Page 1 of 1
4
1
2
Incandescent Model
Ordering Information:
Cat. No.
Diameter Extension Finish Voltage Lamps (by others)
4815BK
8 11/16"
8 1/2"
4839WH
8 11/16"
8 1/2"
4817BK
8 11/16"
8 1/2"
4841WH
8 11/16"
8 1/2"
Features
1. Diffuser: Pressed ceramic coated glass.
2. Diffuser Housing: Die-cast aluminum guard.
3. Backplate: 11 ga. aluminum.
4. Lamp: See Lamps.
5. Ballast: See Electrical/Ballast.
Electrical/Ballast
9W
NPF
120V
Total Input Watts
20
Max. Line Current (amps)
.36
Ballast Factor
.90
THD
< 20%
Min. Starting Temperature
-4°C (-25°F)
Mounting
Wall Mount only to standard 4" octagonal outlet box.
Indoor/Outdoor Wall Mounted Compact Fluorescent/Incandescent
8 11/16"
8 1/2"
4
8"
1
2
3
Black
120V
White
120V
Black
120V
White
120V
Decorative Arco
8 11/16"
8 11/16"
8 1/2"
8 1/2"
4
8"
1
2
3
Twin Tube Model
(1) 100W A19 MAx.
(1) 100W A19 MAx.
(2) 9W Twin 2-pin (G23 base)
General Electric Osram/Sylvania Philips
(2) 9W Twin 2-pin (G23 base)
F9Bx/SPx/*
*Manufactures color temperature designation.
Labels
UL Listed. Suitable for Wet Locations.
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
a Genlyte company
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2005 Genlyte Group LLC • A0805
™
8"
3
CF90S/*
PLS9W/*
Type:
www.lightolier.com
4839
