i-RAM
(GO-RAMDISK-BOX-RH)
User's Manual
Rev. 100
24MD1-IRMBOX-02R
* The WEEE marking on the product indicates this product must not be disposed of with user's other household waste
and must be handed over to a designated collection point for the recycling of waste electrical and electronic equipment!!
* The WEEE marking applies only in European Union's member states.
Copyright
© 2006 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in the manual are legally registered to their respective companies.
Notice
The written content provided with this product is the property of Gigabyte.
No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any
means without Gigabyte's prior written permission. Specifications and features are subject to change
without prior notice.

Advertisement

Table of Contents
loading

Related Manuals for Gigabyte GO-RAMDISK-BOX-RH

Summary of Contents for Gigabyte GO-RAMDISK-BOX-RH

  • Page 1 The written content provided with this product is the property of Gigabyte. No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without Gigabyte's prior written permission. Specifications and features are subject to change without prior notice.

  • Page 2: Table Of Contents

    Thank you for selecting GIGABYTE's latest i-RAM product. This user's manual gives information about i-RAM features and specifications, and will lead you through the installation of i- RAM in your system. Read this guide and related precautions before installing i-RAM.

  • Page 3: Product Features

    1. Product Features Fastest System Boot-Up speed Fully SATA1.0a compliant; i-RAM can be used as a boot device. Fastest Solid State Disk Dedicated DDR design, Supports DDR 266/333/400 memory modules. Fastest Data Access Ideally design for applications that require massive storage data access, like Audio/Video Capture &...

  • Page 4: Product Specifications

    2. Product Specifications Convenience to use for both PC and Server . SATA Interface - SATA 1.0a Compliant - Supports one SATA connector - Up to 150MB/s data transfer rate Memory Interface - Max amount of memory supported is 4GB - Four 184-Pin/2.5V DDR DIMM sockets - Supports DDR 266/333/400 (Note 2)

  • Page 5: Product Introduction

    4. Product Introduction Front Panel Battery Capacity Indicator Button Battery Capacity Indicator Button LED Light Capacity 4 section 100% 3 section 2 section 1 section Even in power off mode, battery indicator button can still be used for the purpose of checking the power level.

  • Page 6: Precautions

    Each time before setting up the i-RAM, make sure to remove system power and the i-RAM battery to prevent damage. Please back up the data in i-RAM regularly using either GIGABYTE's backup tool (please download it from GIGABYTE's website at http://www.gigabyte.com.tw) or third-party backup utilities.

  • Page 7: Installation Directions

    6. Installation Directions Each time before setting up the i-RAM, make sure to remove system power and the i-RAM battery to prevent damage. Please read the following installation directions before using i-RAM: Hardware Installation 8-1 : Open the cover Please remove the four screws on the cover (Figure a ), then pull up the cover (Figure b).
  • Page 8 8- 6: Install i-RAM BOX into the system Put i-RAM box into the 5.25 inch cd-rom drive. 8- 7: Connect the power connector of the rear panel 8-7-1 Connect the cable of the 5V SB Connect the cable of the 5V SB to the 5V SB connector of the rear panel .

  • Page 9: Software Setup

    Transcend Mosel Elixir Elixir Geil Geil ProMOS Mosel Transcend For the latest memory support list information, please visit GIGABYTE's website at http://www.gigabyte.com.tw. DDR400 (256MB) Module P/N. KOREA 0309 PC3200U-30331-A1 M381L3223ETM-CCC 256MB DDR PC3200 CL3 ECC MT16VDDT3264AG-40BB5 PC3200U-30330-B1 256MB DDR400 CL3...
  • Page 10 Module Supplier Comp. Used Transcend Micron Kingston Samsung Apacer Samsung A-DATA ADATA Buffalo Buffalo elixir elixir NANYA NANYA SAMSUNG SAMSUNG TwinMOS Hynix SAMSUNG SAMSUNG KINGSTON HYNIX DDR400 (1GB) Module P/N. 1G184PDDR=LR 1GDDR400 DIMM 3-3-3 KVR400X64C3A/1G 77.11136.464 MDOAD6G3141Y0B1E0H PC3200U-30330-B1 M2U1G64DS8HB1G-5T M924-400-16-P15480 NT1GD64S8HC0GY-5T M368L2923CUN-CCC M2SA016AJAHXAG0811A1...

