SMART START GUIDE
1406031_14a_Mazda_CX-9_SSG_071013.indd 1
7/10/13 9:02 AM

Advertisement

Table of Contents
loading

Related Manuals for Mazda 2014 CX-9

Summary of Contents for Mazda 2014 CX-9

  • Page 1 SMART START GUIDE 1406031_14a_Mazda_CX-9_SSG_071013.indd 1 7/10/13 9:02 AM...

  • Page 2: Advanced Keyless Entry System

    ADVANCED KEYLESS ENTRY SYSTEM Door Request Switch • T his system allows you to lock and unlock the doors, open the liftgate and even start the engine without taking the key out of your pocket or purse. While Carrying the Advanced Key • U nlock the driver’s door by pushing Advanced Key the driver’s door request switch once. Lock • U nlock all doors and the liftgate by pushing the driver’s door request Unlock switch twice or by pushing the passenger’s door request switch...

  • Page 3: Starting The Engine

    www.MazdaUSA.com STARTiNg ThE ENgiNE While Carrying the Advanced Key… • S tart the engine by pushing the start knob in and turning it (like a normal key) while depressing the brake pedal. • S hut the engine OFF by turning the start knob to the ACC position and then pushing in and turning to the OFF position. • T he indicator light will show green when the advanced key is detected. If the indicator light flashes green, the advanced key transmitter battery power is low. NOTE: The RED Key Indicator Light may illuminate if either advance key or keyless entry key is placed in the cup holder. The cup holder is a dead zone for transmitter reception. With the Auxiliary Key… To start engine, remove the Start knob cover by squeezing both release buttons and...
  • Page 4 Seats ELECTRONiCALLY OPERATED SEAT WiTh MEMORY Recline Switch Push forward or backward to adjust seatback angle. Slide/Tilt Switch Seat can be moved back and forth, raised, lowered, or tilted with this control. Lumbar Switch Push forward or backward to increase or decrease lumbar support. Memory Seat Switch To Program the Driver’s Seat Position and Outside Mirror Angle 1 Park the vehicle. 2 A djust the seat to the desired position using the slide/tilt and recline switches. 3 A djust the outside mirror angles. 4 P ush the memory seat SET button followed by one of the programming buttons (1-3) until a beep is heard. Programming is now complete.
  • Page 5 www.MazdaUSA.com SECOND ROW SEATBACK RECLiNE To recline the seatback, lean forward slightly while folding lever. Then lean back to the desired position and release the lever. FOLDiNg ThE SECOND-ROW SEATS 1 Unfasten the lap portion of the center-rear seat belt. 2 Slide seat all the way back toward rear of vehicle. 3 Lower head restraints. 4 Pull the seatback folding lever and fold the seatback forward. SPLiT FOLDiNg ThiRD-ROW SEAT To create a flat luggage compartment space, fold the seatbacks forward. 1 Open liftgate. 2 L ower head restraints. 3 P ull each strap on the rear of the seat while pushing the left Straps and right seat forward to lay flat. To Return to the Original Position P ull the strap to return the seatback to the original position.

  • Page 6: Driver's View

    Driver’s View (shown with optional CRUiSE CONTROL/ LighTiNg/ NAVigATiON VOiCE TURN SigNALS RECOgNiTiON (P. 9) POWER LiFTgATE SWiTCh (P. 16) PARKiNg hEADLighT SENSOR LEVELiNg SYSTEM (P. 15) (P. 9) TRACTiON BLiND SPOT CONTROL MONiTORiNg SYSTEM (BSM) (TCS) (P. 13) NAVigATiON SYSTEM SD CARD (P.

