- Page 1 user manual Oven EB L20...
-
Page 2: Table Of Contents
2 electrolux Electrolux. Thinking of you. Share more of our thinking at www.electrolux.com Contents Safety instructions........3 Cleaning and Care......... 19 Description of the Appliance ....4 What to do if …........24 Before Using for the first time ....5 Installation Instructions ...... -
Page 3: Safety Instructions
electrolux 3 Safety instructions Electrical safety How to avoid damage to the appliance • This appliance must be only connected • Do not line the oven with aluminium foil by a registered electrician. and do not place baking trays, pots, etc. on the oven floor, as the heat that builds •... -
Page 4: Description Of The Appliance
4 electrolux Description of the Appliance General Overview Control panel Door handle Oven door Control Panel Oven Power Indicator Temperature Pilot Light Oven Functions Temperature selector... -
Page 5: Before Using For The First Time
electrolux 5 Oven Features Top heat and heating elements Fat trap Oven lighting Shelf positions Fat Filter Oven lighting Fan heating element Bottom heating element, Aluminium base plate removable Oven shelf runners, removable Oven accessories Oven shelf Baking tray For cookware, cake tins, roasts and grilled For cakes and biscuits. -
Page 6: Using The Oven
6 electrolux Using the Oven Switching the Oven On and Off Oven Power Indicator Temperature Pilot Light Oven Functions Temperature selector 1. Turn the oven functions dial to the de- sired function. 2. Turn the temperature selector to the de- sired temperature. -
Page 7: Oven Functions
electrolux 7 Oven Functions The oven has the following functions: Oven function Application Light Using this function you can light up the oven interior, e.g. for cleaning. Convection with ring To bake on three oven levels maximum at the same time. heating element Decrease the oven temperatures (20-40 °C) compared with Conven- tional. -
Page 8: Inserting/Removing The Fat Filter
8 electrolux Inserting the oven shelf: Inserting/Removing the Fat Filter Only use the fat filter when roasting to protect the rear heating elements from fat splashes. Insert the oven shelf so that the feet point downwards. Push the oven shelf between the guide bars of the selected oven level. -
Page 9: Uses, Tables And Tips
electrolux 9 Uses, Tables and Tips Baking 3 baking trays: Oven function: Convection with ring heating element or Conventional Baking tins • For Conventional dark metal and non-stick tins are suitable. • For Convection with ring heating element bright metal tins are also suitable. -
Page 10: Baking Table
10 electrolux • Cakes and pastries at different heights With longer baking times, the oven can may brown at an uneven rate at first. If be switched off about 10 minutes before this occurs, please do not change the the end of baking time, to make use of temperature setting. - Page 11 electrolux 11 Type of Oven Temperature Time Oven function baking level °C Mins. Cake with crumble topping (dry) Convection with ring 150-160 20-30 heating element Buttered almond cake/sugar Conventional 190-210 20-30 cakes Butter plait Convection with ring 170-180 40-50 heating element Fruit flans Convection with ring 40-50...
- Page 12 12 electrolux Type of Oven Temperature Time Oven function baking level °C Mins. Small cakes (20per tray) Convection with ring 20-30 heating element Small cakes (20per tray) Conventional 20-30 1) Pre-heat the oven Baking on more than one oven level Convection Convection with ring...
-
Page 13: Tips On Baking
electrolux 13 Tips on baking Baking results Possible cause Remedy The cake is not browned Wrong oven level Place cake lower in the oven enough at the bottom The cake sinks (becomes Oven temperature too high Use a slightly lower setting soggy, lumpy, streaky) Baking time too short Set a longer baking time... - Page 14 14 electrolux Bakes and gratins table Tempera- Shelf Time Dish Oven function ture position Mins. °C Pasta bake Conventional 180-200 45-60 Lasagne Conventional 180-200 40-50 Vegetables au gratin Convection grilling 160-170 20-30 Baguettes topped with melted Convection grilling 20-30 cheese Sweet bakes Conventional 180-200...
-
Page 15: Roasting Table
electrolux 15 Roasting table Temper- Shelf Time Type of meat Quantity Ovenfunction ature position Mins. °C Beef Pot roast 1-1.5 kg Conventional 200-250 120-150 per cm. of Roast beef or fillet thickness per cm. Convection - rare 190-200 of thickness grilling per cm. -
Page 16: Grill Sizes
16 electrolux Temper- Shelf Time Type of meat Quantity Ovenfunction ature position Mins. °C Convection Chicken, poulard 1-1.5 kg 190-210 50-70 grilling Convection Duck 1.5-2 kg 180-200 80-100 grilling Convection Goose 3.5-5 kg 160-180 120-180 grilling Convection Turkey 2.5-3.5 kg 160-180 120-150 grilling... - Page 17 electrolux 17 Defrosting Oven function: Defrost (no tempera- ture setting) • Unwrap the food and place it on a plate on the oven shelf. • Do not cover with a plate or bowl, as these can substantially lengthen the de- frosting time.