  • Page 11: Iram Easybackup Utility Introduction

    . Extract the file and it will creat two main to install the iRAM EasyBackup. For DOS : GIGABYTE i-RAM DOS Utility Rev 1.0 Physical Model Name Total Sectors HD Size GIGABYTE i-RAM 4193279 1. Backup i-RAM to File 2.
  • Page 12 - 12 -...
  • Page 13 (GO-RAMDISK-BOX-RH) Rev. 100 WEEE logo W E E E © 2006 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
  • Page 14 ... 3 ... 4 ... 4 ... 5 ... 6 ... 7 ... 7 ... 9 ... 9 i-RAM ...11 i-RAM i-RAM - 2 - i-RAM...
  • Page 15 SATA 1.0a i-RAM DDR 266/333/400 3D/2D i-RAM (Standby Power) i-RAM i-RAM i-RAM i-RAM SATA 1.0a SATA 1.0a - 3 -...
  • Page 16 SATA SATA 1.0a SATA 150MB 184-Pin/2.5V DDR DDR 266/333/400 4.2mm 1,700mAh SATA (1.5Gb/s) Intel ICH6 / ICH7/ ICH8/ C19 SiS 964 nVIDIA MCP51/ MCP55 / MCP61 / CK804 i-RAM i-RAM SATA VIA 8237A/ VIA 8237R/ VIA 8237R+ i-RAM - 4 -...
  • Page 17 L E D 100% - 5 - L E D Full Charge R / W 5V SB SATA...
  • Page 18 ICH7R RAID 0 RAID 1 512MB~ 1GB i-RAM i-RAM i-RAM i-RAM i-RAM i-RAM i-RAM i-RAM i-RAM http://www.gigabyte.com.tw i-RAM - 6 -...
  • Page 19 i-RAM i-RAM - 7 -...
  • Page 20 i-RAM BOX i-RAM BOX 5.25 8 - 7 8-7-1 5V Stand By 5V Stand By i-RAM 24-pin 8-7-2 SATA SATA i-RAM SATA 5V SB 5V SB 4-pin SATA SATA - 8 -...
  • Page 21 HYNIX HYNIX Module Supplier Comp. Used Transcend Mosel Elixir Elixir Geil Geil ProMOS Mosel Transcend (http://www.gigabyte.com.tw) BIOS i-RAM i-RAM i-RAM DDR400 (256MB) Module P/N. KOREA 0309 PC3200U-30331-A1 M381L3223ETM-CCC 256MB DDR PC3200 CL3 ECC MT16VDDT3264AG-40BB5 PC3200U-30330-B1 256MB DDR400 CL3 DD4333-S256/MC PC3200U-30330-A1...
  • Page 22 Samsung A-DATA ADATA Buffalo Buffalo elixir elixir NANYA NANYA SAMSUNG SAMSUNG TwinMOS Hynix SAMSUNG SAMSUNG KINGSTON HYNIX (http://www.gigabyte.com.tw) DDR400 (1GB) Module P/N. 1G184PDDR=LR 1GDDR400 DIMM 3-3-3 KVR400X64C3A/1G 77.11136.464 MDOAD6G3141Y0B1E0H PC3200U-30330-B1 M2U1G64DS8HB1G-5T M924-400-16-P15480 NT1GD64S8HC0GY-5T M368L2923CUN-CCC M2SA016AJAHXAG0811A1 M368L2923CUN-CB3 KVR400X64C3A/1G - 10 - Component P/N.
  • Page 23 i-RAM i-RAM backup utility Windows Windows Wondows iRAM EasyBackup iram iRAM EasyBackup For Windows : For DOS : Backup i-RAM to File iRAM Restore File To i-RAM i-RAM iRAM EasyBackup i-RAM *.img - 11 -...
  • Page 24 - 12 -...
