Attaching the Base ..............................................11 Wall-Mounting ................................................11 PC INPUT SIGNAL REFERENCE CHART ........................12 VIDEO INPUT SIGNAL REFERENCE CHART ....................... 12 USING AOC TV ................................. 13 Turning the TV On and Off ............................................14 Initial Setting ................................................14 Switching Input Source ..............................................16 Adjust Picture Setting ..............................................16 Adjust Sound Setting ..............................................17...
Use the Wall-Mount bracket or TV stand which was recommended by NOTIFICATION AOC, and please consult your dealer for detailed information. Radio Frequency Interference Statement Use with other Wall-Mount Bracket or TV stand may cause instability Warning: and possibly result in injury.
Protect the power cord from being walked on or pinched Usage Instructions particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. Only use attachments/accessories specified by the Installation manufacturer. 10 ) Use only with a cart, stand, tripod, bracket, or table specified Placement by the manufacturer, or sold with the apparatus.
Observe the followings to prevent the AC power cord from being damaged. If the AC power cord is damaged, it may result in a fire or an electric shock. Stop using it and ask your dealer or AOC service center to exchange it.
Lightning Storms For added protection for this TV during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage to the TV due to lightning and power line surges. Antennas Outdoor antenna grounding If you want to connect an outdoor antenna, please assure that it is...
may be removed with a cloth slightly dampened with a solution Sound of mild soap and warm water. Never use strong solvents such as thinner or benzine for cleaning. If a snapping or popping sound from the TV is continuous or frequent while the TV is operating, unplug the TV and consult your dealer or If using a chemically pretreated cloth, please follow the instruction service technician.
Thank you for purchasing this AOC high-definition television. The Objects and ventilation holes quality of the image you see on your AOC TV is only as good as the Never push objects of any kind into the TV through the cabinet slots quality of the signal it receives.
Contents in the Box After unpack the TV box, please check the TV and all accessories are well presented and undamaged. AOC TV Set Base Base Screw User Manual Remote Control Remote Control Battery User Manual Warranty Card Slim Gender Cabel for...
Page 10
LE19K097/LE22K097/LE24K097 LE32K0D7D/LE42K0D7D SCART COMPONENT SPDIF OUT HDMI (RGB/AV) PC IN L - AUDIO - R SPDIF OUT AV OUT SERVICE VIDEO L - AUDIO - R LC32K0D3D/LC42K0D3D Item Description Connects to your headphones. If your headphones do not match the jack, use a suitable plug adapter (not Headphone Jack supplied).
TV, especially to determine the strength of the wall for withstanding the TV’s weight. For product protection and safety reasons, AOC strongly recommends that you use the Wall-Mount Bracket model designed for your TV and the Wall-Mounting of your TV should be performed by AOC dealer or licensed contractor.
PC Input Signal Reference Chart After connecting the PC to the TV, set the output signal from the PC according to the chart below. Presetting PC Mode Standard Resolution Refresh Rate (Hz) VESA 640 x 480 VESA 800 x 600 VESA 1024 x 768 VESA...
USING AOC TV Buttons located at the right side of the TV will operate the same as these buttons on the remote control. Button Description POWER Press to turn on and off the TV. Press to go back to the previous TV channel or exit from the OSD when Back displaying menu items and settings.
You can turn on the TV by using power switch button on the TV set or on the remote controller. Initial Setting When you first start up this AOC LCD TV set, please follow the Initial Wizard to your AOC LCD TV. 1. Selecting Language.
Switching Input Source On AOC TV, you can cpress “Source” to choose the signal source on the display menu. Input List YPbPr SCART HDMI 1 HDMI 2 Press Source to call out source menu. 3UHVV WR VHOHFW LQSXW VRXUFH 79 <3E3U$96&$573&+'0, Press OK to enter.
OSD Manual Setting Channel Search Press MENU to call out MENU. 3UHVV WR VHOHFW ³79” , and press OK. 3UHVV WR VHOHFW ³&KDQQHOV”, and then press OK. Menu Description To select the relevant country. This is the country you are in, or the country whose channels you want to receive if you Country live near its borders.
Features Setup Press MENU/EXIT to call out MENU. 3UHVV WR VHOHFW ³)HDWXUH” , and press OK. 3UHVV WR VHOHFW 6HWWLQJ LWHPV 0HQX ODQJXDJH, Time, Sleep timer, Transparency, Password Setting, Parental control, Closed Captions, Analog Caption, etc. and press OK to enter. 3UHVV WR DGMXVW Press MENU/EXIT again to exit.
Troubleshooting Condition Explanation / Solution No picture No picture Check the Power Saving settings. Make sure the power cord is connected securely. Turn on the power of the TV. Cannot receive any channels Check antenna/cable connections. Make sure the Cable setting is correct for your TV signal source. TV is locked to one channel Perform Auto Program to add receivable channels that are not present in the TV’s memory.
Dimensions & Specifications Model LE19K097 LE22K097 LE24K097 Screen Size 18.5” diagonal 21.5” diagonal 23.6” diagonal Resolution 1366 x 768 1920 x 1080 1920 x 1080 Bulgarian, Croatian, Czech, Danish, Dutch, English, Finnish, French, Gaeilge, German, Greek, Hungarian, Italian, Norwegian, Polish,...
Page 22
Realmedia RealVideo 8/9/10 Caution: AOC is not responsible if the USB storage device is not supported, nor is it responsible for damage or loss of data from the device. Tips: 1. If can’t detect the connected device, it would be caused by the connected device driver not by TV failure.
