USER MANUAL ENGLISH Thank you very much for choosing the iiyama LCD monitor. We recommend that you take a few minutes to read this comprehensive manual carefully before installing and switching on the monitor. Please keep this manual in a safe place for...
IIYAMA CORPORATION: Breguetlaan 8, 1438BC Oude Meer The Netherlands We recommend recycling of used product. Please contact your dealer or iiyama service center. Recycle information is obtained via the Internet, using the address: http://www.iiyama.com...
BEFORE YOU OPERATE THE MONITOR ........4 FEATURES ..................4 CHECKING THE CONTENTS OF THE PACKAGE ......4 UNPACKING .................5 SPECIAL NOTES ON : ProLite T4260MTS........5 CONTROLS AND CONNECTORS : MONITOR ......6 INSTALLATION ................9 CONTROLS AND CONNECTORS : REMOTE CONTROL ..10 PREPARING THE REMOTE CONTROL ........11 BASIC OPERATION ..............12...
STOP OPERATING THE MONITOR WHEN YOU SENSE TROUBLE If you notice any abnormal phenomena such as smoke, strange sounds or fumes, unplug the monitor and contact your dealer or iiyama service center immediately. Further use may be dangerous and can cause fi re or electric shock.
Page 6
CAUTION INSTALLATION LOCATION Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky areas as it may cause fi re, electric shock or damage. You should also avoid areas where the sun shines directly on the monitor. DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION The monitor may topple and cause injury if not suitably located.
Power Switch for hours. Contact your dealer or iiyama service center for the backlight replacement when the screen is dark, fl ickering or not lighting up. Never attempt to replace it by yourself.
CHECKING THE CONTENTS OF THE PACKAGE The following accessories are included in your package. Check to see if they are enclosed with the monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama offi ce.
Moving the monitor requires at least two people. If not, it may drop and could result in a serious injury. When moving/shipping the monitor, please hold by the white handles. SPECIAL NOTES ON : ProLite T4260MTS CAUTION Permanent damage can occur if Sharp Edged, Pointed or Metal items are used to activate Touch.
CONTROLS AND CONNECTORS : MONITOR <Side Controller> Power Button SOURCE Input Select Button Right Button Left Button Up Button Down Button MENU / EXIT Menu/Exit Button <Front> Green Normal Operation Power Management Orange Power Indicator If power off and select LED on via menu "Front LED ON" Power Off If power on and select LED on via menu "Front LED OFF"...
Page 11
<Left Side> AC OUT AC Connector (AC-OUT) AC IN AC Connector (ON) / (OFF) Main Power Switch <Right Side > Touch USB* Touch USB Connector * Available for ProLite T4260MTS only. BEFORE YOU OPERATE THE MONITOR 7...
Page 12
<Back> RS485 RS485 RS232C SPDIF Component Video S-Video Video HDMI1 HDMI2 Audio Composite Audio Extender Component Audio HDMI1 HDMI HDMI Connector HDMI2 HDMI HDMI Connector DVI-D 24pin DVI-D 24pin Connector D-SUB mini 15pin D-SUB mini 15pin Connector PC Audio In Mini Jack Audio Connector IR Extender...
INSTALLATION CAUTION Follow the manual instructions for the type of mount you have selected. Refer all servicing to qualifi ed service personnel. Moving the monitor requires at least two people. Before installing, please make sure the wall is strong enough to hold the necessary weight of the display and the mount.
CONTROLS AND CONNECTORS : REMOTE CONTROL Turns the monitor ON and OFF. VGA / DVI / HDMI1 / COMP1 / Selects the source. AV1(VIDEO1) / HDMI2 ECO+ Brightness of back-light is reduced. ECO- Brightness of back-light is increased. P-SOURCE Selects the secondary sub source. MENU Opens the monitor's on-screen menu systems.
PREPARING THE REMOTE CONTROL To use the remote control, insert the two dry batteries. CAUTION Do not use any other batteries other than those specifi ed in this manual for the Remote Control. Do not insert old and new batteries together in the Remote Control. Make sure that the terminals match the "+"...
BASIC OPERATION Turning the monitor ON [Monitor] [Remote Control] T h e m o n i t o r i s t u r n e d O n a n d t h e P o w e r Indicator turns to Green when you press the Power Button on the monitor or the Remote Control.
Page 17
Move the cursor vertically [Monitor] [Remote Control] Select adjustment by pressing the Button while the menu page is displayed on the screen. MENU Move the cursor horizontally [Monitor] [Remote Control] S e l e c t m e n u o r s e t t i n g , o r p e r f o r m t h e adjustment by pressing the Button while the menu page is displayed on the screen.
Page 18
Adjust the volume of sound [Remote Control] Press the Volume+ / Volume- Button on the Remote Control to adjust the volume of sound when the menu page is not displayed on the screen. MENU Switch the input signal [Monitor] [Remote Control] This is activated when you successively press...
An incorrect connection may cause serious damage to both the monitor and the computer. The cable supplied with the monitor is for a standard 15 pin D-Sub connector. If a special cable is required please contact your local iiyama dealer or regional iiyama offi ce.
Page 20
[ Connection example with the peripheral device ] CAUTION Turn off the power switch and unplug the monitor and peripherals before connection to avoid electric shock or damage. NOTE Refer to the user manual of peripherals at the same time. ...
Change to the desired signal timing listed on page 40: COMPLIANT TIMING. Windows 95/98/2000/Me/XP/Vista/7 Plug & Play The iiyama LCD monitor complies with DDC2B of VESA standard. The Plug & Play function runs on Windows 95/98/2000/Me/XP/Vista/7 by connecting the monitor to DDC2B compliant computer with the Signal Cable supplied.
