Page 1: Instrucciones De Uso
/ frigorífico / congélador INSTRUCTION BOOKLET INSTRUCCIONES DE USO INSTRUÇÕNES DE USO ER8912B 818 17 52--00/0... -
Page 2: Table Of Contents
Safety instructions Carefully read these instructions to learn how the appliance works and how to care for it. Keep the instruction booklet. It will come in handy if you later sell the cabinet or give it to somebody else. These warnings are provided in the interests of your safety. Ensure that you understand them all before installing or using the appliance. -
Page 3: Description Of The Appliance
Description of the Appliance Model ER8912B Glass shelf Bottle shelf Vegetable drawer Butter compartment Door shelf Egg holder Sliding shelf Freezer plate Freezer drawer Ventilation grille Freezer calendar Control Panel -- 18 ACTION FREEZE ACTION COOL A. Refrigerator power switch G. -
Page 4: Before Use
Before use Position and clean the cabinet as explained in the section "Installation". Check that the drain hose at the rear of the cabinet discharges into the drip tray. Before inserting the power plug into the outlet and switching on the cabinet for the first time, leave it standing upright for about 30 minutes, or for 4 hours if it was transported horizontally. -
Page 5: Measuring The Temperature
Measuring the temperature If the temperature is measured using a standard, single thermometer, this should be put in a glass of water centrally placed inside the cabinet. This will reflect the temperature inside the food products. Do not place the thermometer hanging or lying directly on the shelf. -
Page 6: Cabinet Interior
Cabinet interior The shelves and door compartments are removable and can easily be re-arranged. Certain shelves must be lifted up by the rear edge to enable them to be removed. The lower door compartment and the glass shelf above the vegetable drawer must not be moved. They are required for proper air circulation inside the cabinet. -
Page 7: Temperature Inside The Freezer
Temperature inside the freezer To ensure that foodstuff will keep for a long time, be sure that the temperature inside the freezer is -18°C or below. Please note, however, that the energy consumption increases as the temperature decreases. The built-in temperature display shows the warmest temperature inside the freezer. -
Page 8: Freezing
At about -12°C: Most food products can be immediately re-frozen. Ice cream is especially sensitive to temperature changes and should be consumed as soon as possible. At -9° -- -2°C: Food products should be prepared (cooked) prior to eating or re-freezing them. Freezing You need not press the fast-freezing button when freezing smaller quantities of food during any... -
Page 9: Cabinet Interior
Cabinet interior Freezer drawers The freezer drawers make it easy to quickly and easily find the food package you want. To gain space, the drawers can be removed and the products can be put directly on the shelves. On all shelves, except the top shelf, it is possible to place products that protrude 20 mm from the front edge. -
Page 10: Protect The Environment
· When cleaning the cabinet, use a mild Protect the environment washing-up detergent. · Follow the advice in the section "Saving energy" · Hand over the cabinet packaging and discarded · The door gasket and coolant used in this fridges and freezers to a recycling station. cabinet will not harm the ozone layer. -
Page 11: Defrosting The Freezer
Defrosting the freezer A certain amount of frost will always form on the freezer shelves and around the top compartment. Defrost the freezer when the frost layer reaches a thickness of about 3-5 mm. Remove the freezer drawers and place them on top of each other by turning every other drawer one half turn. -
Page 12: Something Not Working
Something Not Working Before contacting your local Service Force Centre check the following point: Problem Possible cause / Remedy " " is displayed in the temperature An error has occurred in measuring the temperature. Call your display. service representative. (The cooling system will continue to keep food products cold, but temperature adjustment will not be possible.) The yellow Action Freeze and red... -
Page 13: Guarantee Conditions
Too much frost and ice are produced. Make sure that the door is completely closed and that the insulating strip is complete and clean. Set a higher temperature. The compressor operates continuously. Set a higher temperature. Make sure that the door is completely closed and that the insulating strip is complete and clean. -
Page 14: Technical Specification
Technical specification ER9012B Model 228 l Volume fridge 124 l Volume freezer 595 mm Width 2000 mm Height 600 mm Depth 504 kWh/year Energy consumption Energy class 160W Rated power 12kg/24 hours Freezing capacity Installation Unpacking Unpack the cabinet and check that it is in good condition and free of any transport damage. -
Page 15: Installing The Cabinet
Installing the cabinet When two appliances are placed beside each other, the distances enclosed in the plastic wrapping should be glued between the appliances. As shown in the illustration. To obtain the best performance from the cabinet, ensure : · the cabinet is placed in a dry, cool place and is not exposed to direct sunlight. -
Page 16: Door Reversal
Door Reversal 1. Close the cabinet and disconnect the appliance from the electricity supply. 2. Remove the ventilation grille. There is a part on the grille that can be removed. Remove it and put it on the other side. 3. Put the cabinet on a wooden board when it is laid down. - Page 17 qÜÉ=bäÉÅíêçäìñ=dêçìé=áë=íÜÉ=ïçêäÇDë=ä~êÖÉëí=éêçÇìÅÉê=çÑ=éçïÉêÉÇ=~ééäá~åÅÉë=Ñçê=âáíÅÜÉåI=ÅäÉ~åáåÖ=~åÇ=çìíÇççê=ìëÉK jçêÉ=íÜ~å=RR=ãáääáçå=bäÉÅíêçäìñ=dêçìé=éêçÇìÅíë=EëìÅÜ=~ë=êÉÑêáÖÉê~íçêëI=ÅççâÉêëI=ï~ëÜáåÖ=ã~ÅÜáåÉëI=î~Åììã=ÅäÉ~åÉêëI ÅÜ~áå=ë~ïë=~åÇ=ä~ïå=ãçïÉêëF=~êÉ=ëçäÇ=É~ÅÜ=óÉ~ê=íç=~=î~äìÉ=çÑ=~ééêçñK=rpa=NQ=Äáääáçå=áå=ãçêÉ=íÜ~å=NRM=ÅçìåíêáÉë ~êçìåÇ=íÜÉ=ïçêäÇK bä=dêìéç=bäÉÅíêçäìñ=Éë=Éä=ã~óçê=Ñ~ÄêáÅ~åíÉ=ÇÉä=ãìåÇç=ÇÉ=~é~ê~íçë=é~ê~=ä~=ÅçÅáå~I=äáãéáÉò~=ó=ìëç=ÉñíÉêáçêK=j•ë=ÇÉ=RR ãáääçåÉë=ÇÉ=éêçÇìÅíçë=ÇÉä=dêìéç=bäÉÅíêçäìñ=EÑêáÖçêáÑáÅçëI=ÅçåÖÉä~ÇçêÉëI=ÅçÅáå~ëI=ä~î~Ççê~ëI=~ëéáê~ÇçêÉëI=ãçíçëáÉêê~ë=ó Åçêí~ŨëéÉÇÉëF=ëÉ=îÉåÇÉå=Å~Ç~=~¥ç=éçê=ìå=î~äçê=~éêçñáã~Çç=ÇÉ=NQ=ÄáääçåÉë=ÇÉ=rpA=Éå=ã•ë=ÇÉ=NRM=é~áëÉë=ÇÉä=ãìåÇçK MARIESTAD KTD--AV...
