- Page 1 U s e r I n s t r u c t i o n s ESF 6250 ANC 822 960 065 - 00 - 0902...
- Page 2 Dear customer, Please read these user instructions carefully. Your dishwasher is fitted with the new Above all please observe the safety instructions on "PULSE WASH" wash system the first few pages ofthese user instructions! Please With this wash system, the motor speed keep these user instructions for later reference.
-
Page 3: Table Of Contents
Contents Safety Instructions ..............5 Dishwasher door safety catch . - Page 4 Contents Installation and Connection Instructions ........... 33 Installing the Dishwasher .
-
Page 5: Safety Instructions
Safety Instructions The safety aspects of ELECTROLUX electrical appli- • Never place the dishwasher in operation if the ances comply with accepted technical standards and mains cable, water inlet or drain hose is damaged; the German Appliance Safety Law. Nevertheless, as... -
Page 6: Dishwasher Door Safety Catch
Dishwasher door safety catch The dishwasher has a door safety catch. This safety catch prevents children opening the dish- washer door by mistake. You can set the door safety catch as follows: 1. There is a catch on the left inside the door handle (1). -
Page 7: Disposal
Disposal Disposing of the Packaging Material Dispose of the dishwasher packaging material cor- rectly. All the packaging materials used are harmless to the environment and can be recycled. • Plastic parts are marked with standard interna- tional abbreviations: – >PE< for polyethylene, e.g. -
Page 8: Appliance Features And Control Panel
Appliance Features and Control Panel Top Spray Nozzle Rubber Seal for Connecting the Water Feed to the Spray Arm Spray Arms Water hardness switch Container for Special Salt Container for Detergent Container for Rinse Aid Interior lighting Rating Plate Filters... -
Page 9: Control Panel
Control Panel Function buttons Set delay Door handle Multi-display start Indicators 1 2 3 4 ON/OFF button Control panel The control panel consists of the ON/OFF button The multi-display can display, and the programme buttons with LED displays. – the start delay that is set. –... -
Page 10: Water Softener
Water softener To avoid scale deposits on the dishes and in the dish- Your water supplier will be able to inform you washer, the dishes must be washed with soft water, about the hardness and hardness range of i.e. water with a low lime content. The dishwasher the water in your area. -
Page 11: Special Salt For The Water Softener
3. Press function button 1 again. The LED indicator for function button 1 will flash. The multi-display will indicate the hardness set- ting. 4. Pressing function button 1 increases the hardness setting by 1 degree. (Exception: hardness setting 1 follows hardness setting 10). 5. -
Page 12: Adding Special Salt
Set the water softener manually and electronically to the desired water hardness: Electronic set- Manual setting Multi-display indi- Addition of special salt ting cator Do not add special salt. Addition of special salt via salt supply container 10 l 0 - 1 2 - 10 (factory setting) If the water softener is electronically set at... -
Page 13: Rinse Aid
RINSE AID Rinse aid ensures that your dishes gleam and are 3. Press function button 2. free from spots, and that your glasses are clear. The LED indicator for function button 2 will flash. The multi-display will indicate the current setting: Rinse aid can be added in one of two ways: Inflow of rinse aid is deactivated... -
Page 14: Adding Rinse Aid
Adding rinse aid If you are using dishwasher detergent and rinse aid separately, add the rinse aid: • Prior to using the dishwasher for the first time. • When the indicator on the control panel is illuminated. The rinse aid compartment is on the inside of the dishwasher door. -
Page 15: In Daily Use
In Daily Use • Is it necessary to refill with special salt or rinse aid? • Load cutlery and dishes into the dishwasher • Fill with dishwasher detergent • Select a wash programme suitable for the cutlery and dishes • Start the wash programme Loading cutlery and dishes Sponges, household cloths and any object... -
Page 16: Loading Cutlery
Loading Cutlery If they are placed in the cutlery basket, long, pointed items of cutlery are a hazard, par- ticularly to children (see Safety Instructions). They must therefore be laid horizontally in the upper basket. To ensure that all cutlery is efficiently washed and reached by the water you should: 1. -
Page 17: Loading Pans, Frying Pans And Large Plates
Loading Pans, Frying Pans and Large Plates Load large and heavily soiled dishes in the lower rack. Your dishwasher has one of the following two types of lower rack: Type 1: The rear plate insert in the lower rack can be removed To make it easier to load large dishes, it is possible - to remove the plate inserts from the lower... -
Page 18: Loading Cups, Glasses And Coffee Services
Loading Cups, Glasses and Coffee Services Arrange smaller, sensitive items in the lower rack and place long, pointed items of cutlery in the knife drawer. • Arrange plates and dishes offset on and under the folding cup racks so that washing water can reach all items. -
Page 19: Adjusting The Height Of The Upper Basket
Adjusting the Height of the Upper Basket Maximum Height of the Dishes in the Upper Rack Lower Rack With upper basket raised 22 cm 31 cm With upper basket lowered 24 cm 29 cm The height of the basket can also be adjusted when it is loaded. -
Page 20: Filling With Detergent
Filling with Detergent Only use dishwasher detergent. Fill with detergent: Prior to the start of a wash programme (not for the pre wash programme). The detergent is released into the wash water during the programme. Please observe the manufacturer's dosing and storage recommendations as stated on the detergent packaging. -
Page 21: Use Of "3 In 1"/ Combi Detergent Tablets
Use of "3 in 1"/ Combi Detergent Concentrated Detergent Tablets Based on their chemical composition, dishwasher detergents can be split into two basic types: – conventional, alkaline detergents with caus- General Advice tic components. – low alkaline concentrated detergents with These products are tablets with combined detergent/ natural enzymes. -
Page 22: Selecting The Wash Programme (Programme Table)
Selecting the Wash Programme (Programme Table) Choose the most suitable wash programme with the aid of this table: Type of Dishes: Dinner Service and Pans in addition: – – – Type of heavy soiling; heavy soiling; heavy to normal soiling, Soiling: dried on left-overs, dried on left-overs,... - Page 23 Dinner service and Dishes Coffee and Type of Dishes: Pans without Pans Party Dishes in addition: with dishes that are sensitive – with delicate glasses to changes in temperature Type of normal soiling dishes that have just been slight soiling Soiling: used, normal to slight soiling Particularly suitable...