  • Page 7: Hazard Warning

    Navigation System) www.MazdaUSA.com PASSENgER iNFORMATiON WiPER/ hAzARD AiRBAg OFF CLOCK WAShER DiSPLAY WARNiNg iNDiCATOR SETTiNg (P. 10) (P. 29) NAVigATiON/ CLiMATE SEAT ACCESSORY AUDiO CONTROL WARMERS SOCKET (PP. 19-20, 23-24) (PP. 17-18) (P. 18) This indicator light illuminates to remind you that the front passenger’s front/side airbags and seat belt pretensioner will not deploy during a collision. The reason for this is that the weight in the seat is less than approximately 66 lbs. Always wear your seat belt and secure children in the rear seats in appropriate child restraints. See the Owner’s Manual for important information on this safety feature. 1406031_14a_Mazda_CX-9_SSG_071013.indd 6 7/10/13 9:03 AM...

  • Page 8: Instrument Cluster

    Instrument Cluster The instrument cluster has a dimmer function that can be cancelled to make the illumination brighter during the day when the headlights are on. If the illumination is too dim during the day, press the knob, or if the illumination does not dim when turning on the headlights at night, press the knob. When dimmed, rotate the knob to adjust the brightness of the illumination. iNSTRUMENT FUEL gAUgE TAChOMETER ShiFT LEVER CLUSTER DiMMER POSiTiON iNDiCATOR gLOSSARY OF WARNiNg AND iNDiCATOR LighTS NOTE: See Owner’s Manual for more details and explanations. Low Fuel Level Tire Pressure Monitoring System ) Warning Light (TPMS KEY Warning Light (RED)

  • Page 9: Security Indicator Light

    www.MazdaUSA.com ODOMETER/ SPEEDOMETER ENgiNE COOLANT TRiP METER TRiP METER TEMPERATURE gAUgE SELECTOR Brake Warning Light Low Engine Oil Pressure Parking brake on/low brake fluid/malfunction Security indicator Light Turn Signals/hazard Warning indicator Lights Door/Liftgate Ajar Automatic Transmission Malfunction On: System is not normal; dealer inspection required. Shift Position indicator Light Flashing: Differential oil temperature is high; dealer inspection required.
  • Page 10 Lights LighTiNg CONTROL/TURN SigNAL LEVER AUTO : The light sensor : Turns tail, : Turns fog lights automatically determines parking, and on only when when to turn the headlights dashboard headlights on or off. lights on. are on. Push for high Beams Pull to Flash high Beams : Turns tail, parking, dashboard, and headlights on. hEADLighT LEVELiNg Adjust headlight angle with headlight leveling switch depending on vehicle passengers & load (example: Driver only = 0, Driver + Passengers = 1 or 2, etc.). Refer to your Owner’s Manual for complete details.

  • Page 11: Rear Window

    Wipers www.MazdaUSA.com WiNDShiELD/REAR WiNDOW WiPER/WAShER CONTROL LEVER AUTO : The rain sensor senses the amount of rainfall and turns the wipers on or off. Rotate inner ring away from you (clockwise) for less sensitivity (requires more rain to turn wipers on) and toward you (counterclockwise) for more sensitivity (requires less rain to turn wipers on). Less sensitive MiST AUTO More sensitive Pull lever to dispense windshield washer fluid Rear Window Wiper/Washer : Intermittent : Normal speed : Washer/wiper (hold as desired) NOTE: Vehicles not equipped with AUTO wipers will have INT wipers. Set the lever to INT and choose an interval timing by rotating the ring between fast and slow. CAUTiON: When the ignition is ON, turn the AUTO wipers OFF when going through a car wash, or while cleaning or touching the windshield.
  • Page 12 Mirrors POWER MiRRORS WiTh REVERSE TiLT DOWN FUNCTiON* When the ignition is switched ON and the selector lever is shifted to Power Door the R position, the outside mirrors tilt Mirror Selector downward to facilitate the view of the Switch lower area on each side of the vehicle. 1 S witch the left/right power door mirror selector switch to the left or right side. 2 S hift the selector lever to the R position while pressing the brake pedal. The outside mirrors tilt downward automatically. NOTE: If the left/right power outside mirror selector switch is in the center position, or the selector lever is shifted to a position other than the R position, the outside mirrors return to their on-road position automatically. The door mirrors return to their on-road position automatically even when the ignition is switched from ON to OFF. 1406031_14a_Mazda_CX-9_SSG_071013.indd 11 7/10/13 9:03 AM...
  • Page 13 Auto-Dimming Auto-Dimming indicator Light Light Sensor Auto-Dimming Mirror • A uto-dimming will automatically darken your rearview mirror to reduce headlight glare from vehicles behind you. • A uto-dimming is activated every time the vehicle is started. NOTE: In addition to the auto-dimming mirror’s rear light sensor, there is also a front light sensor (not shown). Do not place or hang any objects over the front or rear mirror light sensors; otherwise, the auto-dimming mirrors will not operate properly. homeLink ® • T his feature provides a convenient way to replace up to three transmitters such as garage door openers, home lighting remotes and other radio frequency devices. • Refer to your Owner’s Manual for complete programming details. NOTE: Genuine Mazda Accessory Auto-Dimming Mirror with Compass and Homelink or Auto-Dimming Mirror with Rearview Camera is available at your Mazda dealer. 1406031_14a_Mazda_CX-9_SSG_071013.indd 12 7/10/13 9:03 AM...

