Peavey XR 8300 Operating Manual
Powered mixers
Hide thumbs
Also See for XR 8300:
- Operating manual (120 pages) ,
- Specifications (4 pages) ,
- Operating manual (21 pages)
Related Manuals for Peavey XR 8300
Summary of Contents for Peavey XR 8300
- Page 1 8300 8600 ® ® & Powered Mixers Operating Manual www.peavey.com...
- Page 2 Powered Mixer Congratulations on the purchase of your new XR 8300 or XR 8600 powered mixer from Peavey. The XR 8000 Series powered mixers include many of the latest technological developments from Peavey engineering. Incorporating a pair of 300, or 600, Watt amplifiers (XR8300 and XR8600 respectively)‚...
-
Page 3: Input Specifications
8300 & XR 8600 Specifications ® ® Input Specifications Input Levels Input Z Input Gain Function (ohms) Control Connector Settings Min** Nominal* Unbal Lo-Z Mic Max w/o -59dBu -29dBu -11dBu XLR Pin 1 Gnd (150 ohms) pad (50dB) -34dBu -4dBu +14dBu Pin 2 (+) Max w/pad... - Page 4 >80dB Adjacent Input Channels (20Hz-20kHz) >70dB Left to Right Outputs (20Hz-20kHz) Common Mode Rejection Ratio (Mic Input) 50dB minimum (20Hz-20kHz) 60dB typical @ 1kHz XR 8300 - Power Amplifier Specifications Input Sensitivity: Power Section: Total Harmonic Distortion (THD) <0.02% @ rated output @ 1kHz 400 SC Module with DDT 1.225 V RMS for rated power output...
- Page 5 8300 & XR 8600 Specifications ® ® XR 8600 - Power Amplifier Specifications Power Section: Total Harmonic Distortion (THD) Input Sensitivity: <0.01% @ rated output @ 1kHz 1.5 V RMS for 500W @ 4 ohms 1200 SC Module with DDT Rated Power: DDT Dynamic Range: Input Impedance:...