-
Page 24: Starting A Dishwashing Cycle
Starting a dishwashing cycle 1. Check that the dishes and cutlery are stacked in Interrupting the dishwashing cycle by the dishwasher in such a way that the spray arms opening the dishwasher door are free to rotate. Hot steam may escape when the door is 2. -
Page 25: Load Sensing
pressing the start delay button until the length of the selected dishwashing cycle appears in the multi- display. The selected dishwashing cycle will begin immediately. Changing the dishwashing cycle after the start delay has been set: As long as the dishwashing cycle has not started, you are still able to change the start delay set by pressing a cycle button. -
Page 26: Care And Cleaning
Care and Cleaning Do not under any circumstances use furni- ture care products or aggressive cleaners. • If necessary, clean the controls only with a soft cloth and pure warm water. • Occasionally check the internal containers, door seal, and water inlet for soiling, clean if necessary. Cleaning the Filter The filters in the base of the washing com- partment are to a large extent self-cleaning. -
Page 27: Replacing The Internal Light
Replacing the Internal Light The inside of the dishwasher is lit by a high quality, low-voltage lamp. A defective lamp may be replaced only by a trained technician. Before beginning to work, pull the dish- washer power plug out of the socket. For safety reasons, the lamp is not accessible from the inside. -
Page 28: What To Do, When
What to do, when ... Try to rectify minor faults on the dishwasher with the aid of the instructions given here. If you call in cus- tomer service to resolve one of the malfunctions listed here, or rectify an error made in the operation of the appliance, the customer service engineer’s visit is not free of charge, even during the period of guar- antee. -
Page 29: There Are Problems When Operating The Dishwasher
... there are problems when operating the dishwasher. Fault Possible cause Remedy The dishwasher door has not been closed Close the door. properly. The mains plug is not plugged in. Insert the mains plug. The fuse has blown in the household fuse Replace the fuse. -
Page 30: Technical Data
Technical Data Capacity: 12 place settings including serving dishes Permitted Water 1-10 bar (=10-100 N/cm = 0.1-1.0 MPa) Pressure: Electrical Connection: Information on the electrical connection is given on the rating plate on the inner edge of the dishwasher door on the right. Dishwasher: Free-Standing Appliances Dimensions: 850 x 600 x 600 (H x B x D in mm) -
Page 31: Notes For Test Institutes
Notes for Test Institutes Testing in accordance with EN 60704 must be carried out with the appliance fully loaded and using the test pro- gramme (see Programme Table). Tests in accordance with EN 50242 must be carried out when the salt dispenser and rinse aid container have been filled with salt and rinse aid respectively and using the test programme (see Programme Table). - Page 32 Sample loading arrangement: Cutlery basket Some dishwasher models have cutlery baskets with- out a grid insert.
-
Page 33: Installation And Connection Instructions
INSTALLATION AND CONNECTION INSTRUCTIONS Installing the Dishwasher • The dishwasher must be installed on a firm floor and adjusted to ensure that it is stable and level. • To compensate for unevenness in the floor and to match the height of the appliance to that of sur- rounding units extend the threaded feet by unscrewing : –... -
Page 34: Built-In Dishwasher
Built-In Dishwasher (see enclosed installation instructions) Free-Standing Appliances can be set up as stand-alone without addi- tional installation. If the dishwasher is set up next to a cooker, a heat-insulating, non-flammable plate must be mounted between the dishwasher and the cooker, flush to the top edge of the work sur- face (depth 57.5 cm). -
Page 35: Connecting The Dishwasher
Connecting the Dishwasher Water Connection The dishwasher is fitted with safety devices that pre- vent the wash water returning into the drinking water system and comply with the applicable plumbing reg- ulations. • The dishwasher can be connected to cold and hot water supplies up to max. -
Page 36: Water Inlet Hose With Safety Valve
The following section is only applicable to dishwashers that have a safety valve on the threaded hose fitting for the tap: Water inlet hose with safety valve After connecting the double-walled water inlet hose, the safety valve is next to the tap. Therefore the water inlet hose is only under pressure while the water is running. -
Page 37: Water Drain
Water drain Drain hose The drain hose must not be kinked, crushed or entangled. • Connecting the drain hose: – Maximum permitted height: 1 metre. – Minimum required height 40 cm above the lower edge of the machine. Extension hoses •... -
Page 38: Electrical Connection
Electrical connection Prior to connecting ensure that the mains voltage and In compliance with electric company techni- current rating at the site of installation match the cal requirements for mains connections, nominal voltage and current rating given on the rating hard-wired connections to the mains may plate. -
Page 39: Service
SERVICE In the section "What to do, if..." the most important sources of faults that you can rectify yourself are summarised. If, nevertheless, you call in customer service to resolve a problem listed in these instruction, or because of an error made in operating the appliance, the customer service engineer’s visit is not free of charge, even during the warranty period. - Page 40 The Electrolux Group. The world´s No.1 choice. The Electrolux Group is the world´s largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx. USD 14 billion in more...
