Generac Power Systems 004373-1, 004626-0 Owner's Manual page 35

ITEM PART NO. QTY.
1 0D7397 1
2 0D1521A 1
3 0D1522 1
4 067680 1
5 0C8243 1
6 0C8244 1
7 0A6321 1
8 048467 1
9 057907 1
10 064008 1
11 0A6323 1
12 055444 1
13 030468 1
14 049939 1
15 070370 1
16 022158 1
17 023762 1
18 023897 15
19 076009A 1
20 040213 4
21 0A3394 1
22 082573 1
23 076020 1
24 032300 1
25 022676 1
26 064009 1
27 061945 1
28 076037 1
29 070081 1
30 070043 1
31 070045 1
32 070042 1
33 081988 1
Section 7 — Exploded Views and Parts Lists
(Model No. 004626-0) Guardian Liquid-cooled 40 kW Generators
DESCRIPTION
PNL BTM & BACK CNTL PNL 04626
CONTROL PANEL FRONT W/ SILK
SCREEN
PANEL SIDE COVER CONTROL PANEL
ASSY VOLTAGE REGULATOR 60HZ
WASHER LOCK HDP DEUTSCH
NUT, HDP DEUTSCH
PANEL LEFT SIDE E
CIRCT BRK 7 X 1 ETA 46-500-P
RES WW LUG 10R 10% 25W
COVER CON PNL TOP (NOT SHOWN)
CHASSIS AVR & E-GOV
HEATSINK
WASHER STEP NYLON .20
RECTIFIER MSC 12A 600V 1N1206R
WASHER MICA .203
NUT HEX #10-32 STEEL
WASHER SHAKEPROOF EXT #10 STL
WASHER FLAT #10 ZINC
PP LOGIC ASM 50/60HZ
PCB SUPPORT SNAP-IN 1/4"
DECAL, ELEC GOVERNOR
SWITCH ROCKER DPST 125V SPD
SWITCH TOG DPDT 15/10 SP
HOLDER FUSE
FUSE 15A X AGC15
LIGHT 12VDC .02A LED RED PILOT
SWITCH SELECTOR 6A AMP/V
VOLTMETER DC 8-18V
HOURMETER
VOLTMETER AC 0-300
AMMETER AC 0-200
FREQUENCY METER 240V 55-65HZ
DECAL EXERCISE INFO
Control Panel - Drawing No. 0D6978-A
ITEM PART NO. QTY.
34 0C1229 1
35 0D3440 1
36 0A3968 1
37 048766 REF
38 0A1441B 1
39 083264 1
40 0A1441C 1
41 057335 REF
42 076061 1
43 029333 6
44 040479 4
45 022507 4
46 022127 4
47 022097 4
48 033121 14
49 022152 14
50 036902 4
51 022155 6
52 022985 8
53 036918 8
54 022264 8
55 038150 8
56 022471 8
57 022188 6
58 0C2428 8
59 0C2323 4
60 0A2284 4
61 0C1127 1
62* 0D5324 4
63* 0A9611 1
* PART OF CONTROL PANEL WIRE HARNESS
Generac
DESCRIPTION
DECAL CUST CONN BOX
CONTROLLER, B-C #DPG-2103
CAPACITOR FILTER ASY
BLOCK TERM 20A 2 X 6 X 1100V
COVER PLATE AVR
TFMR ASM,CMA 240/12V
COVER PLATE EGOV
BLOCK TERM 20A 20 X 6 X 1100V
DECAL TERM. STRIP
TIE WRAP 7.4" X .19" NATL UL
VIB MNT 1.0 X 1.0 X 1/4-20
SCREW HHC 1/4-20 X 1/2 G5
NUT HEX 1/4-20 STEEL
WASHER LOCK M6-1/4
SCREW HHC #10-32 X 1/2
WASHER LOCK #10
SCREW PPHM #6-32 X 1/2
WASHER LOCK #6
WASHER FLAT #6 ZINC
SCREW PPHM #8-32 X 1/2
WASHER LOCK #8-M4
WASHER FLAT #8 ZINC
NUT HEX #8-32 STEEL
NUT HEX #6-32 STEEL
SCREW PHTT #6-32 X 1/2 ZYC
SCREW PHTT #6-32 X 5/8 ZYC
SCREW SWAGE 8-32 X 1/2 Z/YC
DECAL AVR COVER
FUSE & HOLDER LITTEL 7.5A
FUSE 7.5AXBK/AGC7.5NX
Power Systems, Inc. 33
®
