Generac Power Systems Guardian ULTRA SOURCE 004583-0 Owner's Manual page 37

ITEM PART NO. QTY.
1 0C5729 1
2 0E9843 1
3 090388 3
4 0C5372 1
5 0C3005 1
6 0E3372B 1
7 0D8067A 1
8 071983 4
9 0G0693 1
10 043790A 1
11 0E2950 2
0E2985 2
12 021533 2
13 0E1466 2
14 0D4041 1
15 0D4788 2
16 093064 1
17 0C2977 1
18 0C5943 1
19 0E4357E 1
0E4356E 1
20 0E3223 2
0E3222 2
21 0D2157 2
22 0E6098 1
23 0D4123A 1
24 0E8152 1
25 0C3011 2
26 0C3009 2
27 0C3010 2
28 093873 2
29 0F5458 1
30 0C5998 1
31 0D4497 1
32 0C3971E 1
33 0D3745 1
34 0C3027 3
35 0E9842 1
Commercial-Industrial-Residential Portable Generator System
GT-990 & GT-760 Engine (Page 1) – Drawing No. 0E8589-N
DESCRIPTION
ASSEMBLY, CRANKCASE HOUSING WITH
SLEEVE
SEAL, 38 I.D. CRANKSHAFT
SCREW, TAPTITE M6-1.0 X 12 BP
ASSEMBLY, BREATHER
GASKET, BREATHER COVER
SEPARATOR, OIL BREATHER
ASSEMBLY, HEAD #1
RETAINER, PISTON PIN 20
ASSY, ROCKER COVER W/BARB
BARBED EL 90 3/8NPT X 3/8 W/ VS
PISTON, LC (GT-990)
PISTON, HC (GT-760)
SET, PISTON RING 90MM
PIN PISTON
ASSEMBLY, CAMSHAFT & GEAR
PLUG STD PIPE 3/8 STEEL SQ HD
ASSEMBLY, OIL FILL CAP
GASKET, CRANK CASE
SEAL, OIL PASSAGE
ASSEMBLY, CRANKSHAFT HORIZONTAL
DIRECT DRIVE (GT-990)
ASSEMBLY, CRANKSHAFT HORIZONTAL
DIRECT DRIVE (GT-760)
ASSEMBLY, CONNECTING ROD (GT-990)
ASSEMBLY, CONNECTING ROD (GT-760)
SCREW SHC M6-1.0 X 50 G8.8
SCREEN, OIL PICKUP
ASSEMBLY, OIL PUMP
O-RING, 0.49 ID X 0.07 THICK
COVER, OIL RELIEF
SPRING, OIL RELIEF
BALL, 1/2D OIL RELIEF
WASHER, LOCK RIB M6
SCREW, PLASTITE HI-LOW #10
CLAMP, OIL TUBE
PLUG-CRANKCASE GOVERNOR BORE
ASSEMBLY, DIPSTICK WITH HANDLE
TUBE, DIPSTICK
O-RING, OIL CLR
SEAL, 42 I.D. CRANKSHAFT
Section 9 — Exploded Views and Parts Lists
ITEM PART NO.
36 0C5731
37 0C3006
38 080318
39 0C8808
40 0D2723D
41 0C2979
42 086515
43 0D2274
44 0D3867
45 078672
46 0C5371
47 072694
48 0C3027
49 0D5313
50 0D3998
51 0D6024
52 0C2976
53 086516
54 0C2229
55 083897
56 0D8067B
57 0D9853D
58 0C2978
59 0D6008
60 0D4010
61 0D6007
62 0D4012
63 0D8675A
64 0D8675B
65 0D4015
Item 59 (Kit) includes items 3, 30, 35, 65
Item 60 (Kit) includes items 2, 5, 17, 18, 34, 35, 40, 57, 139, 153.
Item 61 (Kit) includes items 8, 11, 12, 13
Item 62 (Kit) includes items 4, 5, 6
Item 63 (Kit) includes items 7, 41, 42, 43, 44, 45, 46, 47, 49, 50, 51, 52,
Item 64 (Kit) includes items 41, 42, 43, 44, 45, 46, 47, 49, 50, 51, 52, 53,
Item 65 (Kit) includes items 25, 26, 27
QTY. DESCRIPTION
1 ASSEMBLY, HOUSING COVER WITH
SLEEVE
10 SCREW, HHFC M10-1.5 X 55
8 SCREW HHFC M6-1.0 X 25
2 HOOK, LIFTING
1 COVER, ROCKER W/OIL FILL "GENERAC"
TEXT
2 GASKET, VALVE COVER
8 KEEPER, VALVE SPRING
4 RETAINER, VALVE SPRING
4 SPRING, VALVE
2 SEAL, VALVE STEM D7
4 WASHER, VALVE SPRING
4 STUD, ROCKER ARM PIVOT
2 O-RING, 3/8" X 1/2"
4 ROCKER ARM
4 NUT, HEX M8-1.0 GB YELLOW CHROM
2 PLATE, PUSH ROD GUIDE
12 SCREW HHFC M8-1.25 X 65
2 VALVE, EXHAUST
2 VALVE, INTAKE
4 TAPPET, SOLID
1 ASSEMBLY, HEAD #2
4 PUSHROD 147
2 GASKET, HEAD
1 KIT GEAR COVER
1 KIT GASKET
1 KIT PISTON & RINGS
1 KIT BREATHER ASSEMBLY
1 KIT HEAD ASSEMBLY CYLINDER 1
1 KIT HEAD ASSEMBLY CYLINDER 2
1 KIT OIL RELIEF
53, 54, 57, 58
54, 56, 57, 58
35
