Page 2
• NEVER USE STROLLER ON STAIRS or escalators. You may suddenly lose control of the stroller or your child may fall out. Also, use extra care when going up or down a step or curb. • STROLLER TO BE USED only at walking speed.
Page 3
(See figure 34-36 Enclosure). USING GRACO INFANT CAR ® SEAT WITH STROLLER: • USE ONLY A GRACO SNUGRIDE OR INFANT ™ SAFESEAT ™ CAR SEAT with this travel system. (Not intended for...
Page 4
Manquer de suivre ces avertissements et les instructions d'assemblage peut entraîner de sérieuses blessures ou un décès. • VEUILLER GARDER LE MANUEL D’UTILISATEUR POUR USAGE ULTÉRIEUR. • ASSEMBLAGE PAR UN ADULTE REQUIS. • NE LAISSEZ JAMAIS votre enfant sans surveillance. Ayez toujours l’enfant en vue.
Page 5
• LISEZ LE MANUEL d'utilisateur fournit avec votre porte-bébé Graco avant d'utiliser le porte-bébé avec votre poussette. • TOUJOURS ATTACHER votre enfant avec le harnais du porte-bébé quand vous utilisez le porte-bébé...
Page 6
Si no se obedecen estas advertencias y se siguen las instrucciones de montaje, podría resultar en lesiones graves o la muerte. • POR FAVOR, CONSERVELO EL MANUEL DEL PROPIETARIO PARA UTILIZARLO EN EL FUTURO. • SE REQUIERE MONTAJE POR UN ADULTO. •...
Page 7
• LEA EL MANUAL provisto con su transportador Graco antes de usarlo con su cochecito. • ASEGURE SIEMPRE a su bebé con el arnés del...
Page 8
Parts list • Liste des pièces • Lista de las piezas This model may not Ce modèle pourrait ne Este modelo podría no pas inclure certaines incluir algunas de las include some caractéristiques illustrée características que se features shown below. Check that ci-dessous.
Page 9
To Open Stroller • Ouvrir la poussette • Abrir el cochecito WARNING Retirez l'attache et jetez- Remove and la IMMÉDIATEMENT. IMMEDIATELY discard the zip tie. Carton • Boîte • Caja ENCLENCHEZ! ¡CHASQUIDO! MISE EN GARDE Ziptie L’attache Cordón Rotate handle up from storage position by pushing in buttons.
Page 10
Basket • Le panier • La canasta SNAP! ENCLENCHEZ! ¡CHASQUIDO!
Page 11
Front Wheels • Les roues avant • Las ruedas delanteras SNAP! ENCLENCHEZ! ¡CHASQUIDO! Turn stroller over. Pull sleeve back to reveal metal button. Retournez la poussette. Retirez l'enveloppe pour révéler le bouton métallique. Vuelque el cochecito. Retire el manguito para ver el botón metálico.
Page 12
Rear Wheel/Rear Axle • Les roues arrières/L’essieu arrière • Las ruedas traseras/El eje trasero WARNING MISE EN GARDE Choking Hazard: Danger d'étranglement: Remove and enlevez et jetez immediately immédiatement les discard plastic embouts de plastique end caps on the sur l'essieu arrière. rear axle.
Page 13
BEFORE attaching wheel: Be sure to place stroller on top of a piece of cardboard or some other protective cover to prevent any damage to floor. AVANT de fixer la roue: Assurez-vous de placer la poussette sur un morceau de carton ou un autre revêtement de protection pour prévenir tout dégât au plancher.
Page 14
Always secure your child with the seat belt. The tray is not a restraint device. Use care when snapping the tray on the stroller with a child in the stroller. MISE EN GARDE Toujours attaché votre enfant avec la ceinture de retenue.
Page 15
SNAP! ENCLENCHEZ! ¡CHASQUIDO! To open tray. Pour ouvrir le plateau. Para abrir la bandeja.
Page 16
Canopy • Le baldaquin • La capota Fasten hook/loop tape and snaps as shown. Attachez la fermeture auto-agrippante et les bouton-pressions tel qu’illustré. Sujete la cinta del gancho y nudo y los broches como se indica. ENCLENCHEZ! ¡CHASQUIDO! SNAP!
Page 17
Parent Tray • Le plateau pour adulte • Bandeja para padres Open canopy. Ouvrez le baldaquin. Abra la capota. ENCLENCHEZ! ¡CHASQUIDO! To remove tray. Pour retirer le plateau. Para sacar la bandeja. SNAP!
Page 19
Vérifiez que les that brakes are freins fonctionnent en on by trying to essayant de pousser push stroller. la poussette. Swivel Wheels • Les roues pivotantes • Las ruedas giratorias MISE EN GARDE Front swivel wheels lock for use on uneven surfaces such as grass, stones or gravel.
Page 20
To Secure Child • Attacher l’enfant • Para asegurar al niño 5 Point Harness • Harnais à 5 point • Arnés de 5 puntos To adjust harness. To change shoulder harness slots see page 22. Pour ajuster le harnais. Pour changer des fentes de harnais d'épaule voir la page 22.
Page 21
3 Point Buckle • Boucle à 3 point • Hebilla de 3 puntos To convert to 3-pt buckle. Pour convertir en boucle à 3-points. Para convertirlo en un hebilla de 3 puntos.
Page 22
To Change Shoulder Harness Slots • Pour changer des dentes de harnais d'épaule • Para cambiar ranuras del arnés del hombro Shoulder harness anchor—larger child Harnais d 'ancrage à l 'épaule pour grand enfant Anclaje del arnés del hombro - niño grande Shoulder harness anchor—smaller child Harnais d 'ancrage à...
