Receive And Transmit - Icom IC-4088A Instruction Manual

5
q Select the desired operating
channel with [Y]/[Z].
When a signal is received:
• " " indicator appears on the
display.
• Squelch opens and audio is
emitted from the speaker.
- Further adjustment of [VOL]
may be necessary at this point.
w Push and hold [PTT] to transmit
then speak into the microphone.
• Do not hold the transceiver too
close to your mouth or speak too
loudly. This may distort the sig-
nal.
• The transmit indicator "
pears on the display.
e Release [PTT] to return to re-
ceive.
IMPORTANT:
To maximize the readability of the transmitted signal, pause a
few sec. after pushing [PTT], hold the transceiver 4 to 6 in. (10 to
15 cm) from your mouth and speak at a normal voice level.
NOTE:
The transceiver has an auto power save function to conserve
the battery power. The power save function activates automati-
cally when no signal is received for 5 sec.
10

RECEIVE AND TRANSMIT

[Y]
[Z]
Appears
[PTT]
" ap-
