- Page 1 INSTRUCTION MANUAL Deluxe Laser Line Generator Electronic alignment made easy • Melbourne • Perth • Auckland • Hong Kong • Shanghai • Taipei • New York • Verona • London • Paris LSLINE 040504 ed09 JJ...
-
Page 2: Table Of Contents
Contents Warranty Introduction Environmental protection Scope of product Description of symbols Safety rules for laser line generator Additional safety rules for laser line generator Know your product Changing the laser line generator batteries Operating the laser line generator Selecting the mounting method Projection of a vertical laser line on the floor Projection of laser line when fixed on a wall Maintenance... -
Page 3: Introduction
Dear Customer If you require any help with your product, whether it is a Warranty claim, spare part or user information, please phone our Help Line for an immediate response. Phone 1300 880 001 in Australia or 0800 445 721 in New Zealand. -
Page 4: Safety Rules For Laser Line Generator
Safety rules for laser line generators The laser line generator is Class 2 with maximum 1mW and 400nm – 650nm wavelengths. These lasers do not normally present an optical hazard, although staring at the beam may cause flash blindness. WARNING. Do not stare directly at the laser beam. - Page 5 atmospheres, such as in the presence of flammable liquids, gases, or dust. • Do not push the pin push-button of the aluminium base unless you intend to fix the base on the dry wall or soft wood like material, it may result injury because of the sharp pins.
-
Page 6: Know Your Product
Know your product Before using the laser line generator, familiarise yourself with all the operating features and safety requirements. Laser line generator 1. Laser switch 2. Laser line rotating dial 3. Level vials 4. Battery cover 5. Magnetic base 6. Front locating groove 7. -
Page 7: Changing The Laser Line Generator Batteries
Changing the laser line generator batteries 1. Ensure that the laser line generator is switched OFF by checking that the laser lswitch (1) has been pulled up. 2. Turn the battery cover (4) anticlockwise and remove the cap. 3. Remove and replace both AA batteries, taking care to insert the new batteries with the correct polarity. -
Page 8: Projection Of A Vertical Laser Line On The Floor
Projection of laser lines on the floor Once the mounting method has been selected you may commence with the projection of the laser line. The laser line rotating dial (2) is designed to adjust the line from horizontal to vertical and all angles in between. Switching it on To switch the laser line generator ON, push down the... -
Page 9: Maintenance
5. Switch ON the laser line generator. 6. Adjust the rotating dial (2) to achieve desired line projection. Troubleshooting Problem Faint laser line projection Laser line is not projected Laser line angle appears not to line up with a reference point Maintenance 1. - Page 10 Carefully read the entire Instruction Manual Before returning this product for a Warranty Claim or any other reason Please Call 1300 880 001 (Australia) or 0800 445 721 (New Zealand) When you make your call, please have the following information at hand: •...
