Summary of Contents for Electrolux ERCE9025BK
- Page 1 User manual Canopy rangehood ERCE9025BK ERCE9025SA ERCE9025BA...
-
Page 2: Table Of Contents
WE’RE THINKING OF YOU CONTENTS Thank you for purchasing an Electrolux appliance. Important safety instructions You’ve chosen a product that brings with it decades Product description of professional experience and innovation. Ingenious Dimensions and stylish, it has been designed with you in mind. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS This manual explains the proper use of your new Electrolux Electrical connection rangehood. Please read this manual carefully before using Check that the mains voltage matches with the voltage the product. This manual should be kept in a safe place for on the data plate inside the rangehood. -
Page 4: Product Description
PRODUCT DESCRIPTION Screws x 4 Telescopic flue cover set Flexible flue pipe Upper flue cover mounting bracket Lower flue cover mounting bracket Flue transition duct Main body and fan housing assembly Grease filters Additional items required for installation Technical specification • F ixings required to attach rangehood Power supply: 220-240 Volts 50Hz. -
Page 5: Dimensions
DIMENSIONS 290mm 320mm 550mm 1090mm (maximum) 235mm 55mm 900mm 500mm ø150mm NOTE: The fan housing flue transition duct is 150mm in diameter. (See page 10 for optional ducting accessories). -
Page 6: Rangehood Installation
RANGEHOOD INSTALLATION 1. Using a spirit level mark a vertical centre line on 3. Install flue cover wall mounting brackets with suitable the wall where the rangehood is to be positioned, and fixings. Install suitable screws for rangehood mounting a horizontal line at the base position (refer Fig. A). points (to support a total weight of 30kg) to the wall as marked (Fig. - Page 7 Depending on the preferred installation/ducting mode, follow step 6a or 6b below. 6a. Recirculating mode (Fig. D). Using the centre line, secure the recirculating T-piece to the wall with suitable screws/fixings (optional kit AR610RK). Install flexible pipe between T-piece and the exhaust transition duct. Use cable ties or suitable duct tape to secure flexible pipe to T-piece and transition duct (Fig.
- Page 8 To complete the rangehood installation, insert the three filters to the underside of the rangehood body. Place back edge of filter into position and push up front edge so that the filter clips into place. Your Electrolux rangehood is now ready to use.
-
Page 9: Using The Rangehood
USING THE RANGEHOOD Touch control operation Stainless steel surface Clean stainless steel surfaces using non-abrasive cleaning products that are specifically for use on stainless steel. To ensure best results also use an even pressure and follow the grain of the stainless steel. Use of a soft cloth reduces the risk of scratching. -
Page 10: Optional Ducting Accessories
OPTIONAL DUCTING ACCESSORIES AR150RC AR150F AR610FS AR150W AR610RK AR610CF Part Numbers Description AR150RC 150mm G/Bond roof cowl AR150F 150mm G/Bond flue 1200mm AR150WV 150mm Wall vent + flexi duct AR610RK Recirculating kit (tee piece and carbon filter) AR610CF Replacement carbon filter AR610FS Stainless steel exhaust cover extension 1200mm NOTE: Accessories are to be purchased separately. -
Page 11: Warranty
5. You will bear the cost of transportation, travel and delivery of the Appliance of this warranty; to and from Electrolux or its ASC. If you reside outside of the service area, (b) have the model and serial number of the Appliance available;... - Page 12 Do you remember the last time you opened a gift that made you say “Oh! How did you know? That’s exactly what I wanted!” That’s the kind of feeling that the designers at Electrolux seek to evoke in everyone who chooses or uses one of our products. We devote time, knowledge, and a great deal of thought to anticipating and creating the kind of appliances that our customers really need and want.
