JVC DLA-RS66 Specifications

Projection Distance Chart
Display size (16:9)
Screen diagonal (inch) W (mm)
60 1,328
70 1,549
80 1,771
90 1,992
100 2,214
110 2,435
120 2,656
130 2,878
140 3,099
150 3,320
160 3,542
170 3,763
180 3,984
190 4,206
200 4,427

Main Features

DLA-RS66
4K Capability
3D Capability
2D-3D Converter
Aperture
Clear Motion Drive
Colour Management
Colour Temperature
(Xenon-lamp Mode)
Picture Tone
Darkness and Lightness
Correction
Pixel Adjust
(by 1/16-pixel increment)
Screen Adjustment Mode (Max 255 modes)
l
Environmental Setting
Auto Calibration* 1
THX Certification
ISF
Anamorphic Mode
Picture Data In/Out* 2
Lens Memory (10 memories)
l
Digital Keystone* 3
Automatic Lens Cover
*1 Requires a commercially available optical sensor, PC and LAN cable. *2 Requires a PC and LAN cable.

Optional Equipment

RF (Radio Frequency) Method
RF 3D Glasses RF 3D Synchro
Emitter
PK-AG3
PK-EM2
Rechargeable Type
External Dimensions
(unit: mm)
Top
455
• The projector is equipped with an ultra-high pressure mercury lamp, which may break, emitting a loud noise, when it is subjected to shock or after it has been used for some length of time.
• Please note that, depending on how the projector is used, there can be considerable difference between individual lamps regarding how many hours they will operate before requiring replacement.
• An additional payment is required for installation of a new lamp, if necessary. • The projector lamp requires periodic replacement and is not covered by warranty. • Please be aware that, because the
D-ILA device is manufactured using highly advanced technologies, 0.01% or fewer of the pixels may be non-performing (always on or off).
Design and specifications are subject to change without notice. All pictures on this brochure are simulated. Adobe is a trademark or registered trademark of Adobe Systems Incorporated in the U.S.
and/or other countries. ISF is a registered trademark of Imaging Science Foundation, Inc. THX and THX logo are trademarks of THX Ltd., which may be registered in some jurisdictions. HDMI, the HDMI
logo and High-Definition Multimedia Interface are registered trademarks of HDMI Licensing LLC. Microsoft, Windows, Windows Vista are trademarks or registered trademarks of Microsoft Corporation
in the U.S. and other countries. All other brand or product names may be trademarks and/or registered trademarks of their respective owners. Any rights not expressly granted herein are reserved.
Copyright Q 2012, JVC KENWOOD Corporation. All Rights Reserved.
Projection distance
H (mm) Wide (m)
747 1.78
872 2.09
996 2.40
1,121 2.70
1,245 3.01
1,370 3.31
1,494 3.62
1,619 3.92
1,743 4.23
1,868 4.53
1,992 4.84
2,117 5.14
2,241 5.45
2,366 5.75
2,490 6.06
*Projection distances are design specifications, so there is ±5% variation.
DLA-RS56 DLA-RS48
l
l
l
(16 steps)
l
l
(7-axis)
l
−
l
l
l
l
(by 1 pixel increment)
(3 modes)
l
l
−
l
−
l
−
l
l
−
l
(5 memories)
l
l
−
l
*3 Digital keystone cannot be used in 3D mode.
IR (Infrared) Method
IR 3D Glasses IR 3D Synchro
Emitter
PK-AG2
PK-EM1
Rechargeable Type
Bottom
79
41 37
337
