OWNER'S OPERATING MANUAL
SPECIFICATIONS :
Motor Input................................. 900 watt
No Load Speed ........................ 12,000 rpm
Adjustable Height ..................... 5 - 35 mm
Adjustable Angle ....................... 0
Blade Size ................................ 100 x 22 x 4 mm
Biscuit Size ............................... #0, #10, #20
Net Weight ................................ 2.65 kg
THANK YOU FOR BUYING A RYOBI BISCUIT JOINER
Your new Biscuit Joner has been engineered and manufactured to Ryobi's high standard for
dependability, ease of operation and operator safety. Properly cared for, it will give you years of
rugged, trouble free performance.
CAUTION: Carefully read through this entire owner's manual before using your
Pay close attention to the Rules for Safe Operation, Warnings and Cautions.
If you use your Biscuit Joiner properly and only for what it is intended, you will enjoy years
of safe, reliable service.
Thank You again for buying Ryobi tools.
900 WATT BISCUIT JOINER
MODEL EBJ900K
o
- 90
o
Biscuit Joiner
SAVE THIS MANUAL FOR FUTURE REFERENCE.
DOUBLE
INSULATED
N197
Advertisement
Related Manuals for Ryobi EBJ900K
Summary of Contents for Ryobi EBJ900K
- Page 1 N197 THANK YOU FOR BUYING A RYOBI BISCUIT JOINER Your new Biscuit Joner has been engineered and manufactured to Ryobi's high standard for dependability, ease of operation and operator safety. Properly cared for, it will give you years of rugged, trouble free performance.
-
Page 2: Rules For Safe Operation
RULES FOR SAFE OPERATION The purpose of safety rules is to attract your attention to 9. DRESS PROPERLY. Do not wear loose clothing or possible dangers. The safety symbols and the explanations jewellery. They can be caught in moving parts. Rubber gloves and non-skid footwear are recommended when with them, require your careful attention and understanding. - Page 3 FEATURES 7. Depth Adjustment Rod 1. Power Switch 8. Arbor Lock 2. Handle 9. Dust Port 3. Fixed Fence 10. Height Adjustment Knob 4. Adjustable Fence 11. Angle Lock Knob 5. Height Lock Knob 12. Motor Housing 6. Depth Selector Page 2...
- Page 4 APPLICATIONS ADJUSTMENTS Use your biscuit joiner only for the purposes listed The adjustable fence will cut joints at angles from 0 to 90 at below: a fixed cut height of 9mm (5/16") (the center of a 25.4mm Cutting and jointing of timber board).
-
Page 5: Operation
ADJUSTMENTS OPERATION Fine Depth Adjustment (Fig. 4) Making a Normal Biscuit Cut (Fig. 6~7) All biscuits are manufactured to slightly different sizes, so Position your work pieces together and draw a reference you might need to adjust the depth of cut on the tool. The mark at 90 to the center point of each proposed joint depth adjustment rod (7) can be rotated to increase or... -
Page 6: Maintenance
MAINTENANCE OPERATION Replacing the blade Pull out the power plug. Remove the fixed fence and raise the adjustable fence to the o degree position. Turn the machine over and unscrew the two screws in the base plate. Pivot the base plate open.(see Fig. 8) Now, with the arbor lock (8) in the top of the gearbox housing depressed, rotate the blade by hand until the blade locks. - Page 7 MAINTENANCE Dust Extraction (Fig. 10) You can use the dust bag provided or with the aid of the adaptor accessory, connect the tool to a vacuum system. The plastic dust extraction assembly fits in the dust port (9) on the joiner. You can then attach a vacuum hose or the supplied dust bag, to the adaptor.
- Page 8 RYOBI NEW ZEALAND PTY. LTD. AUCKLAND: 27 Clemow Drive, Mt Wellington, N.Z. Tel: (09) 573 0230 - Free Call: 0800 279 624 - Fax: (09) 573 0231 - www.ryobi.co.nz Contact during normal business hours. This Guarantee Form Should Be Retained By The Customer At All Times For your record and to assist in establishing date of purchase (necessary for in-guarantee service) please keep your purchase docket and this form completed with the following particulars.