Page 23
• Para reclinar el asiento WARNING When making Lorsque vous faites des adjustments to the ajustements au siège de stroller seat, make la poussette, s'assurer sure child’s head, que la tête de l'enfant, arms, and legs are les bras, et les jambes clear of moving soient dégagés des...
Page 24
Enceinte qui se remonte WARNING Do not use Ne pas utiliser enceinte enclosure with an qui se remonte avec un older child that enfant plus âgé qui peut can lift up on se remonter sur ses hands and knees mains et ses genoux ou or crawl out.
Page 25
Lorsque le siège est utilisé avec la poussette en position abaissée, l'enveloppe à pression doit être remontée à l'avant du siège. Consulter les mises en garde et directives dans le manuel du propriétaire. Pour ouvrir: Retirer l'appuie-tête (sur certains modèles). Ne jamais utiliser d'appui-tête avec la poussette en position abaissée.
Page 26
To Fold Stroller • Plier la poussette • Para plegar el cochecito ...
Page 27
To Attach Graco ® Infant Car Seat • Pour fixer le dispositif de retenue pour bébé Graco ® • Cómo instalar el asiento de automóvil For models that do not come with an infant car seat one may be purchased separately.
Page 28
ASSURA.) Si no está seguro del modelo o para obtener más información, por favor llame al número de servicio al cliente de Graco: 1-800-345-4109. El uso inadecuado de este cochecito con asientos para automóvil de otros fabricantes podría resultar en lesiones serias o la muerte.
Page 29
SNAP! ENCLENCHEZ! ¡CHASQUIDO! • Snap carseat onto child’s tray. • Verrouiller le siège d'auto au plateau pour enfant. • Instale el asiento para automóvil en la bandeja del niño.
Page 30
• Push carrier down so it is below latches on stroller handle as shown. Turn and lock latches. ALWAYS LOCK LATCHES OVER CARRIER. • Check that carrier is securely attached by pulling up on the carrier handle. • Appuyez sur le porte-bébé vers le bas pour qu’il soit en-dessous des loquets de sûreté...
Page 31
• To remove carrier: unlock latches above carrier, squeeze release handle at back of carrier, and lift carrier out of the stroller. When carrier is not in use, latches should be in unlocked position, away from baby. • Pour enlever le porte-bébé, déverrouillez les loquets de sûreté...
• REMOVABLE SEAT PAD (if so equipped) may be machine washed in cold water on delicate cycle and drip-dried. NO BLEACH. • TO CLEAN STROLLER FRAME, use only household soap and warm water. NO BLEACH or detergent. • FROM TIME TO TIME CHECK YOUR STROLLER for loose screws, worn parts, torn material or stitching.
Page 33
• DE TEMPS EN TEMPS, VÉRIFIEZ VOTRE POUSSETTE pour des vis desserrées, pièces usagées, tissu ou couture déchiré. Remplacez ou réparez ces pièces si nécessaire. Utilisez seulement les pièces de remplacement Graco. • UNE EXPOSITION PROLONGÉE AU SOLEIL peut provoquer une décoloration prématurée du tissu et du plastique.
Cambie o repare las piezas según sea necesario. Use solamente repuestos marca Graco. • EL CONTACTO EXCESIVO CON EL SOL o el calor podría causar que se destiña o se tuerzan algunas piezas.
Page 36
Pour inscrire votre produit Graco aux États-Unis, visitez notre site Internet www.gracobaby.com/productregistration. Pour le moment nous n’acceptons pas d’inscriptions de produits des Para registrar su producto Graco desde los EE.UU., visítenos en línea en www.gracobebe.com/productregistration. Actualmente no aceptamos el registro de productos de personas que viven fuera de los Estados Unidos de América.
Page 38
• NEVER USE STROLLER ON STAIRS or escalators. You may suddenly lose control of the stroller or your child may fall out. Also, use extra care when going up or down a step or curb. • STROLLER TO BE USED only at walking speed.
Page 39
(See figure 34-36 Enclosure). USING GRACO INFANT CAR ® SEAT WITH STROLLER: • USE ONLY A GRACO SNUGRIDE OR INFANT ™ SAFESEAT ™ CAR SEAT with this travel system. (Not intended for...
Page 40
Manquer de suivre ces avertissements et les instructions d'assemblage peut entraîner de sérieuses blessures ou un décès. • VEUILLER GARDER LE MANUEL D’UTILISATEUR POUR USAGE ULTÉRIEUR. • ASSEMBLAGE PAR UN ADULTE REQUIS. • NE LAISSEZ JAMAIS votre enfant sans surveillance. Ayez toujours l’enfant en vue.
Page 41
• LISEZ LE MANUEL d'utilisateur fournit avec votre porte-bébé Graco avant d'utiliser le porte-bébé avec votre poussette. • TOUJOURS ATTACHER votre enfant avec le harnais du porte-bébé quand vous utilisez le porte-bébé...
Page 42
Si no se obedecen estas advertencias y se siguen las instrucciones de montaje, podría resultar en lesiones graves o la muerte. • POR FAVOR, CONSERVELO EL MANUEL DEL PROPIETARIO PARA UTILIZARLO EN EL FUTURO. • SE REQUIERE MONTAJE POR UN ADULTO. •...
Page 43
• LEA EL MANUAL provisto con su transportador Graco antes de usarlo con su cochecito. • ASEGURE SIEMPRE a su bebé con el arnés del...
Page 44
Parts list • Liste des pièces • Lista de las piezas This model may not Ce modèle pourrait ne Este modelo podría no pas inclure certaines incluir algunas de las include some caractéristiques illustrée características que se features shown below. Check that ci-dessous.
