Sylvania SRT2220P Owner's Manual

Get it fixed, at your home or ours!
For repair- in your home -of all major brand appliances,
lawn and garden equipment, or heating and cooling systems,
no matter who made it, no matter who sold it!
For the replacement parts, accessories and
owner's manuals that you need to do-it-yourself.
For Sears professional installation of home appliances
and items like garage door openers and water heaters.
1-800-4-MY-HOME
Call anytime, day or night (U.S.A. and Canada)
www.sears.com
For repair of carry-in items like vacuums, lawn equipment,
and electronics, call or go on-line for the location of your nearest
Sears Parts & Repair Center.
Call anytime, day or night (U.S.A. only)
To purchase a protection agreement on a product serviced by Sears:
1-800-827-6655
(U.S.A.)
Para pedir servicio de reparación
a domicilio, y para ordenar piezas:
1-888-SU-HOGAR
(1-888-784-6427)
Registered Trademark / TM Trademark / SM
R
Marca Registrada / TM Marca de Fábrica /
R
MC MD
Marque de commerce / Marque déposée de Sears, Roebuck and Co.
FULL 90 DAY WARRANTY
For 90 days from the date of purchase, Sears will repair any defect in material or workmanship in this TV, free
of charge. For one year from the date of purchase, SEARS will supply at no charge, replacement for defective
parts.
Two (2) years for Picture Tube. Certain parts are excluded from this warranty.
The above warranty coverage applies only to TV which are used for private household purposes.
TO OBTAIN WARRANTY SERVICE, SIMPLY RETURN THE TV TO THE NEAREST SEARS SERVICE CEN-
TER IN THE UNITED STATES.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Sears Roebuck and Co., Dept. 817WA Hoffman Estates, IL 60179
For the location of a Sears Service Center in your area : 1-800-488-1222
0EMN02309
ANTENNA/CABLE CONNECTIONS
CAUTION: TO PREVENT ELECTRIC
SHOCK, MATCH WIDE BLADE OF
PLUG TO WIDE SLOT, FULLY INSERT.
ATTENTION:
POUR ÉVITER LES CHOC
ÉLECTRIQUES, INTRODUIRE UHF
Antenna
LA LAME LA PLUS LARGE DE
(Not supplied)
LA FICHE DANS LA BORNE
CORRESPONDANTE DE LA
PRISE ET POUSSER
JUSQU'AU FOND.
VHF/UHF
Combination Antenna
(Not supplied)

CLOSED CAPTION

This TV can receive C1 and C2 Caption and Text.
Caption Mode
(1) Closed Caption Characters can be displayed on the TV screen only when the received broad-
cast signal contains Caption Signals.
(2) Paint-on mode: Displays input characters on the screen immediately.
Pop-on mode: Once characters are stored in memory, they are displayed all at once.
Roll-up mode: Displays the characters continuously by scrolling (max. 4 lines)
Note: If CAPTION C1 or C2 is selected but a Closed Caption signal is not included, characters
will not be displayed.
Text Mode
(1) Displays the text on the screen by scrolling (max. 7 lines)
(2) If the received broadcast signal does not contain caption or text signals, no change will occur.
Your Home
R
(1-800-469-4663)
www.sears.ca
Our Home
1-800-488-1222
www.sears.com
1-800-361-6665
(Canada)
Au Canada pour service en français:
1-800-LE-FOYER MC
SM
(1-800-533-6937)
www.sears.ca
Service Mark of Sears, Roebuck and Co.
SM Marca de Servicio de Sears, Roebuck and Co.
© Sears, Roebuck and Co.
UHF/VHF Rod
Antenna
(Not supplied)
VHF
Antenna
(Not supplied)
OR
VHF/UHF Combiner
(Not supplied)
Owner's
Manual
FEATURES
Flat Screen Picture Tube
MTS/SAP Tuner
181 Channel Selection- All VHF/UHF channels plus up to 125 cable channels.
PLL Frequency Synthesized Tuning- The latest PLL frequency synthesized electronic
tuning system provides easy channel selection, and lets you tune directly to any channel using
the channel number buttons (0~9 and +100-key) on the remote control.
On-Screen Function Display.
Full-Function Remote Control
Sleep Timer
Closed Caption Decoder- You may view specially labeled (cc) TV programs, movies, news,
prerecorded tapes, etc. with either a dialogue caption or text display added to the program.
Auto Shut Off Function- If there is no air signal input from the antenna terminal and no
user operation for 15 minutes, the TV will turn itself off automatically.
V-CHIP- Enables parents to prevent their children from watching inappropriate material on TV.
S-VIDEO Input- allows you to get better picture detail and clarity for the playback of S-VHS
VCR tapes satellite, or DVD discs.
PRECAUTIONS
Place your TV in a room with adequate ventilation.
Keep your TV set away from sources of direct heat, such as heat registers or direct sunlight.
Do not place your TV on soft surfaces, such as rugs or blankets.
Leave enough room for air to circulate around the bottom, top and back of the set.
The serial number of this product may be found on the back of the TV. No others have the same
serial number as yours. You should record the number and other vital information here and retain
this book as a permanent record of your purchase to aid identification in case of theft.
Date of Purchase
Dealer Purchase from
Dealer Address
IF YOU NEED ADDITIONAL ASSISTANCE FOR SET-UP OR OPERATING
AFTER READING OWNER'S MANUAL, PLEASE CALL TOLL FREE
1-800-968-3429.
Printed in China
L6505HF * * * * *
*
CATV Box
or Satellite Box
(Not supplied)
OUT IN
ANT.IN
VIDEO 1 INPUT
R L VIDEO
S-VIDEO
75-ohm
Coaxial Cable
ANT. IN
OR
AV input (stereo)
Notes:
(1) When your TV receives a special effects playback signal (i.e., Search, Slow, Still) from a
VCR's video output channel (CH3 or CH4), your TV may not display the correct caption or
text.
(2) Captions and texts may not match the TV voice exactly.
(3) Interference may cause the closed caption system not to function properly.
(4) The caption or text characters will not be displayed while the menu display or functions dis-
play is shown.
(5) If you see this screen:
If your TV displays a black box on the screen, this means that your TV is set to TEXT mode. To
clear screen, select CAPTION C1, C2 or CAPTION [OFF].
20 INCH
COLOR TELEVISION
SRT2220P
Dealer Phone No.
Model No.
Serial No.
*
Some cable TV systems use scram-
bled signals and require a special con-
verter to receive these channels.
Consult your local cable company.
From Cable System
or Satellite Antenna
75-ohm
Coaxial Cable
From Cable System
Note to CATV system installer:
This reminder is provided to call the CATV system installer's attention to Article
820-40 of the NEC that provides guidelines for proper grounding and, in particu-
lar, specifies that the cable ground shall be connected to the grounding system of
the building as close to the point of cable entry as practical.
FCC WARNING- This equip-
ment may generate or use radio
frequency energy. Changes or
modifications to this equipment
may cause harmful interference
unless the modifications are
expressly approved in the
instruction manual. The user
could lose the authority to oper-
ate this equipment if an unau-
thorized change or modification
is made.
