- Page 1 O p e r a t i n g I n s t r u c t i o n s c t i o n s EDE 5360 822 944 155 - 01 - 1201...
-
Page 2: Dear Customer
Dear customer, Please read these operating instructions through carefully. Please make sure you read the safety instructions on the first pages of these operating instructions! Keep the operating instructions for future reference. Pass them on to any future owners. With the warning triangle and/or by means of key words (Danger!, Caution!, Attention!), information is emphasized which is important for your safety or the correct functioning of... -
Page 3: Table Of Contents
Contents Important Safety Information ....4 Program tables ......16 General Information . -
Page 4: Important Safety Information
Important Safety Information Safety of children The safety of Electrolux electrical appliances com- plies with the established technical principles and • Children are often not aware of the dangers statutory equipment safety regulations. Nevertheless, involved when handling electrical equipment. as manufacturer we have to draw your attention to the Therefore provide the necessary supervision of following safety instructions. -
Page 5: General Information
Installation and connection • Please follow the separate Installation and con- • Check that the tumble dryer is not standing on the nection instructions . If necessary get some advice mains cable. from your local chimney sweep or building authori- •... -
Page 6: Environmental Protection Tips
Environmental protection tips • Your laundry will become light and soft in the tum- This is based on the principle: the better you spin the ble dryer even without a fabric softening agent. washing before drying the more economical the dryer •... -
Page 7: The Key Features Of Your Appliance
The key features of your appliance • Program or time setting via the program selector • SPECIAL CARE (SCHON) button for gentle dry- ing of sensitive fabrics • AUDIBLE SIGNAL (SIGNAL) can be selected in addition; an intermittent audible signal is sounded after the end of the program. -
Page 8: Description Of The Appliance
Description of the appliance Front view Fluff filter Control panel Interior Light Rating plate Reversable door Removal Plinth Feet (all height-adjustable) -
Page 9: Control Panel
Control panel A Program selector: for setting the drying program B Program run display: The currently running phase of the drying process is indicated. C Buttons and display block – SPECIAL CARE (SCHON) button: sensitive fabrics. – AUDIBLE SIGNAL (SIGNAL) button: When switched-on, an audible signal is sounded at the end of the drying program;... -
Page 10: The Program Selector
The program selector • OFF (AUS): The tumble dryer is switched off. • LIGHT (BELEUCHTUNG): The drum light switches on when the door is opened. • Program group COTTON (BAUMWOLLE): Programs for drying cotton and linen fabrics; maximum load 5 kg. •... -
Page 11: Brief Instructions
Brief instructions • Ensure the laundry is well spun before tumble dry- ing. • Prepare the laundry. • Open the door and insert washing. • Shut the door. Attention! Do not catch washing in the door. • Select the drying program –... -
Page 12: Drying
Drying Prepare the laundry • To prevent tangled bundles of laundry: Close zip fasteners; button-up bed linen and pillow cases; tie-together loose tapes, e.g. aprons. • Empty all pockets. • Remove all metal objects (paper clips, pins, etc.). • Turn clothing consisting of double-layer fabric inside out (such as cotton-lined anoraks with the cotton layer facing outwards). -
Page 13: Start Time Pre-Selection
2. If required, select the button SPECIAL CARE (SCHON) or AUDIBLE SIGNAL (SIGNAL). • SPECIAL CARE (SCHON) button This program operates with reduced heat. Press the SPECIAL CARE (SCHON) button for fabrics bearing the care symbol S. Gentle drying is advisable for heat-sensitive fabrics (such as acrylic and viscose). -
Page 14: Start The Drying Program
Start the drying program 1. Press button START/PAUSE (START/ PAUSE). The drying programme begins. You can check the progress of the drying procedure in the pro- gramme progress display. Removing laundry or loading laundry when necessary You can interrupt the drying process at any time to remove some of the laundry or to add more laundry. -
Page 15: Clean The Fluff Filter
Clean the fluff filter To ensure efficient operation of the tumble dryer, clean the fluff filter after each drying program. Also check whether there are any remnants or fluff from the washing in the drum; remove immediately. 1. Press the catch of the filter lid downwards. The filter lid will open. -
Page 16: Program Tables
Program tables Program group COTTONS (BAUMWOLLE), care symbols R, Q; maximum load 5 kg Program Laundry Type Examples for EXTRA DRY Heavy weight or mult-layered fabrics Towelling material, bath robes (EXTRATROCKEN) VERY DRY Thick textiles that are to be thoroughly Towelling, terry towels (STARKTROCKEN) dried. -
Page 17: A Small Glossary Of Textile Information
Program WOOL (WOLLPFLEGE), maximum load 1kg To freshen up the wool fibres of woollen garments after they have been line dried, worn or stored for longer peri- ods they can be treated briefly using warm air. The wool emerges beautifully soft. Recommendation: remove fabrics immediately after drying. -
Page 18: Cleaning And Maintenance
Cleaning and maintenance Cleaning the filter area Important! A small amount of fluff may reach the area around the filter in spite of the fluff filter. Therefore you should clean the entire filter area from time to time, or at least every three months. -
Page 19: Something Not Working
Something not working? If the tumble dryer is not working correctly please carry out the following checks before calling an engi- neer. Symptom Possible cause Solution The appliance is not plugged in Plug in the appliance The fuse has blown Check the fuse The START/PAUSE (START/ Press the START/PAUSE (START/... -
Page 20: Replace The Interior Light
Replace the interior light 1. A replacement bulb can be purchased through 3. Screw-off the bulb cover. (The bulb is located at your local Electrolux Service Force Centre (Part the top behind the door; see Front view ). No: 647072580). 4. -
Page 21: Door Reversal Instructions
Door Reversal Instructions The door opening direction can be changed if required. Warning! Before reversing the door, isolate the appliance from the mains supply. Proceed as follows to reverse the door opening direc- tion: A C B A C B 1. -
Page 22: Technical Data
Technical data Height x Width x Depth 85x60x60cm This appliance complies with the following Depth with the door open 117cm EC directives: – 73/23/EEC of 19/2/1973 ’Low voltage Height adjustable from 1.0/–0.4cm directive’ Empty weight approx. 40 kg – 89/336/EEC of 3/5/1989 ’EMC directive’ Load (depending on the program) max. -
Page 23: Points De Service
Servicestellen Points de Service 6032 Emmen 1028 Préverenges Buholzstrasse 1 Le Trési 6 9000 St. Gallen Points de vente de rechange Vonwilstrasse 15 5506 Mägenwil 8048 Zürich Industriestrasse 10 Badenerstrasse 587 0848/ 848 023 8604 Volketswil Hölzliwisenstrasse 12 Demonstration/Vente 8048 Zürich 7000 Chur Badenerstrase 587 Comercialstrasse 19...
