JVC KY-F70BU Quick Manual

1/2" c-mount 3-ccd high resolution sxga digital image capture with scsi output and live color preview

Hide thumbs Also See for KY-F70BU:

Download this manual

3-CCD SXGA Digital Imaging

4.35 million Effective Square Pixels

SXGA Native Picture Resolution

1360 x 1024 Square Pixels per CCD with

Progressive Scanning

3-CCD Color Accuracy (Prism-separated

R, G and B)

C-mount

1/2" C-MOUNT 3-CCD DIGITAL

CAMERA

KY-F70BU

High Resolution SXGA Digital Image

Capture with SCSI Output and Live

Color Preview

Live Color Preview on VGA Monitor

Direct Digital Interface to PC via SCSI-2

Designed to accommodate IR Applications

Long integration periods (Slow Shutter)

High Signal to Noise Ratio

IEC601-1 and UL-2601 Medical Approval

JVC Proprietary 'KY-SCSI' Bundled

Shown with optional lens

Page 1 1360 x 1024 Square Pixels per CCD with Designed to accommodate IR Applications Progressive Scanning Long integration periods (Slow Shutter) 3-CCD Color Accuracy (Prism-separated High Signal to Noise Ratio R, G and B) IEC601-1 and UL-2601 Medical Approval C-mount JVC Proprietary ‘KY-SCSI’ Bundled...
Page 2 Digital Image Capture: KY-F70BU via SCSI output ‘Zip’ drive is a registered trademark of Iomega. The KY-F70BU is an ultra-compact, multi-purpose 1360 x 1024 pixel resolution device for digital image capturing of three dimensional objects seen through scopes and lenses. Its C-mount attachment provides ready attachment to a very wide range of industrial and medical scopes, as well as lenses and other imaging apparatus.
Page 3 JVC Images captured to a PC may be processed and ‘KY-SCSI’ (bundled). manipulated in application software such as JVC ‘KY-SCSI’ provides all control for KY-F70BU. Photoshop ® The Preview Mode is live color but without full To run this system, the JVC camera remote motion.
Page 4: Specifications
AA-P700U (General use) Design and specifications subject to change without notice. DISTRIBUTED BY JVC PROFESSIONAL PRODUCTS COMPANY DIVISION OF JVC AMERICAS CORP. 1700 Valley Road, Wayne, N.J. 07470 TEL: (973) 315-5000, (800) 582-5825 FAX: (973) 315-5030 I The Hachioji Plant of Victor Company of Japan, Ltd., has received ISO14001 Certification Internet Web Site http://www.jvc.com/pro...
