ZyXEL Communications NWD3105 Quick Start Manual

Quick Start Guide
Hardware Installation
1
Turn off your computer
and unplug the power cord.
2
Remove the computer cover.
Insert the adapter into
an available PCI-E x1 slot.
Secure it with a bracket screw.
3
Connect the antenna.
Point it up.
Replace the computer cover.
4
Connect the computer power.
Turn the computer on.
Software Setup
1
Insert provided disc.
2
Run setup and follow instructions.
1/2
NWD3105
Wireless N-lite
PCI Express Adapter
1
2
PCI-E x1
4
Copyright © 2012 ZyXEL Communications Corp. All Rights Reserved
3
