All-in-one connectivity with DIGITAL LINK-ready Panasonic projectors
Digital Interface Box
ET-YFB100G (optional)
Compatible projector: PT-VW431DU
The compact body enables easy and
space-saving installation.
[Mounting brackets attached]
Easy wireless projection with wireless-ready Panasonic projectors
Easy Wireless Stick
ET-UW100 (optional)
Compatible projectors: PT-VW435NU/VX505NU/VX400NTU
Easy Wireless
Stick*
1
for high ceilings*
ET-UW100
VW435NU
VX505NU
VX400NTU
—
Specifications
Power supply
Power consumption
(use with supplied AC adaptor)
AC adapter
Scanning frequency
Terminals
Dimensions (W x H x D)
Weight
Operating environment
Supplied accessories
*1 Supported only when the signals are compliant with VESA CVT-RB.
*2 Average value. May differ depending on models.
Specifications
Dimensions
Weight
Operating environment
For more information, please visit
Ceiling mount
Ceiling mount
bracket
bracket
2
for low ceilings*
ET-PKV100H
ET-PKV100S
DC 16 V (DC input terminal)
16 W [0.2 W with the power off]
(including power consumption of the AC adaptor)
Input
100-240 V AC, 50/60 Hz
Output
DC 16 V, 3.75 A
HDMI
f
: 27-99 kHz, f
H
RGB (analog)
f
: 15.6-99 kHz, f
H
f
: 15.75 kHz, f
H
f
: 31.50 kHz, f
H
f
: 45.00 kHz, f
H
YP
P
(YC
C
)
f
: 33.75 kHz, f
B
R
B
R
H
f
: 28.13 kHz, f
H
f
: 33.75 kHz, f
H
f
: 56.25 kHz, f
H
f
: 15.75 kHz, f
H
Video/S-Video
f
: 15.63 kHz, f
H
HDMI 19-pin x 2 (Deep Color, compatible with HDCP)
480p, 576p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/24p, 1080/25p, 1080/30p, 1080/60p,
HDMI IN
1080/50p, VGA (640 x 480)-WUXGA*
audio signal: linear PCM (sampling frequencies: 48 kHz, 44.1 kHz, 32 kHz)
COMPUTER IN
D-sub HD 15-pin (female) x 2 (RGB/YP
VIDEO IN
RCA pin x 1 (Composite VIDEO)
S-VIDEO IN
Mini DIN 4-pin x 1 (S-VIDEO)
AUDIO IN
M3 (L-R) x 1
AUDIO OUT
M3 (L-R) x 1 (variable)
SERIAL IN
D-sub 9-pin (female) x 1 for external control (RS-232C compliant)
REMOTE IN
D-sub 9-pin (female) x 1 for external control (parallel)
LAN
RJ-45 x 1, for network connection, 10Base-T/100Base-TX
DIGITAL LINK
RJ-45 x 1, for DIGITAL LINK connection (video, audio and control signals)
8-9/32" x 1-23/32" x 9-27/32" (210 x 44 x 250 mm) (not including protruding parts)
Approximately 2.54 lbs (1.15 kg)*
Operating temperature: 32-104 °F (0-40 °C)
Operating humidity: 20-80 % (no condensation)
AC adaptor x 1, power cords (6.6 feet) x 3, AC power cord holder x 1,
AC power cord holder screw x 1, mounting brackets for rack or countertop installation x 2,
mounting bracket for rack installation x 1, countersunk screws x 6, legs x 4,
screws for installing legs x 4
1-3/7" x 3-2/3" x 2/5"
(36 x 93 x 10 mm) (not including protective cap)
Approximately 0.04 lbs (20 g) (not including protective cap)
Operating temperature: 32-95 °F (0-35 °C)
Operating humidity: 20-80 % (no condensation)
