1
0G0207
REF
2
0G0834
1
3
0G0820
REF
4
0E9747
1
5
0G0839
2
6
0G0781
1
7
0G0722
1
8
0G0758
1
9
0G0431
1
10
0G0663
1
11
0G0786
1
12
0G0486
1
13
0F9617A
1
14
0A1354B
1
15
0G0823
1
16
0G1467
1
17
0D2244M
1
18
036710
2
19
0C5479
1
20
059980
7
21
046526
17
22
022131
18
23
0G3922
9
24
0G0464
1
25
0G0465
1
26
052858
14
27
061652
1
28
0G3920
4
29
0A7387
4
30
039414
1
31
022129
4
32
022145
3
33
029333A
1
34
057821
3
35
045771
3
36
022507
2
37
022097
2
38
022473
5
39
057823
1
40
077996
1
41
0A6751
1
42
035579
1
43
0A8584
1
44
0C1852
1
45
070928
1
46
069860C
1
47
069811
1
48
0G1241
1
49
025065
1
50
027738A
1
51
0E3257
3
52
0A8830
29
53
0G0905
1
54
0G02070100
1
55
0F5512
1
56
0G2068
REF
57
055596
1
58
0C7649
2
59
0C5210
1
60
051756
1
61
0G3900
1
62
0G38620ST03
1
63
0G38580ST03
1
ENGINE GENERAC 1.6L NG
ENGINE PLATE 1.6L
HOUSING BLOWER MACHINED 1.6L
STARTER 12 VOLT
ENGINE MOUNTING FOOT STAMPING
EXHAUST MANIFOLD 1.6L MACHINED
INTAKE MANIFOLD MACHINED 1.6L
HEAT SHIELD LOWER 1.6L
HEAT SHIELD UPPER 1.6L
PULLEY CRANKSHAFT MACHINED
WASHER PULLEY
BRACKET TENSIONER
SPACER ALTERNATOR
DC ALTERNATR HAN-KOK
V-BELT 3/8 X 30.6
HEAT SHIELD FRONT 1.6L
ASSY MAGPICKUP(3/8-24 MALE)
PIN SPRING 1/4 X 3/4
SCREW HHC M12-1.5 X 40 G10.9
SCREW HHC M10-1.5 X 25 G10.9
WASHER LOCK M10
WASHER FLAT 3/8-M10 ZINC
NUT HEX M10-1.5 CLASS 10 ZINC
GASKET INTAKE MANIFOLD 1.6L
GASKET EXHAUST MANIFOLD 1.6L
NUT TOP LOCK FL M8-1.25
SCREW HHC M10-1.5 X 85 G8.8
SCREW HHC M10-1.5 X 110 G10.9
SCREW HHC M10-1.5 X 40 G10.9
SCREW HHC M8-1.25 X 35 G8.8
WASHER LOCK M8-5/16
WASHER FLAT 5/16-M8 ZINC
TIE WRAP UL 7.4" X .19" BLK
SCREW HHC M8-1.25 X 40 G8.8
NUT HEX M8-1.25 G8 CLEAR ZINC
SCREW HHC 1/4-20 X 1/2 G5
WASHER LOCK M6-1/4
WASHER FLAT 1/4-M6 ZINC
CLAMP HOSE #10 .56-1.06
CAP ANTIFREEZE RUBBER
SWITCH HI-TEMP 245 D X 3/8 NPT
BSHG RDCR HEX 1/4 TO 1/8
SWITCH OIL PRESSURE 10PSI 2POL
ADAPTER DRAIN OIL
CLAMP HOSE - OIL DRAIN
HOSE OIL DRAIN ASSY 21"
CAP HEX 1/4 NPT BRASS
THERMOSTAT HOUSNG MACHIND 1.6L
NIPPLE PIPE 3/8 NPT X 1-1/2
PIPE TEE 3/8 NPT
SCREW HWHTF M6-1.0 X 16
WASHER FLAT .34 ID X .75 OD
HARN 1.6L R-200 CPL (NOT SHOWN)
OIL FILTER 1.6L
REFLEX WRAP 13MM 13 X 460 (6" LG)
GASKET T-STAT HOUSING 1.6L
BARBED STR 3/8 NPT X 3/8
CLAMP HOSE .38-.87
HOSE 3/8 ID LOW PRES OIL/WATER (11" LG)
SCREW HHC M10-1.5 X 20 G8.8
CAP, 1.5" HOLE SHALLOW
STRUT RH 1.6L ENG ADAPT PLATE
STRUT LH 1.6L ENG ADAPT PLATE