Page 45
To Open Stroller • Ouvrir la poussette • Abrir el cochecito WARNING Retirez l'attache et jetez- Remove and la IMMÉDIATEMENT. IMMEDIATELY discard the zip tie. Carton • Boîte • Caja ENCLENCHEZ! ¡CHASQUIDO! MISE EN GARDE Ziptie L’attache Cordón Rotate handle up from storage position by pushing in buttons.
Page 46
Basket • Le panier • La canasta SNAP! ENCLENCHEZ! ¡CHASQUIDO!
Page 47
Front Wheels • Les roues avant • Las ruedas delanteras SNAP! ENCLENCHEZ! ¡CHASQUIDO! Turn stroller over. Pull sleeve back to reveal metal button. Retournez la poussette. Retirez l'enveloppe pour révéler le bouton métallique. Vuelque el cochecito. Retire el manguito para ver el botón metálico.
Page 48
Rear Wheel/Rear Axle • Les roues arrières/L’essieu arrière • Las ruedas traseras/El eje trasero WARNING MISE EN GARDE Choking Hazard: Danger d'étranglement: Remove and enlevez et jetez immediately immédiatement les discard plastic embouts de plastique end caps on the sur l'essieu arrière. rear axle.
Page 49
BEFORE attaching wheel: Be sure to place stroller on top of a piece of cardboard or some other protective cover to prevent any damage to floor. AVANT de fixer la roue: Assurez-vous de placer la poussette sur un morceau de carton ou un autre revêtement de protection pour prévenir tout dégât au plancher.
Page 50
Always secure your child with the seat belt. The tray is not a restraint device. Use care when snapping the tray on the stroller with a child in the stroller. MISE EN GARDE Toujours attaché votre enfant avec la ceinture de retenue.
Page 51
SNAP! ENCLENCHEZ! ¡CHASQUIDO! To open tray. Pour ouvrir le plateau. Para abrir la bandeja.
Page 52
Canopy • Le baldaquin • La capota Fasten hook/loop tape and snaps as shown. Attachez la fermeture auto-agrippante et les bouton-pressions tel qu’illustré. Sujete la cinta del gancho y nudo y los broches como se indica. ENCLENCHEZ! ¡CHASQUIDO! SNAP!
Page 53
Parent Tray • Le plateau pour adulte • Bandeja para padres Open canopy. Ouvrez le baldaquin. Abra la capota. ENCLENCHEZ! ¡CHASQUIDO! To remove tray. Pour retirer le plateau. Para sacar la bandeja. SNAP!
Page 55
Vérifiez que les that brakes are freins fonctionnent en on by trying to essayant de pousser push stroller. la poussette. Swivel Wheels • Les roues pivotantes • Las ruedas giratorias MISE EN GARDE Front swivel wheels lock for use on uneven surfaces such as grass, stones or gravel.
Page 56
To Secure Child • Attacher l’enfant • Para asegurar al niño 5 Point Harness • Harnais à 5 point • Arnés de 5 puntos To adjust harness. To change shoulder harness slots see page 22. Pour ajuster le harnais. Pour changer des fentes de harnais d'épaule voir la page 22.
Page 57
3 Point Buckle • Boucle à 3 point • Hebilla de 3 puntos To convert to 3-pt buckle. Pour convertir en boucle à 3-points. Para convertirlo en un hebilla de 3 puntos.
Page 58
To Change Shoulder Harness Slots • Pour changer des dentes de harnais d'épaule • Para cambiar ranuras del arnés del hombro Shoulder harness anchor—larger child Harnais d 'ancrage à l 'épaule pour grand enfant Anclaje del arnés del hombro - niño grande Shoulder harness anchor—smaller child Harnais d 'ancrage à...
Page 59
• Para reclinar el asiento WARNING When making Lorsque vous faites des adjustments to the ajustements au siège de stroller seat, make la poussette, s'assurer sure child’s head, que la tête de l'enfant, arms, and legs are les bras, et les jambes clear of moving soient dégagés des...
Page 60
Enceinte qui se remonte WARNING Do not use Ne pas utiliser enceinte enclosure with an qui se remonte avec un older child that enfant plus âgé qui peut can lift up on se remonter sur ses hands and knees mains et ses genoux ou or crawl out.
Page 61
Lorsque le siège est utilisé avec la poussette en position abaissée, l'enveloppe à pression doit être remontée à l'avant du siège. Consulter les mises en garde et directives dans le manuel du propriétaire. Pour ouvrir: Retirer l'appuie-tête (sur certains modèles). Ne jamais utiliser d'appui-tête avec la poussette en position abaissée.
Page 62
To Fold Stroller • Plier la poussette • Para plegar el cochecito ...
Page 63
To Attach Graco ® Infant Car Seat • Pour fixer le dispositif de retenue pour bébé Graco ® • Cómo instalar el asiento de automóvil For models that do not come with an infant car seat one may be purchased separately.
Page 64
ASSURA.) Si no está seguro del modelo o para obtener más información, por favor llame al número de servicio al cliente de Graco: 1-800-345-4109. El uso inadecuado de este cochecito con asientos para automóvil de otros fabricantes podría resultar en lesiones serias o la muerte.
Page 65
SNAP! ENCLENCHEZ! ¡CHASQUIDO! • Snap carseat onto child’s tray. • Verrouiller le siège d'auto au plateau pour enfant. • Instale el asiento para automóvil en la bandeja del niño.
Page 66
• Push carrier down so it is below latches on stroller handle as shown. Turn and lock latches. ALWAYS LOCK LATCHES OVER CARRIER. • Check that carrier is securely attached by pulling up on the carrier handle. • Appuyez sur le porte-bébé vers le bas pour qu’il soit en-dessous des loquets de sûreté...
