GIGABYTE ODIN
Power Supply User's Manual
ATX 12V version 2.2 power supply
Products: ODIN GT / ODIN PRO
Models: GE-S800A-D1, GE-S680A-D1, GE-S550A-D1 /
GE-M800A-D1, GE-M680A-D1, GE-M550A-D1
Specifications are subject to change without notice.
All brand names and products are registered trademarks of their
respective companies
Advertisement
Table of Contents
Related Manuals for Gigabyte ODIN GT GE-S800A-D1
Summary of Contents for Gigabyte ODIN GT GE-S800A-D1
- Page 1 GIGABYTE ODIN Power Supply User’s Manual ATX 12V version 2.2 power supply Products: ODIN GT / ODIN PRO Models: GE-S800A-D1, GE-S680A-D1, GE-S550A-D1 / GE-M800A-D1, GE-M680A-D1, GE-M550A-D1 Specifications are subject to change without notice. All brand names and products are registered trademarks of their...
- Page 2 As a member of the global community, Gigabyte provides environment friendly products and observes the European Union’s Restriction of Hazardous Substances (RoHS) directive, which limits the use of lead, mercury, cadmium and other hazardous substances in electronic products.
- Page 3 GIGABYTE will continue to develop RoHS compliant PC components and provide valuable resources to promote and advance RoHS directive goals and objectives. The following are not covered by the warranty: 1. Using the product incorrectly or in a manner other than the designed purpose.
-
Page 4: Power Supply Unit
System Requirement 1. Windows 2000\ XP\ Vista 2. CD-Rom 3. Recommended HDD Space: 30Mb 4. Recommended RAM: 512mb RAM 5. Recommended display resolution: >1024 x 768 System fan speed con- Thermal sensor cable Power Supply Unit Fixing Screws trol and power cable (ODIN GT only) (ODIN GT only) PCI-E (Blue) power... -
Page 5: Table Of Contents
Contain Item 1. Power Supply Power Supply Unit .............P.06 Power Supply Cables ..........P.07 Power Supply Connectors ........P.08 2. Specification Input ................P.10 Output ................P.11 Remote On/Off ............P.12 Hold-Up Time ............P.12 Power Good Delay ............P.12 Power Fail Delay ............P.12 Turn-On Delay Time ..........P.12 Transient Overshoot ..........P.12 Rise Time ..............P.12 Protection ..............P.13... -
Page 6: Power Supply Cables
1. Power Supply 1-1.Power Supply Unit a. AC In b. AC power switch c. PCI-E 1 cable management Red d. PCI-E 2 cable management Blue e. 12V, 5V, 3.3V peripheral power cable management f. Thermal sensor cable management (For Odin GT only) g. - Page 7 1-2.Power Supply Cables a. 24-pin main power connector b. 8-pin +12V CPU power connector c. 4-pin +12V CPU power connector d. 6-pin PCI-E power connector (for 550W only one PCI-E connector) e. USB Data connector (For Odin GT only) f. Smart cable management - PCI-E (Red and Blue) power cable g.
-
Page 8: Power Supply Connectors
1-3.Power Supply Connectors 1-3-1. 24-PIN Main Power Connector 18AWG Signal Signal 18AWG (Wire) (Wire) Orange +3.3Vdc +3.3Vdc Orange Blue -12Vdc +3.3Vdc Orange Black Black Green PS-ON +5Vdc (22AWG) Black Black Black +5Vdc Black Black Gray (22 AWG) +5Vdc +5VSB Purple +5Vdc +12V1dc Yellow... - Page 9 1-3-5. FDD connector cable Signal 18AWG (Wire) +5VDC Black Black +12V4DC Yellow 1-3-6. Peripheral power with S-ATA HDD connector cable Signal 18AWG (Wire) +3.3 VDC Orange Black +5VDC Black +12V4DC Yellow 1-3-7. Smart cable management - Peripheral power with SATA HDD connector cable Signal 18AWG (Wire) +12 VDC...
