- Page 1 NS2522 115 34 40-10 (002) OWNER’S MANUAL POWER SPRAYER NS2522 Original Language GB-1...
- Page 2 COUNCIL’S DIRECTIVE. The products referred to are : DESIGNATION : Power sprayer MANUFACTURER : Husqvarna Zenoah Co., Ltd. MODELS : NS2522 SERIAL NUMBERS DATING : 2010 and onwards (The year is cleary stated on the rating plate,...
-
Page 3: Table Of Contents
NS2522 SAFETY PRECAUTIONS Contents Warning labels bearing the mark on the product and in this Manual refer to important safety matters. Please familiarize your- 1. Parts location ..........3 self with them and observe them well. If a warning label on the product becomes soiled or detached, 2. -
Page 4: Specification
21.7 Fuel used Lubricating oil/gasoline mix Lubricating oil used 2-cycle engine oil Admixture ratio Gasoline 50 : Oil 1 (when using ZENOAH genuine oil) Carburetor Diaphragm, rotary valve type Ignition system Electronic controlled flywheel magnet type Spark plugs NGK BPMR7A... -
Page 5: For Safe Operation
NS2522 5. For safe operation Before using this product, please read this Operator's • When using for the first time, before commencing Manual thoroughly to ensure correct operation. The fol- actual spraying please receive guidance in operat- lowing are precautions that should be observed in order ing the product from a person with adequate experi- to use the product smoothly. - Page 6 NS2522 5. For safe operation IMPORTANT PRECAUTIONS WHEN TRANSPORTING THE SPRAYER Check and follow the local regulations as to sound • Do not transport the sprayer while it has chemicals or level and hours of operations for the product. fuel in the tank, as these could leak out as a result of impact during transportation.
- Page 7 Manual are required, please con- another similar method. In addition, please take ev- sult your product supplier or nearest ZENOAH prod- ery care that the water used to clean spraying tools uct dealer.
-
Page 8: Set Up
NS2522 6. Set up A Package contains the items as illustrated. (1) Unit (2) Spray rod (3) Cock (4) Grip (5) Joint (6) Spray hose (7) Rod (8) Plug wrench (S13/S19) with phillips screw driver (9) Mix tank (10) Owner’s manual... - Page 9 6. Set up ■ Connecting the spray hose and nozzle ■ Adjusting spray pressure • NS2522 has a pressure regulating dial to change spray pressure. Set the pressure at a level appropri- ate to the spray conditions. Set the pressure regulating dial as follows: •...
-
Page 10: Fuel
• The Zenoah engines are lubricated by oil specially WARNING formulated for air-cooled 2-cycle gasoline engine use. If Zenoah oil is not available, use an anti-oxidant added 1. Select bare ground for fueling. quality oil expressly labeled for air-cooled 2-cycle 2. -
Page 11: Chemical Filling
NS2522 8. Chemical filling ■ Procedure for filling WARNING 1. Use a bucket or other suitable container and dilute • Chemical substances should be handled correctly, the chemical to the requisite strength. observing the precautions marked on the container. 2. Place the sprayer on an even and stable surface and Some chemicals are extremely hazardous to humans remove the chemical tank cap. - Page 12 NS2522 9. Operation ■ Spraying 3. Place the sprayer in a stable location, and pull the starter knob with the right hand while holding the chemical tank down with the left hand. The starter knob WARNING should first be pulled out lightly, then, when resistance is felt, pulled more swiftly and vigorously.
-
Page 13: Maintenance
• Do not modify the sprayer or dismantle the engine. • When replacing parts please use Zenoah original parts or designated parts. ■ Air cleaner • After every 25 hours of operation, please remove the air cleaner cover and inspect the element. - Page 14 NS2522 10. Maintenance • When replacing plugs, please use designated items. NOTE • Warm up the engine before adjusting the idling speed. • Throttle wire play Throttle wire play should be 1 to 2 mm. After com- pletely returning the throttle lever, take the throttle wire...
-
Page 15: Storage
→ clogged with dust → wash cylinder fin, fan cover → clogged with dust → consult with the repair specialty store ® When your unit seems to need further service, please consult with our ZENOAH service shop in your area. GB-15... -
Page 16: Disposal
STRUCTION LISTED IN THE OWNER/OPERATOR MANUAL THE PURCHASER SHALL BEAR COSTS OF TRANS- FOR PROPER USE AND MAINTENANCE OF THE UNITS PORTING THE UNIT TO AND FROM THE ZENOAH DEALER. ACCIDENT MISHANDLING, ALTERATION, ABUSE, IM- PROPER LUBRICATION, USE OF ANY PARTS OR ACCES-...