  • Page 14: Blind Spot Monitoring

    Blind Spot Monitoring BLiND SPOT MONiTORiNg (BSM) SYSTEM (if equipped) The Blind Spot Monitoring (BSM) system is designed to assist the driver by monitoring the blind spots to the rear of the vehicle on both sides. • I f your vehicle speed is 20 mph (32 km/h) or more, the BSM will warn you of vehicles in the detection area by illuminating the BSM warning lights located on the left and right door mirrors.

  • Page 15: Rear Cross Traffic Alert

    Rear Cross Traffic Alert REAR CROSS TRAFFiC ALERT (RCTA) (if equipped) The RCTA is designed to alert the driver of oncoming traffic when backing out of a parking spot. RCTA is active when your vehicle is in reverse and your vehicle speed is 0 to 8 mph (13 km/h). When BSM sensors detect an object moving 3 to 18 mph (5 to 30 km/h) (vehicle/motorcycle), RCTA will notify the driver with indicators and sound: • Rear View Monitor and outside mirror flashing indications.

  • Page 16: Rear View Monitor

    Rear View Monitor Rear View Monitor REAR ViEW MONiTOR (if equipped) Placing the gearshift lever into Reverse automatically operates the Rear View Parking Camera and is viewable via the 5.8” LCD screen. NOTE: When using the Rear View Parking Camera, please check your surroundings as objects may be closer than they appear. PARKiNg SENSOR SYSTEM (if equipped) The parking sensor system uses ultrasonic sensors to detect obstructions behind the vehicle with transmission in Reverse and speed below 6 mph (10 km/h). The system notifies the driver of the approximate distance from the vehicle to the obstruction using a beeping sound. • P ush the parking sensor switch on the dash to turn the system on (switch indicator lit) and off. 1406031_14a_Mazda_CX-9_SSG_071013.indd 15 7/10/13 9:03 AM...

  • Page 17: Manual Liftgate

    Liftgate MANUAL LiFTgATE • T o open, unlock the liftgate, pull up on the handle and raise the liftgate. • T o close, push liftgate down until it securely locks, but do not slam. POWER LiFTgATE • T o open or close using the advanced keyless transmitter, unlock the liftgate and push and hold the liftgate button for one second or more. • T o open or close from the driver’s seat, unlock the liftgate and push and hold the power liftgate switch on the dashboard (see Driver’s View) for one second or more. • T o close when the liftgate is open, push and hold the power liftgate switch located on the lower edge of the liftgate panel for one second or more. • F or safety, the power liftgate will open in the event an obstruction is detected while the liftgate is attempting to close. • I f you wish to open the power liftgate while it is in the process of closing, you may push and hold the switch on the dashboard or the switch located on the lower edge of the liftgate panel for one second or more.