Page 67
• To remove carrier: unlock latches above carrier, squeeze release handle at back of carrier, and lift carrier out of the stroller. When carrier is not in use, latches should be in unlocked position, away from baby. • Pour enlever le porte-bébé, déverrouillez les loquets de sûreté...
Page 68
• REMOVABLE SEAT PAD (if so equipped) may be machine washed in cold water on delicate cycle and drip-dried. NO BLEACH. • TO CLEAN STROLLER FRAME, use only household soap and warm water. NO BLEACH or detergent. • FROM TIME TO TIME CHECK YOUR STROLLER for loose screws, worn parts, torn material or stitching.
Page 69
• DE TEMPS EN TEMPS, VÉRIFIEZ VOTRE POUSSETTE pour des vis desserrées, pièces usagées, tissu ou couture déchiré. Remplacez ou réparez ces pièces si nécessaire. Utilisez seulement les pièces de remplacement Graco. • UNE EXPOSITION PROLONGÉE AU SOLEIL peut provoquer une décoloration prématurée du tissu et du plastique.
Page 70
Cambie o repare las piezas según sea necesario. Use solamente repuestos marca Graco. • EL CONTACTO EXCESIVO CON EL SOL o el calor podría causar que se destiña o se tuerzan algunas piezas.
Page 72
Pour inscrire votre produit Graco aux États-Unis, visitez notre site Internet www.gracobaby.com/productregistration. Pour le moment nous n’acceptons pas d’inscriptions de produits des Para registrar su producto Graco desde los EE.UU., visítenos en línea en www.gracobebe.com/productregistration. Actualmente no aceptamos el registro de productos de personas que viven fuera de los Estados Unidos de América.
1.0 Warnings to Parents and Other Users No infant restraint can guarantee protection from injury in every situation. However, proper use of this infant restraint reduces the risk of serious injury or death to your child. Failure to properly use this infant restraint increases the risk of serious injury or death in a sharp turn, sudden stop or crash.
Page 77
5. Properly routing the vehicle seat belt or LATCH. 6. Properly reclining the infant restraint. 7. Properly securing the infant restraint in the vehicle using a seat belt designed to restrain an infant restraint or by using LATCH. Many seat belts are NOT safe to use with infant restraints, even though they can easily be threaded through the infant restraint!
Graco Children’s Products Inc. 150 Oaklands Blvd. Exton, PA 19341 or call 1-800-345-4109 or www.gracobaby.com 2.2 Recall Information • Call the U.S. Government’s Auto Safety Hotline at 1-800-424-9393 (202-366-0123 in D.C. area) • www.nhtsa.dot.gov • Graco: 1-800-345-4109 or www.gracobaby.com...
2.3 If You Need Help In the U.S.A. or Canada, please contact our Customer Service Department with any questions you may have concerning parts, use, or maintenance. When you contact us, please have your product’s model and serial numbers ready so that we may help you efficiently.
3.0 Features and Components Each model of the infant restraint comes with different harness options. To adjust your infant restraint properly, it is very important to follow the instructions that are appropriate for the model you have purchased. 3-Point Harness 5-Point Harness Vehicle belt/LATCH* path LATCH...
3.1 3-Point Harness Model FRONT VIEW: 3-POINT HARNESS Harness Handle slots Handle adjustment Harness button clip Vehicle belt hook Harness Harness straps buckle...
Page 82
REAR VIEW: 3-POINT HARNESS Harness tightener Level indicator* Owner’s manual pocket *Level Indicator **Locking Clip Locking clip** The level indicator is attached to the side of the infant restraint, and indicates whether or not the infant restraint is properly reclined. The locking clip is stored on the bottom of the infant restraint.
3.2 5-Point Harness Model FRONT VIEW: 5-POINT HARNESS Handle Harness slots Harness Handle clip adjustment button Harness buckle Vehicle Harness belt adjustment hook button Harness buckle tongues Harness adjustment strap...
Page 84
REAR VIEW: 5-POINT HARNESS Level indicator* Owner’s manual pocket Metal junction plate *Level Indicator **Locking Clip The level indicator is attached to the side of the infant restraint, and indicates whether or not the infant restraint is properly reclined. The locking clip is stored on the bottom of the infant restraint.
3.3 Removing and Attaching Base To remove infant restraint, squeeze handle at back of seat and lift infant restraint from base as shown To put infant restraint in base, push infant restraint down until it clicks into base. Pull up on infant restraint to be sure it is latched firmly into base.
3.5 Attaching Canopy (on certain models) 1. Infant restraint comes with four (two on certain models) identical canopy support parts. Thread one canopy support completely through one sewn tunnel 2. Slide straight end of a second support into the straight end of the first support 3.
3.6 Head Support (on certain models) Some infants may need extra support to keep their head and body in a comfortable position. Unsnap the sides and resnap them with the harness straps threaded through the slots in the cushion If your model does not include a head support, you may want to use a rolled towel or a blanket for support...
4.0 Important Information 4.1 Warnings for Use as Infant Restraint • DO NOT INSTALL OR USE THIS INFANT RESTRAINT AND BASE UNTIL YOU READ AND UNDERSTAND THE INSTRUCTIONS IN THIS MANUAL AND IN YOUR VEHICLE OWNER’S MANUAL. DO NOT let others install or use the infant restraint unless they understand how to use it.
Page 89
• SOME SPECIAL NEEDS CHILDREN, such as pre-term babies or those who have tested positive for positional apnea, may be at increased risk of suffering breathing or other difficulties in an infant restraint. If your child has special needs, we recommend that you have your physician or hospital staff evaluate your child and recommend the proper infant restraint or car bed before using this product.
