Electrolux EFT 600-2 User Manual

Electrolux EFT 600-2 User Manual

Electrolux cooker hood
Hide thumbs Also See for EFT 600-2:
Table of Contents

Advertisement

Quick Links

Gebrauchsanweisung, Libro de Instrucciones
EFT 600-2 - EFT 604
Manual de Instruções, User Manual
D
E
P
UK

Advertisement

Table of Contents
loading

Related Manuals for Electrolux EFT 600-2

Summary of Contents for Electrolux EFT 600-2

  • Page 1 Gebrauchsanweisung, Libro de Instrucciones EFT 600-2 - EFT 604 Manual de Instruções, User Manual...

  • Page 2: Table Of Contents

    Contents Safety instructions ......................30 At installation and service ........................30 At use of cooker hood ......................... 30 At disposal ............................30 Description of the appliance ..................... 31 Standard accessories included: ......................31 Function .............................. 31 Exhausting ............................31 Recycling ............................. 31 Special accessories ......................

  • Page 3: Safety Instructions

    Congratulations to your new Cooker Hood Thank you for your choice of an Electrolux product. We are convinced that you will have great use and pleasure from your new cooker hood. Before you use the cooker hood we recommend that you read through the whole user manual giving a direct description of the cooker hood and its functions.

  • Page 4: Description Of The Appliance

    1. Light switch 2. Motor speed switch 3. Work light EFT 604 4. Suction grid with grease filter Standard accessories included: EFT 600-2 Screws: Duct with no return valve Plug for unused outlet hole Function The hood may be used as follows: Fig.

  • Page 5: Special Accessories

    Special accessories Active carbon filter When the hood is used in recirculation mode an active carbon filter should be used. Order by the retailer PNC 942 120 388 Installation Unpacking Check that the cooker hood has no damages. Transportation damages should immediately be reported to the one responsible for the transport Damages, faults and eventually missing details should immediately be reported to the seller.

  • Page 6: Mounting Under Cupboard

    Mounting of hood on wall In this case 3 expansion plugs Ø 8 mm and 3 screws 5x45 are needed and must be pur- chased separate. Make 3 Ø 8 mm holes in the wall. 2 at points H, 1 as desired at points I. Insert the three Ø...

  • Page 7: Using The Hood

    EFT 604 we recommend using the highest speed in particular cases of strong odour and vapour concentration. EFT 600-2 We recommend starting up the hood a few minutes before cooking and keeping it running until all the odours have been eliminated.

  • Page 8: Maintenance

    Maintenance Before performing any maintenance operation, disconnect the hood from the electricity. Grease filter This serves to hold the grease particles in sus- pension. The metal filter should be washed every Fig. 11 month with warm soapy water or, if possible, in the dishwasher (60°C).

  • Page 9: If The Hood Does Not Function

    If the hood does not function Before you make contact to service Check that the power plug is connected to the wall power outlet and that no fuse is blown. Do not do any operations that can cause hazard or damage to the product.

  • Page 10: Technical Data

    Technical data Model EFT 600-2 / EFT 604 Capacity 230 m 170 m Min. 120 m Dimension Height 130 mm Width 599 mm Depth 493 mm Light 2 x 40 W E 14 Grease filter 1 pc Mains Voltage 220-230 V...
  • Page 13 LI1BMC Ed.12/05...
