- Page 1 WASHER-DRYER KURUTMALI ÇAMAÇIR MAKINESI INSTRUCTION BOOKLET KULLANIM KILAVUZU EW 1289 W 132 991 030...
- Page 2 Dear customer, Please read these operating instructions carefully and pay particular attention to the safety notes indicated in the first pages. We recommend that you keep this instruction booklet for future reference and pass it on to any future owners. Transport damages When unpacking the appliance, check that it is not damaged.
-
Page 3: Table Of Contents
Contents Operating sequence 19-21 Warnings Washing programmes Disposal Drying programmes International wash code symbols Tips for environmental protection 5 Maintenance Technical specifications Bodywork Detergent dispenser drawer Installation Drain pump Unpacking Water inlet filter Positioning Emergency emptying out Water inlet Frost precautions Water drainage Electrical connection Something not working? -
Page 4: Warnings
Warnings The following warnings are provided in the interests of overall safety. You must read them carefully before installing or using the appliance. • Use only the recommended quantities of fabric Installation softener. An excessive amount could damage the • All internal packing must be removed before using laundry. -
Page 5: Disposal
• This machine incorporates a special child safety feature to prevent small children from being trapped inside the machine. To activate this device, rotate the button (without pressing it) inside the door clockwise until the groove is horizontal. If necessary use a coin. To disable this device and restore the possibility of closing the door, rotate the button anti-clockwise until the groove is vertical. -
Page 6: Technical Specifications
Technical specifications DIMENSIONS Height 85 cm Width 60 cm Depth 60 cm WASHING DRYING MAXIMUM LOAD Cotton 5.5 kg 2.7 kg Synthetics Delicates Woollens SPIN SPEED 1200 rpm max. POWER SUPPLY VOLTAGE/FREQUENCY 220-230 V/50 Hz TOTAL POWER ABSORBED 2200 W MINIMUM FUSE PROTECTION 10 A WATER PRESSURE... -
Page 7: Installation
Installation 6. Set the machine upright and remove the Unpacking remaining rear screw. Slide out the relevant pin. 7. Plug the open holes with the plugs which you will All transit bolts and packing must be removed find in the plastic envelope containing the before using the appliance. -
Page 8: Water Drainage
The inlet hose must not be lengthened. If it is too Electrical connection short and you do not wish to move the tap, you will This machine is designed to operate on a 220-230 V, have to purchase a new, longer hose specially single-phase, 50 Hz supply. -
Page 9: Your New Washer-Dryer
Your new washer-dryer This new machine, which is fitted with the Direct Spray system, patented Electrolux, meets all modern needs for effective treatment of laundry with low water, energy and detergent consumption. Further savings are achieved by washing small loads of laundry, since water and electricity consumption is proportional to the quantity and type of laundry being washed. -
Page 10: Use
Control panel Position SOGUK corresponds to a COLD WASH. 1 ON/OFF button This option can be used for very delicate laundry, Press this button to switch the machine on. The such as curtains. display (8) will show three blinking dashes or a Important! blinking zero.You will find more detailed explanations By depressing TEMPERATURE and SPIN SPEED... -
Page 11: Electronic Drying Button
• Drain only 7 Electronic Drying button - Press the SKIP/RESET button (ELEKTRONIK KURUTMA) (ILERLETME/IPTAL) once, so as tocause the By means of this button you can choose the required DRAIN light (BOSALTMA) to light up, then press degree of drying for cottons and synthetics: the START/PAUSE button. - Page 12 • Duration of washing programme in hours and • Delay start, a time value indicated in hours and minutes, after you have selected a programme. selected by means of the relevant button While the programme is running (after you have (GECIKTIRME).
- Page 13 - set the washing machine to PAUSE by pressing the 10 START/PAUSE button START/PAUSE button (the relevant light will flash); (Baslat/Beklet) - press the SKIP/RESET button once or several This button has three functions: times, until the required phase(s) is(are) cancelled (the light next to the name of the phase(s) will go •...