If you do not have an instruction sheet, please call toll-free, 1-800-345-4109 to obtain one, or visit our website, www.gracobaby.com. • Improper use of Graco’s infant car seat with other manufacturer’s strollers may result in serious injury or death.
4.3 Additional Warnings for Use as Carrier • FALL HAZARD: Child’s movements can slide carrier. NEVER place carrier near edges of countertops, tables or other high surfaces. Always stay within arms reach whenever carrier is not on floor/ground. BE SURE handle locks into position before lifting carrier. NEVER place carrier in the top of a shopping cart.
4.4 Height and Weight Limits FAILURE TO USE INFANT RESTRAINT IN A MANNER APPROPRIATE FOR YOUR CHILD’S SIZE MAY INCREASE THE RISK OF SERIOUS INJURY OR DEATH. Your child MUST meet all requirements: • WEIGHT: 5-22 lbs (2.3-10 kg) • HEIGHT: 29 inches (73 cm) or less...
If you are not sure where to place the infant restraint in your vehicle, consult your vehicle owner’s manual or call Graco at 1-800-345-4109. • Whenever possible, secure the infant restraint in the center position of the...
Pay careful attention to these systems; some of the seat belts that are not safe to use look very much like seat belts that are safe to use. If you are unsure, consult your vehicle owner’s manual or Graco at 1-800-345-4109.
5.2.1 UNSAFE DO NOT use any of the following systems to secure the infant restraint. LATCH can be used IN PLACE OF the vehicle belt system. Please refer to vehicle owners manual for LATCH locations. • Lap Belts with Emergency Locking Retractor (ELR) This lap belt stays loose and can move until it locks in a crash or sudden stop.
5.2.2 SAFE THE FOLLOWING BELT SYSTEMS CAN BE USED WITH YOUR INFANT RESTRAINT, IF the seat location meets all other requirements of these instructions and those in your vehicle owner's manual. LATCH can be used in place of the vehicle belt system. Please refer to vehicle owners manual for LATCH locations.
Page 97
• Combination Lap/Shoulder Belt with Sliding Latch Plate This belt has a latchplate that slides freely along the belt. This belt MUST be converted to prevent movement of the lap portion of the belt. You must use the locking clip provided with the infant restraint, unless your vehicle's seat belt can be converted in another way as described in your vehicle owner's manual.
5.3 LATCH locations Newer vehicles may have one or more seating positions with LATCH anchorage systems. If vehicle is equipped with LATCH, the vehicle lower anchor points may be visible at the vehicle seat crease. If not visible, they may be marked with the symbol See your vehicle owner’s manual for exact locations, anchor identification, and requirements for use with an infant restraint.
6.0 Using Infant Restraint 6.1 Positioning Harness Straps FAILURE TO PROPERLY ADJUST THE HARNESS STRAPS FOR YOUR CHILD INCREASES THE RISK OF SERIOUS INJURY OR DEATH IN THE EVENT OF A SHARP TURN, SUDDEN STOP OR CRASH. The harness straps must be properly adjusted to fit your child according to the following instructions.
6.1.1 3-Point Harness 1. From back, push harness anchor buckle back through harness slot. If necessary, from front, use harness strap to pull buckle from slot 2. Reinsert harness anchor buckle in the appropriate slot 3. From back, remove harness strap from harness tightener.
6.1.2 5-Point Harness 1. Depress the harness adjustment button under the seat flap straps out to loosen the harness. 2. Behind seat, remove the ends of the two shoulder straps from the metal junction plate 3. From front, pull straps through the harness slots and then reinsert them through the appropriate slots.
Page 102
FOR SMALLER BABY: Use the lower harness slots (if they are even with or just below your child’s shoulders) and the upper strap loops . The ends of the straps must hang in front of the metal plate as shown , not as shown in CHECK that the loops are completely within junction plate slots...
6.2 Securing Child in Infant Restraint Failure to properly secure your child in the infant restraint/carrier increases the risk of serious injury or death from suffocation or falls, or in the event of a sudden stop or crash. Even when used only as a carrier, make sure the harness straps are properly secured.
5. Buckle harness to the latch between child’s legs. Make sure that you hear a “click.” DO NOT use the infant restraint if the harness does not latch in place. Call Graco at 1-800-345-4109. 6. From the back, pull strap through harness tightener to tighten the straps as shown .
Make sure that you hear each tongue click into the buckle. DO NOT use the infant restraint if the harness does not latch in place. Call Graco at 1-800-345-4109. 6. Snap harness clip pieces together 7. Pull on harness adjustment strap to tighten straps as shown straps are flat and tight on shoulders.
6.3 Installing the Infant Restraint/Base Using Vehicle Belt You must carefully follow the instructions provided by your vehicle manufacturer, in addition to the information in this manual. Be sure you have read and understood section 5, “Infant Restraint Location” on p.21-26. Make sure vehicle is on level ground so that the level indicator, which is attached to the infant restraint, can be used to properly...
Page 107
3. Thread the seat belt: Base with seat belt Belt MUST go under tongue Infant restraint with seat belt 4. Buckle the seat belt. Make sure the buckle tongue goes into the correct buckle be twisted or turned. . The seat belt should not...
Page 108
5. Tighten the vehicle seat belt. Refer to your vehicle owners manual and the instructions in “5.2.2 SAFE Vehicle Belt Systems”, p. 24-25, on tightening your vehicle belt. To create a very tight installation, push down hard with your knee or free hand in the middle of the infant restraint or base and pull and tighten the vehicle belt.
Using LATCH to install Base For ease of installation, extend LATCH to its maximum length. Position base in vehicle seat as shown. 3. Thread LATCH through base belt path normally used for vehicle seat belt. Make sure that LATCH is UNDER tongue on base Belt must lay flat and not be twisted.
