Guild warranty. General Maintenance Clean the instrument after each use, making sure to wipe the fingerboard and strings, as well as any of the plated parts, i.e., machine heads, pickups, etc., with a... -
Page 9: Tuning Machines
Please note: Damage caused to the instrument by the use of non-Guild-approved polishes, cleaning materials or accessories will not be covered under the Guild warranty. Tuning Machines Guild uses only the finest tuning machines. These... -
Page 10: Tuning 6-String Guitars
Tuning 6-String Guitars There are a couple of different methods for tuning a guitar, depending on whether it is acoustic, electric or an acoustic with a pickup. If you don’t own an electronic chromatic tuner with a reference tone, you may want to purchase one. It will dramatically simplify tuning your acoustic or electric guitar. Always tune from below pitch up to the correct pitch instead of down from a higher pitch. This will help eliminate string slack from the tuning machine and decrease the possibility of slippage and tuning changes as you play. The strings should be tuned as follows, starting from the thickest string to the thinnest: E A D G B E. If you have an acoustic guitar, use the A-440 reference tone on your tuner, a guitar pitch pipe, an A-440 tuning fork or other pitch reference, and tune the second string (A) to pitch. Then depress the second (A) string at the 5th fret to produce a D, and tune the D string to that same pitch. Next, depress the D string at the 5th fret, to produce a G, and tune the G string until the pitches match. Then depress the G string at the 4th fret to produce a B, and tune the B string until the two pitches match. -
Page 11: Tuning 2-String Guitars
E A D G B E. Tuning 12-String Guitars Due to the tremendous amount of tension exerted on the neck by the 2 strings, we suggest that you use a light-gauge string set such as the Guild XL-000 or L-250 on your 2-string guitar. In standard 2-string tuning, the second string in each pair is tuned to the same pitch (E A D G B E) and using the same methods as the six-string tuning process on the previous page. For the E, A, D, and G strings, the first smaller string in each pair is tuned to the same note, but an octave higher in pitch than its partner. -
Page 12: Changing Strings
12-string tuned at standard pitch should be monitored regularly for pos- sible truss rod adjustment. If ignored, a guitar needing adjustment may develop permanent problems (see page 5). Please note: Warping of the neck caused by neglect of necessary adjustments will not be covered under the Guild warranty. Changing Strings A new set of strings can breathe renewed life into your instrument. That is why many “tone-conscious” touring professionals change their strings before every performance. While there is no set rule on how often to change strings, we have found that most players do not change them nearly as often as they should. - Page 13 When tuning a brand-new string, always bring it up to pitch slowly. Otherwise, the rapid stretching may cause the string to break. Re-Stringing The procedure for re-stringing acoustic guitars, electric guitars and basses is quite similar in the way the strings are wound onto the tuning machines. There are differences, though, in how the strings are attached to the bridges of acoustic and electric guitars. Guild flat-top acoustics have a pin-style bridge with holes and bridge pins to hold the strings in place. Guild jazz and electric guitars have a surface-mounted bridge or slotted tailpiece through which the strings are fed. To string a flat-top, remove the bridge pin and the old string, drop the ball end of the new string into the hole in the bridge, then re-insert the bridge pin to keep the string in place. Make sure that the bridge pin is positioned with the groove over the string. Do not hammer the bridge pin in. A firm push with the thumb will secure it in place.
- Page 14 Make sure that each string is seated well, stretched and snugged down on the tuning machine post. This will prevent slipping and prevent tuning problems later. Note: Never cut a string to length before putting it on your guitar and tuning it to pitch. Premature cutting may cause the string to unwrap and become useless. Crimp the string first, then clip near the machine head post. Illustration 1 String is passed through hole near top of string post.
-
Page 15: Truss Rod Adjustment
Truss Rod Adjustment String tension exerts a tremendous bending force on the guitar neck. Environmental conditions such as temperature and humidity may also cause bowing of the neck. Guild guitars have an adjustable truss rod (or dual truss rods on all Guild 2-strings) running the length of the neck that counteracts this force, strengthens the neck and ensures straightness. A truss rod that is too loose will result in a concave neck bow (action too high); a truss rod that is too tight will result in a convex neck bow (low action and fret buzz). - Page 16 Truss rod cover Illustration 4 Remove truss rod cover from headstock. Using /4 inch nut driver, turn rod nut gently.