  • Page 18: Automatic Climate Control

    Automatic Climate Control iNFORMATiON DiSPLAY Driver Temperature Fan Control Dial Passenger Control Dial Temperature • P ush OFF to turn climate Control Dial control system off. AUTO ON: Push dial • P ush to turn DUAL • R otate the dial to select to turn Automatic mode on or off. the desired fan speed. Air Conditioning • W ith DUAL mode system on. Rotate P ush to defrost FRONT...

  • Page 19: Rear Climate Control

    www.MazdaUSA.com FRONT SEAT WARMERS The driver and front passenger seats can be warmed by pushing the applicable seat warmer button while the ignition is ON. • S eat temperature increases as the number of indicator lights increases. Two lights equal high, one light equals low. • W hen the seat warmers are not needed, push button until indicator lights are off. REAR CLiMATE CONTROL Rear Control Panel Operation from Front Seats 1 Turn the front air conditioning on. on the front control panel (indicator on). 3 S election of the airflow mode, airflow amount and temperature will be automatically controlled to the same setting as the front air conditioner. Operation from Rear Seats AUTO ON: 1 Turn the front air conditioning on.
  • Page 20 1 M ake sure BT audio device is paired to your vehicle. 2 T urn on BT audio device. 3 T ouch the Bluetooth on-screen tab. ® 4 S elect the BT-Audio option. gRACENOTE The Gracenote media database is used to improve voice recognition of artist and album names with the Mazda Hands Free system. To make best use of the voice recognition, install the most recent database. 1 L oad the Gracenote update on a memory stick from www.MazdaUSA.com/USB. Insert memory stick into the USB port. 2 Push the PHONE button. 3 S elect Setup and scroll down to Gracenote Update. POWER ON TUNiNg Push the Power/Volume dial to Manual: Turn the TUNE/FILE dial to turn the audio system on.
  • Page 21 www.MazdaUSA.com LOADiNg A CD BLUETOOTh AUDiO ® Bluetooth enabled devices ® provide an opportunity to play music through the audio system with no wires attached, however, there are some limitations: Some phone models do not support all features. Go to www.MazdaUSA.com/bluetooth or contact (800) 430-0153 for further assistance or to report a phone /MP3 device concern. 4 R epeat this operation for the other stations and bands you want to hD RADiO store. When receiving a programmed frequency, select AM, FM1, or FM2 HD radio has a special receiver and touch the preset on-screen button. which allows it to receive digital The station frequency will be displayed. broadcasts (where available) in addition to the analog broadcasts it already receives. AUDiO OPERATiON Digital broadcasts have better USiNg VOiCE sound quality than analog broadcasts as digital broadcasts Audio operation and media selection...
  • Page 22 USB PORT OR AUX JACK Your vehicle is equipped with a USB port (some models) and auxiliary AUX jack located in the center console. This will allow you to play your iPod, USB device, or portable audio player through the vehicle’s audio system. Learn the system when parked and do not let it distract you while driving. iMPORTANT: • S et the volume level on your portable audio player to the highest level before distortion starts, then use the vehicle’s audio system to adjust the volume. • U nplug any device from the USB port and accessory socket before turning off the vehicle. Leaving devices plugged in can drain the battery and cause issues during the Bluetooth pairing process at startup. Wait about 15 seconds after starting the vehicle before plugging anything into the USB port. Auxiliary Jack NOTE: You will need an audio cable with an 1/8 inch (3.5 mm) mini stereo plug (available as a Genuine Mazda accessory) to connect your portable audio player into the aux jack. NOTE: AUX jack is not available on vehicles equipped with Rear Seat Entertainment System (RSES). Refer to the Owner’s Manual for additional information. P lug 1/8 inch mini stereo cable into the portable audio player and the AUX jack. 1406031_14a_Mazda_CX-9_SSG_071013.indd 21 7/10/13 9:04 AM...
  • Page 23 www.MazdaUSA.com 2 • A udio Controls (without navigation): Push the AUX button on the audio unit to switch to the AUX mode. • A udio Controls (with navigation): Push AUDIO button on audio system, then touch AUX on-screen button. Use the portable audio player controls to play music. USB Port Refer to the Owner’s Manual for additional information. C onnect the cable into the portable audio player and the USB port. 2 • A udio Controls (without navigation): Push the AUX button on the audio unit to switch to the USB mode and start playback. • A udio Controls (with navigation): Push AUDIO button on audio system, then touch the USB on-screen button.
  • Page 24 • Insert card: Push the card in (label-side up), then slide door closed (left). NOTE: • Visit www.mazdausa.com/navigation within 60 days of vehicle delivery and download the most recent map available for your device for free. In order to download or upgrade your map, the TomTom Home software must be downloaded. Please refer to the Navigation System Owners Manual section of www.mazdausa.com/navigation for additional information. • O nly use your MAP SD card for operating and updating your navigation system. Do not insert the MAP SD card into another vehicle or into any other device such as a camera. • I f your vehicle is not equipped with a factory navigation system, your audio system can be upgraded to include navigation. Contact your Authorized Mazda Dealer for more details. Navigation System PLANNiNg A ROUTE USiNg ThE TOUCh-SCREEN iMPORTANT: In the interest of safety and to reduce distractions while you are driving, you should always plan a route before you start driving. To plan a route on your Navigation system, do the following: 1 Push the NAV button to access the Navigation System. 2 Touch the screen (above) to open the Main Menu (below). 3 Touch Navigate to. 4 Touch Address. NOTE: You can change the country or state setting by touching the flag before you select a city.
  • Page 25 www.MazdaUSA.com 6 Enter the street name. 7 Enter the house number, then touch Done. 8 T he location is shown on the map. Touch Select to continue or Back to enter another address. 9 When the new route is shown, touch Done. For more information about the route, touch Details. PLANNiNg A ROUTE USiNg YOUR VOiCE You can navigate to any of the following places using your voice: • An address, including home. • P OIs for named brands of, for example, restaurants, gas • Favorites. stations, car rental and gyms. • Cities and towns. • A recent destination. • POI (Point of Interest) categories. NOTE: POI in a city searches the system in your present location. To plan a route to an address using your voice, do the following: NOTE: Planning a route using your voice can be done while driving the vehicle.