6.5 Reclining Infant Restraint/Base For your child’s safety, it is important that your infant restraint/base be properly reclined. Attached to the side of your infant restraint is a level indicator to help properly recline the infant restraint/base on the vehicle seat. Failure to properly recline the infant restraint on the vehicle seat increases the risk of serious injury or death.
Page 111
When using the base: To lower the foot; pull down on the bottom of the foot to the desired setting to adjust the recline To raise the foot; set the base on a flat surface, push in on the fingers on the base and push down on the base to adjust the recline If there is still orange in the level indicator...
Page 112
Final Safety Check: Every time you drive with your child, PUSH DOWN on the top of the infant restraint slowly but firmly to make sure the vehicle belt does not lengthen at all and that the vehicle belt or LATCH is fastened very tightly around the infant restraint/base Holding the infant restraint near the vehicle belt path, TWIST AND PULL the seat forward and to...
7.0 Additional Information 7.1 Airplane Use Install in an airplane the same way as in an automobile. Notify the airline ahead of time that you intend to bring the seat on board. Use only in forward-facing aircraft seat. Follow the flight attendant’s instructions about infant restraint placement.
Repeat step 3 for LATCH with adjustment belt. After fastening onto storage bar, pull on adjustment belt to make sure LATCH is securely fastened. LATCH storage should look like this when complete 7.3 Cleaning and Maintenance ! TO REMOVE AND WASH INFANT RESTRAINT PAD, follow instructions in “6.1 Positioning Harness Straps”, p.
Page 115
INFANT RESTRAINT METAL AND PLASTIC PARTS may be cleaned by wiping with a mild soap and water solution. DO NOT USE BLEACH. Use of bleach may weaken plastic parts. HARNESS STRAPS may be spot cleaned or replaced. DO NOT IMMERSE THE HARNESS STRAPS IN WATER. Doing so may weaken the harness straps.
Replacement Parts To purchase parts or accessories in the United States for your Graco product, please contact us at the following: www.gracobaby.com 1-800-345-4109...
Page 118
1.0 Advertencias a padres y otros usuarios ....4-5 2.0 Información sobre el registro ..... . .6-7 2.1 Registro de su sistema de seguridad para niños .
Page 119
5.0 Ubicación del sistema de seguridad para niños ..21-26 5.1 Requisitos del asiento del vehículo ....21 5.2 Requisitos del cinturón de seguridad del vehículo ..22 5.2.1Sistemas PELIGROSOS de cinturones para vehículos 23 5.2.2 Sistemas SEGUROS de cinturones para vehículos .24 5.3 Ubicación del LATCH .
1.0 Advertencias a padres y otros usuarios Ningún asiento de seguridad infantil puede garantizar la protección contra lesiones en todas las situaciones. Sin embargo, el uso correcto de este asiento de seguridad infantil reduce el riesgo de que su niño sufra lesiones serias o la muerte. El uso incorrecto de este sistema de seguridad infantil aumenta el riesgo de graves lesiones o la muerte durante un giro brusco, una parada repentina o un accidente.
Page 121
3. Sujetar a su niño de manera adecuada en el sistema de seguridad infantil. 4. Colocar el sistema de seguridad infantil/base en una posición orientada hacia atrás. 5. Colocar el cinturón de seguridad del vehículo o LATCH de manera correcta. 6.
Debe registrar este sistema para que lo podamos contactar en dicho caso. Envíe su nombre y apellido, dirección y números de serie y de modelo a: Graco Children’s Products Inc. 150 Oaklands Blvd. Exton, PA 19341 o llame al 1-800-345-4109 o www.gracobebe.com...
EE.UU. al 1-800-424-9393 (202-366-0123 en la zona de Washington, D.C.) • www.nhtsa.dot.gov • Graco: 1-800-345-4109 o www.gracobebe.com 2.3 Si necesita ayuda En los EE.UU. o Canadá, por favor, comuníquese con el Departamento de Servicio al Cliente con cualquier pregunta que pudiera tener sobre piezas, uso o mantenimiento.
3.0 Funciones y componentes Cada modelo del sistema de seguridad para niños viene con diferentes opciones en el arnés. Para ajustar debidamente el sistema de seguridad para niños, es muy importante que observe las instrucciones que son apropiadas para el modelo que compró. Arnés de 3 puntos Arnés de 5 puntos Cinturón del vehículo/recorrido...
3.1 Modelo con arnés de 3 puntos VISTA DELANTERA: ARNÉS DE 3 PUNTOS Ranura para el Manija arnés Botón de ajuste de la Traba del manija arnés Gancho del cinturón del vehículo Correas Hebilla del del arnés arnés...
Page 126
VISTA TRASERA: ARNÉS DE 3 PUNTOS Tensionador del arnés Indicador del nivel* Bolsillo del manual del propietario *Indicador del nivel **Traba de seguridad Traba de seguridad** El indicador de nivel se conecta al costado del sistema de seguridad para niños e indica si el sistema de seguridad para niños está...
3.2 Modelo con arnés de 5 puntos VISTA DELANTERA: ARNÉS DE 5 PUNTOS Manija Ranura para el arnés Traba del Botón de arnés ajuste de la manija Hebilla del arnés Gancho del Botón de cinturón del ajuste del vehículo arnés Lengüetas de la hebilla del arnés Correa de ajuste...
Page 128
VISTA TRASERA: ARNÉS DE 5 PUNTOS Indicador del nivel* Bolsillo del manual del propietario Placa de la unión de metal *Indicador del nivel **Traba de seguridad El indicador de nivel se conecta al costado del sistema de seguridad para niños e indica si el sistema de seguridad para niños está...