-
Page 17: Adjustment Of Action
To lower the action on a flat-top or classical guitar, the bridge saddle must be removed, cut down to the appropriate height and then re-installed. To raise the action, the saddle must be removed and replaced by a new, higher saddle. Please note: These types of action adjustments on acoustic guitars should be performed only by an experienced and qualified repairman. A comprehensive Guild guitar setup guide, with detailed setup specifications, is available on the Guild website (www.guildguitars.com/resources). -
Page 18: Traveling With Your Guitar
Traveling With Your Guitar Guild guitars demonstrate the highest standards of quality in material and craftsmanship, and deserve only the best in protection. We recommend that you purchase a Guild factory guitar case that has been designed and fitted exclusively for your guitar to give it the utmost protection. Keep your guitar in its case when not playing it. If you plan to travel, carry your instrument in a hard-shell case at all times for protection. When traveling by air, your guitar may be exposed to dramatic changes in temperature and pressure. To help prevent possible damage, de-tune the strings approximately one whole step so that the tension is reduced from the guitar’s top and neck. Guild offers a variety of standard and deluxe cases for most guitar models. Please contact your local Guild dealer for more information or to place an order. When ordering your factory case, please specify the exact model of your guitar. -
Page 19: Limited Lifetime Warranty
Limited Lifetime Warranty Fender Musical Instruments Corporation warrants this Guild instrument to be free from defects in materials and workmanship for as long as it is owned by the original retail purchaser, except that pickups, switches, jacks, controls, all other electronic components, tuning machines, hardware, pickguards, plated surfaces, cases and case hardware are warranted for a period of one () year from the date of original purchase. This warranty applies only to the original retail purchaser when this instrument is purchased from an Authorized Guild Dealer and is subject to the limitations set forth herein. IMPORTANT: PLEASE RETAIN YOUR ORIGINAL SALES RECEIPT, AS IT IS YOUR PROOF OF PURCHASE VALIDATING THIS LIMITED WARRANTY. Fender has established a network of independent Authorized Service Centers for warranty service. The Guild dealer from whom you purchased your instrument may also be authorized for warranty service and should be the first point of contact when service of any kind is required for your Guild instrument. To receive warranty service, return the complete instrument to an Authorized Fender Service Center, with your sales receipt as proof of purchase, during the applicable warranty period. - Page 20 Defective components that qualify for coverage under this warranty will be repaired or replaced (at Fender’s discretion) without charge. Remedies beyond normal service repair of any Guild instrument require both an evaluation and confirmation of the defect and a direct recommendation to Fender from an Authorized Fender Service Center for alternative considerations. All transportation, insurance and freight charges associated with warranty service and repairs on Guild instruments are the responsibility of the purchaser, as is any service initiated for the purpose of customizing setups or adjustments beyond factory specifications. Initial standard setup and adjustment of the instrument and its components at the time of purchase are considered normal dealer product preparation, and are not covered by this warranty. Limitations and exclusions The following items are not covered by this warranty: . Fret wear, saddle wear, nut wear, strings and batteries. 2. Setups, adjustments or routine maintenance of any kind. 3. Damage to finishes or cracks, splitting, or...
- Page 21 6. Normal wear and tear on any part of the instrument or case including jacks, controls, switches, plated surfaces, tuning machines, pickguards, handles, latches, case hardware etc. 7. All other damage and deterioration due to normal usage, wear and tear, aging, accidents, neglect, abuse, or Acts of Nature. 8. Any instrument, whose serial number is missing, altered or tampered with in any fashion. 9. Any instrument purchased from anyone other than an Authorized Guild Dealer. 0. Instruments that have been serviced by unauthorized persons (any person other than a Fender Certified Technician at an Authorized Fender Service Center). THE FOREGOING CONSTITUTES THE ONLY WARRANTY MADE BY FENDER WITH RESPECT TO THE PRODUCTS AND IS MADE EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES EXPRESS OR IMPLIED. Any implied warranties, including without limitation, any implied warranties of merchantability or fitness for any particular purpose, imposed under state law are limited to the duration of this limited warranty.
- Page 22 FMIC ASSUMES NO LIABILITY FOR PROPERTY DAMAGE RESULTING FROM FAILURE OF THIS PRODUCT NOR ANY LOSS OF INCOME, SATISFAC- TION, OR DAMAGES ARISING FROM THE LOSS OF USE OF SAME DUE TO DEFECTS OR AVAILABILITY OF SAME DURING SERVICE. *This warranty applies only to Guild instruments purchased and serviced within the U.S.A. and Canada. Warranties outside these countries are as defined by the authorized Fender/Guild Distributor for your country or region, and may vary from the above in terms and/or length. Guild is a division of FMIC GUILD GUITARS 8860 EAST CHAPARRAL ROAD, SUITE 00 SCOTTSDALE, AZ 85250-268, U.S.A. Phone: (480) 596-9690 We cannot guarantee top performance of your instru- ment if strings other than Guild or their equivalent, are used. Upon request, we will be happy to send you a full catalog of all available Guild products.
-
Page 23: Servicing Your Guitar
If major service is required, please contact your local authorized Guild service center. If you need assistance locating an authorized Guild service center, please contact your Guild dealer, visit the Guild website (www.guildguitars.com) or call our Consumer Relations Department (480-596-795). For comprehensive Guild setup specifications, wiring diagrams, preamp manuals and other support documentation, visit the “resources” section of the Guild website (www.guildguitars.com/resources). Please note: Truss rod adjustments and action adjustments are considered routine maintenance and will not be covered under the Guild warranty. - Page 24 ©2007 GUILD GUITARS 8860 EAST CHAPARRAL ROAD, SUITE 00 SCOTTSDALE, AZ 85250-268, U.S.A. Printed in U.S.A, P/N 3507508 Rev. D...