  • Page 26: Call History

    5 T ouch the on-screen Add New Device button to display the message and switch Talk to the device operation. 6 U sing the device, perform a search for the Bluetooth device (Peripheral device). ® 7 S elect “Mazda” from the device list searched by the device. 8 Y our phone will pair using one of the two ways: Pick-up hang up a. I nput the displayed 4-digit pairing code into the device. b. V erify the displayed 6-digit code on the audio unit, which is also displayed on the device, and touch the Yes on-screen button. Call history Incoming/Outgoing history for the device is downloaded automatically.

  • Page 27: To Make Or Receive A Hands-Free Call

    www.MazdaUSA.com NOTE: For connection issues, please confirm the Bluetooth connection status by pushing the PHONE button and looking in the top left corner for the Bluetooth icon and your phone’s name. Some phones will turn off the Bluetooth signal after connecting the USB cable to the vehicle or after downloading an update • If not displayed, check your phone and make sure Bluetooth is turned on (or discoverable) in the Settings menu. Detailed instructions for some phones are available online. • If there is still no connection, delete the pairing data on the system and your phone and try again after confirming your cell phone is compatible at www.MazdaUSA.com/bluetooth. TO MAKE OR RECEiVE A hANDS-FREE CALL Automatic Bluetooth Basic Operation: Reconnection: button: To make/receive/swap a call. On engine start, the last connected button: To end/reject a call. device will automatically be re-connected button: To skip voice guidance after several seconds. To switch phones, (for speeding up operation). go to BLUETOOTH SETUP. BLUETOOTh FEATURES (WiTh NAVigATiON) See your Owner’s Manual for more information.
  • Page 28 Transmission SPORT A/T MANUAL ShiFT MODE The Sport A/T Manual Shift Mode gives you the feel of driving a manual transmission by allowing you to manually shift to control engine rpm and torque when more control is desired. To Use To Shift Up To Shift Down Manual Shift Mode:...