3.3 Sacar y conectar la base Para sacar el sistema de seguridad para niños, apriete la manija de liberación en la parte trasera del asiento y levante el sistema de seguridad para niños de la base como se indica Para poner el sistema de seguridad para niños en la base, empuje el sistema de seguridad para niños hacia abajo hasta que se trabe en la base.
3.5 Colocación de la capota (ciertos modelos) 1. El sistema de seguridad para niños viene con cuatro (dos en ciertos modelos) piezas idénticas de soporte de la capota. Pase un soporte de la capota completamente a través del túnel cosido 2.
3.6 Apoyacabezas (en ciertos modelos) Algunos bebés necesitan apoyo adicional para mantener la cabeza y el cuerpo en una posición cómoda. Destrabe los costados y vuelva a trabarlos con las correas del arnés pasadas a través de las ranuras en el cojín Si su modelo no incluye un apoyacabezas, puede usar una toalla enrollada o una manta...
4.0 Información importante 4.1 Advertencias para uso como sistema de seguridad para niños • NO INSTALE O USE ESTE SISTEMA DE SEGURIDAD PARA NIÑOS Y BASE HASTA QUE HAYA LEÍDO Y ENTIENDA LAS INSTRUCCIONES EN ESTE MANUAL Y EN EL MANUAL DEL PROPIETARIO DE SU VEHÍCULO.
Page 133
• ALGUNOS NIÑOS CON NECESIDADES ESPECIALES, tales como bebés que nacen antes de tiempo o quienes sufren de apnea de posición, podrían sufrir más riesgo de sufrir problemas respiratorios u otras dificultades en un sistema de seguridad para niños. Si su niño tiene necesidades especiales, recomendamos que su médico o personal del hospital evalúe a su niño y recomiende el sistema de seguridad para niños adecuado para su bebé...
1-800-345-4109 para obtener una, o visite nuestro sitio Web, www.gracobebe.com. • El uso inadecuado de asientos para automóvil Graco con este cochecito de otros fabricantes podría resultar en lesiones serias o la muerte.
4.3 Advertencias adicionales para el uso como transportador • PELIGRO DE CAÍDA: Los movimientos del niño pueden mover el transportador. NUNCA ponga el transportador cerca de los bordes de mesadas, mesas u otras superficies altas. Manténgase siempre cerca cuando el transportador no esté en el piso/tierra. Antes de levantar el transportador, ASEGÚRESE que las manijas estén trabajadas en posición.
4.4 Limitaciones de peso y estatura NO USAR EL SISTEMA DE SEGURIDAD PARA NIÑOS DE MANERA APROPIADA DE ACUERDO AL TAMAÑO DE SU NIÑO PODRÍA AUMENTAR EL RIESGO DE QUE SUFRA LESIONES SERIAS O FATALES. Su niño DEBE cumplir con todos los requisitos: •...
Si no está seguro sobre dónde colocar el sistema de seguridad para niños en su vehículo, consulte el manual del propietario del vehículo o llame a Graco al 1-800-345-4109. • Cuando sea posible, sujete el sistema de seguridad para niños en la posición de asiento central directamente detrás...
Preste mucha atención a estos sistemas ya que muchos de los sistemas de cinturones de seguridad que no son seguros se parecen mucho a los que no presentan peligro. Si no está seguro, consulte el manual del propietario del vehículo o llame a Graco al 1-800-345-4109.
Page 139
5.2.1 Sistemas para vehíc NO USE ninguno de los siguientes sistemas para asegurar el sistema de seguridad para niños. El LATCH se puede usar EN LUGAR DE el sistema de cinturon para vehículo. Por favor, consulte el manual del propietario del vehículo para obtener las ubicaciones donde debe instalarse el LATCH.
5.2.2 Sistemas para vehículos LOS SIGUIENTES CINTURONES DE SEGURIDAD PUEDEN USARSE CON SU SISTEMA DE SEGURIDAD PARA NIÑOS, SI el asiento cumple con todos los otros requisitos de estas instrucciones y los que se incluyen en el manual del propietario de su vehículo. Se puede usar el LATCH en lugar de el sistema de seguridad del vehículo.
Page 141
• Combinación c inturón para el hombro/abdomen y placa de seguridad con traba móvil Este cinturón tiene una placa de seguridad que se mueve libremente a lo largo del cinturón. Este cinturón DEBE convertirse para prevenir el movimiento de la parte de la falda del cinturón. Debe usar la traba de seguridad provista con el sistema de seguridad para niños, a menos que el cinturón de seguridad del asiento de su vehículo pueda...
5.3 Ubicación del LATCH Los vehículos nuevos pueden tener uno o varios asientos equipados con sistemas de anclaje LATCH . Si el vehículo viene equipado con LATCH, se pueden ver los puntos de anclaje inferiores en el pliegue del asiento del vehículo. Si no están visibles, pueden estar marcados con el símbolo que sigue Vea el manual del propietario de su vehículo para informarse sobre las ubicaciones exactas, la identificación de los anclajes y...
6.0 Usar el asiento de seguridad infantil 6.1 Colocación de las correas del arnés NO AJUSTAR DEBIDAMENTE LAS CORREAS DEL ARNÉS DEL NIÑO AUMENTA EL RIESGO DE LESIONES SERIAS O FATALES EN CASO DE UNA CURVA CERRADA, ACCIDENTE O PARADA REPENTINA.
6.1.1 Arnés de 3 puntos 1. Por atrás, empuje la hebilla del anclaje del arnés hacia atrás a través de la ranura del arnés. De ser necesario, por delante, use la correa del arnés para tirar la hebilla de la ranura 2.