-
Page 14: Delay Start Button
• If the machine is switched off: 13 Programme phase indicator - depress ON/OFF (AÇMA/KAPAMA) button to lights switch it on; When you select a programme, the lights relevant to - select the type of fabric by means of button the phases that form the programme light up. -
Page 15: Washing Hints
Laundry weights Washing hints The following weights are indicative: Sorting the laundry bathrobe 1200 g napkin 100 g Follow the wash code symbols on each garment label and the manufacturer’s washing instructions. quilt cover 700 g Sort the laundry as follows: sheet 500 g whites, coloureds, synthetics, delicates, woollens. -
Page 16: Detergents And Additives
residual marks with bleach. Quantity of detergent to be used Ink: depending on the type of ink, moisten the fabric The type and quantity of detergent will depend on first with acetone (*), then with acetic acid; treat any the type of fabric, load size, degree of soiling and residual marks on white fabrics with bleach and then hardness of the water used. -
Page 17: Drying Hints
Drying symbols on garment labels Drying hints Always look at the garment label to check whether As a dryer, the machine works on the condensation garments can be machine dried. principle. The following symbols refer to drying: Therefore, the water tap must be open and the drain hose must drain water into a sink or into Machine drying is usually possible the drain pipe, even during the drying cycle. -
Page 18: Operating Sequence
4. Switch the machine on Operating sequence Press the ON/OFF button (AÇMA KAPAMA) to switch the machine on. Washing only The display will show three blinking dashes or a Before washing your first load of laundry, we blinking zero. The light above the button will light up. recommend that you run a cotton cycle at 60°C, with the machine empty, in order to remove any manufacturing residue from the drum and tub. -
Page 19: Select The Temperature
6. Select the temperature 9. Select the DELAY TIME Press the TEMPERATURE button SICAKLIK if you Before you start the programme, if you wish the wish to select a temperature value different from the starting to be delayed, press the DELAY button one proposed by the washing machine or the COLD GECIKTIRME repeatedly, or keep it pressed, to WASH “SOGUK”. -
Page 20: At The End Of The Programme
If it is necessary to drain the water in order to change stops automatically, gives an audible signal, and the programme in progress, proceed as follows: displays a blinking zero. • PAUSE the machine by pressing the If you had selected the RINSE HOLD option, the START/PAUSE button;... -
Page 21: Autodrying 2 Kg Of Synthetics
4. Press the START/PAUSE button to start the Drying 2.7 kg of cotton programme. You have for example just machine-washed and spun at 1200 rpm 5.5 kg of laundry. They are cotton fabrics of medium weight which you want to iron as soon as they are dry. Press the SKIP/RESET button repeatedly to erase the programme that has just been carried out, the display will show 3 dashes and switch the machine... -
Page 22: Washing Programmes
Washing programmes Washing programmes Consumption* Wash Additional Temp. Fabrics Programme options Load Energy Water Time litres h/min. Cottons (Whites) SPIN SPEED 1.95 2.39 °- Cotton fabrics, e.g. 5.5 kg 95° Beyazlar sheets, tablecloths, RINSE HOLD PREWASH household linen AA40° QUICK WASH Coloured cotton or SPIN SPEED 5.5 kg... -
Page 23: Drying Programmes
Drying programmes Timed drying Degree of Drying time Type of fabric Max. load Spin speed drying mins 85-95 1200 2.7 kg Extra dry Ideal Cotton and linen for towelling (bathrobes, bath materials towels, etc.) 1.5 kg 1200 55-65 1200 75-85 2.7 kg Cotton and linen (towels, T-shirts,... -
Page 24: International Wash Code Symbols
International wash code symbols These symbols appear on fabric labels, in order to help you choose the best way to treat your laundry. Energetic wash Max. wash Max. wash Max. wash Max. wash temperature temperature temperature temperature 95°C 60°C 40°C 30°C Hand wash Do not... -
Page 25: Maintenance
Maintenance 1. Bodywork 3. Drain pump Clean the outside of the machine with warm water The pump should be inspected if and a detergent used to handwash dishes. Rinse • the machine does not empty and/or spin with clean water and dry with a soft cloth. •... -
Page 26: Water Inlet Filter
• Put the cap back on the emergency emptying hose 6. Frost precautions and place the latter back in its seat. If the machine is installed in a place where the temperature could drop below 0°C, proceed as follows: • Remove the plug from the socket. •... -
Page 27: Something Not Working
Something not working? Problems which you can resolve yourself. During machine operation it is possible that one of the following alarm codes appears on the display: - E10 : problem with the water supply - E20 : problem with water draining - E40 : door open Once the problem has been eliminated, press the START/PAUSE button to restart the programme. - Page 28 Problem Possible cause • The electronic unbalance detection device has cut • Spinning starts late or the in because the laundry is not evenly distributed in laundry is not spun enough: the drum. The laundry is redistributed by reverse rotation of the drum. This may happen several times before the unbalance disappears and normal spinning can resume.