-
Page 10: Specification
1-3-9. Fan Speed Control connectors Signal 24 AWG (Wire) Black +5VDC Signal Yellow 1-3-10. Smart Cable Management - Fan Speed Con- trol connectors Signal 24 AWG (Wire) Black +5VDC Signal Yellow 1-3-11. Smart cable management - Thermal sensor Smart cable management - Thermal sensor Connector... -
Page 11: Output
2-1-3 CURRENT 115Vac - 8.0A max / 230Vax - 4.0A max 115Vac - 10.0A max / 230Vax - 5.0A max (800W only) 2-1-4 INRUSH CURRENT 55A max. when AC input 115Vac at 25°C cold start 110A max. when AC input 230Vac at 25°C cold start 2-1-5 POWER EFFICIENCY 80% (min) at full load (typical) and 115Vac and... -
Page 12: Remote On/Off
2-3 REMOTE ON/OFF TTL High/PS-OFF; TTL Low/PS-ON VIL = 0.8V max, IIL = -1.6mAmax@Vin=0.4V VIH = 2.0V min @ Iin=-200uA, VIH = 5.25Vmax@open ckt. 2-4 HOLD-UP TIME 16msec (min.) at 80% of full load at 230Vac input 2-5 POWER GOOD DELAY 100-500 msec 2-6 POWER FAIL DELAY >1msec. -
Page 13: Protection
t 1: TURN-ON DELAY TIME t 2: RISE TIME t 3: POWER GOOD DELAY t 4: POWER FAIL DELAY t 5: HOLD-UP TIME 2-10 PROTECTION When OCP, OVP, OTP, or short protection is triggered, the main output will be latched off. The main outputs can be reset by cycling the DC remote on/off or AC power +5Vsb output is automatically recovered when a fault condition is removed. -
Page 14: Hi-Pot (Input/Out Isolation)
0°C to +50°C 2-11-2 Storage Temp -20°C to +70°C 2-11-3 Operating Humidity 20% to 90%, non condensing 2-11-4 Storage Humidity 5% to 95%, non condensing 2-11-5 Operating Altitude 0-10,000 feet 2-11-6 Storage Altitude 0-50,000 feet 2-12 HI-POT (Input/Out isolation) 2-12-1 PRIMARY TO SECONDARY 3535 Vdc for 3 seconds 2-12-2 INSULATION RESISTANCE Primary to earth ground 500Vdc, 50M ohms Min. -
Page 15: Installation Instruction
3. Installation Instruction (For a new system, please go directly to Section 4) 1. Switch off the system. 2. Disconnect the power cord from your old power supply. 3. Follow the direction provided in your case’s user manual to open your computer case. 4. - Page 16 10. To connect peripheral devices, please use Smart Cable Management power connectors. 11. With a Smart Cable Management -Fan speed control pow- er connector, users may connect two 3-pin system fans. This allows Odin GT power supply to monitor and control the speed of the fans you’ve connected (Odin GT only).
- Page 17 13. To enable the software control function, connect the USB connector from the power supply to Motherboard. If there is no USB connector on the motherboard, please use the USB converter to connect to the rear of the motherboard or an add-on card with a USB I/O port. (Odin GT series only) To connect the USB connector to the rear I/O USB port, please use the converter, which is included in the package,...
-
Page 18: Power Tuner Installation Instruction (Odin Gt Series Only)
4. Power Tuner Installation Instruc- tion (ODIN GT se- ries only) For the first time of the system’s boot-up, Windows will inform that a new hardware is found, and there is no driver needed for Odin GT. To enable the software control function, please install the power supply management software, “Power Turner”, in the system to monitor and adjust the hardware function. - Page 19 6. Power Tuner main page The images below display the Power Tuner window; all func- tion can be controlled by a click of the mouse. Peak rate of power usage Display of power usage Clear peak button Click to get the reading Display voltage reading Click “all”...
- Page 20 7. P-Tuner Voltage page Power Supply fan / System fan switch Fan speed and Fan curve voltage setting window Start Voltage Fan curve mode Start Temperature selection Switch between Thermometer °C & °F sensor selection Confirm setting Cancel setting Performance mode: High Fan speed to cool down power supply and system more efficiently.
- Page 21 Please don’t set the voltage over Intel spec. It may cause the system into protection mode. (Power Tuner only allows the power supply to adjust the volt- age within Intel spec. It is safe to adjust the voltage setting.) 8. P-Tuner Alarm: Watt 9.
- Page 22 10. P-Tuner Alarm Current 11. P-Tuner Alarm Fan Speed 12. P-Tuner Alarm Temperature...
- Page 23 NOTE: 1. When the program crashes, simply close the program and re-start it. 2. When there is an error within the settings, it will cause a boot-up failure to the hardware, normally caused by over- voltage or under-voltage protection. Therefore, to protect the hardware, the system will not boot up.