-
Page 18: Making Preserves
18 electrolux Oven level Temperature in Time in hours Food to be dried °C (Guideline) 1 level 2 levels Vegetables Beans 60-70 1 / 4 Peppers (strips) 60-70 1 / 4 Vegetables for soup 60-70 1 / 4 Mushrooms 50-60 1 / 4 Herbs 40-50... -
Page 19: Cleaning And Care
electrolux 19 Cooking time until Continue to cook Temperature Preserve simmering at 100°C in°C in mins. in mins. Vegetables Carrots 160-170 50-60 5-10 Cucumbers 160-170 50-60 Mixed pickles 160-170 50-60 Kohlrabi, peas, asparagus 160-170 50-60 15-20 1) Leave standing in oven when switched off Cleaning and Care Warning: First switch off the appliance Clean stubborn dirt with a special oven... -
Page 20: Shelf Support Rails
20 electrolux Shelf Support Rails To re-insert, first hook the rail into place at the back (1) and then insert the front and The shelf support rails on the left and right press into place (2). hand sides of the oven can be removed for cleaning the side walls. -
Page 21: Oven Lighting
electrolux 21 2. Rotate the fat trap to the left from the If necessary: replace with oven roof (see illustration). 25 watt, 230 V, 300 °C heat-resistant oven lighting. Refit the glass cover. Changing side oven light/Cleaning glass cover 3. Wash the fat trap in hot water with washing-up liquid and a soft brush or simply wash in the dishwasher. -
Page 22: Oven Ceiling
22 electrolux Oven Ceiling Oven door The upper heating element can be folded For easier cleaning of the oven interior the down to make it easier to clean the oven ceil- oven door of your appliance can be taken off ing. - Page 23 electrolux 23 4. Take hold of the oven door with a hand Open the oven door as far as it will go. on each side and pull it away from the oven at an upwards angle (Take care: It is heavy). Fold up the clamping levers (A) on both door hinges back into their original positions.
-
Page 24: What To Do If
24 electrolux What to do if … Fault Possible cause Remedy The oven does not heat. The oven has not been switched Switch the oven on. The required settings have not Check the settings. been made. The domestic electrical protection Check the fuses or protection de- device (fuse) has been tripped. -
Page 25: Installation Instructions
electrolux 25 Installation Instructions Installing the oven Electrical connection/power supply The oven must be connected to the electric- When installing into combustible materi- ity supply by a designated electrician. al, NIN 2005, chapter 4.2.2 and the fire Use a H05VV-F type power cable or higher. protection guidelines and their provi- The appliance must be installed with a sock- sions set by the Association of Swiss... - Page 26 26 electrolux 9. Tighten the screws on the terminal box from underneath. 10. Do not use the terminal box to connect other appliances (e.g. hobs). In case of repair the appliance must be switched off from the mains. Installation diagram Phase definitions: L1, L2 (equivalent to R, S)
-
Page 27: Disposal
electrolux 27 Disposal Packaging material The packaging materials are environ- mentally friendly and can be recycled. The plastic components are identified by markings, e.g. >PE<, >PS<, etc. Please dispose of the packaging materials in the appropriate container at the com- munity waste disposal facilities. - Page 28 28 electrolux Garantie/Kundendienst, Garantie/service-clientèle, Garanzia/Servizio clienti, Guarantee/Customer Service Centres Servicestellen Points de Service Servizio dopo vendita Point of Service 5506 Mägenwil/Zürich 3018 Bern 1028 Préverenges 6916 Grancia Industriestrasse 10 Morgenstrasse 131 Le Trési 6 Zona Industriale E 9000 St. Gallen Zürcherstrasse 204 e 4127 Birsfelden Hauptstrasse 52...
-
Page 29: Service
electrolux 29 Service In the event of technical faults, please first check whether you can remedy the problem yourself with the help of the operating in- structions (section “What to do if…”). If you were not able to remedy the problem yourself, please contact the Customer Care Department or one of our service partners. - Page 32 www.electrolux.com www.electrolux.ch 315 9000 03-N-091208-01...
