American Standard MOMENTS T506.50X Installation Instructions

MOMENTS
BATH/SHOWER TRIM KIT
Thank you for selecting American-Standard...the benchmark
of fine quality for over 100 years.
To ensure that your installation proceeds smoothly--please
read these instructions carefully before you begin.
Recommended Tools
Pipe Wrench
ROUGHING-IN DIMENSIONS
To assure proper positioning in relation to wall, note
roughing-in dimensions.
FINISHED WALL
5-5/8" REF.
8-1/8" REF.
"SEE ILLUSTRATION "
74" FOR
HEAD CLEARANCE
8-3/8"
18"
OPTIONAL
TOP OF
TUB RIM
BOTTOM OF
TUB
CARE INSTRUCTIONS:
DO: SIMPLY RINSE THE PRODUCT CLEAN WITH CLEAR WATER. DRY WITH A SOFT COTTON FLANNEL CLOTH.
DO NOT: DO NOT CLEAN THE PRODUCT WITH SOAPS, ACID, POLISH, ABRASIVES, HARSH CLEANERS, OR A
CLOTH WITH A COARSE SURFACE.
Flat Blade Screwdriver
Plumbers' Putty or Caulking
Phillips Screwdriver
3/4"" TO 2-3/8"
1/2" NPT
2-3/8"
OPTIONAL TO FINISHED
FLOOR USUALLY
BETWEEN 65'' AND 80''
SHR
TUB
6-1/2"
1/2" NPT
1-1/2" REF.
4"
Installation
Instructions
T506.50X
Adjustable Wrench
SHR. 1/2" NOM.
COPPER SWEAT
SWEAT
INLETS
TUB 1/2" NOM.
COPPER SWEAT
SWEAT
INLETS (STOPS)
SHR. 1/2" NOM.
COPPER SWEAT
TUB 1/2" NOM.
COPPER SWEAT
INLETS 1/2" NPT
3-3/8"
3-3/8"
OUTLETS
1/2" NPT
THREADED INLETS
Certified to comply with ANSI A112.18.1
M 9 6 8 9 5 1 R ev. 1. 4
Channel Locks
INLETS
INLETS
1/2" NOM.
4-1/16"
COPPER
SWEAT
2"
4-1/16"
5-7/8"
4-1/16"
INLETS
1/2" NOM.
COPPER
SWEAT
OUTLETS
1/2" NPT
5-7/8"
3-3/8"
THREADED INLETS (STOPS)
INLETS
1/2" NPT