  • Page 29: Break-In Period

    Fuel Fuel Door Release Fuel Door (located on floor in front of driver’s seat) Release To open, pull the fuel door release. Fuel Regular Unleaded Fuel – 87 Octane Fuel Door To avoid scratching the paint during refueling, secure the fuel filler cap tether over the hook hook as shown. BREAK-iN PERiOD FUEL ECONOMY: No special break-in is necessary, To achieve the best fuel economy, but a few precautions in the first 600 visit www.fueleconomy.gov for miles should be observed. more information. • Do not race the engine. • Do not maintain one constant speed, either slow or fast, for a long period of time.

  • Page 30: Feature Highlights

    Outside Temperature/ Driver Side interior Passenger Side Set Temperature Clock Set Temperature Climate Control ALUMiNUM WhEEL CARE Your aluminum wheels have a protective coating on them. Only use a mild soap or neutral detergent with a sponge or soft cloth to clean them. CAUTiON: Using a wire brush, polishing compound, solvent, or any type of abrasive cleaner may damage the protective coating. PERSONALizE YOUR MAzDA CX-9 WiTh gENUiNE MAzDA ACCESSORiES Go to www.MyMazda.com, then select "Accessories" below the MyMazda Home header for a complete listing of available accessories for your Mazda CX-9. 1406031_14a_Mazda_CX-9_SSG_071013.indd 29 7/10/13 9:04 AM...
  • Page 31 Official Site for M{zd{ Owners Register today on www.MyMazda.com—the ultimate destination for Mazda Owners. Once registered, you’ll be able to take advantage of benefits exclusively for Mazda Owners: • Insider access to exclusive events and promotions • Personalized maintenance schedules • Zoom-Zoom Owner Magazine • Warranty information and on-line Owner’s Manuals • Wallpaper, videos and other fun stuff • Accessories specifically designed for your vehicle...
  • Page 32 Customer Delivery Checklist VEhiCLE PRESENTATiON: Refer to the Smart Start Guide during presentation Keyless Entry ....... Auto-Dimming Mirror* ....• K eyless Transmitter homeLink * ........® • A dvanced Key* • D oor Request Switches* Blind Spot Monitoring* ....• Liftgate Request Switch* Rear Cross Traffic Alert* .....

  • Page 33: Service Department

    Customer Delivery Checklist DEALERShiP DATE SALES CONSULTANT CUSTOMER’S NAME E-MAiL PRESENTATiON OF OWNER’S MATERiALS: Review the following items with the customer Smart Start guide www.MyMazda.com • R emove this checklist from • O ffer to register customer on Smart Start Guide www.MyMazda.com • P ersonalization Features Owner’s Manual (including all Auto Lock/Unlock function settings, refer to your Owner’s Manual) Maintenance Passport Warranty information...
  • Page 34 Remember, to further enhance your driving experience, visit your local Mazda Service Center for your scheduled maintenance. It’s also the place where you can find a wide variety of tires, parts, and accessories that are just right for your vehicle. *See vehicle’s scheduled-maintenance program for details. ** Visit the Mazda Owners website at www.MyMazda.com/fullcircle to find a participating Mazda Full Circle Service Dealer. 1-800-222-5500 Customer Assistance Center: 1-800-866-1998 Roadside Assistance Contact: FREE FULL CiRCLE SERViCE iNSPECTiON We’re committed to providing...