OPERATING THE MONITOR To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT TIMING shown on page 40. You are also able to adjust the picture by following the button operation shown below. For more detailed adjustments, see page 31 for SCREEN ADJUSTMENTS.
Page 23
OSD LOCK MODE: LOCK: Press ENTER, ENTER, EXIT, EXIT, ENTER and EXIT on the Remote Control in sequence and OSD will be locked. UNLOCK: Press ENTER, ENTER, EXIT, EXIT, ENTER and EXIT on the Remote Control in sequence and OSD will be Unlocked. OPERATING THE MONITOR 19...
ADJUSTMENT MENU CONTENTS Image Settings Image Settings Scheme User Brightness Contrast Sharpness Saturation Backlight Colour Temperature & Gamma Adjustment Item Problem / Option Button to Press Displays a picture on a screen set by Image User Settings adjustments. For displaying outdoor scenery images. Vivid Scheme * For movie and video environment.
Image Settings Image Settings Colour Temperature & Gamma Gamma Colour Temerature User Red Gain Green Gain Blue Gain Red Offset Green Offset Blue Offset Adjustment Item Problem / Option Button to Press High contrast Gamma Normal User Go to adjustment menu of Gain and Offset. Greenish white 5000K Colour Temperature...
Page 26
Display Settings Display Settings Main Main Aspect Ratio Full Screen Zoom Auto Scan Select Source PIP Mode PIP Position Top-Left Aspect Ratio Full Screen Side By Side Scale Auto Scan Select Source Adjustment Item Problem / Option Button to Press Full Screen Expansion display Native...
Page 27
Display Settings Display Settings Main Aspect Ratio Full Screen Zoom Auto Scan Select Source PIP Mode PIP Position Top-Left Aspect Ratio Full Screen Side By Side Scale Auto Scan Select Source Adjustment Item Problem / Option Button to Press PIP function is turned off. Sub screen is displayed at maximum size.
Page 28
PIP = Picture in Picture With this function, you can display two different picture. Main Screen Main Screen Sub Screen Sub Screen Side by Side Small Middle Large PIP Screen Table Main HDMI1 HDMI2 Component S-Video Video HDMI1 HDMI2 Component S-Video Video 24 OPERATING THE MONITOR...
Page 29
Audio Settings Audio Settings Volume Bass Treble Balance HDMI HDMI Audio Input Adjustment Item Problem / Option Button to Press Too soft Volume Too loud Too weak Bass Too strong Too weak Treble Too strong Adjust the volume balance of the speaker right Balance and left.
Page 30
Real Time Clock Buttons : Number select, Move the cursor vertically MENU Button: Return previous menu item iiyama Logo displayed when the monitor is turned on. Start Up Logo iiyama Logo does not display when the monitor is turned on.
Page 31
Advanced Settings Advanced Setting Auto Adjustment Image Position Phase Clock Flesh Tone Power LED IRFM Baud Rate 115200 Monitor ID Light Sensor Factory Reset VGA ADC Settings Adjustment Item Problem / Option Button to Press Return to Menu. 1,2,4 Auto Adjustment * Adjust Position, Clock and Phase automatically.
Advanced Settings Advanced Setting Auto Adjustment Image Position Phase Clock Flesh Tone Power LED IRFM Baud Rate 115200 Monitor ID Light Sensor Factory Reset VGA ADC Settings Adjustment Item Problem / Option Button to Press Return to Menu. Factory Reset Factory-preset data is restored.
Page 33
Advanced Settings Advanced Setting VGA ADC Settings ADC Mode Default User ADC Calibration Restore ADC to Default Adjustment Item Problem / Option Button to Press Factory Mode Default ADC Mode User Setting Mode User Return to Menu. User ADC Calibration* Press Button.
System Status System Status Channel Information Source Resolution Main 1920x1080@60.0Hz Firmware Version V0.20d Adjustment Item Problem / Option Button to Press Displays information regarding the current input signal coming from the graphic card in your computer. System Status NOTE See your graphic card user guide for more information about changing the resolution and refresh.
If the screen has a fl icker or blur, or the picture does not fi t in the display area after performing the Auto Adjust, manual adjustments are required. Both adjustments should be made by using the screen adjustment pattern (Test.bmp) obtained via the IIYAMA web site (http://www.iiyama.com). Adjust the image by following the procedure below to get the desired picture.
Page 36
C Press the AUTO Button. (Auto Adjustment : Remote Control) D Adjust the image manually by following procedure below when the screen has a fl icker or blur, or the picture does not fi t in the display area after performing the Auto Adjust. E Adjust the V-Position so that the top and bottom of the picture frame will fi...
Page 37
G Adjust the Phase to correct horizontal wavy noise, fl icker or blur in the zebra pattern. In case the strong fl icker or blurs remain on a part of the screen, repeat steps F and NOTE G because the Clocks may not be adjusted correctly. If the fl icker or blurs still remain, set the refresh rate of computer to low (60Hz) and repeat steps from C again.
POWER MANAGEMENT FEATURE The power management feature of this product complies with power saving requirement of VESA DPMS. When activated, it automatically reduces unnecessary power consumption of the monitor when your computer is not in use. To use the feature, the monitor needs to be connected to a VESA DPMS compliant computer. There is a power management step the monitor takes as described below.
MONITOR or if the problem persists. 3. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance. Problem Check ...
RECYCLING INFORMATION For better environment protection please don't dispose your monitor. Please visit our web site: www.iiyama.com/recycle for monitor recycling. 36 Recycling information...
APPENDIX SPECIFICATIONS : ProLite T4260MTS Touch Technology Optical Screen Light transmission Communication USB serial transfer system Size Category 42" LCD Panel Driving system a-Si TFT Active Matrix Size Diagonal: 42" (106.5cm) Pixel pitch 0.1615mm H × 0.4845mm V Brightness 370cd/m...
