4 electrolux
Service
• Any electrical work required to do the serv-
icing of the appliance should be carried
out by a qualified electrician or compe-
tent person.
• This product must be serviced by an au-
thorized Service Centre, and only genu-
ine spare parts must be used.
Environment Protection
This appliance does not contain gasses
which could damage the ozone layer,

CONTROL PANEL

1 Temperature Regulator
2 S/N switch (Action Freeze Function)
3 S/N light (Action Freeze Function)
4 Pilot light
5 High temperature alarm light
6 I/O Switch
Switching on
Insert the plug into the wall socket.
Move the "I/O" switch to "I" position.
Turn the Temperature regulator clockwise
to a medium setting.
The Pilot light and the Alarm light will light up.
Switching off
To turn off the appliance, move the "I/O"
switch to "O" position.
The Pilot light will switch off.
Temperature regulation
The temperature is automatically regulated.
To operate the appliance, proceed as fol-
lows:
• turn the Temperature regulator toward
lower settings to obtain the minimum cold-
ness.
4) If a water connection is foreseen
1
in either its refrigerant circuit or insula-
tion materials. The appliance shall not
be discarded together with the urban re-
fuse and rubbish. The insulation foam
contains flammable gases: the appli-
ance shall be disposed according to
the applicable regulations to obtain
from your local authorities. Avoid dam-
aging the cooling unit, especially at the
rear near the heat exchanger. The ma-
terials used on this appliance marked
by the symbol
2 3 4 5
• turn the Temperature regulator toward
higher settings to obtain the maximum
coldness.
The intermediate position is usually the
most suitable.
However, the exact setting should be chos-
en keeping in mind that the temperature in-
side the appliance depends on:
• room temperature
• how often the door is opened
• the quantity of food stored
• the location of the appliance.
Action Freeze function
To activate the Action Freeze function,
move the Action Freeze switch to "S" posi-
tion.
The Action Freeze light will light up.
High temperature alarm
In the event of an abnormal temperature
rise inside the freezer (e.g. power cut) alarm
light comes on.
When normal conditions are restored the
alarm light will switch off automatically.
are recyclable.
6