6.1.2 Arnés de 5 puntos 1. Apriete el botón de ajuste del arnés debajo de la tapa del asiento las correas de los hombros para aflojar el arnés. 2. Detrás del asiento, saque los extremos de las dos correas de los hombros de la placa de unión de metal 3.
Page 146
PARA UN BEBÉ PEQUEÑO: Use las ranuras inferiores del arnés (si están a la par o apenas debajo de los hombros de su niño) y los nudos superiores del arnés . Los extremos de las correas deben quedar al frente de la placa de metal como se indica en , no como se indica en VERIFIQUE que los nudos estén...
6.2 Cómo sujetar el niño en al sistema de seguridad para niños No ajustar debidamente a su niño en el sistema de seguridad para niños/transportador aumenta el riesgo de lesiones serias o fatales en una curva cerrada, parada repentina o accidente. Inclusive cuando lo usa solamente como transportador, asegúrese que las correas del arnés estén debidamente ajustadas.
5. Trabe el arnés a la traba por las piernas del niño. Asegúrese de escuchar un "clic". NO use el sistema de seguridad para niños si el arnés no se traba en su lugar. Llame a Graco al 1-800-345-4109. 6. Por atrás, pase la correa a través del tensionador del arnés para tensionar las correas como se indica ASEGÚRESE que ambas correas estén...
NO use el sistema de seguridad para niños si el arnés no se traba en su lugar. Llame a Graco al 1-800-345-4109. 6. Trabe la hebilla del arnés 7. Tire de la correa de ajuste del arnés para ajustar las correas como se indica ASEGÚRESE que ambas correas estén...
6.3 Instalación del sistema de seguridad para niños/base usando el cinturón del vehículo Debe seguir detenidamente las instrucciones provistas por el fabricante de su vehículo, además de la información de este manual. Antes de seguir, asegúrese que ha leído y entendido la sección 5, "Ubicación del sistema de seguridad para niños"...
Page 151
3. Pase el cinturón de seguridad: Base con cinturón de seguridad El cinturón DEBE pasar debajo de la lengüeta. Sistema de seguridad para niños con cinturón de seguridad 4. Trabe el cinturón del asiento. Asegúrese que la lengüeta de la hebilla pase por la hebilla correcta El cinturón del vehículo no deberá...
Page 152
5. Ajuste el cinturón de seguridad del vehículo. Consulte el manual del propietario del vehículo y las instrucciones en la sección "5.2.2. "Sistemas SEGUROS de cinturones de seguridad para vehículo", página 24 y 25 sobre cómo ajustar el cinturón del vehículo. Para crear una instalación bien ajustada, apriete hacia abajo con fuerza con su rodilla o mano en el medio del sistema de seguridad para niños o base...
6.4 Uso del LATCH para instalar la base 1. Para facilitar la instalación, extienda el LATCH hasta el máximo. 2. Ponga la base en el asiento del vehículo como se indica. 3. Pase el LATCH por el recorrido del cinturón en la base que normalmente se usa para el cinturón del asiento del vehículo.
6.5 Inclinación del sistema de seguridad para niños/base Es importante que su sistema de seguridad para niños/base esté debidamente inclinado para mayor seguridad del niño. En el costado de su sistema de seguridad para niños hay un indicador del nivel para ayudar a reclinar debidamente el sistema de seguridad para niños/base en el asiento del vehículo.
Page 155
Cuando usa la base: Para bajar el pie; tire hacia abajo del fondo del pie hasta alcanzar el valor deseado para ajustar la inclinación Para levantar el pie; ponga la base en una superficie plana, empuje hacia adentro los dedos de la base y empuje hacia abajo la base para ajustar la inclinación Si todavía aparece la zona de color naranja en el indicador de nivel cuando el pie está...
Page 156
Verificación final de seguridad: Cada vez que sale en el automóvil con su niño, EMPUJE HACIA ABAJO lenta pero firmemente la parte de arriba del sistema de seguridad para niños para asegurarse que el cinturón del vehículo o LATCH no se estira y que esté sujetado apretadamente alrededor de la base/sistema de seguridad GIRE Y TIRE el asiento hacia adelante agarrando...
7.0 Información adicional 7.1 Uso en aviones Instálelo en un avión de la misma manera que en un automóvil. Notifique a la compañía aérea por adelantado que va a usar el asiento abordo. Úselo solamente en un asiento del aeronave orientado hacia delante.
Page 158
4. Repita el Paso 3 del LATCH con el cinturón de ajuste. Después de ajustarlo sobre la barra de almacenamiento, tire el cinturón de ajuste para asegurarse que el LATCH esté debidamente ajustado. 5. El almacenamiento del LATCH debería tener este aspecto cuando esté terminado Parte inferior de la base...
7.3 Limpieza y mantenimiento ! PARA SACAR Y LAVAR LA ALMOHADILLA DE SEGURIDAD DEL NIÑO, siga las instrucciones en la sección "6.1 Colocación de las correas del arnés", páginas 27 y 30. En los modelos con arnés de 5 puntos, separe la pequeña lengüeta que mantiene las hebillas del anclaje en su lugar y saque las hebillas del anclaje...
Page 160
! LAS PIEZAS DE METAL Y DE PLÁSTICO DEL SISTEMA DE SEGURIDAD PARA NIÑOS pueden limpiarse con una solución de jabón suave y agua. NO USE CLORO. El uso de cloro puede debilitar las piezas de plástico. ! LAS CORREAS DEL ARNÉS Y LAS CORREAS DEL LATCH pueden limpiarse a mano o cambiarse.
Piezas de repuesto Para comprar repuestos o accesorios en los Estados Unidos para su producto Graco, por favor comuníquese con nosotros en: www.gracobebe.com 1-800-345-4109...
